BAT43W-7-F

SPICE MODELS: BAT42W BAT43W BAT42W / BAT43W SURFACE MOUNT SCHOTTKY BARRIER DIODE Features · · · · Low Forward Voltage Drop Fast Switching Time SOD-123 Surface Mount Package Ideally Suited for Automatic Insertion Available in Lead Free/RoHS Compliant Version (Note 3) Mechanical Data · · · · · D H Case: SOD-123 J G Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0 E C Also Available in Lead Free Plating (Matte Tin Finish annealed over Alloy 42 leadframe). Please See Ordering Information, Note 5, on Page 2 · · Ordering Information: See Page 2 Max 3.55 3.85 B 2.55 2.85 C 1.40 1.70 D — 1.35 0.55 Typical G Terminals: Solderable per MIL-STD-202, Method 208 Polarity: Cathode Band Min A E A B Moisture Sensitivity: Level 1 per J-STD-020C · · · Dim 0.25 — H 0.11 Typical J — 0.10 a 0° 8° All Dimensions in mm Marking: Date Code & Type Code, See Page 2 Type Codes: BAT42W S7 BAT43W S8 Weight: 0.01 grams (approx.) Maximum Ratings @ TA = 25°C unless otherwise specified Characteristic Symbol BAT42W / BAT43W Unit VRRM VRWM VR 30 V Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage VR(RMS) 21 V IFM 200 mA @ t < 1.0s IFRM 500 mA Non-Repetitive Peak Forward Surge Current @ t < 10ms IFSM 4.0 A Pd 200 mW RqJA 500 °C/W Tj , TSTG -55 to +125 °C RMS Reverse Voltage Forward Continuous Current (Note 1) Repetitive Peak Forward Current (Note 1) Power Dissipation Thermal Resistance Junction to Ambient Air (Note 1) Operating and Storage Temperature Range Electrical Characteristics @ TA = 25°C unless otherwise specified Characteristic Symbol Min Max Unit V(BR)R 30 ¾ V IR = 100mA VFM ¾ ¾ ¾ 0.26 ¾ 1.0 0.40 0.65 0.33 0.45 V IF = 200mA IF = 10mA IF = 50mA IF = 2.0mA IF = 15mA Peak Reverse Current (Note 2) IRM ¾ 500 100 nA mA VR = 25V VR = 25V, Tj = 100°C Total Capacitance CT ¾ 10 pF VR = 1.0V, f = 1.0MHz Reverse Recovery Time trr ¾ 5.0 ns IF = IR = 10mA, Irr = 0.1 x IR, RL = 100W Rectification Efficiency hv 80 ¾ % RL = 15W, CL = 300pF, f = 45MHz, VRF = 2.0V Reverse Breakdown Voltage (Note 2) Forward Voltage Drop (Note 2) Notes: All Types BAT42W BAT42W BAT43W BAT43W Test Condition 1. Part mounted on FR-4 board with recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf. 2. Short duration pulse test used to minimize self-heating effect. 3. No purposefully added lead. DS30016 Rev. 9 - 2 1 of 3 www.diodes.com BAT42W/BAT43W ã Diodes Incorporated 80 60 40 20 Tj = 125°C 0 0 25 50 75 100 125 150 IF, INSTANTANEOUS FORWARD CURRENT (mA) IFM, FORWARD CURRENT (mA) 100 100 TA = 125ºC TA = 75ºC 10 TA = 25ºC 1.0 TA = -25ºC 0.1 0 600 400 200 800 VF, INSTANTANEOUS FORWARD VOLTAGE (mV) Fig. 2 Typical Forward Characteristics TA, AMBIENT TEMPERATURE (°C) Fig. 1 Forward Current Derating Curve 100 CT, TOTAL CAPACITANCE (pF) 1000 TA = 125ºC 100 10 TA = 75ºC 1.0 0.1 Tj = 25°C f = 1MHz 10 TA = 25ºC 0.01 0 10 20 30 40 1.0 0 Notes: 10 15 20 25 30 35 40 VR, REVERSE VOLTAGE (V) Fig. 4 Total Capacitance vs. Reverse Voltage VR, INSTANTANEOUS REVERSE VOLTAGE (V) Fig. 3 Typical Reverse Characteristics Ordering Information 5.0 (Note 4) Device Packaging Shipping BAT42W-7 SOD-123 3000/Tape & Reel BAT43W-7 SOD-123 3000/Tape & Reel 4. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf. 5. For Lead Free/RoHS Compliant version part numbers, please add "-F" suffix to the part numbers above. Example: BAT43W-7-F. DS30016 Rev. 9 - 2 2 of 3 www.diodes.com BAT42W/BAT43W Marking Information YM XX = Product Type Marking Code YM = Date Code Marking Y = Year (ex: N = 2002) M = Month (ex: 9 = September) XX Date Code Key Year 2001 2002 2003 2004 2005 2006 2007 2008 2009 Code M N P R S T U V W Month Jan Feb March Apr May Jun Jul Aug Sep Oct Nov Dec Code 1 2 3 4 5 6 7 8 9 O N D DS30016 Rev. 9 - 2 3 of 3 www.diodes.com BAT42W/BAT43W
