2C-14

BTCPower BTCPower 2C Series Features • • • • • • High performance Regulated Outputs 60% Efficiency Pi Input Filter Low Ripple and Noise 500 VDC Isolation Input Voltage Output Voltage 5 VDC 12 VDC 5 VDC 15 VDC ±12 VDC ±15 VDC 5 VDC 12 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC 5 VDC 12 VDC 24 VDC 15 VDC ±12 VDC ±15 VDC 5 VDC 12 VDC 28 VDC 15 VDC ±12 VDC ±15 VDC 5 VDC 12 VDC 48 VDC 15 VDC ±12 VDC ±15 VDC TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 5-6W DC-DC Converters Model Number 2C-01 2C-02 2C-03 2C-04 2C-05 2C-11 2C-12 2C-13 2C-14 2C-15 2C-21 2C-22 2C-23 2C-24 2C-25 2C-31 2C-32 2C-33 2C-34 2C-35 2C-41 2C-42 2C-43 2C-44 2C-45 Output Current 1 000 mA 4 70 mA 4 00 mA ± 230 mA ± 190 mA 1 000 mA 470 mA 400 mA ± 230 mA ± 190 mA 1 000 mA 4 70 mA 4 00 mA ± 230 mA ±190 mA 1000 mA 470 mA 400 mA ± 230 mA ±190 mA 1000 mA 470 mA 400 mA ± 230 mA ±190 mA Input Current No Load Full Load 6 0 mA 7 0 mA 7 0 mA 1 30 mA 140 mA 4 0 mA 4 0 mA 4 0 mA 6 0 mA 6 0 mA 2 0 mA 2 0 mA 2 0 mA 3 5 mA 3 5 mA 2 0 mA 2 0 mA 20 mA 2 5 mA 2 5 mA 1 4 mA 1 4 mA 1 4 mA 2 0 mA 2 0 mA 1700 mA 1750 mA 1800 mA 1700 mA 1700 mA 690 mA 700 mA 750 mA 710 mA 710 mA 350 mA 340 mA 360 mA 360 mA 3 60 mA 2 90 mA 3 00 mA 3 10 mA 2 90 mA 2 90 mA 1 70 mA 1 70 mA 1 80 mA 1 70 mA 1 70 mA Case Alt Pin Out C S C S C S C S C S Note: Alternative pin-out version. To order, suffix an “S” to the standard model number. Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 2C Rev2 16-1-04 2C Series Specifications Input Specifications: 5-6W DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………….…………………...…………+/- 10% Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy…………….. ………………………….+/- 1.0 % max. Voltage Balance ( Dual )………………………………...+/- 0.5 % max. Ripple & Noise, 20 MHz BW Single Output…………………………….… 50 mV p-p max. Dual Output………………………………….35mV p-p max. Temperature Coeffcient Single Output ………………………. +/- 0.02 % / ºC max. Dual Output ………………………… +/- 0.01 % / ºC max. Short Circuit Protection………………………………..…..…Short term Line Regulation …………………..………….………...+/- 0.02 % max. Load Regulation ……………………..…………….….+/- 0.05 % max. General Specifications : Efficiency………………………………………………..……...……60% Isolation Capacitance………………………………………..…….80pF Isolation Voltage…………………………………………...500VDC min. Isolation Resistance………………………………………….100Mohm Switching Frequency………………………………….…..20 KHz, min. Operating Temperature Range…………………………-25ºC ~ +71ºC Case Temperature (plastic case)………….……………….95 ºC max. (copper case)….…….………………100 ºC max. Cooling……………………………………………….Free air convection Storage Temperature Range……………………..…..-40 ºC ~ +100ºC Isolation Voltage………………………….………………..500VDC min. EMI / RFI…………………………………..Six-sided continuous shield Dimensions………….…………2” x 2” x 0.4 “(50.8 x 50.8 x 10.2 mm) Case Material (Standard Models)…….Non-Conductive Black Plastic (Suffix “M” Models)……….……..Black Coated Copper with Non-conducted base Outline Information and Pin-out Standrad Pin Configuration Alternative Pin Configuration Suffix “S” * NP---No Pin Input Voltage 60% FL 80% FL 100% FL The information and specifications contained in this brief are believed to be accurate and reliable at the time of publication. Specifications are subject to change without notice. Refer to product specification sheet for performance characteristics and application guidelines. 5V 12V 24V 28V 48V 4.4-6.5V 4.5V-6.0V 10.56-15.6V 10.8V-14.4V 21.12V-31.2V 21.6V-28.8V 24.64V-36.4V 25.2V-33.6V 42.24-62.4V 43.2-57.6V 4.65-5.5V 11.16V-13.2V 22.32V-26.4V 26.04V-30.8V 44.64-52.8V All Dimensions in Inches(mm) Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 2C Rev2 16-1-04
