BTCPower BTCPower 4EE Series Features • • • • • • 25W Isolation output 4:1 Input Range Six-sided Shield Remote On/Off Control Efficiency To 82% 200KHz switching frequency TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 25-30W DC-DC Converters Model Number 4EE-01 4EE-02 4EE-03 4EE-04 4EE-05 4EE-06 4EE-07 4EE-08 4EE-11 4EE-12 4EE-13 4EE-14 4EE-15 4EE-16 4EE-17 4EE-18 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC 5/±12 VDC 5/±15 VDC Output Current 3000 mA 1250 mA 1000 mA ± 625mA ± 500mA 1500/±310 mA 1500/±250 mA Input Current No Load Full Load 15 mA 15 mA 15 mA 810 mA 780 mA 780 mA 7 80 mA 7 80 mA 7 80 mA 7 80 mA 7 15 mA 4 10 mA 3 90 mA 3 90 mA 3 80 mA 3 80 mA 3 80 mA 3 80 mA 3 50 mA % Efficiency Case 77 80 80 80 80 80 80 80 77 80 80 82 82 82 82 82 E E 9-36 VDC + 5/+ 12/-5 VDC 1500/310/500 mA 5 VDC 12 VDC 18-72 VDC 15 VDC ±12 VDC ±15 VDC 5/±12 VDC 5/±15 VDC 3000 mA 1250 mA 1000 mA ± 625mA ± 500mA 1500/±310 mA 1500/±250 mA 20 mA 20 mA 20 mA 20 mA 20 mA 10 mA 10 mA 10 mA 15 mA 15 mA 15 mA 15 mA 15 mA + 5/+ 12/-5 VDC 1500/310/500 mA Note: Nominal Input Voltage 12, 24, 28 or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 4EE Rev2 16-1-04 4EE Series Specifications Input Specifications: 25-30W DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………….……24V……...………………..9-36V 48V……………………..18-72V Input Filter…………………………………………………..……..Pi Type Output Specifications: Voltage Accuracy Single output………………………..…………………….+/- 1.0 % max. Daul output………………………………………………..+/- 3.0 % max. Triple, 5V………………………………………………….+/- 2.0 % max. 12V/15V…………………………………………..………+/- 3.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. External trim Adj. Range……………………………..…………+/- 10% Ripple & Noise, 20 MHz BW……………………….… 75 mV p-p max. Temperature Coeffcient………………………… +/- 0.02 % / ºC max. Short Circuit Protection………………………………..……Continuous Line Regulation ¹ Single / Dual Output………….……..+/- 0.2 % max. Triple………………………….………..+/- 1.0% max. Load Regulation ² Single / Dual Output…………….….+/- 1.0 % max. Triple………………………..…………+/- 5.0 % max. General Specifications : Efficiency………………………………………………..……..see table Isolation Resistance…………………………………………..100Mohm Switching Frequency……………………………………..200 KHz, min. Operating Temperature Range…………………………-25ºC ~ +71ºC Case Temperature………………………………………….100 ºC max. Cooling……………………………………………….Free air convection Storage Temperature Range……………………..…..-55 ºC ~ +105ºC Isolation Voltage………………………….………………..500VDC min. EMI/RFI…………………………………….....Six-sided continus shield Dimensions…………………2.65” x3” x 0.83 “(65 x 76.2 x 21.1 mm) Case Material……..Black Coated Copper with Non-conducted base Triple output loading table Ouput (pin no.) 6 3&5 3&5 3&5 Voltage (V) +5 +12 or -12 +15 or -15 +12 or -5 Amperes Min. (2) Nom. 0.25 1.5 0.1 0.31 0.1 0.25 0.1/0.1 0.31/0.5 Note: 1. measured from high lin to low line 2. measured from full load to ¼ load 3. maximum total power from all outputs is limited to 25/30W but no output should be allowed to exceed its maximum current 4. minmum current on each output is required to maintain specified regulation Outline Information and Pin-out Pin Connection Pin 1 2 3 4 5 6 7 8 Single +Input - Input No pin Trim No pin +Output - Output Dual Triple +Input +Input -Input -Input +Output +Output Common Common -Output -Output No pin +5V output No pin No pin Remote On/Off Control Remote On/Off Control Logic compatibility CMOS or Open collector TTL Ec-0n >5.5 Vdc or open circuit Ec-Off
