6A-01

BTCPower BTCPower 6A Series Features • • • • • • • • TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 7.5W DC-DC Converters 7.5W Isolated output 24-Pin DIP Package Regulated Outputs 83% Efficiency Pi Input Filter Low Ripple and Noise Continuous Short Circuit Protection 2:1 Input Range Model Number 6A-01 6A-02 6A-03 6A-04 6A-05 6A-06 6A-11 6A-12 6A-13 6A-14 6A-15 6A-16 6A-21 6A-22 6A-23 6A-24 6A-25 6A-26 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±5 VDC ±12 VDC ±15 VDC 5 VDC 12 VDC 15 VDC ±5 VDC ±12 VDC ±15 VDC 5 VDC 12 VDC 15 VDC ± 5 VDC ± 12 VDC ± 15 VDC Output Current 1 500 mA 6 25 mA 5 00 mA ± 750 mA ± 310 mA ± 250 mA 1 500 mA 6 25 mA 5 00 mA ± 750 mA ± 310 mA ± 250 mA 1 500 mA 625 mA 500 mA ±750 mA ± 310 mA ± 250 mA Input Current No Load Full Load 25 25 25 30 30 30 20 20 20 25 25 25 10 10 10 15 15 15 mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA mA 762 mA 762 mA 762 mA 762 mA 753 mA 753 mA 381 mA 381 mA 381 mA 381 mA 377 mA 377 mA 190 mA 190 mA 190 mA 190 mA 188 mA 188 mA % Efficiency Case 9-18 VDC 82 82 82 82 83 83 82 82 82 82 83 83 82 82 82 82 83 83 A 18-36 VDC A 36-72 VDC A Note: Nominal Input Voltage 12, 24, 28 or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 6A Rev2 16-6-04 6A Series Specifications Input Specifications: 7.5W DC-DC Converters BTCPower BTCPower TM Input Voltage Range……………….……12V…………….…..…9-18V 24V……………….…18-36V 48V…………………36-72V Input Filter………………………………………………………..Pi Type Output Specifications: Voltage Accuracy…………….. ………………………….+/- 1.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. Ripple & Noise, 20 MHz BW……………………….… 75 mV p-p max. Temperature Coeffcient………………………… +/- 0.05 % / ºC max. Short Circuit Protection………………………………..……Continuous Line Regulation ¹ Single / Dual Output………….……..+/- 0.2 % max. Load Regulation ² Single ……………..…………….….+/- 0.5 % max. Dual……………………………….+/- 1.0 % max. General Specifications : Efficiency………………………………………………..……...see table Isolation Resistance…………………………………………..100Mohm Switching Frequency………………………………….….200 KHz, min. Operating Temperature Range…………………………-25ºC ~ +71ºC Case Temperature………………………………………….100 ºC max. Cooling………………………………………………Free air convection Storage Temperature Range……………………..…..-40 ºC ~ +100ºC Isolation Voltage………………………….……………..1500VDC min. Dimensions………….……1.25” x 0.8” x 0.4 “(31.8 x 20.3 x 10.2 mm) Case material…………..Black Coated Copper with Non-conducted base Outline Information and Pin-out PIN CONCECTION Pin 1 2 3 5 9 10 11 12 13 14 15 16 22 23 24 * NP---No Pin Single NP - V input - V input NP NC NC NC NP NP +V output NC -V output +V output +V output NP Dual NP -V input -V input NP Common NC -V output NP NP +V output NC Common +V output +V output NP * NC---No connection with pin Note: 1. 2. 3. Measured from high line to low line Measured from full load to 10% load Measured from full load to ¼ load All dimensions are in inches [mm] All pins sizes are dia. 0.02” [0.508mm] and 0.14”[0.35mm] length The information and specifications contained in this brief are believed to be accurate and reliable at the time of publication. Specifications are subject to change without notice. Refer to product specification sheet for performance characteristics and application guidelines. Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 6A Rev2 16-6-04
