3BB-12

BTCPower BTCPower 3BB Series Features • • • • • • • TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 7.5W DC-DC Converters 7.5W Isolated Output Remote On/Off option 82% Efficiency 2:1 Input Range Regulated Outputs Continuous Short Circuit Protection Conductive EMI Meet EN55022 Class B Model Number 3BB-01 3BB-02 3BB-03 3BB-04 3BB-05 3BB-06 3BB-07 3BB-11 3BB-12 3BB-13 3BB-14 3BB-15 3BB-16 3BB-17 3BB-21 3BB-22 3BB-23 3BB-24 3BB-25 3BB-26 3BB-27 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 3.3 VDC Output Current 1500 mA 625 mA 500 mA ±310 mA ±250 mA ±750 mA 1500 mA 1500 mA 625 mA 500 mA ±310 mA ± 250 mA ± 750 mA 1 500mA 1 500 mA 6 25 mA 5 00 mA ± 310 mA ± 250 mA ± 750 mA 1 500 mA • Pi Input Filter Input Current No Load Full Load 7.5 mA 7.5 mA 7.5 mA 12 mA 12 mA 7.5 mA 7.5 mA 5 mA 5 mA 5 mA 7.5 mA 7 .5 mA 7 .5 mA 5 mA 2 2 2 3 3 3 3 mA mA mA mA mA mA mA 820 mA 780 mA 780 mA 775 mA 780 mA 820 mA 557 mA 400 mA 380 mA 380 mA 385 mA 3 85 mA 4 00 mA 2 71 mA 2 00 mA 1 92 mA 1 92 mA 1 92 mA 1 92 mA 2 00 mA 1 36 mA % Efficiency Case 9-18 VDC 76 80 80 80 80 76 74 78 82 82 81 81 78 76 78 81 81 81 81 78 76 B 18-36 VDC B 36-72VDC B Note: Nominal Input Voltage 12, 24, 28 or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 3BB Rev2 16-1-04 3BB Series Specifications Input Specifications: 7.5W DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………….………12V………………...…9-18V 24V…………………..18-36V 48V……………………36-72V Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy…………….. ………………………….+/- 2.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. Ripple & Noise, 20 MHz BW………3.3V / 5V……. 100 mV p-p max. 12V / 15V……….…1 % p-p max. Temperature Coeffcient………………………… +/- 0.05 % / ºC max. Short Circuit Protection………………………………..……Continuous Line Regulation ¹ Single / Dual Output………….……..+/- 0.5 % max. Load Regulation Single² …………………………….….+/- 0.5 % max. Dual³……………………….………+/- 1.0 % max. General Specifications : Efficiency………………………………………………..……...see table Isolation Resistance………………………………………….100Mohm Switching Frequency……………………………...….…..100 KHz, min. Operating Temperature Range…………………………-25ºC ~ +71ºC Case Temperature………………………………………….100 ºC max. Cooling …………………………………..………….Free air convection Storage Temperature Range……………………..…..-40 ºC ~ +100ºC Isolation Voltage………………………….……………....1500VDC min. Dimensions……………….……2” x 1” x 0.4“ (50.8 x 25.4 x 10.2 mm) Case Material…….Black Coated Copper with Non-conducted base Note: 1. 2. 3. 4. Measured from high line to low line Measured from full load to 10% load Measured from full load to ¼ load Suffix “T” to the Model Number with Remote On/Off Outline Information and Pin-out PIN CONNECTION Pin 1 2 3 4 5 6 Function + Input - Input + Output Common / NP - Output NP (Remote control) * NP---No Pin Remote On/Off Control Logic compatibility Ec-0n Ec-Off Shutdown Idle current Input resistance Control common CMOS or Open collector TTL >5.5 Vdc or open circuit
