AFC-12S

P o w e r B l o c k M i c r o-Miniature Modular Switching Power Supplies 5 Watt and 10 Watt Models pwb series 3.3VDC to 24VDC Single Outputs Universal 85VAC to 265VAC Input 3,000VAC Input to Output Isolation -25 to +70°C Operation High Efficiency 2”L x 1”W x 0.6”H (5W) 2”L x 1”w x 0.9”H (10W) Model Number 5 wATT OUTpUT PWB-5000 PWB-5001 PWB-5002 PWB-5003 PWB-5005 10 wATT OUTpUT AFC-3.3S AFC-5S AFC-12S AFC-15S AFC-24S Output Voltage Output Amps Output watts Size (inches) 3.3 VDC 5 VDC 12 VDC 15 VDC 24 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC 24 VDC 1.25 1 0.42 0.33 0.23 2.5 2 0.83 0.66 0.42 4W 5W 5W 5W 5W 8W 10W 10W 10W 10W 1 x 2 x 0.6 1 x 2 x 0.6 1 x 2 x 0.6 1 x 2 x 0.6 1 x 2 x 0.6 1 x 2 x 0.9 1 x 2 x 0.9 1 x 2 x 0.9 1 x 2 x 0.9 1 x 2 x 0.9 Fully Approved IEC60950 EN60950 UL60950-1 CSA22.2-60950-1 Order On-Line! www.ASTRODYNE.COM astrodyne.com 300 Myles Standish blvd., Taunton, MA 02780 ph: 1-800-823-8082 Fax: 508-823-8181 P o w e r B l o c k M i c r o-Miniature Modular Switching Power Supplies INpUT SpECIFICATIONS Input Voltage, Nominal Input Frequency Inrush Current 85-265VAC Nominal: 100-240VAC 47-440 Hz, 50-60Hz Nom. 20A @ 100VAC, typ 40A @ 200VAC, typ pwb series GENERAL SpECIFICATIONS Input-Out Isolation Output-Ground Isolation Input-Ground Isolation Operating Frequency Efficiency (@ Full Load) Safety 3000VAC 1000VAC 2500VAC 100 Khz, fixed, typ 75 - 80%, typ EN60950, TUV File# B050122749064 IEC60950, CB File# DE 3-51024 UL60950-1, UL File# E167432 OUTpUT SpECIFICATIONS Output Voltage/Current Initial Accuracy Load Regulation 20%-FL Line Regulation Temperature Coefficient Ripple/Noise(20Mhz BW) Overvoltage Protection Hold Up Time Short Circuit Protection OverTemp Protection Current Limit See Specific Model +/-1%, typ 3.3V & 5V:+/-1%, typ 12V, 15V, & 24V:+/-0.5%, typ 3.3V & 5V:+/-1%, typ 12V, 15V, & 24V:+/-0.5%, typ +/-0.03%/°C 200-250mV Pk-Pk, typ Clamp, 130-150% * 30mS, typ Continuous * Latching, Recovering 130% typ,Self-Reset Foldback ENVIRONMENTAL SpECIFICATIONS Oper. Temperature Relative Humidity Storage Temperature MTBF -25 to +50°C FL Derate Linearly to 25%L @ 70°C 0-95%, Non-Condensing -25 to +71°C * 466,553 Hrs MIL-HDBK 217, Parts Count Method, 25°C, Ground Benign pHYSICAL SpECIFICATIONS Case Material Construction Weight Rynite, 94V-0 Rated Encapsulated, Soft Pot 1.5 oz (42g) All specifications are typical at nominal input, full load, and 25DegC unless otherwise noted * These are stress ratings. Exposure of the devices to any of these conditions may adversely affect long term reliability. Proper operation under conditions other than the standard operating conditions is neither warranteed nor implied. Astrodyne products are not authorized or warranteed for use as critical components in life support systems, equipment used in hazardous environments, nuclear controls systems, or other mission-critical applications. www.ASTRODYNE.COM 300 Myles Standish blvd., Taunton, MA 02780 ph: 1-800-823-8082 Fax: 508-823-8181 P o w e r B l o c k M i c r o-Miniature Modular Switching Power Supplies MECHANICAL SpECIFICATIONS ACL pwb SIDE VIEW series 1.00 (25.40) .80 (20.32) .10 (2.54) BOTTOM VIEW Dim. “H” -Vout ACN 1.80 (45.72) 2.00 (50.80) +Vout .20 (5.08) MIN. .040 (1.016) DIA. .40 (10.16) .10 (2.54) NOTES: Dimension “H” 0.6 (15.24) for 5Watt/PWB Version 0.9 (22.86) for 10Watt/AFC Version DIMENSIONS ARE IN INCH (mm) TOLERANCES: .XXX +/-.02(.508) .XX +/-.05(1.27) pOwER bLOCk AppLICATION NOTES Output Noise EMI The figure below ia a sample diagram to reduce Output Ripple and Noise. The figure below ia a suggested diagram to reduce Electromagnetic Interference (EMI). C1 = Electrolytic Capacitor Capacitance = 22uF - 220uF Voltage = Two times rated output voltage L1 = 3uH - 10uH C2 = Electrolytic Capacitor Capacitance = 22uF - 47uF Voltage = Two times rated output voltage C3 = Ceramic Capacitor Capacitance = 0.01uF - 0.1uF Voltage = 50 volt Notes: 1. The use of C1 alone may reduce noise to desired levels, if not use L1, C2 and C3 in addition to C1. 2. The figure above is a suggested circuit. Only by trying true application can levels be tested. C1 = 0.22uF X Capacitor L1 = 10mH - 30mH Common Mode, Choke C2, C3 = 220pF Y Capacitors Notes: The diagram above is a recommended circuit, only by trying true application can levels be measured. Inrush Current If desired, the use of a Choke, NTC or Inrush Current Limiter may be used to reduce the Inrush Current www.ASTRODYNE.COM 300 Myles Standish blvd., Taunton, MA 02780 ph: 1-800-823-8082 Fax: 508-823-8181
