BD-E505RD

BRIGHT LED ELECTRONICS CORP. SINCE 1981 BD-E505RD ● 1. 2. 3. 4. 5. 6. 7. Features : 0.50 inch (12.70mm) Digit Height. Continuous uniform segments. Low power requirement. Excellent characters appearance. Solid state reliability. Categorized for luminous intensity. Duplex drive common anode. ● Package Dimensions : 10 7.10(.280) 12.70(.500) 19.00(.748) 15.24(.600) 25.00(.984) 1.5(.059) 1.00(.039) MARK ● 1. Description : The BD-E505RD is a 12.7mm(0.50") high dual digit seven segments display. 0.50(.020) xxxxx 8.00(.315) 4.3±0.5(.169±020) 2.54(.100) 2. This product use bright red chips, which are made from GaP on GaP substrate. 3. 4. This product have a black face and white segments. This product doesn't contain restriction substance, comply ROHS standard. Notes: 1. All dimensions are in millimeters(inches). 2. Tolerance is ±0.25mm(.01")unless otherwise specified. 3. Specifications are subject to change without notice. ● Internal Circuit Diagram : E 佰鴻工業股份有限公司 http://www.brtled.com D1 A D2 10 5 D1. D2. F B G A B C D E F G DP A B C D E F G DP C D + PIN 1. DP1 DP2 7 6 4 1 3 8 9 2 Ver.2.0 Page 1 of 3 BRIGHT LED ELECTRONICS CORP. SINCE 1981 BD-E505RD ● Absolute Maximum Ratings(Ta=25℃) Parameter Power Dissipation Per Segment Forward Current Per Segment Peak Forward Current Per Segment Reverse Voltage Per Segment Operating Temperature Storage Temperature Soldering Temperature (1/16" From Body) Symbol Pd IF IFP (Duty 1/10, 1KHZ) VR Topr Tstg Tsol Rating 40 15 50 5 -40℃~80℃ -40℃~85℃ 260℃ For 5 Seconds Unit mW mA mA V - ● Electrical And Optical Characteristics(Ta=25℃) Parameter Forward Voltage Per Segment Luminous Intensity Per Segment Reverse Current Per Segment Peak Wave Length Symbol Condition Vf Iv IR IF=10mA IF=10mA VR=5V Min. - Typ. 2.1 1.6 - Max. 2.5 100 - Unit V mcd µA nm nm nm Dominant Wave Length Spectral Line Half-width 佰鴻工業股份有限公司 http://www.brtled.com λp IF=10mA 700 λd IF=10mA 650 100 ∆λ IF=10mA Ver.2.0 Page 2 of 3 BRIGHT LED ELECTRONICS CORP. SINCE 1981 BD-E505RD ● Typical Electro-Optical Characteristics Curves (25℃ Ambient Temperature Unless Otherwise Noted) Fig.1 Relative Radiant Intensity VS. Wavelength 1.0 Relative Radiant Intensity 0.5 0 550 600 650 700 750 800 850 Wavelength(nm) Fig.3 Relative Luminous Intensity VS. Ambient Temperature Relative Luminous Intensity (@20mA) 1 2 3 4 5 50 Fig.2 Forward Current VS. Forward Voltage 3.0 2.5 2.0 1.5 1.0 0.5 Forward Current (mA) 40 30 20 10 0 Forward Voltage (V) Fig.4 Relative Luminous Intensity VS. Forward Current 0 -40 Ambient Temperature Ta( C) Fig.5 Forward Current Derating Curve VS. Ambient Temperature -20 0 20 40 60 Relative Luminous Intensity (@20mA) 2.0 25 20 15 1.5 1.0 0.5 0 佰鴻工業股份有限公司 http://www.brtled.com 10 5 0 10 20 30 40 50 20 40 60 80 Forward Current(mA) 100 120 Forward Current(mA) Ambient Temperature Ta( C) Ver.2.0 Page 3 of 3
