74LVC1G07
SINGLE BUFFER/DRIVER WITH OPEN DRAIN OUTPUT
Description
Pin Assignments
The 74LVC1G07 is a single buffer gate with an open-drain output.
The device is designed for operation with a power supply range of
1.65V to 5.5V. The input is tolerant to 5.5V allowing this device to be
used in a mixed voltage environment. The device is fully specified for
partial power down applications using IOFF. The IOFF circuitry disables
( Top View )
( Top View )
NC 1
5 Vcc
NC 1
5 Vcc
A 2
A 2
the output preventing damaging current backflow when the device is
powered down. The open-drain output can be connected to other
open drain outputs to implement active-low wired-OR or active-high
wired-AND functions. The maximum sink current is 32mA.
4 Y
GND 3
GND 3
SOT553
4 Y
SOT25 / SOT353
( Top View )
NC
1
8
Vcc
A
2
5
NC
GND
3
4
Y
X2-DFN1410-6
( Bottom View )
GND 3
A2
NC 1
4Y
5 NC
(Top View )
NC
A
GND
6
2
5
Vcc
NC
3
4 Y
X1-DFN1010-6
(Type B)
(Top View )
Vcc
NC
3
4 Y
X2-DFN1010-6
NC
A
GND
1
6
2
5
(Top View)
5 Vcc
NC 1
3
GND
6 Vcc
X2-DFN1409-6
Chip Scale
Alternative
1
A 2
4 Y
X2-DFN0808-4
Packages not to scale
Applications
Features
•
•
•
•
•
•
•
•
Wide Supply Voltage Range from 1.65 to 5.5V
24mA Sink Current at 3.3V
CMOS Low Power Consumption
IOFF Supports Partial-Power-Down Mode Operation
•
•
Inputs Accept Up to 5.5V
ESD Protection Tested per JESD 22
Exceeds 2000-V Human Body Model (A114)
Exceeds 1000-V Charged Device Model (C101)
Latch-Up Exceeds 100mA per JESD 78, Class I
Range of Package Options
Direct Interface with TTL Levels
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
For automotive applications requiring specific change
control (i.e. parts qualified to AEC-Q100/101/200, PPAP
capable, and manufactured in IATF 16949 certified facilities),
please contact us or your local Diodes representative.
https://www.diodes.com/quality/product-definitions/
An Automotive-Compliant Part is Available Under Separate
Datasheet (74LVC1G07Q)
•
•
•
•
•
•
•
Notes:
Voltage Level Shifting
General Purpose Logic
Power Down Signal Isolation
Wide Array of Products Such as
PCs, Networking, Notebooks, Netbooks, PDAs
Tablet Computers, E-Readers
Computer Peripherals, Hard Drives, CD/DVD ROM
TV, DVD, DVR, Set Top Box
Cell Phones, Personal Navigation / GPS
MP3 Players ,Cameras, Video Recorders
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS), 2011/65/EU (RoHS 2) & 2015/863/EU (RoHS 3) compliant.
2. See https://www.diodes.com/quality/lead-free/ for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and
Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain
