APX803S-26SA-7

APX803S 3-PIN MICROPROCESSOR RESET CIRCUIT Description Pin Assignments NEW PRODUCT The APX803S is used for microprocessor (µP) supervisory circuits to monitor the power supplies in µP and digital systems. They provide excellent circuit reliability and low cost by eliminating external components and adjustments when used with 5.0V, 3.3V, 3.0V and 2.5V powered circuits. (Top View) GND 1 APX803S These circuits perform a single function: they assert a reset signal on power up and whenever the VCC supply voltage declines below a RESET preset threshold, keeping it asserted for a fixed period of time after VCC has risen above the reset threshold. For the APX803S this period is a minimum of 1ms while for other APX803S variants it is at least 140ms. The reset comparator is designed to ignore fast transients on VCC, and the outputs are guaranteed to be in the correct logic state for VCC down to 1V. (Top View) RESET SOT23 (SR Package) • • • • Precision Monitoring of 2.5V, 3.0V, 3.3V, and 5.0V Power-Supply Voltages Fully Specified Over Temperature Open-drain RESET Active Low Power-On/Power Supply Glitch Reset Pulse  APX803S00 1.7ms (Typ.)  APX803S05 50ms (Typ.)  APX803S 240ms (Typ.) 10µA Supply Current (Typ.) Guaranteed Reset Valid to VCC = 1V Totally Lead-Free & Fully RoHS Compliant (Note 1 & 2) Halogen and Antimony Free. “Green” Device (Note 3) Notes: 3 VCC GND 2 Features • • 1 APX803S APX809S/810S which have push-pull output stages. Low supply current makes the APX803S ideal for use in portable equipment. The APX803S is available in two pin out variants of the 3-pin SOT23 package. • 2 SOT23 (SA Package) The APX803S is available with different reset thresholds suitable for operation with a variety of supply voltages. The APX803S has an open drain active low RESET output and compliment Diodes • 3 VCC Applications • • • • • Computers Controllers Intelligent Instruments Critical µP and µC Power Monitoring Portable/Battery Powered Equipment 1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. 2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free. 3. Halogen- and Antimony-free "Green” products are defined as those which contain
