A-20042-LP/FS

A B C D E F G H 1 1 7 3 8 File No.: E345352 RoHS compliant Unit:mm 1 2 2 3 Scale ±0.20 4 4 Free X.X ±0.15 TOLERANCE X.XX ±5° TOL X.XXX ±0.10 DIM Angle 21.12.2021 Amy Peter Approved Drawn 21.12.2021 07.11.2007 Date Peter N.Schulz Name 5 Update the packing quantity 16.05.2016 Amy 4 6 7 NOTES: Mechanical: 1. Housing material : High Temp. Polyester UL94V-0 , Color: Black 2. Contact material: Phosphor Bronze t=0.35mm 6 3 3. Contact plating: 6u" Gold on contact area 100u"~200u" Tin on solder area all over 30u"~50u" Nickel 4 4. Shell material: Copper Alloy 5. Shell plating: Nickel plated 6. Operating Life: 750 Cycles min. 7. PCB Retention Pre-solder: 1 LB min. 8. PCB Retention Post-solder: 10 LBS min. Electrical: 1. Voltage Rating: 125VAC. 2. Current Rating: 1.5AMP. 3. Contact Resistance: 45mΩ max. 4. Insulation Resistance: 1000MΩ min. @ 500 VDC 5. Dielectric Strength: 1000 VAC 60Hz, 1 min. Environmental: 1. Storage: -40°C To +85°C 2. Operation: -40°C~+85°C 3. Wave Soldering Temperature: 255°C~265°C 5~10S 8 Correct PEG dimensions 25.08.2015 Amy 3 3 8 7 Update the contact plating 18.12.2014 Amy 4 1 6 Modify the dimensions 27.05.2013 Dean 6 Customer-No. 7 SHEET 1/1 rev08 A-20042-LP/FS ASS 0574 CO Drawing-No. ASSMANN WSW-No. Description. Modular Jack Pitch 1.27 8Pin 8 Packing: 80pcs/Tray,1920pcs/Carton 5 Update 02.07.2009 PC Board Layout Component Side Shown 4 Modify notes Add dimensions 3 5 Name Modification 4 Date Id. 3 A B C D E F G H Downloaded from Arrow.com.
