CSD19533Q5A
SLPS486A – DECEMBER 2013 – REVISED MAY 2014
CSD19533Q5A 100 V N-Channel NexFET™ Power MOSFET
1 Features
•
•
•
•
•
•
•
1
Product Summary
Ultra-Low Qg and Qgd
Low Thermal Resistance
Avalanche Rated
Pb-Free Terminal Plating
RoHS Compliant
Halogen Free
SON 5-mm × 6-mm Plastic Package
TA = 25°C
TYPICAL VALUE
Drain-to-Source Voltage
100
V
Qg
Gate Charge Total (10 V)
27
nC
Qgd
Gate Charge Gate to Drain
4.9
RDS(on)
Drain-to-Source On Resistance
VGS(th)
Threshold Voltage
nC
VGS = 6 V
8.7
mΩ
VGS = 10 V
7.8
mΩ
2.8
V
.
Ordering Information(1)
2 Applications
•
•
•
UNIT
VDS
Primary Side Telecom
Secondary Side Synchronous Rectifier
Motor Control
Device
Media
Qty
Package
Ship
CSD19533Q5A
13-Inch Reel
2500
CSD19533Q5AT
7-Inch Reel
250
SON 5 x 6 mm
Plastic Package
Tape and
Reel
3 Description
(1) For all available packages, see the orderable addendum at
the end of the data sheet.
This 100 V, 7.8 mΩ, SON 5 mm × 6 mm NexFET™
power MOSFET is designed to minimize losses in
power conversion applications.
TA = 25°C
Top View
S
8
1
D
Absolute Maximum Ratings
VALUE
UNIT
VDS
Drain-to-Source Voltage
100
V
VGS
Gate-to-Source Voltage
±20
V
Continuous Drain Current (Package limited)
100
Continuous Drain Current (Silicon limited),
TC = 25°C
75
ID
(1)
S
7
2
D
Continuous Drain Current, TA = 25 °C
13
Pulsed Drain Current, TA = 25 °C(2)
231
Power Dissipation(1)
3.2
Power Dissipation, TC = 25°C
96
TJ,
Tstg
Operating Junction and
Storage Temperature Range
–55 to 150
°C
EAS
Avalanche Energy, single pulse
ID = 46 A, L = 0.1 mH, RG = 25 Ω
106
mJ
IDM
PD
S
6
3
D
D
G
5
4
D
RDS(on) vs VGS
W
Gate Charge
30
10
TC = 25°C, I D = 13A
TC = 125°C, I D = 13A
27
VGS - Gate-to-Source Voltage (V)
RDS(on) - On-State Resistance (mΩ)
A
(1) Typical RθJA = 40 °C/W on a 1-inch2, 2-oz. Cu pad on a
0.06-inch thick FR4 PCB.
(2) Max RθJC = 1.3°C/W, pulse duration ≤100 μs, duty cycle ≤1%
P0093-01
24
21
18
15
12
9
6
3
0
A
0
2
4
6
8
10
12
14
16
VGS - Gate-to- Source Voltage (V)
18
20
G001
ID = 13A
VDS = 50V
9
8
7
6
5
4
3
2
1
0
0
3
6
9
12
15
18
21
Qg - Gate Charge (nC)
24
27
30
G001
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
CSD19533Q5A
SLPS486A – DECEMBER 2013 – REVISED MAY 2014
www.ti.com
Table of Contents
1
2
3
4
5
Features ..................................................................
Applications ...........................................................
Description .............................................................
Revision History.....................................................
Specifications.........................................................
1
1
1
2
3
5.1 Electrical Characteristics.......................................... 3
5.2 Thermal Information .................................................. 3
5.3 Typical MOSFET Characteristics.............................. 4
6
Device and Documentation Support.................... 7
6.1 Trademarks ............................................................... 7
6.2 Electrostatic Discharge Caution ................................ 7
6.3 Glossary .................................................................... 7
7
Mechanical, Packaging, and Orderable
Information ............................................................. 8
7.1
7.2
7.3
7.4
Q5A Package Dimensions ........................................ 9
Recommended PCB Pattern................................... 10
Recommended Stencil Opening ............................. 11
Q5A Tape and Reel Information ............................. 11
4 Revision History
Changes from Original (December 2013) to Revision A
Page
•
Added small reel order number .............................................................................................................................................. 1
•
Increased pulsed drain current to 231A ................................................................................................................................ 1
•
Added line for max power dissipation with case temperature held to 25°C .......................................................................... 1
•
Updated the pulsed drain current conditions ......................................................................................................................... 1
•
Fixed y-axis on Figure 1 to state that it is a normalized RθJC curve ...................................................................................... 4
•
Updated the safe operating area in Figure 10 ....................................................................................................................... 6
2
Submit Documentation Feedback
Copyright © 2013–2014, Texas Instruments Incorporated
Product Folder Links: CSD19533Q5A
CSD19533Q5A
www.ti.com
SLPS486A – DECEMBER 2013 – REVISED MAY 2014
5 Specifications
5.1
Electrical Characteristics
(TA = 25°C unless otherwise stated)
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
STATIC CHARACTERISTICS
BVDSS
Drain-to-Source Voltage
VGS = 0 V, ID = 250 μA
IDSS
Drain-to-Source Leakage Current
VGS = 0 V, VDS = 80 V
1
μA
IGSS
Gate-to-Source Leakage Current
VDS = 0 V, VGS = 20 V
100
nA
VGS(th)
Gate-to-Source Threshold Voltage
VDS = VGS, ID = 250 μA
RDS(on)
Drain-to-Source On Resistance
gfs
Transconductance
100
2.2
V
2.8
3.4
V
VGS = 6 V, ID = 13 A
8.7
11.1
mΩ
VGS = 10 V, ID = 13 A
7.8
9.4
mΩ
VDS = 10 V, ID = 13 A
63
S
DYNAMIC CHARACTERISTICS
Ciss
Input Capacitance
Coss
Output Capacitance
2050
2670
pF
395
514
pF
Crss
RG
Reverse Transfer Capacitance
9.6
12.5
pF
Series Gate Resistance
1.2
2.4
Ω
Qg
Gate Charge Total (10 V)
27
35
nC
Qgd
Gate Charge Gate to Drain
Qgs
Gate Charge Gate to Source
Qg(th)
Gate Charge at Vth
Qoss
Output Charge
td(on)
Turn On Delay Time
tr
Rise Time
td(off)
Turn Off Delay Time
tf
Fall Time
VGS = 0 V, VDS = 50 V, ƒ = 1 MHz
VDS = 50 V, ID = 13 A
VDS = 50 V, VGS = 0 V
VDS = 50 V, VGS = 10 V,
IDS = 13 A, RG = 0 Ω
4.9
nC
7.9
nC
5.7
nC
75
nC
6
ns
6
ns
16
ns
5
ns
DIODE CHARACTERISTICS
VSD
Diode Forward Voltage
ISD = 13 A, VGS = 0 V
0.8
1.0
V
Qrr
Reverse Recovery Charge
nC
Reverse Recovery Time
VDS= 50 V, IF = 13 A,
di/dt = 300 A/μs
163
trr
62
ns
5.2 Thermal Information
(TA = 25°C unless otherwise stated)
THERMAL METRIC
MIN
TYP
MAX
RθJC
Junction-to-Case Thermal Resistance (1)
1.3
RθJA
Junction-to-Ambient Thermal Resistance (1) (2)
50
(1)
(2)
UNIT
°C/W
RθJC is determined with the device mounted on a 1-inch2 (6.45-cm2), 2-oz. (0.071-mm thick) Cu pad on a 1.5-inches × 1.5-inches (3.81cm × 3.81-cm), 0.06-inch (1.52-mm) thick FR4 PCB. RθJC is specified by design, whereas RθJA is determined by the user’s board
design.
Device mounted on FR4 material with 1-inch2 (6.45-cm2), 2-oz. (0.071-mm thick) Cu.
Submit Documentation Feedback
Copyright © 2013–2014, Texas Instruments Incorporated
Product Folder Links: CSD19533Q5A
3
CSD19533Q5A
SLPS486A – DECEMBER 2013 – REVISED MAY 2014
GATE
www.ti.com
GATE
Source
N-Chan 5x6 QFN TTA MIN Rev3
N-Chan 5x6 QFN TTA MAX Rev3
Max RθJA = 50°C/W
when mounted on
1 inch2 (6.45 cm2) of
2-oz. (0.071-mm thick)
Cu.
Source
Max RθJA = 115°C/W
when mounted on a
minimum pad area of
2-oz. (0.071-mm thick)
Cu.
DRAIN
DRAIN
M0137-02
M0137-01
5.3 Typical MOSFET Characteristics
(TA = 25°C unless otherwise stated)
Figure 1. Transient Thermal Impedance
4
Submit Documentation Feedback
Copyright © 2013–2014, Texas Instruments Incorporated
Product Folder Links: CSD19533Q5A
CSD19533Q5A
www.ti.com
SLPS486A – DECEMBER 2013 – REVISED MAY 2014
Typical MOSFET Characteristics (continued)
(TA = 25°C unless otherwise stated)
120
180
IDS - Drain-to-Source Current (A)
IDS - Drain-to-Source Current (A)
200
160
140
120
100
80
60
VGS =10V
VGS =8V
VGS =6V
40
20
0
0
0.5
1
1.5
2
2.5
3
3.5
4
VDS - Drain-to-Source Voltage (V)
4.5
VDS = 5V
100
80
60
40
0
5
TC = 125°C
TC = 25°C
TC = −55°C
20
0
1
Figure 2. Saturation Characteristics
6
G001
Figure 3. Transfer Characteristics
Ciss = Cgd + Cgs
Coss = Cds + Cgd
Crss = Cgd
ID = 13A
VDS = 50V
9
C − Capacitance (pF)
8
7
6
5
4
3
10000
1000
100
2
10
1
0
0
3
6
9
12
15
18
21
Qg - Gate Charge (nC)
24
27
1
30
0
10
20
G001
Figure 4. Gate Charge
30
40
50
60
70
80
VDS - Drain-to-Source Voltage (V)
90
100
G001
Figure 5. Capacitance
3.4
30
ID = 250uA
3.2
RDS(on) - On-State Resistance (mΩ)
VGS(th) - Threshold Voltage (V)
5
100000
10
VGS - Gate-to-Source Voltage (V)
2
3
4
VGS - Gate-to-Source Voltage (V)
G001
3
2.8
2.6
2.4
2.2
2
1.8
1.6
−75
−25
25
75
125
TC - Case Temperature (ºC)
Figure 6. Threshold Voltage vs Temperature
175
TC = 25°C, I D = 13A
TC = 125°C, I D = 13A
27
24
21
18
15
12
9
6
3
0
0
2
G001
4
6
8
10
12
14
16
VGS - Gate-to- Source Voltage (V)
18
20
G001
Figure 7. On-State Resistance vs Gate-to-Source Voltage
Submit Documentation Feedback
Copyright © 2013–2014, Texas Instruments Incorporated
Product Folder Links: CSD19533Q5A
5
CSD19533Q5A
SLPS486A – DECEMBER 2013 – REVISED MAY 2014
www.ti.com
Typical MOSFET Characteristics (continued)
(TA = 25°C unless otherwise stated)
2
100
VGS = 6V
VGS = 10V
ISD − Source-to-Drain Current (A)
Normalized On-State Resistance
2.2
1.8
1.6
1.4
1.2
1
0.8
0.6
0.4
−75
TC = 25°C
TC = 125°C
10
1
0.1
0.01
0.001
ID = 13A
−25
25
75
125
TC - Case Temperature (ºC)
175
0.0001
0
Figure 8. Normalized On-State Resistance vs Temperature
10us
100us
1ms
10ms
DC
TC = 25ºC
TC = 125ºC
IAV - Peak Avalanche Current (A)
IDS - Drain-to-Source Current (A)
G001
100
100
10
1
Single Pulse
Max RthetaJC = 1.3ºC/W
0.1
0.1
1
Figure 9. Typical Diode Forward Voltage
5000
1000
0.2
0.4
0.6
0.8
VSD − Source-to-Drain Voltage (V)
G001
1
10
100
VDS - Drain-to-Source Voltage (V)
1000
10
0.01
0.1
TAV - Time in Avalanche (mS)
G001
Figure 10. Maximum Safe Operating Area
1
G001
Figure 11. Single Pulse Unclamped Inductive Switching
IDS - Drain- to- Source Current (A)
100
90
80
70
60
50
40
30
20
10
0
−50
−25
0
25
50
75
100 125
TC - Case Temperature (ºC)
150
175
G001
Figure 12. Maximum Drain Current vs Temperature
6
Submit Documentation Feedback
Copyright © 2013–2014, Texas Instruments Incorporated
Product Folder Links: CSD19533Q5A
CSD19533Q5A
www.ti.com
SLPS486A – DECEMBER 2013 – REVISED MAY 2014
6 Device and Documentation Support
6.1 Trademarks
NexFET is a trademark of Texas Instruments.
6.2 Electrostatic Discharge Caution
These devices have limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam
during storage or handling to prevent electrostatic damage to the MOS gates.
6.3 Glossary
SLYZ022 — TI Glossary.
This glossary lists and explains terms, acronyms and definitions.
Submit Documentation Feedback
Copyright © 2013–2014, Texas Instruments Incorporated
Product Folder Links: CSD19533Q5A
7
CSD19533Q5A
SLPS486A – DECEMBER 2013 – REVISED MAY 2014
www.ti.com
7 Mechanical, Packaging, and Orderable Information
The following pages include mechanical packaging and orderable information. This information is the most
current data available for the designated devices. This data is subject to change without notice and revision of
this document. For browser-based versions of this data sheet, refer to the left-hand navigation.
8
Submit Documentation Feedback
Copyright © 2013–2014, Texas Instruments Incorporated
Product Folder Links: CSD19533Q5A
CSD19533Q5A
www.ti.com
SLPS486A – DECEMBER 2013 – REVISED MAY 2014
2
3
4
5
4
5
6
3
6
7
2
7
1
8
1
8
7.1 Q5A Package Dimensions
DIM
MILLIMETERS
MIN
NOM
MAX
A
0.90
1.00
1.10
b
0.33
0.41
0.51
c
0.20
0.25
0.34
D1
4.80
4.90
5.00
D2
3.61
3.81
4.02
E
5.90
6.00
6.10
E1
5.70
5.75
5.80
E2
3.38
3.58
3.78
E3
3.03
3.13
3.23
e
1.17
1.27
1.37
e1
0.27
0.37
0.47
e2
0.15
0.25
0.35
H
0.41
0.56
0.71
K
1.10
–
–
L
0.51
0.61
0.71
L1
0.06
0.13
0.20
θ
0°
–
12°
Submit Documentation Feedback
Copyright © 2013–2014, Texas Instruments Incorporated
Product Folder Links: CSD19533Q5A
9
CSD19533Q5A
SLPS486A – DECEMBER 2013 – REVISED MAY 2014
www.ti.com
7.2 Recommended PCB Pattern
F1
F7
F3
8
1
F2
F11
F5
F9
5
4
F6
F8
F4
F10
M0139-01
DIM
MILLIMETERS
INCHES
MIN
MAX
MIN
MAX
F1
6.205
6.305
0.244
0.248
F2
4.46
4.56
0.176
0.18
F3
4.46
4.56
0.176
0.18
F4
0.65
0.7
0.026
0.028
F5
0.62
0.67
0.024
0.026
F6
0.63
0.68
0.025
0.027
F7
0.7
0.8
0.028
0.031
F8
0.65
0.7
0.026
0.028
F9
0.62
0.67
0.024
0.026
F10
4.9
5
0.193
0.197
F11
4.46
4.56
0.176
0.18
For recommended circuit layout for PCB designs, see application note SLPA005 – Reducing Ringing Through
PCB Layout Techniques.
10
Submit Documentation Feedback
Copyright © 2013–2014, Texas Instruments Incorporated
Product Folder Links: CSD19533Q5A
CSD19533Q5A
www.ti.com
SLPS486A – DECEMBER 2013 – REVISED MAY 2014
7.3 Recommended Stencil Opening
(0.020) 8x
0.500
(0.020)
0.500
5
4
0.500
(0.020) 8x
1.585
(0.062)
1.235
(0.049)
(0.024)
0.620
(0.170) 4.310
0.385
(0.015)
1.270 (0.050)
1
8
1.570 (0.062)
4x
0.615
(0.024)
1.105
(0.044)
3.020
(0.119)
K0
4.00 ±0.10 (See Note 1)
0.30 ±0.05
2.00 ±0.05
+0.10
–0.00
12.00 ±0.30
Ø 1.50
1.75 ±0.10
7.4 Q5A Tape and Reel Information
5.50 ±0.05
B0
R 0.30 MAX
A0
8.00 ±0.10
Ø 1.50 MIN
A0 = 6.50 ±0.10
B0 = 5.30 ±0.10
K0 = 1.40 ±0.10
R 0.30 TYP
M0138-01
Notes:
1. 10-sprocket hole-pitch cumulative tolerance ±0.2
2. Camber not to exceed 1 mm in 100 mm, noncumulative over 250 mm
3. Material: black static-dissipative polystyrene
4. All dimensions are in mm (unless otherwise specified)
5. A0 and B0 measured on a plane 0.3 mm above the bottom of the pocket
Submit Documentation Feedback
Copyright © 2013–2014, Texas Instruments Incorporated
Product Folder Links: CSD19533Q5A
11
PACKAGE OPTION ADDENDUM
www.ti.com
10-Dec-2020
PACKAGING INFORMATION
Orderable Device
Status
(1)
Package Type Package Pins Package
Drawing
Qty
Eco Plan
(2)
Lead finish/
Ball material
MSL Peak Temp
Op Temp (°C)
Device Marking
(3)
(4/5)
(6)
CSD19533Q5A
ACTIVE
VSONP
DQJ
8
2500
RoHS-Exempt
& Green
SN
Level-1-260C-UNLIM
-55 to 150
CSD19533
CSD19533Q5AT
ACTIVE
VSONP
DQJ
8
250
RoHS-Exempt
& Green
SN
Level-1-260C-UNLIM
-55 to 150
CSD19533
(1)
The marketing status values are defined as follows:
ACTIVE: Product device recommended for new designs.
LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.
NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in a new design.
PREVIEW: Device has been announced but is not in production. Samples may or may not be available.
OBSOLETE: TI has discontinued the production of the device.
(2)
RoHS: TI defines "RoHS" to mean semiconductor products that are compliant with the current EU RoHS requirements for all 10 RoHS substances, including the requirement that RoHS substance
do not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered at high temperatures, "RoHS" products are suitable for use in specified lead-free processes. TI may
reference these types of products as "Pb-Free".
RoHS Exempt: TI defines "RoHS Exempt" to mean products that contain lead but are compliant with EU RoHS pursuant to a specific EU RoHS exemption.
Green: TI defines "Green" to mean the content of Chlorine (Cl) and Bromine (Br) based flame retardants meet JS709B low halogen requirements of
