HFBR-1506AM/HFBR-2506AM
Fiber Optic SMA Transmitters and Receivers for 16 MBd SERCOS Applications
Data Sheet
Description SERCOS, an acronym for S E rial R ealtime CO mmunications S ystems, is a standard digital interface for communication in industrial CNC applications. SERCOS is a European (EN 61491) and international standard (IEC 61491). The optical interface allows data rates of 2,4,8 and 16 MBd and data transfer between numerical controls and drives via fiber-optic rings, with voltage isolation and noise immunity. The HFBR-1506AM and HFBR-2506AM products have a guaranteed performance up to 16 MBd.
Features • • • • • • Meets Industrial SERCOS 16MBd standard SMA ports 650 nm wavelength Metal coated, plastic packaging Specified for use with 1 mm POF and 200 µm HCS DC - 16 MBd data rate
Applications • Industrial Control Data Links • Factory Automation Data Links • Voltage Isolation Applications
°, ±, ≥,≤,≠,∅, ∞,µ,π,ο,θ,λ, ρ,σ,γ,φ,η, δ,χ,β,α,Ω,, Σ,,,∏,, ∝,∂,τ,υ,ϖ, ω,ξ,ψ,ζ,∅, ≈,,, • • Bullet Bold
Obsoletes: 5988-8402EN 5988-9121EN
Package Information The transmitters and receivers are housed in a lowcost, dual-in-line package that is made of high strength, heat resistant, chemically resistant and UL 94V-O (UL file # E121562) flame retardant plastic. Both the transmitter and receiver are coated with a layer of conductive alloy for better air discharge (ESD) performance. The package is designed for auto insertion and wave soldering so it is ideal for high volume production applications. Handling and Design Information When soldering, it is advisable to leave the protective cap on the unit to keep the optics clean. Good system performance requires clean port optics and cable ferrules to avoid obstructing the optical path. Clean compressed air often is sufficient to remove particles of dirt; methanol on a cotton swab also works well.
Recommended Chemicals for Cleaning/Degreasing Alcohols: methyl, isopropyl, isobutyl. Aliphatics: hexane, heptane. Other: soap solution, naphtha. Do not use partially halogenated hydrocarbons such as 1,1,1 trichloroethane, ketones such as MEK, acetone, chloroform, ethyl acetate, methylene dichloride, phenol, methylene chloride or N-methylpyrolldone. Also, Agilent does not recommend the use of cleaners that use halogenated hydrocarbons because of their potential environmental harm.
CAUTION: The small junction size inherent in the design of these components increases the components’ susceptibility to damage from electrostatic discharge (ESD). It is advised that normal static precautions be taken in handling and assembly of these components to prevent damage and/or degradation which may be induced by ESD.
Table 1. Link Performance Specification 0 °C to +70 °C unless otherwise noted.
Parameter
Link distance with HFBR-1506AM/2506AM
Symbol
I
Min
0.1 0.1
Max
45 200
Unit
m m
Condition
POF HCS
Reference
Note 1, 2, 4, 6 Note 1, 3, 5, 6
Notes: 1. 60 mA nominal drive current. 2. POF HFBR-Exxyyy 0.23 dB/m worst case attenuation. 3. HCS 10 dB/km worst case attenuation. 4. Including a 3 dB optical safety margin accounting for link service lifetime. 5. Including a 2 dB optical safety margin accounting for link service lifetime. 6. Signaling rate dc to 16 MBd.
2
HFBR-1506AM Transmitter
4 5 6 7 1 8
The HFBR-1506AM transmitter incoporates a 650nm LED in a metal-coated, plastic housing. The high light output power enables the use of both plastic optical fiber (POF) and Hard Clad Silica (HCS). This transmitter can operate up to 16MBd using a simple driver circuit. The HFBR-1506AM is compatible with SMA connectors.
PIN 1 4 5 6 7 8
FUNCTION CONNECTED TO PIN 4 CONNECTED TO PIN 1 GND GND CATHODE ANODE
BOTTOM VIEW, HFBR-1506AM SEE NOTE 10
Figure 1.
Absolute Maximum Ratings
Parameter
Storage and Operating Temperature Peak Forward Input Current Average Forward Input Current Reverse Input Voltage Lead Soldering Cycle Temp Time
Symbol
TS,
O
Min
-40
Max
+85 90 60 3
Unit
°C mA mA V
Notes
IF, PK IF, AVG VR
1
TSOL TSOL
260 10
°C s
2
Notes: 1. For I F_PK > 60 mA, the duty factor must maintain I F_AVG
