BTCPower BTCPower 5B Series Features • • • • • • • TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 15W DC-DC Converters 15W Isolated Output 2:1 Input Range 82% Efficiency Pi Input Filter Low Ripple And Noise Continuous Short Circuit Protection Conductive EMI Meet EN55022 Class A Model Number 5B-11 5B-12 5B-13 5B-14 5B-15 5B-16 5B-21 5B-22 5B-23 5B-24 5B-25 5B-26 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC 5 VDC 12 VDC 15 VDC ±12 VDC ±15 VDC ±5 VDC Output Current Min. Max. 150 mA 65 mA 50 mA ± 35mA ± 25mA ±75mA 150mA 65mA 50mA ± 35mA ± 25mA ± 75mA 3000 mA 1250 mA 1000 mA ± 625mA ± 500mA ±1500mA 3 000mA 1 250mA 1 000mA ± 625mA ± 500mA ±1500mA Input Current No Load Full Load 20 mA 20 mA 20 mA 30 mA 30 mA 30 mA 10 mA 10 mA 10 mA 15 mA 15 mA 15 mA 800 mA 780 mA 780 mA 7 80 mA 7 80 mA 7 80 mA 3 90 mA 3 80 mA 3 80 mA 3 80 mA 3 80 mA 3 80 mA % Efficiency Case 18-36 VDC 78 80 80 80 80 80 80 82 82 82 82 82 B 36-72 VDC B Note: Nominal Input Voltage 24, or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 5B Rev2 16-1-04 5B Series Specifications Input Specifications: 15W DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………………….24V……………..……18-36V 48V…………………..36-72V Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy……………Single output…...……….+/- 1.0 % max. Dual output………...….+/- 1.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. Transient Response Single 25% Step Load Change…………………………….
