2A-01N

BTCPower BTCPower 2A-N Series Features • • • • • 24-Pin DIP Package Pi Input Filter Unregulated Outputs Low Ripple and Noise 70% Efficiency Model Number Input Voltage Output Voltage TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 1.0 To 1.5W DC-DC Converters Output Current Input Current No Load Full Load Case 2A-01N 2A-02N 2A-03N 2A-04N 2A-05N 5VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC 220 mA 125 mA 100 mA ±62 mA ±50 mA 115 mA 115MA 115mA 115 mA 115 mA 330 mA 420 mA 420 mA 420 mA 420 mA A A A A A 2A-11N 2A-12N 2A-13N 2A-14N 2A-15N 12VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC 220 mA 125 mA 100 mA ±62 mA ±50 mA 45 mA 45 mA 45 mA 45 mA 45 mA 120 mA 165 mA 165 mA 165 mA 165 mA A A A A A Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840•www.btcpower.com •Email: sales@btcpower.com DS LP 2A-N Rev2 16-1-04 2A-N Series Specifications Input Specifications: 1.0 To 1.5W DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………….…………………...……………..10% Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy…………….. ………………………….+/- 3.0 % max. General Specifications : Efficiency………………………………………………..……..60%~80% Isolation Capacitance………………………………………..…….30pF Isolation Resistance…………………………………………..100Mohm Switching Frequency………………………………….…..20 KHz, min. Operating Temperature Range…………………………-25ºC ~ +71ºC Case Temperature………………………………………….100 ºC max. Cooling……………………………………………….Free air convection Storage Temperature Range……………………..…..-40 ºC ~ +100ºC Isolation Voltage………………………….………………..500VDC min. Suffix “H” Models……………………………………...……3K VDC min. Dimensions………….……1.25” x 0.8” x 0.4 “(31.8 x 20.3 x 10.2 mm) Case Material……………………..Non-Conductive Black Plastic Suffix “M” Models(Material)…………..Black Coated Copper with Non-conducted base Ripple & Noise, 20 MHz BW………………….….… 100 mV p-p max. Temperature Coeffcient………………………… +/- 0.02 % / ºC max. Short Circuit Protection………………………………..……Momentary Line Regulation² ……………………….………….……..+/- 1.2 % max. Load Regulation³, EC2A01N…………. …………….….+/- 8.0 % max. All other models…………………………………………..+/- 6.0 % max. Outline Information and Pin-out PIN CONNECTION PIN 1 24 2 23 3 22 10 11 12 13 14 15 500VDC Single Dual Output Output +V input NC NC -V output +V output -V input -V input +V output -V output +V input Common Common +V output -V input -V input +V output Common PIN 1 2,3 10 11 12 13 14 15 16 17 3K VDC Single Output +V input -V input NP -V output +V output NP NP NP +TP * TP---Test Point * Go---Ground Dual Output +V input -V input Go output -TP -V output NP +V output +TP NP -V output 22, 23, 24 * NP---No Pin * NC---No connection with pin Note: 1. 2. 3. 15uF 35V, Tantalum capacitor acorss each output. Line regulation is per 1.0% change in input voltage Load regulation is for load change from 100% to 20% All dimensions are in inches [mm] All pins sizes are dia. 0.02” [0.508mm] and 0.14”[0.35mm] length The information and specifications contained in this brief are believed to be accurate and reliable at the time of publication. Specifications are subject to change wihout notice. Refer to product specification sheet for performance characteristics and application guidelines. t Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840•www.btcpower.com •Email: sales@btcpower.com DS LP 2A-N Rev2 16-1-04
