0802-1000-03

POTS Filters For DSL Applications • Filter design is compliant with all ADSL, RADSL, SDSL and VDSL coding standards • Available in two popular packaging options, with or without pigtail • Compact and robust package design includes RJ-11 connectors for easy installation • Meets UL, CSA and TUV safety standards • UL 1950 compliant • Meets FCC Part 68 Rules • CS-03 (Industry Canada) compliant • Operating temperature range of -40° to 85° C TM9956 ELECTRICAL SPECIFICATIONS at 25° C 0802-1000-02 Inductor Value Configuration Cutoff Frequency -3 dB Attenuation @ 20kHz Attenuation @ 40kHz Insertion Loss 200Hz to 4kHz Pass Band Ripple 200Hz to 4kHz DCR (each line) Return Loss @ 1kHz 1mH without pigtail 13.5kHz 6.5 dB 15 dB .5 dB + .5 dB 1Ω 23 dB 0802-1000-03 4mH with pigtail 12kHz 9 dB 20 dB .5 dB + .5 dB 3Ω 27 dB 0802-1000-05 4mH without pigtail 12kHz 9 dB 20 dB .5 dB + .5 dB 3Ω 27 dB 0802-1000-06 4mH without pigtail 12kHz 9 dB 20 dB .5 dB + .5 dB 3Ω 27 dB 0802-1000-08 4mH with pigtail 12kHz 9 dB 20 dB .5 dB + .5 dB 3Ω 27 dB 0802-1000-09 1mH with pigtail 13.5kHz 6.5 dB 15 dB .5 dB + .5 dB 1Ω 23 dB TYPICAL LAYOUT RJ11 F1 L1 C1 RJ11 F2 Fuses included with 0802-1000-06 and 0802-1000-08 only. ©2000 Bel Fuse Inc. Specifications subject to change without notice. 03.00 Bel Fuse Inc. 198 Van Vorst Street, Jersey City, NJ 07302 • Tel 201-432-0463 • Fax 201-432-9542 • www.belfuse.com T512 POTS Filters TM9956 For DSL Applications MECHANICALS 0802-1000-02 0802-1000-05 0802-1000-06 PHONE 1.25 [31.75] 2.96 [75.18] 1.20 [30.48] 0802-1000-03 0802-1000-08 0802-1000-09 PH ON E Red Wire PHONE 1.25 [31.75] Green Wire 4.0 [101.6] 2.96 [75.18] 1.20 [30.48] PRODUCT SERVICE geprufte Sischerheit ©2000 Bel Fuse Inc. Specifications subject to change without notice. 03.00 CORPORATE Bel Fuse Inc. 198 Van Vorst Street Jersey City, NJ 07302 Tel 201-432-0463 Fax 201-432-9542 www.belfuse.com FAR EAST Bel Fuse Ltd. 8F / 8 Luk Hop Street San Po Kong Kowloon, Hong Kong Tel 852-2328-5515 Fax 852-2352-3706 www.belfuse.com EUROPE Bel Fuse Europe Ltd. Preston Technology Management Centre Marsh Lane, Suite F23, Preston Lancashire, PR1 8UD, U.K. Tel 44-1772-556601 Fax 44-1772-888366 www.belfuse.com T513 L IN E E IN L LINE LINE PH ON E
