HS-7001

HS-7001 PGA 478 Pentium® 4 Industrial Single Board Computer •Full-size•Giga LAN•CRT•ATA/33/66/100• •Dual LAN•Audio•4COM•PC/104•IrDA• •USB2.0•DOC•WDT•H/W Monitor• •PICMG Bus Industrial Single Board computer• Copyright Disclaimers The accuracy of contents in this manual has passed thorough checking and review before publishing. BOSER Technology Co., Ltd., the manufacturer and publisher, is not liable for any infringements of patents or other rights resulting from its use. The manufacturer will not be responsible for any direct, indirect, special, incidental or consequential damages arising from the use of this product or documentation, even if advised of the possibility of such damage(s). This manual is copyrighted and BOSER Technology Co., Ltd. reserves all documentation rights. Unauthorized reproduction, transmission, translation, and storage of any form and means (i.e., electronic, mechanical, photocopying, recording) of this document, in whole or partly, is prohibited, unless granted permission by BOSER Technology Co., Ltd. BOSER Technology Co., Ltd. reserves the right to change or improve the contents of this document without due notice. BOSER Technology Co., Ltd. assumes no responsibility for any errors or omissions that may appear in this manual, nor does it make any commitment to update the information contained herein. Trademarks Trademarks BOSER is a registered trademark of BOSER Technology Co., Ltd. ISB is a registered trademark of BOSER Technology Co., Ltd. Intel is a registered trademark of Intel Corporation. Award is a registered trademark of Award Software, Inc. AMI is a registered trademark of AMI Software, Inc. All other trademarks, products and or product names mentioned herein are mentioned for identification purposes only, and may be trademarks and/or registered trademarks of their respective companies or owners. © Copyright 2004 BOSER Technology Co., Ltd. All Rights Reserved. Edition 1.2, November 24, 2004 Table of Contents Chapter 1 1.1 1.2 1.3 General Description..................................1 Major Features ................................................................. 2 Specifications .................................................................. 2 Board Dimensions........................................................... 4 Chapter 2 2.1 2.2 Unpacking .................................................5 Opening the Delivery Package....................................... 5 Inspection......................................................................... 5 Chapter 3 3.1 3.2 3.3 3.4 3.5 3.6 3.7 3.8 3.9 3.10 3.11 3.12 3.13 3.14 3.15 3.16 3.17 3.18 3.19 3.20 3.21 3.22 3.23 3.24 Hardware Installation ..............................7 Before Installation ........................................................... 7 Board Layout ................................................................... 8 Jumper List ...................................................................... 9 Connector List ................................................................. 9 Configuring the CPU ..................................................... 10 System Memory ............................................................. 10 DiskOnChip Address Setting .................................... 10 VGA Controller............................................................... 13 PCI E-IDE Drive Connector........................................... 14 Floppy Disk Drive Connector ....................................... 16 Serial Port Connectors ................................................. 17 IrDA Connector .............................................................. 18 Parallel Connector......................................................... 19 Ethernet Connector....................................................... 19 USB Connector.............................................................. 20 CMOS Data Clear ........................................................... 20 Power and Fan Connectors.......................................... 21 Keyboard Connectors................................................... 23 PS/2 Mouse Connector ................................................. 23 System Front Panel Connectors.................................. 23 External Speaker ........................................................... 24 Watchdog Timer ............................................................ 25 Audio Connectors ......................................................... 26 PC/104 Connectors ....................................................... 27 Chapter 4 4.1 4.2 4.3 4.4 4.5 4.6 4.7 4.8 4.9 4.10 4.11 4.12 4.13 4.14 4.15 4.16 Award BIOS Setup .................................30 Starting Setup ................................................................ 30 Using Setup.................................................................... 31 Main Menu ...................................................................... 32 Standard CMOS Features ............................................. 33 Advanced BIOS Features ............................................. 34 Advanced Chipset Features ......................................... 35 Integrated Peripherals .................................................. 36 Power Management Setup ........................................... 37 PnP/PCI Configurations................................................ 38 PC Health Status............................................................ 39 Frequency/Voltage Control........................................... 39 Load Fail-Safe Defaults................................................. 40 Load Optimized Defaults .............................................. 41 Set Supervisor/User Password.................................... 42 Save & Exit Setup .......................................................... 43 Exit Without Saving....................................................... 44 Chapter 5 5.1 5.2 5.3 5.4 5.5 Software Utilities ....................................46 IDE Driver Installation ................................................... 46 VGA Driver Installation ................................................. 53 LAN Driver Installation.................................................. 62 Audio Driver Installation ............................................... 74 USB2.0 Driver Installation ............................................ 76 Safety Instructions Integrated circuits on computer boards are sensitive to static electricity. To avoid damaging chips from electrostatic discharge, observe the following precautions: Do not remove boards or integrated circuits from their anti-static packaging until you are ready to install them. Before handling a board or integrated circuit, touch an unpainted portion of the system unit chassis for a few seconds. This helps to discharge any static electricity on your body. Wear a wrist-grounding strap, available from most electronic component stores, when handling boards and components. Fasten the ALLIGATOR clip of the strap to the end of the shielded wire lead from a grounded object. Please wear and connect the strap before handle the HS-7001 to ensure harmlessly discharge any static electricity through the strap. Please use an anti-static pad when putting down any components or parts or tools outside the computer. You may also use an anti-static bag instead of the pad. Please inquire from your local supplier for additional assistance in finding the necessary anti-static gadgets. NOTE: DO NOT TOUCH THE BOARD OR ANY OTHER SENSITIVE COMPONENTS WITHOUT ALL NECESSARY ANTI-STATIC PROTECTION. Chapter 1 General Description The HS-7001 is an Intel® 82845GV/82801DB chipset-based board designed for PICMG Bus PGA 478 Intel® Pentium® 4 up to 2.8GHz CPU compatibility. These features combine and make the HS-7001 an ideal all-in-one industrial single board computer. Additional features include an enhanced I/O with CRT, Dual LAN, audio and 4 COM ports interface. Its onboard ATA/33/66/100 to IDE drive interface architecture allows the HS-7001 to support data transfers of 33, 66 or 100MB/sec. to each IDE drive connection. Designed with the Intel® 82845GV/82801DB core logic chipset, the board supports all PGA 478 Pentium® 4 CPU series operating up to 2.8GHz. The CRT display controller is Intel 82845GV with 1MB or 8MB memory supporting CRT display up to 1920 x 1200 x 32-bit at 60Hz. System memory is also sufficient with the two DDR sockets that can support up to 2GB(DDR-333). While using 533MHz FSB CPU, it could support DDR-333, but using 400MHz FSB CPU, it only could support DDR-266. Additional onboard connectors include an advanced USB and IrDA ports providing faster data transmission, a DOS-compatible DiskOnChip socket with a maximum capacity of 288MB, and two external RJ-45 or two internal 5x2 connectors for one 100/1000 and one 10/100 OR two 10/100 Base-TX Ethernet use. 1 1.1 Major Features The HS-7001 comes with the following features: PGA 478 for Intel Pentium 4 up to 2.8GHz CPU Intel 82845GV/82801DB system chipset Two DDR sockets with a max. capacity of 2GB Winbond W83627 super I/O chipset x 2 Fast PCI ATA/33/66/100 IDE controller Four RS-232 serial ports PC/104 Bus connector Intel 82845GV CRT display controller Intel 82540EM 10/100 Based (or Intel 82551 10/100 Based) and Intel 82562 10/100 Based LAN AC97 3D audio controller DiskOnChip TM ® ® ® ® ® ® ® socket supporting memory sizes of up to 288MB Supports USB2.0, two USB connectors Supports Hardware Monitor function 1.2 Specifications ® ® CPU: PGA 478 for Intel Pentium 4 up to 2.8GHz CPU (400MHz FSB up to 2.4GHz, 533MHz FSB up to 2.8GHz) Bus Interface: PICMG Bus Memory: Two DDR sockets supporting up to 2GB(DDR-333) ® Chipset: Intel 82845GV/82801DB I/O Chipset: Winbond W83627 x 2 ® VGA: Intel 82845GV with 1MB or 8MB supporting CRT display up to 1920 x 1200 x 32-bit at 60Hz 2 IDE: Four IDE disk drives supporting ATA/33/66/100 and with transfer rates of up to 33/66/100MB/sec. FDD: Supports up to two floppy disk drives Parallel: One enhanced bi-directional parallel port supporting SPP/ECP/EPP ® ® LAN: One Intel 82540EM 100/1000 Based(or one Intel 82551 10/100 ® Based) and one Intel 82562 10/100 Based LAN Audio: AC97 3D audio controller Serial Port: 16C550 UART-compatible RS-232 x 4 serial ports with 16-byte FIFO PC/104: PC/104 connector for 8-bit x 2clock ISA Bus IrDA: One IrDA TX/RX header USB: Supports USB2.0, two USB connectors Keyboard: PS/2 6-pin Mini DIN or 5-pin connector Mouse: PS/2 6-pin Mini DIN TM TM DiskOnChip : DiskOnChip socket supporting memory sizes of up to 288MB BIOS: Award PnP Flash BIOS Watchdog Timer: Software program time-out intervals from 1~256sec. CMOS: Battery backup Power Connector: One 4-pin and one 20-pin ATX power connector Temperature: 0~60°C (operating) Hardware Monitor: Winbond W83627 Board Size: 33.6 x 12.2 cm 3 1.3 Board Dimensions 4 Chapter 2 Unpacking 2.1 Opening the Delivery Package The HS-7001 is packed in an anti-static bag. The board has components that are easily damaged by static electricity. Do not remove the anti-static wrapping until proper precautions have been taken. Safety Instructions in front of this manual describe anti-static precautions and procedures. 2.2 Inspection After unpacking the board, place it on a raised surface and carefully inspect the board for any damage that might have occurred during shipment. Ground the board and exercise extreme care to prevent damage to the board from static electricity. Integrated circuits will sometimes come out of their sockets during shipment. ExAwardne all integrated circuits, particularly the BIOS, processor, memory modules, ROM-Disk, and keyboard controller chip to ensure that they are firmly seated. The HS-7001 delivery package contains the following items: HS-7001 Board x 1 Utility CD Disk x 1 Cables Package x 1 Cooling Fan x 1 Jumper Bag x 1 User’s Manual 5 NO. 1 2 3 4 5 6 7 Cables Package Description Floppy flat cable x 1 ATA/100 IDE flat cable x 2 5-pin ATX power cable x 1 Two USB split type cable with bracket x 1 Parallel port flat cable with bracket x 1 MIC/Audio 8-pin cable x 1 Two COM flat cable with bracket x 2 It is recommended that you keep all the parts of the delivery package intact and store them in a safe/dry place for any unforeseen event requiring the return shipment of the product. In case you discover any missing and/or damaged items from the list of items, please contact your dealer immediately. 6 Chapter 3 Hardware Installation This chapter provides the information on how to install the hardware using the HS-7001. This chapter also contains information related to jumper settings of switch, watchdog timer, and the DiskOnChip address selection etc. 3.1 Before Installation After confirming your package contents, you are now ready to install your hardware. The following are important reminders and steps to take before you begin with your installation process. 1. Make sure that all jumper settings match their default settings and CMOS setup correctly. Refer to the sections on this chapter for the default settings of each jumper. (Set JP2 1-2) Go through the connections of all external devices and make sure that they are installed properly and configured correctly within the CMOS setup. Refer to the sections on this chapter for the detailed information on the connectors. Keep the manual and diskette in good condition for future reference and use. Make sure your power supply is using for P4 only. One of 4-pin connector is for +12V lead which should connect to PW1 connector of HS-7001. 2. 3. 4. 7 3.2 Board Layout 8 3.3 Jumper JP1 JP2 JP4 Jumper List Default Setting Clock Speed Select: CPU Select Clear CMOS: Normal Operation DiskOnChip Address Select: D000H~D1FFH Setting 1-2 Short 1-2 Short 3-4, 7-8 Short Page 10 19 10 3.4 Connector List Definition CD Analog Input Connector Line In Analog Input Connector COM1 Connector (DB9) Green LED Connector Reset Connector HDD LED Connector 2-pin ATX Power On/Off Switch Keylock Connector 5-pin Keyboard Connector Speaker Connector COM1~COM4 Connector (5x2 header) MIC In/Line Out Connector 5-pin ATX Power Connector 188-pin DDR Socket Floppy Connector Chassis/CPU/System Fan IDE Connectors IrDA Connector PS/2 6-pin Mini DIN Keyboard Connector Dual RJ-45 Connector Parallel Connector PS/2 6-pin Mini DIN Mouse Connector PC/104 64-pin Connector PC104 40-pin Connector 4-pin ATX Power Connector 20-pin ATX Power Connector USB 2.0 Connector CRT Connector Wake On LAN Connector Connector CD1 CD2 COM1 CN1 CN2 CN3 CN4 CN5 CN6 CN7 CN11 / CN12 / CN8 / CN9 CN10 CN13 DM1 / DM2 FDC1 FN1 / FN2 / FN3 IDE1 / IDE2 IR1 KB1 LN1A / LN1B LPT1 MS1 PC1 PC2 PW1 PW2 USB1 VGA1 WOL1 Page 25 25 16 22 22 22 20 22 22 23 16 25 20 10 15 20 13 17 22 19 18 22 26 26 20 20 19 12 18 9 3.5 Configuring the CPU The HS-7001 offers the convenience in CPU installation with its auto-detect feature. After installing a new microprocessor onboard, the HS-7001 automatically identifies the frequency and clock speed of the installed microprocessor chip, thereby eliminating the need for user to do additional CPU configuration or hardware settings related to it. JP1: Clock Speed Select Setting 1-2 Short (default) 2-3 Short Empty Description CPU Auto Detect 100MHz 133MHz 3.6 System Memory The HS-7001 provides two DDR sockets at locations DM1 and DM2. The maximum capacity of the onboard memory is 2GB. While using 533MHz FSB CPU, it could support DDR-333, but using 400MHz FSB CPU, it only could support DDR-266. 3.7 DiskOnChip Address Setting The DiskOnChip function allows the system to boot or operate without a FDD or a HDD. DiskOnChip modules may be formatted as drive C or A. With DiskOnChip, user may also execute DOS commands such as FORMAT, SYS, COPY, XCOPY, DISCOPY and DISKCOMP etc. The DiskOnChip module socket is location on U15 on the HS-7001. Jumper JP4 assigns the starting memory address of the installed module. If you have another memory device that has a similar memory capacity with that of the DOC in your system, please set both at different memory address mapping to avoid the mapping area conflicts. Failing to do so will not make the HS-7001 and the additional memory device function properly. JP4: DiskOnChip Address Select Address CC00H-CDFFH D000H-D1FFH (default) D400H-D5FFH D800H-D9FFH JP4 1-2, 9-10 Short 3-4, 7-8 Short 3-4, 9-10 Short 5-6, 7-8 Short 10 DC00H-DDFFH 5-6, 9-10 Short 11 3.7.1 Installing DiskOnChip Modules When installing a DiskOnChip module onto your board, please take note of the following: 1. Orient yourself properly with the location of the DiskOnChip socket. Try to locate the pin 1 location on your socket. Pin numbers are usually printed on either the component side or the solder side of your board. 2. Locate the Pin 1 location on your DiskOnChip module. More often than not, Pin 1 can be found on the lower right corner of the chip. Please refer to the diagram for the exact location. 3. Once you have figured out where the pin 1 locations are on both chip and socket, align the module’s pins on an upright angle against the socket. Using both thumbs, gently press the module into the socket until all the pins are secured to their designations. Disk On C hip Pin 1 Location 4. The installation is now complete and your module is now ready for use. NOTE: If you encounter difficulty installing your DiskOnChip module, please consult a qualified technician or engineer to perform the installation. 3.7.2 Removing DiskOnChip Modules When removing a DiskOnChip module from its socket, please take note of the following: 1. Loosen the contact of the module from its socket using a screwdriver. 2. Insert the screwdriver’s flat head into a gap on either end of the socket. Do not insert the screwdriver head on either side where the pins are located. Doing so might damage the pins in the process. 12 3. Slowly lift the screwdriver handle upwards. This will disengage the module from its socket. NOTE: If you encounter difficulty removing your DiskOnChip module, please consult a qualified technician or engineer to remove it for you. 3.8 VGA Controller The onboard Intel 82845GV with 1MB or 8MB memory supporting CRT display up to 1280 x 1024 x 32-bit. The HS-7001 provides one connection method of a VGA device. VGA1 offers a single standard CRT connector (DB15). VGA1: 15-pin CRT Connector (DB15) PIN 1 3 5 7 9 11 13 15 Description Red Blue GND GND N/C N/C HSYNC SCL PIN 2 4 6 8 10 12 14 Description Green N/C GND GND GND SDA VSYNC 6 1 11 5 10 15 13 3.9 PCI E-IDE Drive Connector IDE1 and IDE2 are standard 40-pin connector daisy-chain driver connector serves the PCI E-IDE drive provisions onboard the HS-7001. A maximum of four ATA/33/66/100 IDE drives can connect to the HS-7001 via IDE1 and IDE2. IDE1: Primary IDE Connector PIN 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 4 2 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 Description RESET PDATA 7 PDATA 6 PDATA 5 PDATA 4 PDATA 3 PDATA 2 PDATA 1 PDATA 0 GND PDREQ PIOW# PIOR# PIORDY RPDACKInterrupt PDA1PDA0PDCS1HDD Active P 6 PIN 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 Description GND PDATA 8 PDATA 9 PDATA 10 PDATA 11 PDATA 12 PDATA 13 PDATA 14 PDATA 15 N/C GND GND GND PR1PD1GND N/C PATA66 PDA2RPCS3GND 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 39 14 IDE2: Secondary IDE Connector PIN 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 4 2 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 Description RESET SDATA 7 SDATA 6 SDATA 5 SDATA 4 SDATA 3 SDATA 2 SDATA 1 SDATA 0 GND SDREQ SIOW# SIOR# SIORDY SDDACKInterrupt SDA1SDA0SDCS1HDD Active S 6 PIN 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 Description GND SDATA 8 SDATA 9 SDATA 10 SDATA 11 SDATA 12 SDATA 13 SDATA 14 SDATA 15 N/C GND GND GND PR1SD1GND N/C SATA66 SDA2SDCS3GND 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 39 15 3.10 Floppy Disk Drive Connector The HS-7001 uses a standard 34-pin header connector, FDC1, for floppy disk drive connection. A total of two FDD drives may be connected to FDC1 at any given time. FDC1: FDD Connector PIN 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 DRVDEN0 DRVDEN1 INDEX# Description GND GND GND GND GND GND GND GND GND GND GND GND GND GND N/C GND N/C MTR0# MTR1# PIN 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 Description DRVDEN0 N/C DRVDEN1 INDEX# MTR0# DS1# DS0# MTR1# DIR# STEP# WDATA# WGATE# TRAK00# WRTPRT# RDATA# HDSEL# DSKCHG# WRTPRT# WGATE# WDATA# ¡¦ DSKCHG# 34 33 N/C TRAK00# RDATA# N/C u 2 1 GND GND GND GND GND GND GND GND GND GND GND GND GND GND GND 16 HDSEL# STEP# DS1# DS0# DIR# N/C 3.11 Serial Port Connectors The HS-7001 offers two NS16C550 compatible UARTs with Read/Receive 16-byte FIFO serial ports and four internal 10-pin headers. CN11: COM1 Connector (5x2 Header) PIN Description PIN Description 1 3 5 7 9 DCD0 RXDD0 TXDD0 DTR0 GND 2 4 6 8 10 DSR0 RTS0 CTS0 RI0 N/C DCD0 1 RXDD0 3 TXDD0 DTR0 GND 5 7 9 2 DSR0 4 RTS0 6 CTS0 8 RI0 10 N/C CN12: COM2 Connector (5x2 Header) PIN Description PIN Description 1 3 5 7 9 DCD1 RXDD1 TXDD1 DTR1 GND 2 4 6 8 10 DSR1 RTS1 CTS1 RI1 N/C DCD1 1 RXDD1 3 TXDD1 DTR1 GND 5 7 9 2 DSR1 4 RTS1 6 CTS1 8 RI1 10 N/C CN8: COM3 Connector (5x2 Header) PIN Description PIN Description 1 3 5 7 9 DCD2 RXDD2 TXDD2 DTR2 GND 2 4 6 8 10 DSR2 RTS2 CTS2 RI2 N/C DCD2 1 RXDD2 3 TXDD2 DTR2 GND 5 7 9 2 DSR2 4 RTS2 6 CTS2 8 RI2 10 N/C 17 CN9: COM4 Connector (5x2 Header) PIN Description PIN Description 1 3 5 7 9 DCD3 RXDD3 TXDD3 DTR3 GND 2 4 6 8 10 DSR3 RTS3 CTS3 RI3 N/C DCD3 1 RXDD3 3 TXDD3 DTR3 GND 5 7 9 2 DSR3 4 RTS3 6 CTS3 8 RI3 10 N/C COM1: COM1 Connector (DB9) PIN 1 2 3 4 5 6 7 8 9 Description DCD0 RXDD0 TXDD0 DTR0 GND DSR0 RTS0 CTS0 RI0 GND DTR0 TXDD0 RXDD0 DCD0 5 9 RI0 CTS0 RTS0 DSR0 1 6 3.12 IrDA Connector IR1 is a 5-pin internal FIR communication connector for connection of an IrDA device. IR1: IrDA Connector PIN 1 2 3 4 5 Description VCC N/C IRRX GND IRTX VCC N/C IRRX GND IRTX 1 2 3 4 5 18 3.13 Parallel Connector LPT1 is a standard 26-pin flat cable connector deigned to accommodate parallel port connection onboard the HS-7001. LPT1: Parallel Connector PIN 1 2 3 4 5 6 7 8 9 10 11 12 13 Auto Form Feed Description PIN Strobe DATA 0 DATA 1 DATA 2 DATA 3 DATA 4 DATA 5 DATA 6 DATA 7 Acknowledge Busy Paper Empty Printer Select Printer Select LN# Description Auto Form Feed ERROR# Initialize Printer Select LN# GND GND GND GND GND GND GND GND N/C 14 15 16 17 18 19 20 21 22 23 24 25 26 ERROR# Initialize GND GND GND GND GND GND GND GND Paper Empty N/C 26 13 Printer Select 14 1 PDD0 PDD1 PDD2 PDD3 PDD4 PDD5 PDD6 Strobe PDD7 Acknowledge Busy 3.14 Ethernet Connector The HS-7001 provides one 10/100 and one 100/1000 OR two 10/100 Base-TX LAN interface connector. Please refer to the following for its pin information. 19 LN1A and LN1B: Dual RJ-45 Connector PIN Description PIN Description 1 3 5 7 9 11 13 15 TX+ RX+ R/C GND R/C GND TTX+B RRX+B TTX+C RRX+C 2 4 6 8 10 12 14 16 TXR/C GND RXR/C GND TTX-B RRX-B TTX-C RRX-C 2 TXR/C GND RXR/C GND 8 9 10 TTX-B RRX-B TTX-C RRX-C 16 Giga LAN 15 TTX+B RRX+B TTX+C RRX+C 7 1 TX+ RX+ R/C GND R/C GND WOL1: Wake On LAN Connector PIN 1 2 3 Description PME GND VCC5SBY 1 3 3.15 USB Connector The HS-7001 provides one 8-pin USB2.0 connectors, at locations USB1, for two USB connections to the HS-7001. USB1: USB2.0 Connector PIN Description PIN Description 1 3 5 7 VCC USBP0N USBP0P GND 2 4 6 8 VCC USBP1N USBP1P GND VCC USBP0N USBP0P GND 7 8 1 2 VCC USBP1N USBP1P GND 3.16 CMOS Data Clear The HS-7001 has a Clear CMOS jumper on JP2. JP2: Clear CMOS Options Normal Operation Clear CMOS Settings Short 1-2 Short 2-3 20 IMPORTANT: Before you turn on the power of your system, please set JP2 to short 1-2 for normal operation. 3.17 Power and Fan Connectors HS-7001 provides one 4-pin and one 20-pin ATX power connectors at PW1 and PW2. HS-7001 must using P4 power supply. One of 4-pin connector is for +12V lead which should connect to PW1. 20-pin ATX Power Connector can connect to Backplane or to PW2. If 20-pin ATX Power Connector connects to Backplane, please make sure CN13 and Backplane’s 5-pin ATX controller is connected together! PW1: 4-pin ATX Power Connector PIN Description PIN Description 1 3 GND 12V 2 4 GND 12V GND +12V 3 4 1 2 GND +12V PW2: 20-pin ATX Power Connector PIN Description PIN Description 1 2 3 4 5 6 7 8 9 10 3.3V 3.3V GND +5V GND +5V GND N/C 5Vsb +12V 11 12 13 14 15 16 17 18 19 20 3.3V -12V GND PS_ON GND GND GND -5V +5V +5V 3.3V 3.3V GND +5V GND +5V GND N/C 5VSB +12V 10 20 1 11 3.3V -12V GND PS_ON GND GND GND -5V +5V +5V CN4: 2-pin ATX Power On/Off Switch PIN 1 2 Description Pull 220Ω to VCC5SBY ATX On/Off 1 2 21 CN13: 5-pin ATX Power Control (Connector to BOSER’s HPCI or HPP serial backplane) PIN Description PIN Description 1 3 5 GND N/C +5V 2 4 PS_ON VCC5SBY 1 5 Connector FN1, FN2 and FN3 onboard HS-7001 are 3-pin chassis, CPU, System fan connector. FN1: Chassis Fan Connector PIN 1 2 3 Description GND +12V Chassis Fan Speed 3 Chassis Fan Speed +5V GND 1 FN2: CPU Fan Connector PIN 1 2 3 Description GND +12V CPU Fan Speed 3 CPU Fan Speed +5V GND 1 FN3: System Fan Connector PIN 1 2 3 Description GND +12V System Fan Speed 3 System Fan Speed +5V GND 1 22 3.18 Keyboard Connectors The HS-7001 offers two possibilities for keyboard connections. The connections are via KB1 for an external PS/2 type keyboard or via CN6 for an internal 5-pin cable converter to an AT keyboard. CN6: 5-pin Keyboard Connector PIN 1 2 3 4 5 Description Keyboard Clock Keyboard Data N/C GND +5V 1 2 3 4 5 Keyboard Clock Keyboard Data GND N/C KB1: PS/2 6-pin Mini DIN Keyboard Connector PIN 1 2 3 4 5 6 Description Keyboard Data N/C GND +5V Keyboard Clock N/C Keyboard Clock 5 3 GND 1 Data 2 N/C 4 +5V Keyboard 6 N/C 3.19 PS/2 Mouse Connector MS1 is a 6-pin Mini DIN connector for connections to an external PS/2 mouse connector. MS1: PS/2 6-pin Mini DIN Mouse Connector PIN 1 2 3 4 5 6 Description Mouse Data N/C GND +5V Mouse Clock N/C MS Clock 5 3 GND 1 MS Data 2 N/C 4 +5V 6 N/C 3.20 System Front Panel Connectors The HS-7001 has one LED at location CN3 that indicates the power-on status. This visual feature of the IDE LED may also be connected to an external IDE LED via connector CN3. +5V 23 CN3: IDE LED Connector PIN 1 2 Description 150Ω Pull +5V HDD Active # CN5 and CN2 are the Keylock and Reset Button connectors onboard. The CN1 is Green function LED indicates. CN1: Green LED Connector PIN 1 2 Description 150Ω Pull +5V Suspend LED CN5: Keylock Connector PIN 1 2 3 4 5 Description +5V N/C GND Keylock GND CN2: Reset Button Connector PIN 1 2 Description GND Reset 1 2 3.21 External Speaker Aside from the buzzer at location BZ1 onboard, the HS-7001 also offers a connector (CN7) for an external speaker connection. The table below lists the pin assignments of CN7. CN7: Speaker Connector PIN 1 2 3 4 Description +5V GND GND Speaker 24 Reset GND 3.22 Watchdog Timer Once the Enable cycle is active, a Refresh cycle is requested before the time-out period. This restarts counting of the WDT period. When the time counting goes over the period preset of WDT, it will assume that the program operation is abnormal. A System Reset signal to re-start when such error happens. The following sample programs show how to Enable, Disable and Refresh the Watchdog Timer: ;---------------------------------------------------------------------------------; Enter the WDT function mode, interruptible double-write ;---------------------------------------------------------------------------------MOV DX, 2EH MOV AL, 87H OUT DX, AL OUT DX, AL MOV DX, 2EH MOV AL, 07H OUT DX, AL MOV DX, 2FH MOV AL, 08H OUT DX, AL MOV DX, 2EH MOV AL, F5H OUT DX, AL ; select CRF0 MOV DX, 2FH MOV AL, 80H OUT DX, AL MOV DX, 2EH MOV AL, F7H OUT DX, AL MOV DX, 2FH MOV AL, 00H OUT DX, AL MOV DX, 2EH MOV AL, F6H OUT DX, AL MOV DX, 2FH MOV AL, 00H ; * 00H=Disabled OUT DX, AL ;--------------------------------------------------------------------------------; Exit extended function mode ;------------- ------------------------------------------------------------------MOV DX, 2EH MOV AL, AAH OUT DX, AL User can also use AL, 00H’s defined time for reset purposes, e.g.00H for Disable, 01H = 1sec, 02H = 2sec…..FFH = 255sec. 25 3.23 Audio Connectors The HS-7001 has an onboard AC97 3D audio interface. The following tables list the pin assignments of the CD-ROM Analog Input, the Line_ In analog Input and the MIC In/Line Out connectors. CD1: CD-ROM Analog Input Connector PIN 1 2 3 4 Description CD_R CD_GND CD_GND CD_L 1 2 3 4 CD2: Line In Analog Input Connector PIN 1 2 3 4 Description LINE_IN_R GND GND LINE_IN_L 1 2 3 4 CN10: Mic In/Line Out Connector PIN 1 3 5 7 Description AOUT_L GND MIC GND PIN 2 4 6 8 Description AOUT_R GND N/C GND 2 1 8 7 26 3.24 PC/104 Connectors The PC/104 expansion bus offers provisions to connect all types of PC/104 modules. With the PC/104 bus being known as the new generation of industrial embedded 16-bit PC standard bus, thousands of PC/104 modules from multiple venders can be easily installed onboard. The detailed pin assignment of the PC/104 expansion bus connectors PC1 and PC2 are listed on the following tables: NOTE： The PC/104 connector allows direct plugging or stack-through piling of PC/104 modules without requiring the PC/104 mounting kit. PC2: PC/104 40-pin Connector PIN 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Description PIN Description GND MEMCS16* IOSC16* IRQ10 IRQ11 IRQ12 IRQ15 IRQ14 DACK0* DRQ0 DACK5* DRQ5 DACK6* DRQ6 DACK7* DRQ7 +5V MASTER* GND GND 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 GND SBHE* LA23 LA22 LA21 LA20 LA19 LA18 LA17 MEMR* MEMW* SD8 SD9 SD10 SD11 SD12 SD13 SD14 SD15 GND Connector diagram rotated 90 degrees clockwise from original position 1 21 20 40 27 PC1: 64-pin PC/104 Expansion Slot PIN 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 Description PIN Description IOCHECK* SD7 SD6 SD5 SD4 SD3 SD2 SD1 SD0 IOCHRDY AEN SA19 SA18 SA17 SA16 SA15 SA14 SA13 SA12 SA11 SA10 SA9 SA8 SA7 SA6 SA5 SA4 SA3 SA2 SA1 SA0 GND 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 GND RESETDRV +5V IRQ9 -5V DRQ2 -12V 0WS* +12V GND SMEMW* SMEMR* IOW* IOR* DACK3* DRQ3 DACK1* DRQ1 REFRESH* SYSCLK IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 DACK2* TC BALE +5V OSC N/C GND Connector diagram rotated 90 degrees clockwise from original position 1 33 32 64 28 This page is intentionally left blank. 29 Chapter 4 Award BIOS Setup The HS-7001 uses Award BIOS for the system configuration. The Award BIOS setup program is designed to provide the maximum flexibility in configuring the system by offering various options that could be selected for end-user requirements. This chapter is written to assist you in the proper usage of these features. 4.1 Starting Setup The Award BIOS is immediately activated when you first power on the computer. The BIOS reads the system information contained in the CMOS and begins the process of checking out the system and configuring it. When it finishes, the BIOS will seek an operating system on one of the disks and then launch and turn control over to the operating system. While the BIOS is in control, the Setup program can be activated in one of two ways: 1. By pressing immediately after switching the system on, or 2. By pressing the key when the following message appears briefly at the bottom of the screen during the POST (Power On Self Test). Press DEL to enter SETUP. If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" button on the system case. You may also restart by simultaneously pressing , , and keys. If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to... PRESS F1 TO CONTINUE, DEL TO ENTER SETUP 30 4.2 Using Setup In general, you use the arrow keys to highlight items, press to select, use the and keys to change entries, press for help and press to quit. The following table provides more detail about how to navigate in the Setup program using the keyboard. Up arrow Down arrow Left arrow Right arrow Esc key Move to previous item Move to next item Move to the item in the left hand Move to the item in the right hand Main Menu -- Quit and not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -Exit current page and return to Main Menu Increase the numeric value or make changes Decrease the numeric value or make changes Increase the numeric value or make changes Decrease the numeric value or make changes General help, only for Status Page Setup Menu and Option Page Setup Menu Change color from total 16 colors. F2 to select color forward, (Shift) F2 to select color backward Calendar, only for Status Page Setup Menu Reserved Restore the previous CMOS value from CMOS, only for Option Page Setup Menu Load the default CMOS value from BIOS default table, only for Option Page Setup Menu Load the default Reserved Reserved Save all the CMOS changes, only for Main Menu PgUp key PgDn key + key - key F1 key (Shift)F2 key F3 key F4 key F5 key F6 key F7 key F8 key F9 key F10 key 4.2.1 Getting Help Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window press or the F1 key again. 31 4.3 Main Menu Once you enter the Award BIOS CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and two exit choices. Use the arrow keys to select among the items and press to enter the sub-menu. CMOS Setup Utility – Copyright © 1984-2001 Award Software Standard CMOS Features Advanced BIOS Features Advanced Chipset Features Integrated Peripherals Power Management Setup PnP/PCI Configurations PC Health Status Frequency/Voltage Control Load Fail-Safe Defaults Load Optimized Defaults Set Supervisor Password Set User Password Save & Exit Setup Exit Without Saving Esc：Quit F10：Save & Exit Setup F9：Menu in BIOS ：Select Item NOTE: A brief description of the highlighted choice appears at the bottom of the screen. 32 4.4 Standard CMOS Features The Standard Setup is used for the basic hardware system configuration. The main function is for Data/Time and Floppy/Hard Disk Drive settings. Please refer to the following screen for the setup. When the IDE hard disk drive you are using is larger than 528MB, you must set the HDD mode to LBA mode. Please use the IDE Setup Utility in BIOS SETUP to install the HDD correctly. CMOS Setup Utility – Copyright © 1984-2001 Award Software Standard CMOS Features Date (mm:dd:yy) Time (hh:mm:ss) IDE Primary Master IDE Primary Slave IDE Secondary Master IDE Secondary Slave Drive A Drive B Video Halt On Base Memory Extended Memory Total Memory Wed, Jul 11 2001 10 : 32 :57 [None] [None] [None] [None] [1.44M, 3.5in.] [None] [EGA/VGA] [All, But Keyboard] 640K 252928K 253952K Item Help Menu Level Change the day, month, year and century : Select Item + / - /PU/PD: Value F10: Save ESC: Quit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 33 4.5 Advanced BIOS Features This section allows you to configure your system for the basic operation. You have the opportunity to select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. CMOS Setup Utility－Copyright ©1984-2001 Award Software Advanced BIOS Features Virus Warning CPU L1 & L2 Cache Quick Power On Self Test First Boot Device Second Boot Device Third Boot Device Boot Other Device Swap Floppy Drive Boot Up Floppy Seek Boot Up Num Lock Status Gate A20 Option Typematic Rate Setting Typematic Rate (Chars/Sec) Typematic Delay (Msec) Security Option APIC Mode MPS Version Control For OS OS Select For DRAM > 64MB Report on FDD for WIN95 Small Logo (EPA) Show Disabled Enabled Enabled Floppy HDD-0 LS120 Enabled Disabled Enabled On Fast Disabled 6 250 Setup Enabled 1.4 Non-OS2 NO Enabled Item Help Menu Level Change the day, month, year and century : Select Item + / - /PU/PD: Value F10: Save ESC: Quit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 34 4.6 Advanced Chipset Features This section allows you to configure the system based on the specific features of the installed chipset. This chipset manages bus speeds and the access to the system memory resources, such as DRAM and the external cache. It also coordinates the communications between the conventional ISA and PCI buses. It must be stated that these items should never be altered. The default settings have been chosen because they provide the best operating conditions for your system. You might consider and make any changes only if you discover that the data has been lost while using your system. CMOS Setup Utility－Copyright ©1984-2001 Award Software Advanced Chipset Features DRAM Timing Selectable CAS Latency Time Active to Precharge Delay DRAM RAS# to CAS# Delay DRAM RAS# Precharge Memory Frequency For System BIOS Cacheable Video BIOS Cacheable Memory Hole At 15M-16M Delayed Transaction Delay Prior to Thermal AGP Aperture Size (MB) ** ON-chip VGA Setting ** On-chip VGA On-chip Frame Buffer size Boot Display By SPD 2.5 7 3 3 Auto Enabled Enabled Disabled Enabled 16Min 64 Enabled 8MB Auto Item Help Menu Level Change the day, month, year and century : Select Item + / - /PU/PD: Value F10: Save ESC: Quit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 35 4.7 Integrated Peripherals The IDE hard drive controllers can support up to two separate hard drives. These drives have a master/slave relationship that is determined by the cabling configuration used to attach them to the controller. Your system supports two IDE controllers--a primary and a secondary--so you can install up to four separate hard disks. PIO means Programmed Input/Output. Rather than having the BIOS issue a series of commands to affect the transfer to or from the disk drive, PIO allows the BIOS to tell the controller what it wants and then let the controller and the CPU perform the complete task by them. This is much simpler and more efficient (also faster). CMOS Setup Utility－Copyright ©1984-2001 Award Software Integrated Peripherals On-chip Primary PCI IDE IDE Primary Master PIO IDE Primary Slave PIO IDE Primary Master UDMA IDE Primary Slave UDMA On-chip Secondary PCI IDE IDE Secondary Master PIO IDE Secondary Slave PIO IDE Secondary Master UDMA IDE Secondary Slave UDMA USB Controller USB2.0 Controller USB Keyboard Support USB Mouse Support AC97 Audio Init Display First IDE HDD Block Mode POWER ON Function KB Power ON Password Hot Key Power ON Onboard FDC Controller Onboard Serial Port1 Onboard Serial Port2 UART Mode Select RxD, TxD Active IR Transmission delay UR2 Duplex Mode Use IR Pins Onboard Parallel Port Parallel Port Mode EPP Mode Select ECP Mode Use DMA POWER After PWR-Rail Onboard Serial Port 3 Serial Port 3 Use IRQ Onboard Serial Port 4 Serial Port 4 Use IRQ : Select Item F5: Previous Values + / - /PU/PD: Value F6: Fail-Safe Defaults F10: Save Enabled Auto Auto Auto Auto Enabled Auto Auto Auto Auto 1 USB Port Enabled Disabled Disabled Auto Onboard/AGP Enabled BUTTON ONLY Enter Ctrl-F1 Enabled 3F8/IRQ4 2F8/IRQ3 Normal Hi, Lo Enabled Half IR-Rx2Tx2 378/IRQ7 SPP EPP1.7 3 Off 3E8 IRQ10 2E8 IRQ11 ESC: Quit F1: General Help F7: Optimized Defaults Item Help Menu Level Change the day, month, year and century 36 4.8 Power Management Setup The Power Management Setup allows user to configure the system for saving energy in a most effective way while operating in a manner consistent with his own style of computer use. CMOS Setup Utility－Copyright ©1984-2001 Award Software Power Management Setup ACPI function Enabled ACPI Suspend Type S1(POS) Run VGABIOS if S3 Resume Auto Power Management User Define Video off Method DPMS Video off In Suspend Yes Suspend Type Stop Grant MODEM Use IRQ N/A Suspend Mode Disabled HDD Power Down Disabled Soft-off by PWR-BTTN Instant-Off CPU THRM-throttling 50.00% Wake-up by PCI card Enabled Power On by Ring Disabled USB KB Wake-up From S3 Disabled Resume by Alarm Disabled Date(of Month) Alarm 0 Time(hh:mm:ss) Alarm 0:0:0 ** Reload Global Timer Events ** Primary IDE 0 Disabled Primary IDE 1 Disabled Secondary IDE 0 Disabled Secondary IDE 1 Disabled FDD, COM, LPT Port Disabled PCI PIRQ[A-D]# Disabled Item Help Menu Level Change the day, month, year and century : Select Item + / - /PU/PD: Value F10: Save ESC: Quit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 37 4.9 PnP/PCI Configurations This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system that allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings. CMOS Setup Utility－Copyright ©1984-2001 Award Software PnP/PCI Configurations Reset Configuration Date Resources controlled By IRQ Resources IRQ-3 Assigned to IRQ4 IRQ5 IRQ7 IRQ9 IRQ10 IRQ11 IRQ12 IRQ13 IRQ14 IRQ15 PCI/VGA Palette Snoop Disabled Auto (ESCD) Press Enter PCI Device PCI Device PCI Device PCI Device PCI Device PCI Device PCI Device PCI Device PCI Device PCI Device PCI Device Disabled Item Help Menu Level Change the day, month, year and century : Select Item + / - /PU/PD: Value F10: Save ESC: Quit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 38 4.10 PC Health Status CMOS Setup Utility－Copyright ©1984-2001 Award Software PC Health Status CPU Warning Temperature Current System Temp Current CPU Temperature Current CPU FAN Speed Current System FAN Speed Current Chassis FAN Speed Vcore +3.3V +5V +12V -12V -5V VBAT(V) 5VSB(V) Shutdown Temperature Disabled XXXX RPM XXXX RPM XXXX RPM 3.37V 5.08V 12.09V -12.19V -5.04 3.2V 5.00V Disabled Item Help Menu Level Change the day, month, year and century : Select Item + / - /PU/PD: Value F10: Save ESC: Quit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 4.11 Frequency/Voltage Control CMOS Setup Utility－Copyright ©1984-2001 Award Software Frequency/Voltage Control CPU Clock Ratio Auto Detect PCI Clk Spread Specturm Enabled Disabled Item Help Menu Level Change the day, month, year and century : Select Item + / - /PU/PD: Value F10: Save ESC: Quit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 39 4.12 Load Fail-Safe Defaults When you press on this item you will get a confirmation dialog box with a message shown below. This option allows you to load/restore the BIOS default values permanently stored in the BIOS ROM. Pressing ‘Y’ loads the BIOS default values for the most stable, minimal-performance system operations. CMOS Setup Utility－Copyright ©1984-2001 Award Software STANDARD CMOS Features Advanced BIOS Features Advanced Chipset Features Integrated Peripherals Power Management PnP/PCI Configura PC Health Status Esc : Quit F10 : Save & Exit Setup Frequency/Voltage Control Load Fail-Safe Defaults Load Optimized Defaults Set Supervisor Password word etup Load Fail-Safe Defaults (Y/N)? N Saving : Select Item Load Fail-Safe Defaults 40 4.13 Load Optimized Defaults When you press on this item you get a confirmation dialog box with a message similar to the figure below. This option allows you to load/restore the default values to your system configuration, optimizing and enabling all high performance features. Pressing ‘Y’ loads the default values that are factory settings for optimal performance system operations. CMOS Setup Utility－Copyright ©1984-2001 Award Software Standard CMOS Features Frequency/Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password word Power Management Load Optimized Defaults (Y/N)? N PnP/PCI Configura etup Saving PC Health Status Esc : Quit F10 : Save & Exit Setup Load Optimized Defaults : Select Item 41 4.14 Set Supervisor/User Password CMOS Setup Utility－Copyright ©1984-2001 Award Software Standard CMOS Features Advanced BIOS Features Advanced Chipset Features Integrated Peripherals Power Management Setup PnP/PCI Configurati Enter Password : PC Health Status Esc : Quit F10 : Save & Exit Setup Frequency/Voltage Control Load Fail-Safe Defaults Load Optimized Defaults Set Supervisor Password Set User Password t Setup ut Saving : Select Item Change / Set / Disable Password You can set either supervisor or user password, or both of then. The differences between are: supervisor password: can enter and change the options of the setup menus. user password: just can only enter but do not have the right to change the options of the setup menus. When you select this function, the following message will appear at the center of the screen to assist you in creating a password. ENTER PASSWORD: Type the password, up to eight characters in length, and press . The password typed now will clear any previously entered password from CMOS memory. You will be asked to confirm the password. Type the password again and press . You may also press to abort the selection and not enter a password. To disable a password, just press when you are prompted to enter the password. A message will confirm the password will be disabled. Once the password is disabled, the system will boot and you can enter Setup freely. 42 PASSWORD DISABLED. When a password has been enabled, you will be prompted to enter it every time you try to enter Setup. This prevents an unauthorized person from changing any part of your system configuration. Additionally, when a password is enabled, you can also require the BIOS to request a password every time your system is rebooted. This would prevent unauthorized use of your computer. You determine when the password is required within the BIOS Features Setup Menu and its Security option (see Section 3). If the Security option is set to “System”, the password will be required both at boot and at entry to Setup. If set to “Setup”, prompting only occurs when trying to enter Setup. 4.15 Save & Exit Setup Pressing on this item asks for confirmation: Pressing “Y” stores the selections made in the menus in CMOS – a special section of memory that stays on after you turn your system off. The next time you boot your computer, the BIOS configures your system according to the Setup selections stored in CMOS. After saving the values the system is restarted again. CMOS Setup Utility－Copyright ©1984-2001 Award Software Standard CMOS Features Advanced BIOS Features Advanced Chipset Features Integrated Peripherals Power Management PnP/PCI Configura PC Health Status Esc : Quit F10 : Save & Exit Setup Save Data to CMOS Frequency/Voltage Control Load Fail-Safe Defaults Load Optimized Defaults Set Supervisor Password word SAVE to CMOS and EXIT (Y/N)? N etup Saving : Select Item 43 4.16 Exit Without Saving Pressing on this item asks for confirmation: Quit without saving (Y/N)? Y This allows you to exit Setup without storing in CMOS any change. The previous selections remain in effect. This exits the Setup utility and restarts your computer. CMOS Setup Utility－Copyright ©1984-2001 Award Software Standard CMOS Features Frequency/Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password word Power Management Quit Without Saving (Y/N)? N: etup PnP/PCI Configura Saving PC Health Status Esc : Quit F10 : Save & Exit Setup Abandon all Data : Select Item 44 This Page is intentionally left blank. 45 Chapter 5 Software Utilities This chapter contains the detailed information of IDE, VGA, LAN and Audio driver installation procedures. The utility disk that came with the delivery package contains an auto-run program that invokes the installation programs for the IDE, VGA, LAN and Audio drivers. The following sections describe the installation procedures of each driver based on Win 95/98, Win 2000 and Win NT operating systems. It is recommended that you install the drivers matching the sections listed in this chapter. 5.1 1. IDE Driver Installation Insert Utility CD Disk to your CD ROM drive. The main menu will pop up as shown below. Select on the HS-7001 button to launch the installation program. 5.1.1 Installing Intel Chipset Software Utility 46 2. Click on the ICH4 Driver button to continue. 3. Immediately after clicking the IDE button in Step 1, the program launches the InstallShield Wizard that will assist you in the installation process. Click on the Next > button to proceed. 47 4. The Intel OEM Software License Agreement dialog box then appears on the screen. Choose Yes to proceed. 5. When the Readme Information dialog box pops up, just click on the Next button to proceed. 48 6. Once the Install Shield Wizard finishes updating your system, it will prompt you to restart the computer. Tick on the Yes, I want to restart my computer now followed by a click on the Finish button to reboot. Only after your computer boots will the new settings take effect. 49 5.1.2 Installing Intel Application Accelerator 1. Insert Utility CD Disk to your CD ROM drive. The main menu will pop up as shown below. Select on the HS-7001 button to launch the installation program. 2. Click on the IDE Driver button to continue. 50 3. When the dialog box below appears, make sure you close all other Windows applications then click on the Next > button to proceed. 4. The Intel OEM Software License Agreement dialog box then appears on the screen. Choose Yes to proceed. 51 5. Setup will then prompt you to specify the path where you would like the Security driver installed. Select the Next > button after you have made your path/installation choice. 6. Once the setup program finishes copying files into your system, it will prompt you to restart the computer. Tick on the Yes, I want to restart my computer now followed by a click on the Finish button to reboot. Only after your computer boots will the new settings take effect. 52 5.2 1. VGA Driver Installation 5.2.1 Win 95/98 Insert Utility CD Disk to your CD ROM drive. The main menu will pop up as shown below. Select on the HS-7001 button to launch the installation program. 2. Click on the VGA Driver button to continue. 53 3. Click on the Windows 9x button to continue. 4. When the dialog box below appears, make sure you close all other Windows applications then click on the Next > button to proceed. 5. The Intel OEM Software License Agreement dialog box then appears on the screen. Choose Yes to proceed. 54 6. Once the setup program finishes copying files into your system, it will prompt you to restart the computer. Tick on the Yes, I want to restart my computer now followed by a click on the Finish button to reboot. Only after your computer boots will the new settings take effect. NOTE: Installation procedure for Windows 98 is similar to Windows95. 55 5.2.2 Win NT NOTE: 1. Please make sure you have already install Service Pack 6.0. Insert Utility CD Disk to your CD ROM drive. The main menu will pop up as shown below. Select on the HS-7001 button to launch the installation program. 2. Click on the VGA Driver button to continue. 56 3. Click on the Windows NT button to continue. 4. When the dialog box below appears, make sure you close all other Windows applications then click on the Next > button to proceed. 57 5. The Intel OEM Software License Agreement dialog box then appears on the screen. Choose Yes to proceed. 6. Once the setup program finishes copying files into your system, it will prompt you to restart the computer. Tick on the Yes, I want to restart my computer now followed by a click on the Finish button to reboot. Only after your computer boots will the new settings take effect. 58 5.2.3 Win 2000 1. Insert Utility CD Disk to your CD ROM drive. The main menu will pop up as shown below. Select on the HS-7001 button to launch the installation program. 2. Click on the VGA Driver button to continue. 59 3. Click on the Windows 2K button to continue. 4. When the dialog box below appears, make sure you close all other Windows applications then click on the Next > button to proceed. 60 5. The Intel OEM Software License Agreement dialog box then appears on the screen. Choose Yes to proceed. 6. Once the setup program finishes copying files into your system, it will prompt you to restart the computer. Tick on the Yes, I want to restart my computer now followed by a click on the Finish button to reboot. Only after your computer boots will the new settings take effect. 61 5.3 1. LAN Driver Installation 5.3.1 Win 95/98 Insert Utility CD Disk to your CD ROM drive. The main menu will pop up as shown below. Select on the HS-7001 button to launch the installation program. 2. Click on the LAN Driver button to continue. 62 3. Click on the Windows 9x button to continue. 4. When the dialog box below appears, make sure you close all other Windows applications then click on the Next > button to proceed. 63 5. The Intel OEM Software License Agreement dialog box then appears on the screen. Choose Accept to proceed. 6. The Setup Type dialog box then appears on the screen. Choose Typical to proceed. 64 7. When the dialog box below appears, make sure you close all other Windows applications then click on the Install button to proceed. 8. When the dialog box below appears, it means your driver is install completed. Click Finish button to proceed. 65 9. Once the setup program finishes copying files into your system, it will prompt you to restart the computer. Tick on the Yes to reboot. Only after your computer boots will the new settings take effect. 5.3.2 Win NT NOTE: 1. Please make sure you have already install Service Pack 6.0. The system automatically detects the absence of Windows NT Networking. Click on the Yes button to start installation. 2. Tick on the Wired to Network once the following screen appears. Click on the Next to proceed. 66 3. Click on the Start Search button for the program to locate the Network Adapter. 4. Once setup finishes the search, it will list a number of adapters for you to choose from. Press on the Have Disk button to assign the driver path location. 67 5. Setup now asks you for the location of the driver. When you have entered the new driver path, press on the OK button to continue. 6. When Setup finds the information it needs about the new driver, it will display the device it found on the following screen. If using 82551 or 82562, please choose “Intel(R) PRO/100 Family Adapter”. If using 82540EM, please choose “Intel(R) PRO/1000 Family Adapter”. Press on the OK button to accept and proceed. 68 7. Setup then returns to Network Setup Wizard screen and displays your new Network Adapter. Click on Next to continue. 8. The Network Setup Wizard then allows you to set the Network Protocols on your network. Select the appropriate protocol and then click on Next to continue. 69 9. Before Setup starts installing the components found and the settings you made, it will give you the option to proceed or go back for changes from the following screen. Click on the Next button once you are sure of your devices. 10. Windows NT Setup will then need to copy files necessary to update the system information. Specify the path then press Continue. 11. When Setup asks if you wish to change the TCP/IP settings of your system, select the appropriately. The default choice is No. 70 12. Setup then starts the Networking installation and copies the files. 13. When the screen below appears, click on Next to continue. 14. Setup then prompts you that it is ready to start the network. You may complete the installation thereafter. Click on Next to continue. 71 15. Assign the workgroup or domain setting of your computer. Click on Next to continue. 16. Click on the Yes button to restart your computer. The LAN1 driver installation for WIN NT4.0 is now complete. 72 17. With the Utility CD Disk still in your CD ROM drive, we can install LAN2. Right click on “Network Neighborhood” icon from the desktop. Select on Properties and then proceed to the Network from the main menu. Click on Add to continue. 18. Setup then returns to Network Setup Wizard screen and displays your new Network Adapter. Click on OK to continue. 73 19. Click on the Close button. The LAN2 driver installation for WIN NT4.0 is now complete. 5.4 1. Audio Driver Installation Insert Utility CD Disk to your CD ROM drive. The main menu will pop up as shown below. Select on the HS-7001 button to launch the installation program. 74 2. Click on the AUDIO Driver button to continue. 3. When the dialog box below appears, make sure you close all other Windows applications then click on the Next > button to proceed. 4. Once the InstallShield Wizard completes the operation and update of your AC’97 driver, it will ask you to remove disks from their drives, and prompt you to restart your system. Tick on the Yes, I want to restart my computer now. Afterwards, click on the Finish button to complete the installation process. The system changes you made will take effect after the system restarts. 75 5.5 1. USB2.0 Driver Installation 5.5.1 Win 95/98 With the Utility CD Disk still in your CD ROM drive, right click on “My Computer” icon from the Windows menu. Select on System Properties and then proceed to the Device Manager from the main menu. 76 2. Select on Other Devices from the list of devices then double-click on PCI Universal Serial Bus. 3. The PCI Universal Serial Bus Properties screen then appears, allowing you to re-install the driver. Select Driver from the main menu to proceed. 77 4. When the dialog box below appears, make sure you close all other Windows applications then click on the Next > button to proceed. 5. Tick on the “Search for a better driver” once the following screen appears. Click on the Next to proceed. 78 6. Once the program returns to the Add New Hardware Wizard screen, your specified location will appear. Press on the Next button to continue 7. When Setup finds the information it needs about the new driver, it will display the device it found on the following screen. Press on the Next button to accept and proceed. 79 8. Once the InstallShield Wizard completes the operation and update of your USB2.0 driver. Click on the Finish button to complete the installation process. 5.4.2 Win 2000 1. With the Utility CD Disk still in your CD ROM drive, right click on “My Computer” icon from the Windows menu. Select on System Properties and then proceed to the Device Manager from the main menu. Select on Other Devices from the list of devices then double-click on PCI Universal Serial Bus. 2. 80 3. The PCI Universal Serial Bus Properties screen then appears, allowing you to re-install the driver. Select Driver from the main menu to proceed. 4. When the dialog box below appears, make sure you close all other Windows applications then click on the Next > button to proceed. 81 5. Tick on the “Search for a suitable driver” once the following screen appears. Click on the Next to proceed. 6. Once the program returns to the Add New Hardware Wizard screen, your specified location will appear. Press on the Next button to continue 82 7. Choose sisusb2.inf and press on the Open button to accept and proceed. 8. Once the InstallShield Wizard completes the operation and update of your USB2.0 driver. Click on the Finish button to complete the installation process. 83 5.4.3 Win XP 1. Insert Utility CD Disk to your CD ROM drive. The main menu will pop up as shown below. Select on the HS-7001 button to launch the installation program. 2. Click on the USB2.0 Driver button to continue. 84 3. Click on the Windows XP button to continue. 4. When the dialog box below appears, make sure you close all other Windows applications then click on the Next > button to proceed. 85 5. Once the InstallShield Wizard completes the operation and update of your USB2.0 driver. Click on the Finish button to complete the installation process. 86
