SS-39200-020

C AT6a Features / Benefits Shielded Plugs SS-39200 Series CAT6a Shielded Plugs • Ideal for creating superior high performance CAT6a patch cables in 10Gigabit Ethernet applications where high density routers and switches are employed • Mechanical design features wire aligner and management bar combo to guarantee consistent twisted pair orientation during plug assembly • Meets CAT6a performance requirements per ANSI/TIA-568-B.2-10 and IEC 60603-7-51 • Robust shield termination and strain relief allow for one-step termination process • Optional slim line boot features integrated strain relief and latch protection • Selectively plated contacts with 50 micro-inches (0.76 um) of gold • UL 94-V0 plastic components Part Number Boot Cable Diameter Range • RoHS compliant SS-39200-020 SS-39200-021 Bel Stewart Connector GmbH Industriestrasse 20 61381 Friedrichsdorf Germany Tel 49-6172-9552-0 www.belstewart.com Bel Stewart Connector 11118 Susquehanna Trail South Glen Rock, PA 17327 USA Tel 717-235-7512 Fax 717-235-4675 www.belstewart.com SS-39200-022 Black Boot not included Black .220” - .240” [5.59mm - 6.10mm] .220” - .240” [5.59mm - 6.10mm] .230” - .250” [5.84mm - 6.35mm] Bel Stewart’s SS-39200 Series of shielded plugs is designed for use on CAT6a patch cables in premise .230” - .250” wiring systems. Engineered to meet the 500 MHz SS-39200-023 Boot not included [5.84mm - 6.35mm] requirements of CAT6a specifications, the SS-39200 plugs offer robust shield terminations and strain relief which allow for a one-step termination process and provide a 360° connection between the cable shield and plug shield. The SS-39200 Series' high performance is achieved through an innovative mechanical design featuring a wire aligner and management bar combination that guarantees consistent twisted pair orientation during plug assembly. The wire aligner includes a patent-pending "cross talk zone" where a precise amount of cross talk is introduced to the plug allowing for centered near end cross talk (NEXT) performance on pairs 3,6 - 4,5 according to ANSI/TIA-568-B.2-10 and IEC 60603-7-51 standards. This wire aligner feature also provides the cable assembler with a visual and mechanical means for building consistent assemblies capable of delivering CAT6a performance. As a result, operator efficiency in building patch cables improves immediately and over the long term, and productivity is much higher than with typical CAT6 or CAT6a plug assemblies. For increased space efficiency, the boot design of the plug does not increase the overall width, making the SS-39200 Series ideal for use in high-density routers and switches. Document part number LIT-CAT6A-Plugs. ©2010 Bel Stewart Connector Specifications subject to change without notice. 10.10 CAT6a 120 Shielded Plugs Typical Patch Cord NEXT 3 Meter CAT6a Shielded Patch Cord Using Bel Stewart CAT6a Shielded Plug 60 Typical Patch Cord RL 3 Meter CAT6a Shielded Patch Cord Using Bel Stewart CAT6a Shielded Plug 100 50 80 NEXT (dB) IEC Limit (dB) TIA Limit (dB) 1,2-3,6 1,2-4,5 1,2-7,8 3,6-4,5 3,6-7,8 4,5-7,8 RL (dB) 40 Limit (dB) 1,2 60 30 3,6 4,5 7,8 40 20 20 10 0 0 50 100 150 200 250 300 350 400 450 500 Frequency (MHz) 0 0 50 100 150 200 250 Frequency (MHz) 300 350 400 450 500 Bel Stewart Connector GmbH Industriestrasse 20 61381 Friedrichsdorf Germany Tel 49-6172-9552-0 www.belstewart.com Bel Stewart Connector 11118 Susquehanna Trail South Glen Rock, PA 17327 USA Tel 717-235-7512 Fax 717-235-4675 www.belstewart.com Performance data for Bel Stewart’s SS-39200 Series of shielded plugs clearly demonstrates a significant NEXT margin over the TIA limit and the more stringent IEC limit. This is achieved through a designed headroom which allows for both assembly and cable variations while still maintaining excellent margins. With superior performance and one-step termination, this RoHS- compliant plug is a very cost effective CAT6a solution. PLUG BODY SHIELD GROMMET .464 [11.79] MAX. .47 [12.0] .36 [9.0] ISOMETRIC VIEW OF TERMINATED PLUG (.58 [14.7]) .049 [1.24] 1.75 [44.4] .264 [6.71] MAX. .358 [9.09] .045 [1.14] Document part number LIT-CAT6A-Plugs. ©2010 Bel Stewart Connector Specifications subject to change without notice. 10.10
