4CE-12

BTCPower BTCPower 4CE Series Features • • • • • • TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 5-6W DC-DC Converters 5-6W Isolation Output 2:1 Input Range Regulated Outputs 82% Efficiency Pi Input Filter Continuous Short Circuit Protection Model Number 4CE-01 4CE-02 4CE-03 4CE-04 4CE-05 4CE-11 4CE-12 4CE-13 4CE-14 4CE-15 4CE-21 4CE-22 4CE-23 4CE-24 4CE-25 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC Output Current 1000 mA 470 mA 400 mA ± 230 mA ± 190 mA 1000 mA 470 mA 400 mA ± 230 mA ± 190 mA 1000 mA 470 mA 400 mA ± 230 mA ± 190 mA Input Current No Load Full Load 7.5 mA 7.5 mA 7.5 mA 12 mA 12 mA 5 mA 5 mA 5 mA 7.5 mA 7.5 mA 2 mA 2 mA 2 mA 3 mA 3 mA 545 mA 585 mA 625 mA 5 75 mA 5 90 mA 2 65 mA 2 85 mA 3 05 mA 2 85 mA 2 95 mA 1 33 mA 1 43 mA 1 54 mA 1 42 mA 1 47 mA % Efficiency Case 9-18 VDC 77 80 80 80 80 78 82 82 81 81 78 81 81 81 81 C/S 18-36 VDC C/S 36-72 VDC C/S Note: Nominal Input Voltage 12, 24, or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 4CE Rev2 16-1-04 4CE Series Specifications Input Specifications: 5-6W DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………….……12V……...………………..9-18V 24V……………………..18-36V 48V……………………..36-72V Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy…………….. ……………..………… .+/- 2.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. Ripple & Noise, 20 MHz BW…………5V………..… 100 mV p-p max. 12V / 15V…………1% p-p max. Temperature Coeffcient………………………… +/- 0.05 % / ºC max. Short Circuit Protection………………..……………………Continuous Line Regulation ¹ Single / Dual Output………….……..+/- 0.5 % max. Load Regulation Single²……………… …………….….+/- 0.5 % max. Dual Output³………………….…………...….+/- 1.0 % max. General Specifications : Efficiency………………………………………………..……...see table Isolation Resistance…………………………………………..100Mohm Switching Frequency……………………………………..100 KHz, min. Operating Temperature Range…………………………-25ºC ~ +71ºC Case Temperature (plastic case)……………………….. ..95 ºC max. (copper case)…………………………100ºC max. Cooling……………………………………………….Free air convection Storage Temperature Range……………………..…..-40 ºC ~ +100ºC Isolation Voltage………………………….………………..500VDC min. Dimensions…………..…………2” x 2” x 0.4 “(50.8 x 50.8 x 10.2 mm) Case Materi………..Black Coated Copper with Non-conducted base Note: 1. 2. 3. Mesured from high line to low line Measured form full load to 10% load Measured from full load to ¼ load Outline Information and Pin-out • • NP---No Pin All dimensions are in inches [mm] The information and specifications contained in this brief are believed to be accurate and reliable at the time of publication. Specifications are subject to change without notice. Refer to product specification sheet for performance characteristics and application guidelines. Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 4CE Rev2 16-10403
