ZXMN6A09G
Green
60V N-CHANNEL ENHANCEMENT MODE MOSFET
Product Summary
Features and Benefits
ID
V(BR)DSS
RDS(ON)
TA = +25°C
0.04Ω @ VGS = 10V
7.5A
0.06Ω @ VGS = 4.5V
6.2A
60V
High Voltage
Low On-resistance
Fast Switching Speed
Low Gate Drive
Low Threshold
Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
Description
This new generation trench MOSFET features a unique structure
combining the benefits of low on-resistance and fast switching,
making it ideal for high efficiency power management applications.
Applications
•
•
•
•
Mechanical Data
DC-DC Converters
Power Management Functions
Disconnect Switches
Motor Control
Case: SOT223
Case Material: Molded Plastic, “Green” Molding Compound; UL
Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Matte Tin Finish
Weight: 0.112 grams (Approximate)
SOT223
D
D
G
S
Top View
Pin Out - Top
View
Equivalent Circuit
Ordering Information (Note 4)
Part Number
ZXMN6A09GTA
Notes:
Marking
ZXMN6A09
Reel size (inches)
7
Tape width (mm)
12
Quantity per reel
1,000
1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. All applicable RoHS exemptions applied.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain
