TS-16

TEM-STAT TEMPERATURE CONTROL DIN RAIL Ordering Information Catalog Number TS-16 Dimensions (H x W x D) 2.4” x 1.3” x 1.7” Contact Type NO/ close on rise Temperature Range 30°to 140° F Voltage Rating 250 vac • Priced, sold and packaged in quantities of one • Available June 1, 2009 BUD INDUSTRIES, INC. • 4605 E. 355th Street • P.O. Box 998 Willoughby, Ohio 44094 • (440) 946-3200 • Fax (440) 951-4015 E-MAIL: saleseast@budind.com • WEB SITE: w ww.budind.com BUD WEST • 10000 N 31st Ave. Suite D-401 • Phoenix, Arizona 85051 • (602) 870-8377 • Fax (602) 870-8477 Tradename • Tem-Stat Temperature Control Din Rail Competition and Competitive Advantages • Hammond • Rotron • Rittal • McLean • Emcor • Great Lakes Benefits and Features • UL 94V-0, light grey plastic housing • UL, CSA agency approved • Mounts to 35mm DIN rail (EN 60 715) • Connection is for 2-pole terminal for AWG 14 maximum • Sensor element is made from thermostatic bi-metal. Related Products • Cabinet Racks • Fans • Fan Trays Key Customer Contacts • Design Engineers • Installation Designers/Managers • Manufacturing Engineers Applications • Prevention of shut-downs caused by over-heating of electronic or electrical equipment in enclosures with DIN rails. Questions to Ask • Who specifies your enclosures? • Does your equipment require additional cooling? Technical Data Switching Difference (hysteresis) Max. Tolerance Service Life Switching Capacity (max. load) 12.6°F ± 7°F (7°C ± 4K) ±7.2°F (4K) 100,000 cycles 15A resistive/ 2A inductive at 120 VAC 10A resistive/ 2A inductive at 250 VAC DC 30W 20 mA (all voltages) EN 55014-1-2, EN 61000-3-2, EN 61000-3-3 2-pole terminal for AWG 14 max. 1.4 oz (40g) -4 to 176°F (-20 to 80°C) -49 to 176°F (-45 to 80°C) IP20 30 to 140°F Minimum Load EMI/EMC compliance Connection Weight Operating temperature Storage temperature Protection Type Scale on Housing BUD INDUSTRIES, INC. • 4605 E. 355th Street • P.O. Box 998 Willoughby, Ohio 44094 • (440) 946-3200 • Fax (440) 951-4015 E-MAIL: saleseast@budind.com • WEB SITE: w ww.budind.com BUD WEST • 10000 N 31st Ave. Suite D-401 • Phoenix, Arizona 85051 • (602) 870-8377 • Fax (602) 870-8477
