BTCPower BTCPower 4AB Series Features • • • • • • • • • TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 5W-6W Wide Input DC-DC Converters 5W-6W Isolated Output 24-Pin DIP Package Efficiency to 82% 2:1 Input Range Regulated Outputs Pi Input Filter Continuous Short Circuit Protection Conductive EMI meet EN55022 Class B Remote On/Off option Model Number 4AB-01 4AB-02 4AB-03 4AB-04 4AB-05 4AB-06 4AB-07 4AB-11 4AB-12 4AB-13 4AB-14 4AB-15 4AB-16 4AB-17 4AB-21 4AB-22 4AB-23 4AB-24 4AB-25 4AB-26 4AB-27 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 3.3 VDC Output Current 1000 mA 470 mA 400 mA ±230 mA ±190 mA ±500 mA 1000 mA 1000 mA 470 mA 400 mA ±230 mA ±190 mA ±500 mA 1000 mA 1000 mA 470 mA 400 mA ±230 mA ±190 mA ±500 mA 1000 mA Input Current No Load Full Load 7.5 mA 7.5mA 7.5mA 12 mA 12 mA 12mA 7.5 mA 5mA 5mA 5mA 7.5mA 7.5mA 7.5 mA 5mA 2mA 2mA 2mA 3mA 3mA 3 mA 2mA 545 mA 585 mA 625 mA 575 mA 590 mA 545 mA 405 mA 265 mA 285 mA 305 mA 285 mA 2 95 mA 2 65 mA 1 95 mA 133 mA 145 mA 154 mA 142 mA 1 47 mA 2 65 mA 9 8 mA % Efficiency Case 9-18VDC 76 80 80 80 80 76 68 78 82 82 81 81 78 70 78 81 81 81 81 78 70 A 18-36VDC A 18-36VDC A Note: Nominal Input Voltage 12, 24 or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com• Email: sales@btcpower.com DS LP 4AB Rev2 16-1-04 4AB Series Specifications Input Specifications: 5W-6W Wide Input DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………….…………….12V…………...………………..9-18V 24V……………………………18-36V 48V……………………………36-72V Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy………………………………….……..+/- 2.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. Ripple & Noise, 20 MHz BW…………3.3V / 5V….. 100 mV p-p max. 12V / 15V………..1% p-p max. Temperature Coeffcient………………………… +/- 0.05 % / ºC max. Short Circuit Protection………………………………..……Continuous Line Regulation ¹ Single / Dual Output………….……..+/- 0.5 % max. Load Regulation ² Single……………….…………….….+/- 0.5 % max. Dual³……………………………….+/- 1.0 % max. General Spe cifications : Efficiency………………………………………………....……see table Isolation Resistance…………………………………………..100Mohm Switching Frequency……………………………….…..100 KHz, min. Operating Temperature Range…………………………-25ºC ~ +71ºC Case Temperature………………………………………….100 ºC max. Cooling………………………………………………Free air convection Storage Temperature Range……………………..…..-40 ºC ~ +100ºC EMI/RFI…………………….Conductive EMI meet EN55022 class B Isolation voltage………Standard models…..………….500VDC min. Suffix “H” Models…….…...……3K VDC min. Dimensions………….……1.25” x 0.8” x 0.4 “(31.8 x 20.3 x 10.2 mm) Case Material…………………….……..Non-Conductive Black Plastic Suffix “M” Models(Material)…………..Black Coated Copper with Non-conducted base Outline Information and Pin-out 500VDC PIN 1 2 3 5 9 10 11 12 13 14 15 16 22 23 24 Single Output +V input NC NC NP NP -V output +V output -V input -V input +V output -V output NP NC NC +V input PIN CONNECTION 1.5K & 3K VDC Dual Output +V input -V output Common NP NP Common +V output -V input -V input +V output Common NP Common -V output +V input PIN 1 2 3 5 9 10 11 12 13 14 15 16 22 23 24 Single Dual Output Output NP NP -V input -V input -V input -V input NP (Remote control) NC Common NC NC NC -V output NP NP NP NP +V output +V output NC NC -V output Common +V input +V input +V input +V input NP NP * NP---No Pin * NC---No connection with pin All dimensions are in inches [mm] All pins sizes are dia. 0.02” [0.508mm] and 0.14”[0.35mm] length Note: 1. 2. 3. 4. 5. 6. 7. Measured from high line to low line Measured from full load to 10% load Measured from full load to ¼ load Non-conductive black plastic only Suffix “HM” 1.5KVDC instead of 3KVDC isolation Suffix “T” to the Model Number with Remote On/Off for “H” 3KDC isolation only 4AB-23HT can be used in application with up to 500Vdc working voltage Remote On/Off Control Logic compatibility Ec-0n Ec-Off Shutdown Idle current Input resistance Control common CMOS or Open collector TTL >5.5 Vdc or open circuit
