SECTION 3: LEADED TANTALUM Introduction Introduction Foreword KYOCERA AVX offers a broad line of solid Tantalum capacitors in a wide range of sizes, styles, and ratings to meet any design needs. This catalog combines into one source KYOCERA AVX’s leaded tantalum capacitor information from its worldwide tantalum operations. The TAP/TEP is rated for use from -55°C to +85°C at rated voltage and up to +125°C with voltage derating. There are three preferred wire forms to choose from which are available on tape and reel, and in bulk for hand insertion. And if the customer requirements are outside our standard testing, KYOCERA AVX will work with you to define and implement a test or screening plan. KYOCERA AVX is determined to become the world leader in tantalum capacitor technology and has made, and is continuing to make, significant investments in equipment and research to reach that end. We believe that the investment has paid off with the devices shown on the following pages. KYOCERA AVX has a complete tantalum applications service available for use by all our customers. With the capability to prototype and mass produce solid tantalum capacitors in special configurations, almost any design need can be fulfilled. DIPPED RADIAL CAPACITORS SOLID TANTALUM RESIN DIPPED SERIES TAP/TEP The TAP/TEP resin dipped series of miniature tantalum capacitors is available for individual needs in both commercial and professional applications. From computers to automotive to industrial, KYOCERA AVX has a dipped radial for almost any application. Tantalum Graphite Resin encapsulation Tantalum wire Terminal Wire Silver Solder Manganese dioxide Tantalum pentoxide 230 The Important Information/Disclaimer is incorporated in the catalog where these specifications came from or available online at www.kyocera-avx.com/disclaimer/ by reference and should be reviewed in full before placing any order. – polymer, tantalum and niobium oxide capacitors – Dipped Radial Capacitors TAP/TEP Series Wire Form Outline Dipped Radial Capacitors Wire Form Outline SOLID TANTALUM RESIN DIPPED TAP/TEP Preferred Wire Forms Figure 1 Wire Form C D D Figure 2 Wire Form B D Figure 3 Wire Form S H H1 + 4 (0.16) max + 2.0(0.08) max H1 + L L S L S S d d 2.0 (0.079) min 2 (0.079) min d Non-Preferred Wire Forms (Not recommended for new designs) Figure 4 Figure 5 D Figure 6 D D H1 max +0.118 (3.0) H + 3.8 (0.15) max + 0.079 (2) min L 1.10 +0.25 -0.10 L L S (0.4 +0.010 -0.004 ) H S d d S Wire Form F Wire Form D Wire Form G millimeters (inches) DIMENSIONS Wire Form Figure Case Size L (see note 1) S d Preferred Wire Forms C Figure 1 A - R* 16.0±4.00 (0.630±0.160) 5.00±1.00 (0.200±0.040) 0.50±0.05 (0.020±0.002) B Figure 2 A - J* 16.0±4.00 (0.630±0.160) 5.00±1.00 (0.200±0.040) 0.50±0.05 (0.020±0.002) S Figure 3 A - J* 16.0±4.00 (0.630±0.160) 2.50±0.50 (0.100±0.020) 0.50±0.05 (0.020±0.002) Non-Preferred Wire Forms (Not recommended for new designs) Notes: Packaging Suffixes Available* CCS Bulk CRW Tape/Reel CRS Tape/Ammo BRW Tape/Reel BRS Tape/Ammo SCS Bulk SRW Tape/Reel SRS Tape/Ammo F Figure 4 A-R 3.90±0.75 (0.155±0.030) 5.00±0.50 (0.200±0.020) 0.50±0.05 (0.020±0.002) FCS Bulk D Figure 5 A - H* 16.0±4.00 (0.630±0.160) 2.50±0.75 (0.100±0.020) 0.50±0.05 (0.020±0.002) DCS Bulk DTW Tape/Reel DTS Tape/Ammo G Figure 6 A-J H Similar to Figure 1 A-R 16.0±4.00 (0.630±0.160) 16.0±4.00 (0.630±0.160) 3.18±0.50 (0.125±0.020) 6.35±1.00 (0.250±0.040) 0.50±0.05 (0.020±0.002) 0.50±0.05 (0.020±0.002) GSB Bulk HSB Bulk (1) Lead lengths can be supplied to tolerances other than those above and should be specified in the ordering information. (2) For D, H, and H1 dimensions, refer to individual product on following pages. * For case size availability in tape and reel, please refer to pages 253-254. The Important Information/Disclaimer is incorporated in the catalog where these specifications came from or available online at www.kyocera-avx.com/disclaimer/ by reference and should be reviewed in full before placing any order. 040920 – polymer, tantalum and niobium oxide capacitors – 231 Dipped Radial Capacitors TAP Series SOLID TANTALUM RESIN DIPPED CAPACITORS TAP is a professional grade device manufactured with a flame retardant coating and featuring low leakage current and impedance, very small physical sizes and exceptional temperature stability. It is designed and conditioned to operate to +125°C (see page 282 for voltage derating above 85°C) and is available loose or taped and reeled for auto insertion. The 15 case sizes with wide capacitance and working voltage ranges means the TAP can accommodate almost any application. MAXIMUM CASE DIMENSIONS: Wire Case A B C D E F G H J K L M N P R C, F, G, H H 8.50 (0.330) 9.00 (0.350) 10.0 (0.390) 10.5 (0.410) 10.5 (0.410) 11.5 (0.450) 11.5 (0.450) 12.0 (0.470) 13.0 (0.510) 14.0 (0.550) 14.0 (0.550) 14.5 (0.570) 16.0 (0.630) 17.0 (0.670) 18.5 (0.730) B, S, D *H1 7.00 (0.280) 7.50 (0.300) 8.50 (0.330) 9.00 (0.350) 9.00 (0.350) 10.0 (0.390) 10.0 (0.390) 10.5 (0.410) 11.5 (0.450) 12.5 (0.490) 12.5 (0.490) 13.0 (0.510) millimeters (inches) D 4.50 (0.180) 4.50 (0.180) 5.00 (0.200) 5.00 (0.200) 5.50 (0.220) 6.00 (0.240) 6.50 (0.260) 7.00 (0.280) 8.00 (0.310) 8.50 (0.330) 9.00 (0.350) 9.00 (0.350) 9.00 (0.350) 10.0 (0.390) 10.0 (0.390) LEAD-FREE COMPATIBLE COMPONENT HOW TO ORDER 232 TAP 475 M 035 SCS Type Capacitance Code pF code: 1st two digits represent significant figures, 3rd digit represents multiplier (number of zeros to follow) Capacitance Tolerance K = ±10% M = ±20% (For J = ±5% tolerance, please consult factory) Rated DC Voltage Suffix indicating wire form and packaging (see page 246) The Important Information/Disclaimer is incorporated in the catalog where these specifications came from or available online at www.kyocera-avx.com/disclaimer/ by reference and should be reviewed in full before placing any order. 040920 – polymer, tantalum and niobium oxide capacitors – Dipped Radial Capacitors TAP Series TECHNICAL SPECIFICATIONS Technical Data: Capacitance Range: Capacitance Tolerance: Rated Voltage DC (VR) Category Voltage (VC) Surge Voltage (VS) Surge Voltage (VS) Temperature Range: Environmental Classification: Dissipation Factor: ≤ +85°C: ≤ +125ºC: ≤ +85°C: ≤ +125ºC: Reliability: Qualification: All technical data relate to an ambient temperature of +25°C 0.10 μF to 330 μF ±20%; ±10% (±5% consult your representative for details) 6.3 10 16 20 25 35 50 4 6.3 10 13 16 23 33 8 13 20 26 33 46 65 5 9 12 16 21 28 40 -55°C to +125°C 55/125/56 (IEC 68-2) ≤0.04 for CR 0.1-1.5μF ≤0.06 for CR 2.2-6.8μF ≤0.08 for CR 10-68μF ≤0.10 for CR 100-330μF 1% per 1000 hrs. at 85°C with 0.1Ω/V series impedance, 60% confidence level. CECC 30201 - 032 CAPACITANCE AND RATED VOLTAGE RANGE (LETTER DENOTES CASE SIZE) Capacitance μF Code 0.10 104 0.15 154 0.22 224 0.33 334 0.47 474 0.68 684 1.0 105 1.5 155 2.2 225 3.3 335 4.7 475 6.8 685 10 106 15 156 22 226 33 336 47 476 68 686 100 107 150 157 220 227 330 337 6.3V 10V 16V A A A B C D E F H J K N N A A A B C D E F F J L N N R A A A B C D E F G H K N P R A A A B C D E F G H K M P Rated Voltage DC (VR) 20V 25V A A A B C D E F H J M N 35V A A A A A A A A B C E F F H K M N 50V A A A A A B C D E F G H J K L Values outside this standard range may be available on request. KYOCERA AVX reserves the right to supply capacitors to a higher voltage rating, in the same case size, than that ordered. MARKING Polarity, capacitance, rated DC voltage, and an "A" (KYOCERA AVX logo) are laser marked on the capacitor body which is made of flame retardant gold epoxy resin with a limiting oxygen index in excess of 30 (ASTM-D-2863). • • • • Polarity Capacitance Voltage KYOCERA AVX logo • Tolerance code: ±20% = Standard (no marking) ±10% = “K” on reverse side of unit ±5% = “J” on reverse side of unit The Important Information/Disclaimer is incorporated in the catalog where these specifications came from or available online at www.kyocera-avx.com/disclaimer/ by reference and should be reviewed in full before placing any order. 040920 – polymer, tantalum and niobium oxide capacitors – 233 Dipped Radial Capacitors TAP Series RATINGS AND PART NUMBER REFERENCE Part Number TAP 335(*)006 TAP 475(*)006 TAP 685(*)006 TAP 106(*)006 TAP 156(*)006 TAP 226(*)006 TAP 336(*)006 TAP 476(*)006 TAP 686(*)006 TAP 107(*)006 TAP 157(*)006 TAP 227(*)006 TAP 337(*)006 TAP 225(*)010 TAP 335(*)010 TAP 475(*)010 TAP 685(*)010 TAP 106(*)010 TAP 156(*)010 TAP 226(*)010 TAP 336(*)010 TAP 476(*)010 TAP 686(*)010 TAP 107(*)010 TAP 157(*)010 TAP 227(*)010 TAP 337(*)010 TAP 155(*)016 TAP 225(*)016 TAP 335(*)016 TAP 475(*)016 TAP 685(*)016 TAP 106(*)016 TAP 156(*)016 TAP 226(*)016 TAP 336(*)016 TAP 476(*)016 TAP 686(*)016 TAP 107(*)016 TAP 157(*)016 TAP 227(*)016 TAP 105(*)020 TAP 155(*)020 TAP 225(*)020 TAP 335(*)020 TAP 475(*)020 TAP 685(*)020 TAP 106(*)020 TAP 156(*)020 TAP 226(*)020 TAP 336(*)020 TAP 476(*)020 TAP 686(*)020 TAP 107(*)020 234 DCL (μA) Max. 6.3 volt @ 85°C (4 volt @ 125°C) A 3.3 0.5 A 4.7 0.5 A 6.8 0.5 B 10 0.5 C 15 0.8 D 22 1.1 E 33 1.7 F 47 2.4 G 68 3.4 H 100 5.0 K 150 7.6 M 220 11.0 P 330 16.6 10 volt @ 85°C (6.3 volt @ 125°C) A 2.2 0.5 A 3.3 0.5 A 4.7 0.5 B 6.8 0.5 C 10 0.8 D 15 1.2 E 22 1.7 F 33 2.6 G 47 3.7 H 68 5.4 K 100 8.0 N 150 12.0 P 220 17.6 R 330 20.0 16 volt @ 85°C (10 volt @ 125°C) A 1.5 0.5 A 2.2 0.5 A 3.3 0.5 B 4.7 0.6 C 6.8 0.8 D 10 1.2 E 15 1.9 F 22 2.8 F 33 4.2 J 47 6.0 L 68 8.7 N 100 12.8 N 150 19.2 R 220 20.0 20 volt @ 85°C (13 volt @ 125°C) A 1.0 0.5 A 1.5 0.5 A 2.2 0.5 B 3.3 0.5 C 4.7 0.7 D 6.8 1.0 E 10 1.6 F 15 2.4 H 22 3.5 J 33 5.2 K 47 7.5 N 68 10.8 N 100 16.0 Case Size Capacitance (μF) DF % Max. ESR Max. (Ω) @ 100 kHz 6 6 6 8 8 8 8 8 8 10 10 10 10 13.0 10.0 8.0 6.0 5.0 3.7 3.0 2.0 1.8 1.6 0.9 0.9 0.7 6 6 6 6 8 8 8 8 8 8 10 10 10 10 13.0 10.0 8.0 6.0 5.0 3.7 2.7 2.1 1.7 1.3 1.0 0.8 0.6 0.5 4 6 6 6 6 8 8 8 8 8 8 10 10 10 10.0 8.0 6.0 5.0 4.0 3.2 2.5 2.0 1.6 1.3 1.0 0.8 0.6 0.5 4 4 6 6 6 6 8 8 8 8 8 8 10 10.0 9.0 7.0 5.5 4.5 3.6 2.9 2.3 1.8 1.4 1.2 0.9 0.6 Part Number TAP 105(*)025 TAP 155(*)025 TAP 225(*)025 TAP 335(*)025 TAP 475(*)025 TAP 685(*)025 TAP 106(*)025 TAP 156(*)025 TAP 226(*)025 TAP 336(*)025 TAP 476(*)025 TAP 686(*)025 TAP 104(*)035 TAP 154(*)035 TAP 224(*)035 TAP 334(*)035 TAP 474(*)035 TAP 684(*)035 TAP 105(*)035 TAP 155(*)035 TAP 225(*)035 TAP 335(*)035 TAP 475(*)035 TAP 685(*)035 TAP 106(*)035 TAP 156(*)035 TAP 226(*)035 TAP 336(*)035 TAP 476(*)035 TAP 104(*)050 TAP 154(*)050 TAP 224(*)050 TAP 334(*)050 TAP 474(*)050 TAP 684(*)050 TAP 105(*)050 TAP 155(*)050 TAP 225(*)050 TAP 335(*)050 TAP 475(*)050 TAP 685(*)050 TAP 106(*)050 TAP 156(*)050 TAP 226(*)050 DCL (μA) Max. 25 volt @ 85°C (16 volt @ 125°C) A 1.0 0.5 A 1.5 0.5 A 2.2 0.5 B 3.3 0.6 C 4.7 0.9 D 6.8 1.3 E 10 2.0 F 15 3.0 H 22 4.4 J 33 6.6 M 47 9.4 N 68 13.6 35 volt @ 85°C (23 volt @ 125°C) A 0.1 0.5 A 0.15 0.5 A 0.22 0.5 A 0.33 0.5 A 0.47 0.5 A 0.68 0.5 A 1.0 0.5 A 1.5 0.5 B 2.2 0.6 C 3.3 0.9 E 4.7 1.3 F 6.8 1.9 F 10 2.8 H 15 4.2 K 22 6.1 M 33 9.2 N 47 10.0 50 volt @ 85°C (33 volt @ 125°C) A 0.1 0.5 A 0.15 0.5 A 0.22 0.5 A 0.33 0.5 A 0.47 0.5 B 0.68 0.5 C 1.0 0.5 D 1.5 0.6 E 2.2 0.8 F 3.3 1.3 G 4.7 1.8 H 6.8 2.7 J 10 4.0 K 15 6.0 L 22 8.8 Case Size Capacitance (μF) DF % Max. ESR Max. (Ω) @ 100 kHz 4 4 6 6 6 6 8 8 8 8 8 8 10.0 8.0 6.0 5.0 4.0 3.1 2.5 2.0 1.5 1.2 1.0 0.8 4 4 4 4 4 4 4 4 6 6 6 6 8 8 8 8 8 26.0 21.0 17.0 15.0 13.0 10.0 8.0 6.0 5.0 4.0 3.0 2.5 2.0 1.6 1.3 1.0 0.8 4 4 4 4 4 4 4 4 6 6 6 6 8 8 8 26.0 21.0 17.0 15.0 13.0 10.0 8.0 6.0 3.5 3.0 2.5 2.0 1.6 1.2 1.0 (*) Insert capacitance tolerance code; M for ±20%, K for ±10% and J for ±5% NOTE: Voltage ratings are minimum values. KYOCERA AVX reserves the right to supply higher voltage ratings in the same case size. The Important Information/Disclaimer is incorporated in the catalog where these specifications came from or available online at www.kyocera-avx.com/disclaimer/ by reference and should be reviewed in full before placing any order. 040920 – polymer, tantalum and niobium oxide capacitors –
