2000 3636-20 CLAMP LOGGER 3637-20 AC VOLTAGE LOGGER Environmental Measuring Instrument Easy clamp current recording and convenient, low-cost voltage recording Extended recording of AC current and voltage transients q D a t a b a c k u p w h e n b a t t e r i e s a re e x h a u s t e d o r re p l a c e d q I n s t a n t a n e o u s / a v e r a g e re c o rd i n g ( a v e r a g e o v e r re c o rd i n g i n t e r v a l ) q G r a p h i c d i s p l a y o f re c o rd e d d a t a t h ro u g h a c o m p u t e r q Equipped with alarm output (3636-20) http://www.hioki.co.jp/ ISO14001 JQA-E-90091 HIOKI company overview, new products, environmental considerations and other information are available on our website. 3636-20 CLAMP LOGGER 500A AC 3637-20 AC VOLTAGE LOGGER 600V AC Analyze and Process Data on a Personal Computer The 3911-20 Communication Base is used to transfer data to a personal computer. The 3911-20 accommodates up to 16,000 points of 16-channel data or 32,000 points of 8-channel data. It captures data from multiple loggers, then transfers data to the computer where it can be analyzed and managed. 3911-20 LOGGER Infrared optical communication Approximately 500 data points/second (Logger and 3911 must be in direct contact for communication.) Functions RS-232C Approximately 1000 data points/second Settings for communication software Current time, recording interval, recording start, recording method, comment, recording mode (3636-20/3637-20). Alarm and channel selection (3636-20 only) Communication software included with the 3911-20 Compatible OS: Windows 95/98/NT4.0 q Graph display q Measurement data tabulation q Printing (data, graphs) q Scaling q File saving (in proprietary format or text format) Windows is a registered trademark of Microsoft Corporation s 3636-20/3637-20 Specifications 3636-20 CLAMP LOGGER Input Number of input channels Data recording capacity Measurement range Accuracy (50/60 Hz, 23±5˚C) s 3636-20/3637-20 Common Specifications Display AC voltage 1 channel 32,000 data points 0.0 to 600.0 Vrms.sin ±1% rdg. ±5 dgt. None True RMS calculation : Measured value, recording status, recording interval, battery condition, unit, recording in progress, preset active, average value recording, maximum value, minimum value, alarm (3636-20 only) : Started manually or at preset time Recording start : Manual stop or until memory is full Recording finish : 1/2/5/10/15/20/30 seconds, 1/2/5/10/15/20/30/60 minutes Recording interval : One-time: Recording stops when memory becomes full. Recording methods Endless: Oldest data is overwritten when memory becomes full. : Instantaneous value recording, average value recording Recording modes (average over the recording interval) : Infrared optical communication (requires the 3911) Interface : LR03 (AAA) × 4 alkaline batteries Power supply : 0.1 VA Maximum rated power : About 1 year (with a recording interval of 1 minute and Continuous use time instantaneous value recording) About 1 month (with average value recording) : Approx. 57.5(W) × 86.5(H) × 30.0(D) mm, approx. 130 g Dimensions/mass : Indoors at an altitude of no more than 2000 m Operating environment : 0 to 50˚C, less than 80% rh (no condensation) Ambient use conditions Ambient storage conditions : -10 to 60˚C, less than 80% rh (no condensation) : EMC EN61326-1 : 1997+A1 : 1998 Applicable standards Safety EN61010-1 : 1993+A2 : 1995 Overvoltage category I (anticipated overvoltage: 330V), pollution index 2 (3636-20) Overvoltage category III (anticipated overvoltage: 6000V), pollution index 2 (3637-20) 3637-20 AC VOLTAGE LOGGER AC current 2 channels 32,000 data points (1 ch) 16,000 data points (2 ch) 0.00 to 500.0 Arms.sin (50A/500A, 2 ranges) ±1% rdg. ±5 dgt. (logger only) ±2.5% rdg. ±8 dgt. (logger + sensor)* ON when set upper/lower limits exceeded True RMS calculation LR03 (AAA) alkaline batteries × 4, 9632 connection cord (for alarm output) 3911-20 Communication Base, 9650/9651 Clamp-on Sensor Alarm output Measurement system Accessories Options LR03 (AAA) alkaline batteries ×4, 9639 connection cord (for input) 3911-20 Communication Base * 50A or 500A range when using the 9650, and 500A range when using the 9651 s 9650/9651 Specifications × Rated primary current Rated secondary current s 3911-20 COMMUNICATION BASE Specifications 9651 CLAMP ON SENSOR AC500A AC500mA ±1.5% rdg. ±0.03%f.s. (where f.s. is rated primary current) 40 Hz to 1 kHz, within ±3% 600A continuous (45 to 66 Hz) AC 600Vrms or less (insulated conductor) φ 46 mm or less Approx. 3 m : Max 16,000 data points × 16 ch / 32,000 data points × 8 ch : Logger ⇔ 3911-20: by infrared optical communication (with units in close contact) 3911-20 ¤ PC: by RS-232C connection : LR03 (AAA) × 4 alkaline batteries Power supply : 0.2 VA Maximum rated power : Approx. 69(W) × 92(H) × 36(D) mm, approx. 150 g Dimensions/mass : 0 to 40.0˚C, max 80% rh (no condensation) Ambient use conditions Ambient storage conditions : -10.0 to 50.0˚C, max 80% rh (no condensation) : PC communication software Accessories Recording capacity Communication type 9650 CLAMP ON SENSOR AC100A AC100mA ±1.5% rdg. ±0.03%f.s. (where f.s. is rated primary current) 40 Hz to 1 kHz, within ±8% 130A continuous (45 to 66 Hz) AC 300Vrms or less (insulated conductor) φ 15 mm or less Approx. 3 m Accuracy (50/60 Hz, 23±5˚C) Frequency response Maximum rated input Circuit voltage Measurable conductor diameter Cord length Dimensions/ mass Approx. 46(W) × 135(H) × 21(D) mm, Approx. 77(W) × 151(H) × 42(D) mm, approx. 200 g approx. 340 g 9650 CLAMP ON SENSOR 9651 CLAMP ON SENSOR 9639 CONNECTION CABLE 9632 CONNECTION CABLE 3636-20 CLAMP LOGGER 3637-20 AC VOLTAGE LOGGER The 3636-20 CLAMP LOGGER cannot be used for measurement by itself. A clamp-on sensor (sold separately) is required. s Options 3911-20 COMMUNICATION BASE 9650 CLAMP ON SENSOR (100A) 9651 CLAMP ON SENSOR (500A) 9632 CONNECTION CABLE (included with the 3636-20, 1 m) 9639 CONNECTION CABLE (included with the 3637-20, 3 m) 9637 RS-232C CABLE (9 pin-to-9 pin, null modem, 1.8 m) 9638 RS-232C CABLE (9 pin-to-25 pin, null modem, 1.8 m) DISTRIBUTED BY HEAD OFFICE : 81 Koizumi, Ueda, Nagano, 386-1192, Japan TEL+81-268-28-0562 / FAX +81-268-28-0568 E-mail: os-com@ hioki.co.jp ASM GmbH Am Bleichbach 18 - 22 85452 Moosinning All information correct as of Apr. 7, 2000. All specifications are subject to change without notice. sInter net HIOKI website h t t p : / / w w w . h i o k i . c o . j p / F3636E1-04B-05P Printed in Japan 2001 3638-20 LEAK LOGGER DATA LOGGER Simple Leak Current Recording with Clamp On Sensors. Easy Logging at Low Cost Recording and Monitoring Leak Current qSelect from three types of clamp on leak current sensors qCompact, light weight (130g), two-channel recording qHigh-capacity recording (32,000 data points) Recording interval: 15 steps from 1 second to 60 minutes qAccurate true effective value calculation even for distorted waveforms (100/1000 mA) qMaximum or average value recording (max./ave. within recording interval) qView recording data graphically on a PC qData is protected during battery discharge and replacement Model 9657 Model 9658 Model 9659 http://www.hioki.co.jp/ HIOKI company overview, new products, environmental considerations and other information are available on our website. ISO14001 JQA-E-90091 s HIOKI 3638-20 LEAK LOGGER Specifications Sensor models Inputs & ranges Instrument accuracy Combined accuracy at 50/60 Hz, 23 ±5˚C with 9658 sensor Data Analysis and Processing on a PC Data can be transferred to a PC using the HIOKI 3911-20 COMMUNICATION BASE. Up to 16,000 data points can be collected from 16 channels, (or up to 32,000 data points can be collected from 8 channels), and then transferred to the PC for analysis and processing. 3911-20 3911-20 3638-20 (Infrared transfer) HIOKI 9657, 9658 and 9659 CLAMP ON LEAK SENSORS 2 channels, 100.0 and 1000 mA (manual range selection) ±1% rdg. ±5 dgt. at 50/60 Hz, 23 ±5˚C, with built-in filter for 50/60Hz with 9657 or 9659 sensor ±2% rdg. ±10 dgt. (100 mA range) ±2% rdg. ±6 dgt. (1000 mA range) ±4.5% rdg. ±10 dgt. (100 mA range) ±4.5% rdg. ±6 dgt. (1000 mA range) Measurement period Recording modes Recording interval Recording data quantity Recording start / end Recording methods Max./Min. display Alarm output Backup Interface 1 or 0.2 s (one channel only) Maximum or average value 1, 2, 5, 10, 15, 20 or 30 s, and 1, 2, 5, 10, 15, 20, 30 or 60 min. 32,000 data points (single channel), 16,000 data points (for dual-channel recording) Manual, or at preset time / Manual, or when memory full Single recording, Endless recording Maximum and Minimum values are displayed On when input crosses preset upper and lower limits (open-collector output) Data backup is provided Serial infrared transfer RS-232C Cable Settings that can be made from communications software: current time, recording interval, recording start, recording methods, comment, recording mode, alarm, channel selection Power supply, AAA-size alkaline batteries (LR03 × 4), 0.1 VA consumption Continuous operating One month (with power saver on, 1s measurement period) Ten days (with power saver off, 0.2s measurement period) period Approx. 57.5(W) × 86.5(H) × 30.0(D) mm (less projections), approx. 130g Size & weight (including batteries) Operating temperature & humidity s HIOKI 3911-20 COMMUNICATION BASE Specification Recording capacity Communication method Power supply Size & weight Supported operating systems Up to 16,000 data points × 16 channels, Up to 32,000 data points × 8 channels Infrared between Leak Logger and 3911-20, RS-232C serial between 3911-20 and PC Four AAA size alkaline batteries (LR03 × 4) Approx. 69(W) × 92(H) × 36(D) mm, approx. 150 g 0 to 50˚C, 80% RH or less (noncondensing) AAA-size alkaline batteries (LR03 × 4), Model 9632 CONNECTION CABLE (for alarm output) Supplied accessories Supplied accessories PC communications software Windows 9x, NT 4.0 s Clamp On Current Leak Sensor Specifications Model Measurable conductor size Rated primary current Maximum allowable input Output voltage Amplitude accuracy Residual current External magnetic field effect Cable length Voltage to ground Insulation withstand voltage Operating temp. & humidity Size & weight Approx. 74W × 145H × 42D mm, 340 g 300 Vrms AC 3.7 kV (for 1 min.) ±1.0% rdg. ±12 µV 5 mA (at 100A AC in) 60A Continuous at 45 to 65 Hz 9657 Up to 40 mm dia. 9658 Up to 12 × 30 mm 1.0A AC 10A Continuous at 45 to 65 Hz 25 mV/A AC ±3.5% rdg. ±12 µV 1 mA (at 10A AC in) 5 mA equiv. With 400A/m (AC), 7.5 mA max. Approx. 3 m 150 Vrms AC 2.3 kV (for 1 min.) 0 to 50˚C, 80% RH or less (non-condensating) Approx. 65W × 52H × 18D mm, 50 g Approx. 358W × 108H × 48D mm, 2.5 kg 460 Vrms AC 2.2 kV (for 1 min.) ±1.0% rdg. ±12 µV 30 mA (at 500A AC in) 100A Continuous at 45 to 65 Hz 9659 Up to 30 × 150 mm NOTES: 1. Voltage to ground is that voltage between a power line and earth ground in a groundingdependent electric circuit, or the voltage between one power line and any other power line in a grounding-independent circuit. 2. Coordination of Insulation: determination of the safe and appropriate characteristics of electrical insulation of wiring and connected devices according to the operating voltage. 3. Model 9658 is suitable for coordination of insulation with circuits of up to 150V voltage to ground, up to 240V for 3P3W lines, and up to 120/240V for 3P4W lines. 4. Models 9657 and 9659 are suitable for coordination of insulation with circuits of up to 300V voltage to ground, up to 500V for 3P3W lines, and up to 277/480V for 3P4W lines. COMMON ELECTRIC CIRCUITS and COORDINATION of INSULATION 3P-4W (3-phase, 4-wire) Voltage 3P-3W (3-phase, 3-wire) Voltage Voltage to Ground CATIII Recommended Impulse Withstand Voltage 120/208 V 120/240 V 230/400 V 277/480 V 240 V 500 V 150 V 300 V 2500 V 4000 V (From EN61010-2-032, Annexes J, Table J.1) Model 3638-20 LEAK LOGGER s Options Model 3911-20 COMMUNICATION BASE Model 9657 CLAMP ON LEAK SENSOR Model 9658 CLAMP ON LEAK SENSOR Model 9659 CLAMP ON LEAK SENSOR Model 9637 RS-232C CABLE (9-pin to 9-pin crossover, 1.8 m) Model 9638 RS-232C CABLE (9-pin to 25-pin crossover, 1.8 m) DISTRIBUTED BY HEAD OFFICE : 81 Koizumi, Ueda, Nagano, 386-1192, Japan TEL +81-268-28-0562 / FAX +81-268-28-0568 E-mail: os-com@ hioki.co.jp ASM GmbH Am Bleichbach 18 - 22 85452 Moosinning All information correct as of Apr. 20, 2001. All specifications are subject to change without notice. s Inter net HIOKI website h t t p : / / w w w . h i o k i . c o . j p / 363820E2-14M-05P Printed in Japan
