5C-15

BTCPower BTCPower 5C Series Features • • • • • 15W Isolation Output 4:1 Input Range Six-Sided Shield Remote On/Off Control Efficiency to 82% TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 15W DC-DC Converters Model Number 5C-01 5C-02 5C-03 5C-04 5C-05 5C-06 5C-07 5C-08 5C-09 5C-11 5C-12 5C-13 5C-14 5C-15 5C-16 5C-17 5C-18 5C-19 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±5 VDC ±12 VDC ±15 VDC 5/±12 VDC 5/±15 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC ±5 VDC ±12 VDC ±15 VDC 5/±12 VDC 5/±15 VDC 3.3 VDC Output Current 3 000 mA 1 250 mA 1 000 mA ± 1500 mA ± 625 mA ± 500 mA 1500/±310 mA 1500/±250 mA 3 000 mA 3 000 mA 1 250 mA 1 000 mA ± 1500 mA ± 625 mA ± 500 mA 1500/±310 mA 1500/±250 mA 3 000 mA Input Current No Load Full Load 15 15 15 20 20 20 20 20 15 10 10 10 15 15 15 15 15 10 mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA 810 mA 780 mA 780 mA 810 mA 780 mA 780 mA 780 mA 780 mA 545 mA 410 mA 390 mA 390 mA 400 mA 380 mA 380 mA 380 mA 380 mA 270 mA % Efficiency Case 9-36 VDC 77 80 80 77 80 80 80 80 76 77 80 80 79 82 82 82 82 76 C 18-72 VDC C Note: Nominal Input Voltage 24 or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 5C Rev2 16-1-04 5C Series Specifications Input Specifications: 15W DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………….……24V……...………………..9-36V 48V……………………..18-72V Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy Single output………………………..…………………….+/- 1.0 % max. Daul + output……………………………………………..+/- 1.0 % max. Daul - output………………………………… …………..+/- 3.0 % max. Triple, 5V………………………………………………….+/- 2.0 % max. 12V/15V…………………………………………..………+/- 3.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. Transient Response Single 25% Step Load Change…………………………….
