TS100-06

10 BASE-T, SMD ETHERNET TRANSFORMER P/N: TS100-06 DATA SHEET A.GENERAL SPECIFICATIONS: 1.IEEE 802.3 (10 BASE5/10BASE 2) AND ECMA COMPATIBLE. 2.16 PIN SOL LIKE PACKAGE 3.TURN RATIO 1:1+-5% 4.DISSIPATION RATING 75 mW 5.HI-POT 2000Vrms 6.INSULATION RESISTANCE 10000M MIN. @50 Vdc 7.PEAK PULSE RATING 50VOLTS B.ELECTRICAL SPECIFICATIONS @25°C: 1.OCL (OPEN CIRCUIT INDUCTANCE) 100uH ±20% @100KHz, 50mVrms 2.(OTHER OCL ALSO AVAILABLE UPON REQUEST) 3.ET CONSEANT 1.5V.uS MIN 4.RISE TIME 1.8 ns MAX 5.COUPLING CAPACITANCE (Cw/w) 10 pF MAX 6.LEAKAGE INDUCTANCE (LL) 0.1uH MAX. 7.DC REISITANCE 0.2 OHM C. SCHEMATICS & DIMENSIONS & MARKING (Unit m/m) Date: April 21-2000 Pre by: WuQingli Rev.: X.0
