ATMEGA169PA-AU

ATMEGA169PA-AU

  • 厂商:

    ATMEL(爱特梅尔)

  • 封装:

  • 描述:

    ATMEGA169PA-AU - 8-bit Microcontroller with 16K Bytes In-System Programmable Flash - ATMEL Corporati...

  • 数据手册
  • 价格&库存
ATMEGA169PA-AU 数据手册
Features • High Performance, Low Power AVR® 8-Bit Microcontroller • Advanced RISC Architecture – 130 Powerful Instructions – Most Single Clock Cycle Execution – 32 x 8 General Purpose Working Registers – Fully Static Operation – Up to 16 MIPS Throughput at 16 MHz – On-Chip 2-cycle Multiplier High Endurance Non-volatile Memory segments – 16K Bytes of In-System Self-programmable Flash program memory – 512 Bytes EEPROM – 1K Bytes Internal SRAM – Write/Erase cycles: 10,000 Flash/100,000 EEPROM – Data retention: 20 years at 85°C/100 years at 25°C(1) – Optional Boot Code Section with Independent Lock Bits In-System Programming by On-chip Boot Program True Read-While-Write Operation – Programming Lock for Software Security JTAG (IEEE std. 1149.1 compliant) Interface – Boundary-scan Capabilities According to the JTAG Standard – Extensive On-chip Debug Support – Programming of Flash, EEPROM, Fuses, and Lock Bits through the JTAG Interface Peripheral Features – 4 x 25 Segment LCD Driver – Two 8-bit Timer/Counters with Separate Prescaler and Compare Mode – One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture Mode – Real Time Counter with Separate Oscillator – Four PWM Channels – 8-channel, 10-bit ADC – Programmable Serial USART – Master/Slave SPI Serial Interface – Universal Serial Interface with Start Condition Detector – Programmable Watchdog Timer with Separate On-chip Oscillator – On-chip Analog Comparator – Interrupt and Wake-up on Pin Change Special Microcontroller Features – Power-on Reset and Programmable Brown-out Detection – Internal Calibrated Oscillator – External and Internal Interrupt Sources – Five Sleep Modes: Idle, ADC Noise Reduction, Power-save, Power-down, and Standby I/O and Packages – 54 Programmable I/O Lines – 64-lead TQFP, 64-pad QFN/MLF and 64-pad DRQFN Speed Grade: – ATmega169PA: 0 - 16 MHz @ 1.8 - 5.5V Temperature range: – -40°C to 85°C Industrial Ultra-Low Power Consumption – Active Mode: 1 MHz, 1.8V: 215 µA 32 kHz, 1.8V: 8 µA (including Oscillator) 32 kHz, 1.8V: 25 µA (including Oscillator and LCD) – Power-down Mode: 0.1 µA at 1.8V – Power-save Mode: 0.6 µA at 1.8V (Including 32 kHz RTC) • • • 8-bit Microcontroller with 16K Bytes In-System Programmable Flash ATmega169PA Preliminary Summary • • • • • Rev 8171BS–AVR–03/10 ATmega169PA 1. Pin Configurations 1.1 Pinout - TQFP and QFN/MLF 64A (TQFP)and 64M1 (QFN/MLF) Pinout ATmega169PA PF5 (ADC5/TMS) PF6 (ADC6/TDO) PF4 (ADC4/TCK) PF7 (ADC7/TDI) Figure 1-1. PA0 (COM0) PA1 (COM1) 50 61 60 59 58 57 56 55 54 53 52 51 64 63 62 49 48 PA3 (COM3) 47 PA4 (SEG0) 46 PA5 (SEG1) 45 PA6 (SEG2) 44 PA7 (SEG3) 43 PG2 (SEG4) 42 PC7 (SEG5) 41 PC6 (SEG6) 40 PC5 (SEG7) 39 PC4 (SEG8) 38 PC3 (SEG9) 37 PC2 (SEG10) 36 PC1 (SEG11) 35 PC0 (SEG12) 34 PG1 (SEG13) 33 PG0 (SEG14) (SEG15) PD7 32 LCDCAP (RXD/PCINT0) PE0 (TXD/PCINT1) PE1 (XCK/AIN0/PCINT2) PE2 (AIN1/PCINT3) PE3 (USCK/SCL/PCINT4) PE4 (DI/SDA/PCINT5) PE5 (DO/PCINT6) PE6 (CLKO/PCINT7) PE7 (SS/PCINT8) PB0 (SCK/PCINT9) PB1 (MOSI/PCINT10) PB2 (MISO/PCINT11) PB3 (OC0A/PCINT12) PB4 (OC1A/PCINT13) PB5 (OC1B/PCINT14) PB6 1 2 INDEX CORNER 3 4 5 6 7 8 9 10 11 12 13 14 15 16 22 23 24 25 26 27 28 (OC2A/PCINT15) PB7 17 (T1/SEG24) PG3 18 (T0/SEG23) PG4 19 RESET/PG5 20 VCC 21 29 (SEG17) PD5 30 (SEG16) PD6 31 (ICP1/SEG22) PD0 (INT0/SEG21) PD1 (TOSC2) XTAL2 (TOSC1) XTAL1 GND (SEG20) PD2 (SEG19) PD3 Note: The large center pad underneath the QFN/MLF packages is made of metal and internally connected to GND. It should be soldered or glued to the board to ensure good mechanical stability. If the center pad is left unconnected, the package might loosen from the board. (SEG18) PD4 PA2 (COM2) PF0 (ADC0) PF1 (ADC1) PF2 (ADC2) PF3 (ADC3) AVCC AREF GND GND VCC 2 8171BS–AVR–03/10 ATmega169PA 1.2 Pinout - DRQFN 64MC (DRQFN) Pinout ATmega169PA Figure 1-2. Top view A26 B23 A27 B24 A34 B30 A33 B29 A32 B28 A31 B27 A30 B26 A29 B25 A28 B24 A27 B23 A26 Bottom view A28 B25 A29 B26 A30 B27 A31 B28 A32 B29 A33 B30 A34 A1 B1 A2 B2 A3 B3 A4 B4 A5 B5 A6 B6 A7 B7 A8 A25 B22 A24 B21 A23 B20 A22 B19 A21 B18 A20 B17 A19 B16 A18 A25 B22 A24 B21 A23 B20 A22 B19 A21 B18 A20 B17 A19 B16 A18 B7 B1 A1 A2 B2 A3 B3 A4 B4 A5 B5 A6 B6 A7 A8 A17 B15 A16 B14 A15 B13 A14 B12 A13 B11 A12 B8 A10 B9 A11 B10 A12 B11 A13 B12 A14 B13 A15 B14 A16 B15 A17 B10 A11 B9 A10 B8 Table 1-1. A1 B1 A2 B2 A3 B3 A4 B4 A5 B5 A6 B6 A7 B7 A8 DRQFN-64 Pinout ATmega169PA. PE0 VLCDCAP PE1 PE2 PE3 PE4 PE5 PE6 PE7 PB0 PB1 PB2 PB3 PB5 PB4 A9 B8 A10 B9 A11 B10 A12 B11 A13 B12 A14 B13 A15 B14 A16 B15 A17 PB7 PB6 PG3 PG4 RESET VCC GND XTAL2 (TOSC2) XTAL1 (TOSC1) PD0 (SEG22) PD1 (SEG21) PD2 (SEG20) PD3 (SEG19) PD4 (SEG18) PD5 (SEG17) PD7 (SEG15) PD6 (SEG16) A18 B16 A19 B17 A20 B18 A21 B19 A22 B20 A23 B21 A24 B22 A25 PG1 (SEG13) PG0 (SEG14) PC0 (SEG12) PC1 (SEG11) PC2 (SEG10) PC3 (SEG9) PC4 (SEG8) PC5 (SEG7) PC6 (SEG6) PC7 (SEG5) PG2 (SEG4) PA7 (SEG3) PA6 (SEG2) PA4 (SEG0) PA5 (SEG1) A26 B23 A27 B24 A28 B25 A29 B26 A30 B27 A31 B28 A32 B29 A33 B30 A34 PA2 (COM2) PA3 (COM3) PA1 (COM1) PA0 (COM0) VCC GND PF7 PF6 PF5 PF4 PF3 PF2 PF1 PF0 AREF AVCC GND A9 A9 3 8171BS–AVR–03/10 ATmega169PA 2. Overview The ATmega169PA is a low-power CMOS 8-bit microcontroller based on the AVR enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATmega169PA achieves throughputs approaching 1 MIPS per MHz allowing the system designer to optimize power consumption versus processing speed. 2.1 Block Diagram Block Diagram Figure 2-1. PF0 - PF7 PA0 - PA7 PC0 - PC7 VCC GND PORTF DRIVERS PORTA DRIVERS PORTC DRIVERS DATA REGISTER PORTF DATA DIR. REG. PORTF DATA REGISTER PORTA DATA DIR. REG. PORTA DATA REGISTER PORTC DATA DIR. REG. PORTC 8-BIT DATA BUS AVCC ADC AREF INTERNAL OSCILLATOR CALIB. OSC OSCILLATOR JTAG TAP PROGRAM COUNTER STACK POINTER WATCHDOG TIMER TIMING AND CONTROL LCD CONTROLLER/ DRIVER ON-CHIP DEBUG PROGRAM FLASH SRAM MCU CONTROL REGISTER BOUNDARYSCAN INSTRUCTION REGISTER GENERAL PURPOSE REGISTERS X Y Z TIMER/ COUNTERS PROGRAMMING LOGIC INSTRUCTION DECODER INTERRUPT UNIT RESET CONTROL LINES ALU EEPROM AVR CPU STATUS REGISTER USART UNIVERSAL SERIAL INTERFACE SPI ANALOG COMPARATOR DATA REGISTER PORTE DATA DIR. REG. PORTE DATA REGISTER PORTB DATA DIR. REG. PORTB DATA REGISTER PORTD DATA DIR. REG. PORTD DATA REG. PORTG XTAL1 XTAL2 DATA DIR. REG. PORTG + - PORTE DRIVERS PORTB DRIVERS PORTD DRIVERS PORTG DRIVERS PE0 - PE7 PB0 - PB7 PD0 - PD7 PG0 - PG4 4 8171BS–AVR–03/10 ATmega169PA The AVR core combines a rich instruction set with 32 general purpose working registers. All the 32 registers are directly connected to the Arithmetic Logic Unit (ALU), allowing two independent registers to be accessed in one single instruction executed in one clock cycle. The resulting architecture is more code efficient while achieving throughputs up to ten times faster than conventional CISC microcontrollers. The ATmega169PA provides the following features: 16K bytes of In-System Programmable Flash with Read-While-Write capabilities, 512 bytes EEPROM, 1K byte SRAM, 53 general purpose I/O lines, 32 general purpose working registers, a JTAG interface for Boundary-scan, Onchip Debugging support and programming, a complete On-chip LCD controller with internal step-up voltage, three flexible Timer/Counters with compare modes, internal and external interrupts, a serial programmable USART, Universal Serial Interface with Start Condition Detector, an 8-channel, 10-bit ADC, a programmable Watchdog Timer with internal Oscillator, an SPI serial port, and five software selectable power saving modes. The Idle mode stops the CPU while allowing the SRAM, Timer/Counters, SPI port, and interrupt system to continue functioning. The Power-down mode saves the register contents but freezes the Oscillator, disabling all other chip functions until the next interrupt or hardware reset. In Power-save mode, the asynchronous timer and the LCD controller continues to run, allowing the user to maintain a timer base and operate the LCD display while the rest of the device is sleeping. The ADC Noise Reduction mode stops the CPU and all I/O modules except asynchronous timer, LCD controller and ADC, to minimize switching noise during ADC conversions. In Standby mode, the crystal/resonator Oscillator is running while the rest of the device is sleeping. This allows very fast start-up combined with low-power consumption. The device is manufactured using Atmel’s high density non-volatile memory technology. The On-chip ISP Flash allows the program memory to be reprogrammed In-System through an SPI serial interface, by a conventional non-volatile memory programmer, or by an On-chip Boot program running on the AVR core. The Boot program can use any interface to download the application program in the Application Flash memory. Software in the Boot Flash section will continue to run while the Application Flash section is updated, providing true Read-While-Write operation. By combining an 8-bit RISC CPU with In-System Self-Programmable Flash on a monolithic chip, the Atmel ATmega169PA is a powerful microcontroller that provides a highly flexible and cost effective solution to many embedded control applications. The ATmega169PA AVR is supported with a full suite of program and system development tools including: C Compilers, Macro Assemblers, Program Debugger/Simulators, In-Circuit Emulators, and Evaluation kits. 5 8171BS–AVR–03/10 ATmega169PA 2.2 2.2.1 Pin Descriptions VCC Digital supply voltage. 2.2.2 GND Ground. 2.2.3 Port A (PA7:PA0) Port A is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The Port A output buffers have symmetrical drive characteristics with both high sink and source capability. As inputs, Port A pins that are externally pulled low will source current if the pull-up resistors are activated. The Port A pins are tri-stated when a reset condition becomes active, even if the clock is not running. Port A also serves the functions of various special features of the ATmega169PA as listed on ”Alternate Functions of Port A” on page 72. 2.2.4 Port B (PB7:PB0) Port B is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The Port B output buffers have symmetrical drive characteristics with both high sink and source capability. As inputs, Port B pins that are externally pulled low will source current if the pull-up resistors are activated. The Port B pins are tri-stated when a reset condition becomes active, even if the clock is not running. Port B has better driving capabilities than the other ports. Port B also serves the functions of various special features of the ATmega169PA as listed on ”Alternate Functions of Port B” on page 73. 2.2.5 Port C (PC7:PC0) Port C is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The Port C output buffers have symmetrical drive characteristics with both high sink and source capability. As inputs, Port C pins that are externally pulled low will source current if the pull-up resistors are activated. The Port C pins are tri-stated when a reset condition becomes active, even if the clock is not running. Port C also serves the functions of special features of the ATmega169PA as listed on ”Alternate Functions of Port C” on page 76. 2.2.6 Port D (PD7:PD0) Port D is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The Port D output buffers have symmetrical drive characteristics with both high sink and source capability. As inputs, Port D pins that are externally pulled low will source current if the pull-up resistors are activated. The Port D pins are tri-stated when a reset condition becomes active, even if the clock is not running. Port D also serves the functions of various special features of the ATmega169PA as listed on ”Alternate Functions of Port D” on page 78. 6 8171BS–AVR–03/10 ATmega169PA 2.2.7 Port E (PE7:PE0) Port E is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The Port E output buffers have symmetrical drive characteristics with both high sink and source capability. As inputs, Port E pins that are externally pulled low will source current if the pull-up resistors are activated. The Port E pins are tri-stated when a reset condition becomes active, even if the clock is not running. Port E also serves the functions of various special features of the ATmega169PA as listed on ”Alternate Functions of Port E” on page 80. 2.2.8 Port F (PF7:PF0) Port F serves as the analog inputs to the A/D Converter. Port F also serves as an 8-bit bi-directional I/O port, if the A/D Converter is not used. Port pins can provide internal pull-up resistors (selected for each bit). The Port F output buffers have symmetrical drive characteristics with both high sink and source capability. As inputs, Port F pins that are externally pulled low will source current if the pull-up resistors are activated. The Port F pins are tri-stated when a reset condition becomes active, even if the clock is not running. If the JTAG interface is enabled, the pull-up resistors on pins PF7(TDI), PF5(TMS), and PF4(TCK) will be activated even if a reset occurs. Port F also serves the functions of the JTAG interface, see ”Alternate Functions of Port F” on page 82. 2.2.9 Port G (PG5:PG0) Port G is a 6-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The Port G output buffers have symmetrical drive characteristics with both high sink and source capability. As inputs, Port G pins that are externally pulled low will source current if the pull-up resistors are activated. The Port G pins are tri-stated when a reset condition becomes active, even if the clock is not running. Port G also serves the functions of various special features of the ATmega169PA as listed on page 84. 2.2.10 RESET Reset input. A low level on this pin for longer than the minimum pulse length will generate a reset, even if the clock is not running. The minimum pulse length is given in Table 28-3 on page 329. Shorter pulses are not guaranteed to generate a reset. 2.2.11 XTAL1 Input to the inverting Oscillator amplifier and input to the internal clock operating circuit. 2.2.12 XTAL2 Output from the inverting Oscillator amplifier. 2.2.13 AVCC AVCC is the supply voltage pin for Port F and the A/D Converter. It should be externally connected to VCC, even if the ADC is not used. If the ADC is used, it should be connected to VCC through a low-pass filter. 7 8171BS–AVR–03/10 ATmega169PA 2.2.14 AREF This is the analog reference pin for the A/D Converter. 2.2.15 LCDCAP An external capacitor (typical > 470 nF) must be connected to the LCDCAP pin as shown in Figure 23-2 on page 234. This capacitor acts as a reservoir for LCD power (V LCD ). A large capacitance reduces ripple on VLCD but increases the time until VLCD reaches its target value. 8 8171BS–AVR–03/10 ATmega169PA 3. Resources A comprehensive set of development tools, application notes and datasheets are available for download on http://www.atmel.com/avr. Note: 1. 4. Data Retention Reliability Qualification results show that the projected data retention failure rate is much less than 1 PPM over 20 years at 85°C or 100 years at 25°C. 9 8171BS–AVR–03/10 ATmega169PA 5. Register Summary Address (0xFF) (0xFE) (0xFD) (0xFC) (0xFB) (0xFA) (0xF9) (0xF8) (0xF7) (0xF6) (0xF5) (0xF4) (0xF3) (0xF2) (0xF1) (0xF0) (0xEF) (0xEE) (0xED) (0xEC) (0xEB) (0xEA) (0xE9) (0xE8) (0xE7) (0xE6) (0xE5) (0xE4) (0xE3) (0xE2) (0xE1) (0xE0) (0xDF) (0xDE) (0xDD) (0xDC) (0xDB) (0xDA) (0xD9) (0xD8) (0xD7) (0xD6) (0xD5) (0xD4) (0xD3) (0xD2) (0xD1) (0xD0) (0xCF) (0xCE) (0xCD) (0xCC) (0xCB) (0xCA) (0xC9) (0xC8) (0xC7) (0xC6) (0xC5) (0xC4) (0xC3) (0xC2) (0xC1) (0xC0) Name Reserved LCDDR18 LCDDR17 LCDDR16 LCDDR15 Reserved LCDDR13 LCDDR12 LCDDR11 LCDDR10 Reserved LCDDR8 LCDDR7 LCDDR6 LCDDR5 Reserved LCDDR3 LCDDR2 LCDDR1 LCDDR0 Reserved Reserved Reserved Reserved LCDCCR LCDFRR LCDCRB LCDCRA Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved UDR0 UBRRH0 UBRRL0 Reserved UCSR0C UCSR0B UCSR0A Bit 7 – – SEG323 SEG315 SEG307 – – SEG223 SEG215 SEG207 – – SEG123 SEG115 SEG107 – – SEG023 SEG015 SEG007 – – – – LCDDC2 – LCDCS LCDEN – – – – – – – – – – – – – – – – – – – – – – – – – – – – – Bit 6 – – SEG322 SEG314 SEG306 – – SEG222 SEG214 SEG206 – – SEG122 SEG114 SEG106 – – SEG022 SEG014 SEG006 – – – – LCDDC1 LCDPS2 LCD2B LCDAB – – – – – – – – – – – – – – – – – – – – – – – – – – – – – Bit 5 – – SEG321 SEG313 SEG305 – – SEG221 SEG213 SEG205 – – SEG121 SEG113 SEG105 – – SEG021 SEG013 SEG005 – – – – LCDDC0 LCDPS1 LCDMUX1 – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – Bit 4 – – SEG320 SEG312 SEG304 – – SEG220 SEG212 SEG204 – – SEG120 SEG112 SEG104 – – SEG020 SEG012 SEG004 – – – – LCDMDT LCDPS0 LCDMUX0 LCDIF – – – – – – – – – – – – – – – – – – – – – – – – – – – – – Bit 3 – – SEG319 SEG311 SEG303 – – SEG219 SEG211 SEG203 – – SEG119 SEG111 SEG103 – – SEG019 SEG011 SEG003 – – – – LCDCC3 – – LCDIE – – – – – – – – – – – – – – – – – – – – – – – – – – – – – Bit 2 – – SEG318 SEG310 SEG302 – – SEG218 SEG210 SEG202 – – SEG118 SEG110 SEG102 – – SEG018 SEG010 SEG002 – – – – LCDCC2 LCDCD2 LCDPM2 LCDBD – – – – – – – – – – – – – – – – – – – – – – – – – – – – – Bit 1 – – SEG317 SEG309 SEG301 – – SEG217 SEG209 SEG201 – – SEG117 SEG109 SEG101 – – SEG017 SEG09 SEG001 – – – – LCDCC1 LCDCD1 LCDPM1 LCDCCD – – – – – – – – – – – – – – – – – – – – – – – – – – – – – Bit 0 – SEG324 SEG316 SEG308 SEG300 – SEG224 SEG216 SEG208 SEG200 – SEG124 SEG116 SEG108 SEG100 – SEG024 SEG016 SEG008 SEG000 – – – – LCDCC0 LCDCD0 LCDPM0 LCDBL – – – – – – – – – – – – – – – – – – – – – – – – – – – – – Page 249 249 249 249 249 249 249 249 249 249 249 249 249 249 249 249 248 246 245 244 USART0 I/O Data Register USART0 Baud Rate Register High USART0 Baud Rate Register Low – – RXCIE0 RXC0 – UMSEL0 TXCIE0 TXC0 – UPM01 UDRIE0 UDRE0 – UPM00 RXEN0 FE0 – USBS0 TXEN0 DOR0 – UCSZ01 UCSZ02 UPE0 – UCSZ00 RXB80 U2X0 – UCPOL0 TXB80 MPCM0 193 197 197 195 194 193 10 8171BS–AVR–03/10 ATmega169PA Address (0xBF) (0xBE) (0xBD) (0xBC) (0xBB) (0xBA) (0xB9) (0xB8) (0xB7) (0xB6) (0xB5) (0xB4) (0xB3) (0xB2) (0xB1) (0xB0) (0xAF) (0xAE) (0xAD) (0xAC) (0xAB) (0xAA) (0xA9) (0xA8) (0xA7) (0xA6) (0xA5) (0xA4) (0xA3) (0xA2) (0xA1) (0xA0) (0x9F) (0x9E) (0x9D) (0x9C) (0x9B) (0x9A) (0x99) (0x98) (0x97) (0x96) (0x95) (0x94) (0x93) (0x92) (0x91) (0x90) (0x8F) (0x8E) (0x8D) (0x8C) (0x8B) (0x8A) (0x89) (0x88) (0x87) (0x86) (0x85) (0x84) (0x83) (0x82) (0x81) (0x80) (0x7F) (0x7E) Name Reserved Reserved Reserved Reserved Reserved USIDR USISR USICR Reserved ASSR Reserved Reserved OCR2A TCNT2 Reserved TCCR2A Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved OCR1BH OCR1BL OCR1AH OCR1AL ICR1H ICR1L TCNT1H TCNT1L Reserved TCCR1C TCCR1B TCCR1A DIDR1 DIDR0 Bit 7 – – – – – USISIF USISIE – – – – Bit 6 – – – – – USIOIF USIOIE – – – Bit 5 – – – – – USIPF USIWM1 – – – – Bit 4 – – – – – USIDC USIWM0 – EXCLK – – Bit 3 – – – – – USICNT3 USICS1 – AS2 – – Bit 2 – – – – – USICNT2 USICS0 – TCN2UB – – Bit 1 – – – – – USICNT1 USICLK – OCR2UB – – Bit 0 – – – – – Page USI Data Register USICNT0 USITC – TCR2UB – – 206 206 207 155 Timer/Counter2 Output Compare Register A Timer/Counter2 (8-bit) – FOC2A – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – WGM20 – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – COM2A1 – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – COM2A0 – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – WGM21 – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – CS22 – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – CS21 – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – CS20 – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – 154 154 152 Timer/Counter1 - Output Compare Register B High Byte Timer/Counter1 - Output Compare Register B Low Byte Timer/Counter1 - Output Compare Register A High Byte Timer/Counter1 - Output Compare Register A Low Byte Timer/Counter1 - Input Capture Register High Byte Timer/Counter1 - Input Capture Register Low Byte Timer/Counter1 - Counter Register High Byte Timer/Counter1 - Counter Register Low Byte – FOC1A ICNC1 COM1A1 – ADC7D – FOC1B ICES1 COM1A0 – ADC6D – – – COM1B1 – ADC5D – – WGM13 COM1B0 – ADC4D – – WGM12 – – ADC3D – – CS12 – – ADC2D – – CS11 WGM11 AIN1D ADC1D – – CS10 WGM10 AIN0D ADC0D 131 131 131 131 132 132 131 131 130 129 127 213 231 11 8171BS–AVR–03/10 ATmega169PA Address (0x7D) (0x7C) (0x7B) (0x7A) (0x79) (0x78) (0x77) (0x76) (0x75) (0x74) (0x73) (0x72) (0x71) (0x70) (0x6F) (0x6E) (0x6D) (0x6C) (0x6B) (0x6A) (0x69) (0x68) (0x67) (0x66) (0x65) (0x64) (0x63) (0x62) (0x61) (0x60) 0x3F (0x5F) 0x3E (0x5E) 0x3D (0x5D) 0x3C (0x5C) 0x3B (0x5B) 0x3A (0x5A) 0x39 (0x59) 0x38 (0x58) 0x37 (0x57) 0x36 (0x56) 0x35 (0x55) 0x34 (0x54) 0x33 (0x53) 0x32 (0x52) 0x31 (0x51) 0x30 (0x50) 0x2F (0x4F) 0x2E (0x4E) 0x2D (0x4D) 0x2C (0x4C) 0x2B (0x4B) 0x2A (0x4A) 0x29 (0x49) 0x28 (0x48) 0x27 (0x47) 0x26 (0x46) 0x25 (0x45) 0x24 (0x44) 0x23 (0x43) 0x22 (0x42) 0x21 (0x41) 0x20 (0x40) 0x1F (0x3F) 0x1E (0x3E) 0x1D (0x3D) 0x1C (0x3C) Name Reserved ADMUX ADCSRB ADCSRA ADCH ADCL Reserved Reserved Reserved Reserved Reserved Reserved Reserved TIMSK2 TIMSK1 TIMSK0 Reserved PCMSK1 PCMSK0 Reserved EICRA Reserved Reserved OSCCAL Reserved PRR Reserved Reserved CLKPR WDTCR SREG SPH SPL Reserved Reserved Reserved Reserved Reserved SPMCSR Reserved MCUCR MCUSR SMCR Reserved OCDR ACSR Reserved SPDR SPSR SPCR GPIOR2 GPIOR1 Reserved Reserved OCR0A TCNT0 Reserved TCCR0A GTCCR EEARH EEARL EEDR EECR GPIOR0 EIMSK EIFR Bit 7 – REFS1 – ADEN Bit 6 – REFS0 ACME ADSC Bit 5 – ADLAR – ADATE Bit 4 – MUX4 – ADIF Bit 3 – MUX3 – ADIE Bit 2 – MUX2 ADTS2 ADPS2 Bit 1 – MUX1 ADTS1 ADPS1 Bit 0 – MUX0 ADTS0 ADPS0 Page 227 212, 231 229 230 230 ADC Data Register High byte ADC Data Register Low byte – – – – – – – – – – – PCINT15 PCINT7 – – – – – – – – CLKPCE – I – SP7 – – – – – – – – – – – PCINT14 PCINT6 – – – – – – – – – – T – SP6 – – – – – – – – ICIE1 – – PCINT13 PCINT5 – – – – – – – – – – H – SP5 – – – – – – – – – – – PCINT12 PCINT4 – – – – – PRLCD – – – WDCE S – SP4 – – – – – – – – – – – PCINT11 PCINT3 – – – – – PRTIM1 – – CLKPS3 WDE V – SP3 – – – – – – – – OCIE1B – – PCINT10 PCINT2 – – – – – PRSPI – – CLKPS2 WDP2 N SP10 SP2 – – – – – – – OCIE2A OCIE1A OCIE0A – PCINT9 PCINT1 – ISC01 – – – PRUSART0 – – CLKPS1 WDP1 Z SP9 SP1 – – – – – – – TOIE2 TOIE1 TOIE0 – PCINT8 PCINT0 – ISC00 – – 155 132 103 62 63 61 Oscillator Calibration Register – PRADC – – CLKPS0 WDP0 C SP8 SP0 37 44 37 53 13 15 15 SPMIE – JTD – – – IDRD/OCDR7 ACD – SPIF SPIE RWWSB – – – – – OCDR6 ACBG – WCOL SPE – – – – – – OCDR5 ACO – – DORD RWWSRE – PUD JTRF – – OCDR4 ACI – – MSTR BLBSET – – WDRF SM2 – OCDR3 ACIE – – CPOL PGWRT – – BORF SM1 – OCDR2 ACIC – – CPHA PGERS – IVSEL EXTRF SM0 – OCDR1 ACIS1 – – SPR1 SPMEN – IVCE PORF SE – OCDR0 ACIS0 – 292 59, 87, 277 277 44 256 212 166 SPI Data Register SPI2X SPR0 165 164 28 28 General Purpose I/O Register 2 General Purpose I/O Register 1 – – – – – – – – – – – – – – – – Timer/Counter0 Output Compare Register A Timer/Counter0 (8 Bit) – FOC0A TSM – – WGM00 – – – COM0A1 – – – COM0A0 – – – WGM01 – – – CS02 – – – CS01 PSR2 – – CS00 PSR10 EEAR8 103 103 101 136, 156 27 27 27 EEMWE – – EEWE – – EERE INT0 INTF0 27 28 61 62 EEPROM Address Register Low Byte EEPROM Data Register – PCIE1 PCIF1 – PCIE0 PCIF0 – – – – – – EERIE – – General Purpose I/O Register 0 12 8171BS–AVR–03/10 ATmega169PA Address 0x1B (0x3B) 0x1A (0x3A) 0x19 (0x39) 0x18 (0x38) 0x17 (0x37) 0x16 (0x36) 0x15 (0x35) 0x14 (0x34) 0x13 (0x33) 0x12 (0x32) 0x11 (0x31) 0x10 (0x30) 0x0F (0x2F) 0x0E (0x2E) 0x0D (0x2D) 0x0C (0x2C) 0x0B (0x2B) 0x0A (0x2A) 0x09 (0x29) 0x08 (0x28) 0x07 (0x27) 0x06 (0x26) 0x05 (0x25) 0x04 (0x24) 0x03 (0x23) 0x02 (0x22) 0x01 (0x21) 0x00 (0x20) Name Reserved Reserved Reserved Reserved TIFR2 TIFR1 TIFR0 PORTG DDRG PING PORTF DDRF PINF PORTE DDRE PINE PORTD DDRD PIND PORTC DDRC PINC PORTB DDRB PINB PORTA DDRA PINA Bit 7 – – – – – – – – – – PORTF7 DDF7 PINF7 PORTE7 DDE7 PINE7 PORTD7 DDD7 PIND7 PORTC7 DDC7 PINC7 PORTB7 DDB7 PINB7 PORTA7 DDA7 PINA7 Bit 6 – – – – – – – – – – PORTF6 DDF6 PINF6 PORTE6 DDE6 PINE6 PORTD6 DDD6 PIND6 PORTC6 DDC6 PINC6 PORTB6 DDB6 PINB6 PORTA6 DDA6 PINA6 Bit 5 – – – – – ICF1 – PORTG5 DDG5 PING5 PORTF5 DDF5 PINF5 PORTE5 DDE5 PINE5 PORTD5 DDD5 PIND5 PORTC5 DDC5 PINC5 PORTB5 DDB5 PINB5 PORTA5 DDA5 PINA5 Bit 4 – – – – – – – PORTG4 DDG4 PING4 PORTF4 DDF4 PINF4 PORTE4 DDE4 PINE4 PORTD4 DDD4 PIND4 PORTC4 DDC4 PINC4 PORTB4 DDB4 PINB4 PORTA4 DDA4 PINA4 Bit 3 – – – – – – – PORTG3 DDG3 PING3 PORTF3 DDF3 PINF3 PORTE3 DDE3 PINE3 PORTD3 DDD3 PIND3 PORTC3 DDC3 PINC3 PORTB3 DDB3 PINB3 PORTA3 DDA3 PINA3 Bit 2 – – – – – OCF1B – PORTG2 DDG2 PING2 PORTF2 DDF2 PINF2 PORTE2 DDE2 PINE2 PORTD2 DDD2 PIND2 PORTC2 DDC2 PINC2 PORTB2 DDB2 PINB2 PORTA2 DDA2 PINA2 Bit 1 – – – – OCF2A OCF1A OCF0A PORTG1 DDG1 PING1 PORTF1 DDF1 PINF1 PORTE1 DDE1 PINE1 PORTD1 DDD1 PIND1 PORTC1 DDC1 PINC1 PORTB1 DDB1 PINB1 PORTA1 DDA1 PINA1 Bit 0 – – – – TOV2 TOV1 TOV0 PORTG0 DDG0 PING0 PORTF0 DDF0 PINF0 PORTE0 DDE0 PINE0 PORTD0 DDD0 PIND0 PORTC0 DDC0 PINC0 PORTB0 DDB0 PINB0 PORTA0 DDA0 PINA0 Page 155 133 104 89 89 89 89 89 89 88 88 89 88 88 88 88 88 88 87 87 87 87 87 87 Note: 1. For compatibility with future devices, reserved bits should be written to zero if accessed. Reserved I/O memory addresses should never be written. 2. I/O Registers within the address range 0x00 - 0x1F are directly bit-accessible using the SBI and CBI instructions. In these registers, the value of single bits can be checked by using the SBIS and SBIC instructions. 3. Some of the Status Flags are cleared by writing a logical one to them. Note that, unlike most other AVRs, the CBI and SBI instructions will only operate on the specified bit, and can therefore be used on registers containing such Status Flags. The CBI and SBI instructions work with registers 0x00 to 0x1F only. 4. When using the I/O specific commands IN and OUT, the I/O addresses 0x00 - 0x3F must be used. When addressing I/O Registers as data space using LD and ST instructions, 0x20 must be added to these addresses. The ATmega169PA is a complex microcontroller with more peripheral units than can be supported within the 64 location reserved in Opcode for the IN and OUT instructions. For the Extended I/O space from 0x60 - 0xFF in SRAM, only the ST/STS/STD and LD/LDS/LDD instructions can be used. 13 8171BS–AVR–03/10 ATmega169PA 6. Instruction Set Summary Mnemonics ADD ADC ADIW SUB SUBI SBC SBCI SBIW AND ANDI OR ORI EOR COM NEG SBR CBR INC DEC TST CLR SER MUL MULS MULSU FMUL FMULS FMULSU RJMP IJMP JMP RCALL ICALL CALL RET RETI CPSE CP CPC CPI SBRC SBRS SBIC SBIS BRBS BRBC BREQ BRNE BRCS BRCC BRSH BRLO BRMI BRPL BRGE BRLT BRHS BRHC BRTS BRTC BRVS Rd,Rr Rd,Rr Rd,Rr Rd,K Rr, b Rr, b P, b P, b s, k s, k k k k k k k k k k k k k k k k k k k Operands Rd, Rr Rd, Rr Rdl,K Rd, Rr Rd, K Rd, Rr Rd, K Rdl,K Rd, Rr Rd, K Rd, Rr Rd, K Rd, Rr Rd Rd Rd,K Rd,K Rd Rd Rd Rd Rd Rd, Rr Rd, Rr Rd, Rr Rd, Rr Rd, Rr Rd, Rr k Add two Registers Description Rd ← Rd + Rr Operation Flags Z,C,N,V,H Z,C,N,V,H Z,C,N,V,S Z,C,N,V,H Z,C,N,V,H Z,C,N,V,H Z,C,N,V,H Z,C,N,V,S Z,N,V Z,N,V Z,N,V Z,N,V Z,N,V Z,C,N,V Z,C,N,V,H Z,N,V Z,N,V Z,N,V Z,N,V Z,N,V Z,N,V None Z,C Z,C Z,C Z,C Z,C Z,C None None None None None None None I None Z, N,V,C,H Z, N,V,C,H Z, N,V,C,H None None None None None None None None None None None None None None None None None None None None None #Clocks 1 1 2 1 1 1 1 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 2 3 3 3 4 4 4 1/2/3 1 1 1 1/2/3 1/2/3 1/2/3 1/2/3 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2 ARITHMETIC AND LOGIC INSTRUCTIONS Add with Carry two Registers Add Immediate to Word Subtract two Registers Subtract Constant from Register Subtract with Carry two Registers Subtract with Carry Constant from Reg. Subtract Immediate from Word Logical AND Registers Logical AND Register and Constant Logical OR Registers Logical OR Register and Constant Exclusive OR Registers One’s Complement Two’s Complement Set Bit(s) in Register Clear Bit(s) in Register Increment Decrement Test for Zero or Minus Clear Register Set Register Multiply Unsigned Multiply Signed Multiply Signed with Unsigned Fractional Multiply Unsigned Fractional Multiply Signed Fractional Multiply Signed with Unsigned Relative Jump Indirect Jump to (Z) Direct Jump Relative Subroutine Call Indirect Call to (Z) Direct Subroutine Call Subroutine Return Interrupt Return Compare, Skip if Equal Compare Compare with Carry Compare Register with Immediate Skip if Bit in Register Cleared Skip if Bit in Register is Set Skip if Bit in I/O Register Cleared Skip if Bit in I/O Register is Set Branch if Status Flag Set Branch if Status Flag Cleared Branch if Equal Branch if Not Equal Branch if Carry Set Branch if Carry Cleared Branch if Same or Higher Branch if Lower Branch if Minus Branch if Plus Branch if Greater or Equal, Signed Branch if Less Than Zero, Signed Branch if Half Carry Flag Set Branch if Half Carry Flag Cleared Branch if T Flag Set Branch if T Flag Cleared Branch if Overflow Flag is Set Rd ← Rd + Rr + C Rdh:Rdl ← Rdh:Rdl + K Rd ← Rd - Rr Rd ← Rd - K Rd ← Rd - Rr - C Rd ← Rd - K - C Rdh:Rdl ← Rdh:Rdl - K Rd ← Rd • Rr Rd ← Rd • K Rd ← Rd v Rr Rd ← Rd v K Rd ← Rd ⊕ Rr Rd ← 0xFF − Rd Rd ← 0x00 − Rd Rd ← Rd v K Rd ← Rd • (0xFF - K) Rd ← Rd + 1 Rd ← Rd − 1 Rd ← Rd • Rd Rd ← Rd ⊕ Rd Rd ← 0xFF R1:R0 ← Rd x Rr R1:R0 ← Rd x Rr R1:R0 ← Rd x Rr 1 R1:R0 ← (Rd x Rr)
