6C-21

BTCPower BTCPower 6C Series Features • • • • • 25W Isolation Output 2:1 Input Range Six-Sided Shield Remote On/Off Control Efficiency To 85% TM Broadband TelCom Power, Inc. Redefining “Current” Limits In Power Conversion 25 ~ 30W DC-DC Converters Model Number 6C-01 6C-02 6C-03 6C-04 6C-05 6C-06 6C-07 6C-08 6C-09 6C-11 6C-12 6C-13 6C-14 6C-15 6C-16 6C-17 6C-18 6C-19 6C-21 6C-22 6C-23 6C-24 6C-25 6C-26 6C-27 6C-28 6C-29 Input Voltage Output Voltage 5 VDC 12 VDC 15 VDC ±5 VDC ±12 VDC ±15 VDC 5/±12 VDC 5/±15 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC ±5 VDC ±12 VDC ±15 VDC 5/±12 VDC 5/±15 VDC 3.3 VDC 5 VDC 12 VDC 15 VDC ± 5 VDC ± 12 VDC ± 15 VDC 5/±12 VDC 5/±15 VDC 3.3 VDC Output Current 5 000 mA 2 500 mA 2 000 mA ± 2500 mA ± 1250 mA ± 1000 mA 3500/±310 mA 3500/±250 mA 5000 mA 5 000 mA 2 500 mA 2 000 mA ± 2500 mA ± 1250 mA ± 1000 mA 3500/±310 mA 3500/±250 mA 5000 mA 5 000 mA 2500 mA 2000 mA ±2500 mA ± 1250 mA ± 1000 mA 3500/±310 mA 3500/±250 mA 5000mA Input Current No Load Full Load 30 30 30 35 35 35 35 35 30 mA mA mA mA mA mA mA mA mA 2675 mA 3050 mA 3050 mA 2675 mA 3050 mA 3050 mA 2640 mA 2640 mA 1860 mA 1336 mA 1525 mA 1525 mA 1336 mA 1470 mA 1470 mA 1 320 mA 1 320 mA 9 20 mA 660 mA 765 mA 765 mA 660 mA 735 mA 735 mA 655 mA 655 mA 460 mA % Efficiency Case 9-18 VDC 78 82 82 78 82 82 79 79 74 79 82 82 79 85 85 80 80 75 79 82 82 79 85 85 80 80 75 C 18-36 VDC 3 0 mA 3 0 mA 3 0 mA 3 0 mA 3 0 mA 3 0 mA 30 mA 3 0 mA 3 0 mA 20 20 20 25 25 25 25 25 20 mA mA mA mA mA mA mA mA mA C 36-72 VDC C Note: Nominal Input Voltage 12, 24 or 48VDC Broadband TelCom Power, Inc. – 1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A. Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com DS LP 6C Rev2 16-1-04 6C Series Specifications Input Specifications: 25-30W DC-DC Converters BTCPower BTCPower TM Input Voltage Range…………….……12V……...………………..9-18V 24V……………………..18-36V 48V…………………......36-72V Input Filter………………………………………… ……………..Pi Type Output Specifications: Voltage Accuracy Single output………………………..…………………….+/- 2.0 % max. Daul + output……………………………………………..+/- 2.0 % max. Daul - output……………………………………………..+/- 3.0 % max. Triple, 5V………………………………………………….+/- 2.0 % max. 12V/15V…………………………………………..………+/- 5.0 % max. Voltage Balance ( Dual )………………………………...+/- 1.0 % max. External trim Adj. Range……………………………..…………+/- 10% Transient Response Single 25% Step Load Change…………………………….
