137-440-X

2 REV A AUTH DATE 1/18/2008 1 REVISION HISTORY DESCRIPTION INITIAL RELEASE B B X-SMALL MOUNT APPLICATIONS: 75-440-X 62-440-X 51-440-X 42-440-X 34-440-X 28-440-X 28-441-X SMALL MOUNT APPLICATIONS: 650-440-X 430-440-X 340-440-X 340-441-X 284-440-X 284-441-X 229-440-X 229-441-X 187-440-X 187-441-X 187-442-X 159-440-X 159-441-X 159-442-X 137-440-X 137-441-X 137-442-X 112-440-X 112-441-X 102-440-X 102-441-X 102-449-X/17 102-442-X 90-440-X 90-441-X 90-442-X 75-441-X 75-442-X 62-441-X 62-449-X/17.5 62-442-X 62-449-X/24 51-441-X 51-442-X 42-441-X 42-442-X 42-449-X/24 34-441-X 34-442-X 28-442-X 28-449-X/24 MEDIUM MOUNT APPLICATIONS: 430-441-X 229-442-X 112-449-X/24 90-449-X/24 LARGE MOUNT APPLICATIONS: 650-441-X 430-442-X 340-442-X 284-442-X A A THIRD ANGLE PROJECTION: UNLESS OTHERWISE NOTED, DIMENSIONS ARE IN INCHES, TOLERANCES ARE: FRACTIONS: ±1/64 BASIC DIMENSION UNDER 6" 6" - 12" OVER 12" APPROVALS DRAWN CHKD. APRVD. MATERIAL M.R. DATE ADVANCED TECHNICAL MATERIALS, INC. TEL: (631) 289-0363 FAX: (631) 289-0358 www.atmmicrowave.com THE INFORMATION IN THIS DRAWING IS PROPRIETARY AND SHALL NOT BE USED OR DISCLOSED WITHOUT THE PRIOR WRITTEN CONSENT OF ATM, INC. DO NOT SCALE DWG. ANGLES: ±1/2° DECIMALS 2 PLACE 3 PLACE HORN MOUNT APPLICATIONS SIZE `.02 `.03 `.06 `.005 `.010 `.015 TREATMENT FINISH A CAGE CODE ATM DWG # 0R8N4 7994 REVISION SHEET A 1 - MODEL # XXX-44X-X 1 2
