2A-33

BTCPower BTCPower 2A Series Features • • • • • 24-Pin DIP Package Regulated Outputs 50% Efficiency Pi Input Filter Low Ripple and Noise Model Number 2A-01 2A-02 2A-03 2A-04 2A-05 2A-11 2A-12 2A-13 2A-14 2A-15 2A-21 2A-22 2A-23 2A-24 2A-25 2A-31 2A-32 2A-33 2A-34 2A-35 2A-41 2A-42 2A-43 2A-44 2A-45 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 1.5W DC-DC Converters Output Current 300 mA 125 mA 100 mA ±60 mA ±50 mA 300 mA 125 mA 100 mA ±60 mA ±50 mA 300 mA 125 mA 100 mA ±60 mA ±50 mA 300 mA 125 mA 100 mA ±60 mA ±50 mA 300 mA 125 mA 100 mA ±60 mA ±50 mA Input Current No Load Full Load 620 mA 550 mA 550 mA 550 mA 550 mA 260 mA 215 mA 215 mA 215 mA 215 mA 130 mA 115 mA 115 mA 115 mA 115 mA 110 mA 100 mA 100 mA 100 mA 100 mA 65 60 60 60 60 mA mA mA mA mA % Efficiency Case 5VDC 110 mA 50 50 50 50 50 53 53 54 54 54 55 55 56 56 56 56 56 56 56 56 60 60 62 62 62 A A A A A A A A A A A A A A A A A A A A A A A A A 12VDC 40 mA 24VDC 20 mA 28VDC 20 mA 48VDC 15 mA N ote: Nominal Input Voltage 12, 24, 28 or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 2A Rev2 16-1-04 2A Series Specifications Input Specifications: 1.5W DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………….…………………...……………..10% Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy…………….. ………………………….+/- 4.0 % max. Efficiency………………………………………………..……...……50% Isolation Capacitance………………………………………..…….30pF Isolation Resistance…………………………………………..100Mohm Switching Frequency………………………………….…..20 KHz, min. Operating Temperature Range…………………………-25ºC ~ +71ºC Case Temperature…………………………………………...95 ºC max. Cooling…………………………………………….…Free air convection Storage Temperature Range……………………..…..-40 ºC ~ +100ºC Isolation Voltage………………………….………………..500VDC min. Suffix “H” Models……………………………………...……3K VDC min. Dimensions………….……1.25” x 0.8” x 0.4 “(31.8 x 20.3 x 10.2 mm) Case Material…………………………..Non-Conductive Black Plastic Suffix “M” Models(Material)…………..…..Black Coated Copper with Non-conducted base Ripple & Noise, 20 MHz BW……………………….… 50 mV p-p max. Temperature Coeffcient………………………… +/- 0.02 % / ºC max. Short Circuit Protection………………………………..……Momentary Line Regulation ¹ Single / Dual Output………….……..+/- 0.3 % max. Load Regulation ² Single / Dual Output…………….….+/- 0.5 % max. General Specifications : Outline Information and Pin-out PIN CONNECTION PIN 1 24 2 23 3 22 10 11 12 13 14 15 500VDC Single Dual Output Output +V input NC NC -V output +V output -V input -V input +V output -V output +V input Common Common +V output -V input -V input +V output Common PIN 1 2,3 10 11 12 13 14 15 16 17 3K VDC Single Output +V input -V input NP -V output +V output NP NP NP +TP * TP---Test Point * Go---Ground Dual Output +V input -V input Go output -TP -V output NP +V output +TP NP -V output 22, 23, 24 * NP---No Pin * NC---No connection with pin Note: All dimensions are in inches [mm] All pins sizes are dia. 0.02” [0.508mm] and 0.14”[0.35mm] length The information and specifications contained in this brief are believed to be accurate and reliable at the time of publication. Specifications are subject to change without notice. Refer to product specification sheet for performance characteristics and application guidelines. Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 2A Rev2 16-1-04
