90-740

Service Price Delivery SHORT TERMINATION • Full waveguide frequency range • Units pressure tested to 30 psi • Finish is a unique corrosion-resistant 316 stainless steel epoxy coating LOW POWER TERMINATION • Full waveguide frequency range • ATM series 720 Terminations utilize a • Units pressure tested to 30 psi Precision Conical Element to achieve • Finish is a unique corrosion-resistant very low VSWR. 316 stainless steel epoxy coating • For short size on High Power Terminations contact factory Description: • VSWR: 1.10 max • ATM series 710 Terminations utilizes Medium Power Elements to achieve low VSWR and stable electrical characteristics Description: Ordering Information: Typical Part #: 137-710 B -2 Basic Model #: Material: A=Alum, B=Brass, C=Copper, D=Special Flange 1: 1=CPRG, 2=CPRF 6=COVER, 7=CHOKE, 8=SPECIAL , Basic Model No. 650-710 430-710 340-710 284-710 229-710 187-710 159-710 137-710 112-710 102-710 90-710 75-710 62-710 51-710 42-710 34-710 28-710 22-710 WG Size WR650 WR430 WR340 WR284 WR229 WR187 WR159 WR137 WR112 WR102 WR90 WR75 WR62 WR51 WR42 WR34 WR28 WR22 Freq (GHz) 1.12 - 1.70 1.70 - 2.60 2.20 - 3.30 2.60 - 3.95 3.30 - 4.90 3.95 - 5.85 4.90 - 7.05 5.95 - 8.20 7.05 - 10.00 7.00 - 11.00 8.20 - 12.40 10.00 - 15.00 12.40 - 18.00 15.00 - 22.00 18.00 - 26.50 22.00 - 33.00 26.50 - 40.00 33.00 - 50.00 Standard Flange CPRF (2) CPRF (2) CPRF (2) COVER (6) CPRF (2) COVER (6) CPRF (2) CPRF (2) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) Power Avg. (W) 50 40 40 30 25 25 20 15 15 15 15 15 10 10 10 5 5 5 Length (inches) 7.00 7.00 6.00 3.00 3.00 2.50 2.00 1.75 1.50 1.50 1.50 1.25 1.00 1.00 1.00 0.75 0.75 0.75 Ordering Information: Typical Part #: 137-720 B -2 Basic Model #: Material: A=Alum, B=Brass, C=Copper, D=Special Flange 1: 1=CPRG, 2=CPRF, 6=COVER, 7=CHOKE, 8=SPECIAL Basic Model No. 650-720 430-720 340-720 284-720 229-720 187-720 159-720 137-720 112-720 102-720 90-720 75-720 62-720 51-720 42-720 34-720 28-720 22-720 WG Size WR650 WR430 WR340 WR284 WR229 WR187 WR159 WR137 WR112 WR102 WR90 WR75 WR62 WR51 WR42 WR34 WR28 WR22 Freq (GHz) 1.12 - 1.70 1.70 - 2.60 2.20 - 3.30 2.60 - 3.95 3.30 - 4.90 3.95 - 5.85 4.90 - 7.05 5.95 - 8.20 7.05 - 10.00 7.00 - 11.00 8.20 - 12.40 10.00 - 15.00 12.40 - 18.00 15.00 - 22.00 18.00 - 26.50 22.00 - 33.00 26.50 - 40.00 33.00 - 50.00 Standard Flange CPRF (2) CPRF (2) CPRF (2) COVER (6) CPRF (2) COVER (6) CPRF (2) CPRF (2) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) VSWR max. 1.02 1.02 1.01 1.01 1.01 1.01 1.01 1.01 1.01 1.01 1.01 1.01 1.01 1.01 1.01 1.01 1.02 1.02 Power Avg. (W) 25 15 12 10 10 8 7 6 4 3 4 2 1.5 1.0 0.5 0.5 0.5 0.5 Length (inches) 12.50 11.00 10.75 10.50 7.50 6.25 6.00 5.50 5.00 4.00 4.00 4.00 4.00 4.00 2.50 2.50 2.00 1.50 Description: MEDIUM POWER TERMINATION • VSWR: 1.10 max • ATM series 740 utilizes High Power Ceramic Elements fired at 1300 C for low VSWR and table electrical characteristics • Full waveguide frequency range • Units pressure tested to 30 psi • Finish is a unique corrosion-resistant 316 stainless steel epoxy coating Low outgassing characteristics • Full waveguide frequency range • Units pressure tested to 30 psi • Finish is a unique corrosion-resistant 316 stainless steel epoxy coating • All 745 series Terminations are manufactured from 6061 Aluminum • Low outgassing characteristics • VSWR: 1.10 max • ATM series 745 utilizes High Power Ceramic Elements fired at 1300 C for low VSWR and stable electrical characteristics Description: HIGH POWER TERMINATION Ordering Information: Typical Part #: 137-740 B -2 Ordering Information: Typical Part #: 137-745 -2 Basic Model #: Material: A=Alum, B=Brass, C=Copper, D=Special Flange 1: 1=CPRG, 2=CPRF, 6=COVER, 7=CHOKE, 8=SPECIAL Basic Model No. 650-740 430-740 340-740 284-740 229-740 187-740 159-740 137-740 112-740 102-740 90-740 75-740 62-740 51-740 42-740 34-740 28-740 22-740 Model No 650-760-6 430-760-6 284-760-6 229-760-6 187-760-6 159-760-6 137-760-6 112-760-6 90-760-6 75-760-6 62-760-6 51-760-6 42-760-6 34-760-6 28-760-6 WG Size WR650 WR430 WR340 WR284 WR229 WR187 WR159 WR137 WR112 WR102 WR90 WR75 WR62 WR51 WR42 WR34 WR28 WR22 Waveguide Size WR650 WR430 WR284 WR229 WR187 WR159 WR137 WR112 WR90 WR75 WR62 WR51 WR42 WR34 WR28 Freq (GHz) 1.12 - 1.70 1.70 - 2.60 2.20 - 3.30 2.60 - 3.95 3.30 - 4.90 3.95 - 5.85 4.90 - 7.05 5.95 - 8.20 7.05 - 10.00 7.00 - 11.00 8.20 - 12.40 10.00 - 15.00 12.40 - 18.00 15.00 - 22.00 18.00 - 26.50 22.00 - 33.00 26.50 - 40.00 33.00 - 50.00 Freq (GHz) 1.12 - 1.70 1.70 - 2.60 2.60 - 3.95 3.30 - 4.90 3.95 - 5.85 4.90 - 7.05 5.85 - 8.20 7.05 - 10.00 8.20 - 12.40 10.00 - 15.00 12.40 - 18.00 15.00 - 22.00 18.00 - 26.50 22.00 - 33.00 26.50 - 40.00 Standard Flange CPRF (2) CPRF (2) CPRF (2) COVER (6) CPRF (2) COVER (6) CPRF (2) CPRF (2) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) COVER (6) Power Avg. (W) 8000 6500 5000 4000 3000 3000 3000 3000 1500 1400 1400 1200 1000 700 500 Power Avg. (W) 1500 1200 1200 1200 1000 750 625 500 425 325 225 200 100 100 100 75 75 25 Length (inches) 13.00 12.00 12.00 11.00 9.75 8.38 8.00 8.00 7.00 6.50 5.50 4.50 3.25 3.25 3.50 3.25 4.00 2.50 Basic Model #: Flange 1: 1=CPRG, 2=CPRF, 6=COVER, 7=CHOKE, 8=COVER/GROOVE Basic Model No. 650-745 430-745 340-745 284-745 229-745 187-745 159-745 137-745 137-745A 112-745 102-745 90-745 75-745 75-745A 62-745 51-745 42-745 34-745 28-745 22-745 WG Size WR650 WR430 WR340 WR284 WR229 WR187 WR159 WR137 WR137 WR112 WR102 WR90 WR75 WR75 WR62 WR51 WR42 WR34 WR28 WR22 Freq (GHz) 1.12 - 1.70 1.70 - 2.60 2.20 - 3.30 2.60 - 3.95 3.30 - 4.90 3.95 - 5.85 4.90 - 7.05 5.95 - 8.20 5.95 - 8.20 7.05 - 10.00 7.00 - 11.00 8.20 - 12.40 10.00 - 15.00 10.00 - 15.00 12.40 - 18.00 15.00 - 22.00 18.00 - 26.50 22.00 - 33.00 26.50 - 40.00 33.00 - 50.00 Standard Power Length Flange Avg. (W) (inches) CPRF (2) 2500 13.00 CPRF (2) 2500 9.00 CPRF (2) 2500 12.00 COVER (6) 2400 12.00 CPRF (2) 2000 9.75 COVER (6) 1500 9.00 CPRF (2) 1300 9.00 CPRF (2) 1000 8.50 CPRF (2) 1500 9.00 COVER (6) 850 8.00 COVER (6) 500 6.50 COVER (6) 500 5.50 COVER (6) 350 5.00 COVER (6) 550 5.00 COVER (6) 250 4.50 COVER (6) 250 4.50 COVER (6) 250 4.50 COVER (6) 175 4.00 COVER (6) 175 4.00 COVER (6) 100 3.00 Dim. A 8.00 6.00 6.00 6.00 5.00 4.50 4.50 4.00 4.50 4.00 3.50 3.50 3.50 4.50 3.00 3.00 2.25 2.00 2.00 1.50 Dim. B 8.00 6.00 6.00 5.00 5.00 4.50 4.50 4.00 4.50 4.00 3.50 3.50 3.50 4.50 3.00 3.00 2.25 2.00 2.00 1.50 VERY HIGH POWER WAVEGUIDE TERMINATION VERY HIGH POWER DOUBLE RIDGE WAVEGUIDE TERMINATION Model No. 750-750-C3 650-750-C3 580-750-C3 475-750-C3 Waveguide Size WRD750 WRD650 WRD580 WRD475 Freq (GHz) 7.50 - 18.00 6.50 - 18.00 5.80 - 16.00 4.75 - 11.00 Power Avg. (W) 700 800 1000 1000 High Power Rating Flange Code: C3 = Cover (WRD) 49 Rider Ave, Patchogue, NY 11772 Phone: 631-289-0363 Fax: 631-289-0358 E-mail: atmemail@juno.com Web: www.atmmicrowave.com 10
