defining a degree of excellence 1 TAP BOTH EDGES CONTROLLED STANDARD DELAY MODULES .60 + .02 .375 .350 .60 + .02 8 Out .285 Max Vcc 14 In 1 Gnd 7 .325 Cat 23-R3 bel (DC) (P/N) bel * (DC) (P/N) .285 Max .80 Max .22 Max .018 Coplanarity + .002 .015 .004 .80 Max 4 o .23 Max .012 .008 .012 .008 100o 90o .20 Max .015 Min .045 .030 .12 Min .018 Part Numbers SMD S422-0010-06 S422-0020-06 S422-0030-06 S422-0040-06 S422-0050-06 S422-0060-06 S422-0070-06 S422-0080-06 S422-0090-06 S422-0100-06 S422-0125-06 S422-0150-06 S422-0200-06 Thru-Hole A447-0010-06 A447-0020-06 A447-0030-06 A447-0040-06 A447-0050-06 A447-0060-06 A447-0070-06 A447-0080-06 A447-0090-06 A447-0100-06 A447-0125-06 A447-0150-06 A447-0200-06 Time Delay 10 ns 20 ns 30 ns 40 ns 50 ns 60 70 80 90 100 ns ns ns ns ns Rise Tolerance Time + 2.0 ns 3 ns + 2.0 ns + 2.0 ns + 2.0 ns + 2.5 ns + + + + + 3.0 3.5 4.0 4.5 5.0 ns ns ns ns ns 3 ns 3 ns 3 ns 3 ns 3 3 3 3 3 ns ns ns ns ns Vcc Vih Vil Ioh Iol Voh Vol Vik Iih Iil Ios Icch Iccl Ta PW d Tc Ein Trin PW PP Iccl Vcc Test Conditions @ 25oC Pulse Voltage Rise Time Pulse Width Pulse Period Supply Current Supply Voltage 3.2 Volts 3.0 ns (10%-90%) 1.2 x Total Delay 4 x Pulse Width 35 ma Typical 5.0 Volts Electrical Characteristics Supply Voltage Logic 1 Input Voltage Logic 0 Input Voltage Logic 1 Output Current Logic 0 Output Current Logic 1 Output Voltage Logic 0 Output voltage Input Clamp Voltage Logic 1 Input Current Logic 0 Input Current Short Circuit Output Current Logic 1 Supply Current Logic 0 Supply Current Operating Free Air Temperature Min. Input Pulse Width of Total Delay Maximum Duty Cycle Min. 4.75 2.0 Max. 5.25 0.8 -1 20 2.7 0.5 -1.2 20 -0.6 -150 25 40 70o 50 Units V V V ma ma V V V ua ma ma ma ma C % % 125 ns 150 ns 200 ns + 6.3 ns + 7.5 ns + 8.0 ns 3 ns 3 ns 3 ns Tolerances Input to Output + 2 ns or 5% , Whichever is Greater Delays measured @ 1.5 V levels on Leading Edge and Trailing Edge with no loads on Output Rise and Fall Times measured from 0.75 V to 2.4 V levels -60 0o 40 Drive Capabilities Nh Logic 1 Fanout Nl Logic 0 Fanout 10 TTL Loads Max. 10 TTL Loads Max. Temp. Coeff. of Total Delay (TD) 100 + (25000/TD) PPM/OC Notes Transfer molded for better reliability Compatible with TTL & DTL circuits Terminals: Electro-Tin plate phosphor bronze Performance warranty is limited to specified parameters listed SMD - Tape & Reel available: 32mm Wide x 16mm Pitch, 500 pieces per 13" reel Recommended Temperature Profile 300o C 200 C 100o C Temp. o Infra Red 225o C Max Temp. > 185o C for 90 Seconds Max 0 2 4 6 Ti m e i n M i n u t e s 8 Other Delays and Tolerances Available Consult Sales Specifications subject to change without notice. Corporate Office Bel Fuse Inc. 198 Van Vorst Street, Jersey City, NJ 07302-4496 Tel: 201-432-0463 Fax: 201-432-9542 E-Mail: BelFuse@belfuse.com Internet: http://www.belfuse.com Far East Office Bel Fuse Ltd. 8F/8 Luk Hop Street San Po Kong Kowloon, Hong Kong Tel: 852-2328-5515 Fax: 852-2352-3706 European Office Bel Fuse Europe Ltd. Preston Technology Management Centre Marsh Lane, Preston PR1 8UD Lancashire, U.K. Tel: 44-1772-556601 Fax: 44-1772-888366 9
