MCA-10

1 0 W U l t r a m i n i a t ure Modular Switching Power Supplies MCA-10 Single / Dual / Triple Outputs Universal 85VAC to 265VAC Input 3.3VDC to 24VDC Outputs 3,000VAC Input to Output Isolation PCB and Chassis Mount Packages Full Safety Approvals series PCB 2.56”L x 1.77”W x 0.83”H Chassis 3.77”L x 2.16”W x 1.0”H Model Number Output Voltage Output Amps Output Watts SINGLE OUTPUT - PCB Mount MSCA-0100 3.3 VDC MSCA-0101 5 VDC MSCA-0104 9 VDC MSCA-0102 12 VDC MSCA-0103 15 VDC MSCA-0105 24 VDC SINGLE OUTPUT - Chassis Mount MSCC-0100 3.3 VDC MSCC-0101 5 VDC MSCC-0104 9 VDC MSCC-0102 12 VDC MSCC-0103 15 VDC MSCC-0105 24 VDC SINGLE OUTPUT - DIN Rail Mount MSCC-0100/DRL 3.3 VDC MSCC-0101/DRL 5 VDC MSCC-0104/DRL 9 VDC MSCC-0102/DRL 12 VDC MSCC-0103/DRL 15 VDC MSCC-0105/DRL 24 VDC 2.5 2 1.1 0.85 0.67 0.42 2.5 2 1.1 0.85 0.67 0.42 2.5 2 1.1 0.85 0.67 0.42 8W 10W 10W 10W 10W 10W 8W 10W 10W 10W 10W 10W 8W 10W 10W 10W 10W 10W Fully Approved UL/CSA22.2 60950-1 File# E167432 EN60950 File# B021022749033 IEC60950-1 File# DE354029 Order On-Line! WWW.ASTRODYNE.COM astrodyne.com 300 Myles Standish Blvd., Taunton, MA 02780 Ph: 1-800-823-8082 Fax: 508-823-8181 1 0 W U l t r a m i n i a t ure Modular Switching Power Supplies MCA-10 Single / Dual / Triple Outputs Universal 85VAC to 265VAC Input 3.3VDC to 24VDC Outputs 3,000VAC Input to Output Isolation PCB and Chassis Mount Packages Full Safety Approvals series PCB 2.56”L x 1.77”W x 0.83”H Chassis 3.77”L x 2.16”W x 1.0”H Model Number Output Voltage Output Amps Output Watts DUAL OUTPUT - PCB Mount MDCA-0106 +/-12 VDC MDCA-0107 +/-15 VDC MDCA-0108 +5/12 VDC DUAL OUTPUT - Chassis Mount MDCC-0106 +/-12 VDC MDCC-0107 +/-15 VDC MDCC-0108 +5/12 VDC DUAL OUTPUT - DIN Rail Mount MDCC-0106/DRL +/-12 VDC MDCC-0107/DRL +/-15 VDC MDCC-0108/DRL +5/12 VDC TRIPLE OUTPUT - PCB Mount MTCA-0109 +5,+/-12 VDC MTCA-0111 +5,+/-15 VDC TRIPLE OUTPUT - Chassis Mount MTCC-0109 +5,+/-12 VDC MTCC-0111 +5,+/-15 VDC TRIPLE OUTPUT - DIN Rail Mount MTCC-0109/DRL +5,+/-12 VDC MTCC-0111/DRL +5,+/-15 VDC +/-0.42 +/-0.34 1/0.42 +/-0.42 +/-0.34 1/0.42 +/-0.42 +/-0.34 1/0.42 1.5,0.1/0.1 1.4,0.1/0.1 1.5,0.1/0.1 1.4,0.1/0.1 1.5,0.1/0.1 1.4,0.1/0.1 10W 10W 10W 10W 10W 10W 10W 10W 10W 10W 10W 10W 10W 10W 10W Fully Approved UL/CSA22.2 60950-1 File# E167432 EN60950 File# B021022749033 IEC60950-1 File# DE354029 Order On-Line! WWW.ASTRODYNE.COM astrodyne.com 300 Myles Standish Blvd., Taunton, MA 02780 Ph: 1-800-823-8082 Fax: 508-823-8181 1 0 W U l t r a m i n i a t ure Modular Switching Power Supplies INPUT SPECIFICATIONS Input Voltage, Nominal Input Frequency Inrush Current 85-265VAC Nominal: 100-240VAC 47-440 Hz, 50-60Hz Nom. 20A @ 100VAC, typ 40A @ 200VAC, typ MCA-10 Open Collector Logic “1”/Open=ON Logic “0”/GND=OFF 3000VAC 1000VAC 2500VAC 140 Khz, fixed 75 - 80%, typ series GENERAL SPECIFICATIONS On/Off Control OUTPUT SPECIFICATIONS Output Voltage/Current Initial Accuracy Voltage Adjust Load Regulation Line Regulation Temperature Coefficient Ripple/Noise(20Mhz BW) Overvoltage Protection Hold Up Time Short Circuit Protection Current Limit See Specific Model +/-1%, adjustable +/-6%, typ +/-0.3%, typ +/-0.3%, typ +/-0.03%/°C 150mV Pk-Pk, typ Clamp, 130-150% * 30mS, typ Continuous, self-recovering * 130% typ,Self-Reset Foldback Input-Out Isolation Output-Ground Isolation Input-Ground Isolation Operating Frequency Efficiency (@ Full Load) ENVIRONMENTAL SPECIFICATIONS Oper. Temperature Relative Humidity Storage Temperature MTBF, Single/Multi Output 0 to +50°C FL See Derate * (Free-air Convection) 0-95%, Non-Condensing -25 to +71°C * 180,000 Hrs/110,000 Hrs Mil Std 217, 25C PHYSICAL SPECIFICATIONS Case Material Construction Weight Rynite, 94V-0 Rated Encapsulated, Soft Pot PCB / CHA 4.6 oz (128g) / 8.5 oz (238g) All specifications are typical at nominal input, full load, and 25DegC unless otherwise noted * These are stress ratings. Exposure of the devices to any of these conditions may adversely affect long term reliability. Proper operation under conditions other than the standard operating conditions is neither warranteed nor implied. Astrodyne products are not authorized or warranteed for use as critical components in life support systems, equipment used in hazardous environments, nuclear controls systems, or other mission-critical applications. WWW.ASTRODYNE.COM 300 Myles Standish Blvd., Taunton, MA 02780 Ph: 1-800-823-8082 Fax: 508-823-8181 1 0 W U l t r a m i n i a t ure Modular Switching Power Supplies MECHANICAL DIMENSIONS - PCB MOUNT MCA-10 series Adjustment Pot Power “Good” Indicator 0.040 [1.02] DIA. TYP. Model Type / Pin# 1 2 3 4 5 2.56 [65.0] 0.20 [5.1] Dual Single AC HI AC LO GND No Pin No Pin +Vout No Pin No Pin -Vout Ctrl Matched AC HI AC LO GND No Pin No Pin +Vout No Pin Out Com -Vout Ctrl Dual 5/12V AC HI AC LO GND No Pin No Pin 12Vout No Pin +5Vout Ctrl Triple AC HI AC LO GND +Vout +/-Com No Pin -Vout +5Vout Ctrl 1.77 [45.0] 6 7 8 .XX ± 0.01 [0.25] .XXX ± 0.005 [0.13] 0.83 [21.0] Tolerance: 9 10 Out Com 5V Ret Dimensions shown in inch [mm] 0.22 [5.5] 2.126 [54.0] PERFORMANCE CURVES 100 90 80 80 90 Output Current, % 60 50 40 30 20 10 0 -10 0 10 20 30 40 50 60 70 Typical Efficiency, % 70 70 60 50 40 10 25 50 75 100 Ambient Temp., DegC % of Full Load WWW.ASTRODYNE.COM 300 Myles Standish Blvd., Taunton, MA 02780 Ph: 1-800-823-8082 Fax: 508-823-8181 1 0 W U l t r a m i n i a t ure Modular Switching Power Supplies MECHANICAL DIMENSIONS - CHASSIS MOUNT ADJUSTMENT POT POWER “GOOD” INDICATOR MCA-10 #3-48 SCREW (6 PLACES) 4 series #3-48 SCREW (3 PLACES) 2.16 [54.9] 1.780 [45.21] 0.50 [12.7] TYP. (2 PLACES) 1 2 3 5 6 7 8 9 0.25 [6.4] TYP. (5 PLACES) 0.19 [4.8] 0.17 [4.3] TOLERANCE: .XX .XXX ±0.01 [0.25] ±0.005 [0.13] 3.430 [87.12] 3.77 [95.8] 0.130 [3.30] DIA. TYP. (2 PLACES) ACCEPTS #4 SCREW & NUT DIMENSIONS SHOWN IN INCH [MM] 1.00 [25.4] MECHANICAL DIMENSIONS - DIN RAIL 0.350 [8.89] Model Type / Pin# 1 2 3 4 5 6 7 8 9 Single AC LO GND AC HI Ctrl -Vout -Vout +Vout +Vout N/C Match Dual AC LO GND AC HI Ctrl -Vout Com Com +Vout N/C Unmatch Dual AC LO GND AC HI Ctrl Com Com +5Vout +12Vout N/C Triple AC LO GND AC HI Ctrl +5 Ret +5Vout -Vout +/- Com +Vout DIN Rail mounting kit available for Chassis-mount modules, specify part # M-DRL-01. Kit includes mounting plate, DIN Rail cliip and assembly hardware. 0.100 [2.54] WWW.ASTRODYNE.COM 300 Myles Standish Blvd., Taunton, MA 02780 Ph: 1-800-823-8082 Fax: 508-823-8181
