PAM8901 / PAM8908
25mW TRUE CAP FREE STEREO HEADPHONE AMPLIFIER
Pin Assignments
OUTL
HPVDD
16
15
14
13
INL-
1
12
PVDD
INL+
2
11
CAP+
INR+
3
10
CAP-
INR-
4
9
PGND
7
8
HPVSS
G0
6
OUTR
5
The PAM8901 / PAM8908 operates from a single supply from 2.5V to
5.5V, has short-circuit and over temperature protection. Shutdown
mode reduces supply current to less than 1µA.
G1
The PAM8901 / PAM8908 delivers up to 25mW per channel into a
16Ω load and has low 0.03% THD+N. A high power-supply rejection
ratio (80dB at 1kHz) allows this device to operate from noisy digital
supplies without an additional linear regulator.
SGND
(Top View)
Top View
U-QFN3030-16
U-QFN3030-16
(Type US)
SGND
PVDD
EN
14
13
INL-
1
12
HPVDD
INL+
2
11
CAP+
INR+
3
10
PGND
INR-
4
9
CAP-
5
6
7
8
U-QFN3030-16
U-QFN3030-16
(Type US)
Applications
Notes:
15
HPVSS
16
G1
Patent Pending 3 Phase Power Line Shift Charge Pump
Eliminates Need for DC-Blocking Capacitors
TrueCapFree Architecture, Output Biased at 0V (System
Ground)
Excellent Low Frequency Fidelity
80dB PSRR at 1kHz
Less than 1µA Shutdown Current
Support Both Fully Differential and Single-Ended Inputs
Short Circuit and Over Temperature Protection
Selectable Gain Settings: -6dB, 0dB, 3dB and 6dB
Available in Space Saving Packages: U-QFN3030-16 (Type US)
Lead Free and Green Devices Available (RoHS Compliant)
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green Device (Note 3)
G0
OUTL
TopView)
View
(Top
Features
OUTR
NEW PRODUCT
The PAM8901 / PAM8908 stereo headphone driver is designed for
portable equipment where board space is at a premium. The
PAM8901 / PAM8908 uses a unique, patent pending architecture to
produce a ground-referenced output from a single supply, eliminating
the need for large DC-blocking capacitors, saving cost, board space,
and component height.
EN
Description
Smart Phones/Cellular Phones
Notebook Computers
Portable DVD Player
Personal Digital Assistants (PDAs)
Electronic Dictionaries
Digital Still Cameras
Portable Gaming
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain
