BTCPower BTCPower 5E Series Features • • • • • • 30W Isolation output 2:1 Input Range Six-sided Shield Remote On/Off Control Efficiency To 82% 200KHz switching frequency TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 25-30W DC-DC Converters Model Number 5E-01 5E-02 5E-03 5E-04 5E-05 5E-06 5E-07 5E-08 5E-11 5E-12 5E-13 5E-14 5E-15 5E-16 5E-17 5E-18 5E-21 5E-22 5E-23 5E-24 5E-25 5E-26 5E-27 5E-28 Input Voltage Output Voltage Output Current Input Current No Load Full Load 30 30 30 35 35 35 35 30 30 30 30 30 30 30 30 30 30 15 15 20 20 20 20 20 mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA 2700 mA 3150 mA 3150 mA 3100 mA 3100 mA 3200 mA 3200 mA 2940 mA 1350 mA 1550 mA 1550 mA 1500 mA 1500 mA 1580 mA 1560 mA 1450 mA 1350 mA 770 mA 770 mA 750 mA 750 mA 790 mA 780 mA 725 mA % Efficiency Case 9-18 VDC 5 VDC 5 000 mA 12 VDC 2 500 mA 15 VDC 2 000 mA ±12 VDC ± 1250 mA ±15 VDC ± 1000 mA 5/±12 VDC 3000/±625 mA 5/±15 VDC 3000/±500 mA + 5/+ 12/-5 VDC 3000/600/1000 mA 5 VDC 5 000 mA 12 VDC 2 500 mA 15 VDC 2 000 mA ±12 VDC ± 1250 mA ±15 VDC ± 1000 mA 5/±12 VDC 3000/±625 mA 5/±15 VDC 3000/±500 mA + 5/+ 12/-5 VDC 3000/600/1000 mA 5 VDC 5 000 mA 12 VDC 2500 mA 15 VDC 2000 mA ±1250 mA ± 12 VDC ± 1000 mA ± 15 VDC 3000/±625 mA 5/± 12 VDC 3000/±500 mA 5/± 15 VDC + 5/+ 12/-5 VDC 3000/600/1000 mA 77 79 79 81 81 78 78 77 77 81 81 84 84 79 80 78 78 81 81 84 84 79 80 78 E 18-36 VDC E 36-72 VDC E Note: Nominal Input Voltage 12, 24, 28 or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 5E Rev2 16-1-04 5E Series Specifications Input Specifications: 25-30W DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………….……12V……...………………..9-18V 24V……………………..18-36V 48V…………………......36-72V Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy Single output………………………..…………………….+/- 1.0 % max. Daul output………………………………………………..+/- 3.0 % max. Triple, 5V………………………………………………….+/- 1.0 % max. 12V/15V/ -5V……………………………………..………+/- 3.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. External trim Adj. Range……………………………..…………+/- 10% Ripple & Noise, 20 MHz BW……………………….… 75 mV p-p max. Temperature Coeffcient………………………… +/- 0.02 % / ºC max. Short Circuit Protection………………………………..……Continuous Line Regulation ¹ Single / Dual Output………….……..+/- 0.2 % max. Triple………………………….………..+/- 1.0% max. Load Regulation ² Single / Dual Output…………….….+/- 1.0 % max. Triple………………………..…………+/- 5.0 % max. General Specifications : Efficiency………………………………………………..……..see table Isolation Resistance…………………………………………..100Mohm Switching Frequency……………………………………..200 KHz, min. Operating Temperature Range…………………………-25ºC ~ +71ºC Case Temperature………………………………………….100 ºC max. Cooling……………………………………………….Free air convection Storage Temperature Range……………………..…..-55 ºC ~ +105ºC Isolation Voltage………………………….………………..500VDC min. EMI/RFI…………………………………….....Six-sided continus shield Dimensions…………………2.65” x3” x 0.83 “(65 x 76.2 x 21.1 mm) Case Material……..Black Coated Copper with Non-conducted base Triple output loading table Ouput (pin no.) 6 3&5 3&5 3&5 Voltage (V) +5 +12 or -12 +15 or -15 +12 or -5 Amperes Min. (2) Nom. 0.25 1.5 0.1 0.31 0.1 0.25 0.1/0.1 0.31/0.5 Note: 1. measured from high lin to low line 2. measured from full load to ¼ load 3. maximum total power from all outputs is limited to 25/30W but no output should be allowed to exceed its maximum current 4. minmum current on each output is required to maintain specified regulation Outline Information and Pin-out Pin Connection Pin 1 2 3 4 5 6 7 8 Single +Input - Input No pin Trim No pin +Output - Output Dual Triple +Input +Input -Input -Input +Output +Output Common Common -Output -Output No pin +5V output No pin No pin Remote On/Off Control Remote On/Off Control Logic compatibility CMOS or Open collector TTL Ec-0n >5.5 Vdc or open circuit Ec-Off
