TLV320AIC23BPWR

            ! "#   #$! %$&'  Data Manual February 2004 Digital Audio Products SLWS106H Contents Section 1 2 3 Title Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2 Functional Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3 Terminal Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5 Terminal Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.1 Absolute Maximum Ratings Over Operating Free-Air Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.2 Recommended Operating Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3 Electrical Characteristics Over Recommended Operating Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3.1 ADC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3.2 DAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3.3 Analog Line Input to Line Output (Bypass) . . . . . . . . . . . . . 2.3.4 Stereo Headphone Output . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3.5 Analog Reference Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3.6 Digital I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3.7 Supply Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4 Digital-Interface Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4.1 Audio Interface (Master Mode) . . . . . . . . . . . . . . . . . . . . . . . 2.4.2 Audio Interface (Slave-Mode) . . . . . . . . . . . . . . . . . . . . . . . . 2.4.3 Three-Wire Control Interface (SDIN) . . . . . . . . . . . . . . . . . . 2.4.4 Two-Wire Control Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . How to Use the TLV320AIC23B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.1 Control Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.1.1 SPI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.1.2 2-Wire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.1.3 Register Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2 Analog Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2.1 Line Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2.2 Microphone Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2.3 Line Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2.4 Headphone Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2.5 Analog Bypass Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2.6 Sidetone Insertion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.3 Digital Audio Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.3.1 Digital Audio-Interface Modes . . . . . . . . . . . . . . . . . . . . . . . . Page 1−1 1−1 1−3 1−4 1−5 1−5 2−1 2−1 2−1 2−2 2−2 2−3 2−3 2−4 2−4 2−4 2−4 2−5 2−5 2−6 2−7 2−7 3−1 3−1 3−1 3−1 3−2 3−5 3−5 3−6 3−6 3−6 3−7 3−7 3−7 3−7 iii 3.3.2 Audio Sampling Rates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3−9 3.3.3 Digital Filter Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . 3−11 A Mechanical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A−1 iv List of Illustrations Figure 2−1 2−2 2−3 2−4 2−5 3−1 3−2 3−3 3−4 3−5 3−6 3−7 3−8 3−9 3−10 3−11 3−12 3−13 3−14 3−15 3−16 3−17 3−18 3−19 3−20 3−21 3−22 3−23 3−24 3−25 3−26 Title System-Clock Timing Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Master-Mode Timing Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Slave-Mode Timing Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Three-Wire Control Interface Timing Requirements . . . . . . . . . . . . . . . . . . Two-Wire Control Interface Timing Requirements . . . . . . . . . . . . . . . . . . . SPI Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-Wire Compatible Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Analog Line Input Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Microphone Input Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Right-Justified Mode Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Left-Justified Mode Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I2S Mode Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DSP Mode Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Digital De-Emphasis Filter Response − 44.1 kHz Sampling . . . . . . . . . . . Digital De-Emphasis Filter Response − 48 kHz Sampling . . . . . . . . . . . . ADC Digital Filter Response 0: USB Mode (Group Delay = 12 Output Samples) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ADC Digital Filter Ripple 0: USB (Group Delay = 20 Output Samples) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ADC Digital Filter Response 1: USB Mode Only . . . . . . . . . . . . . . . . . . . . ADC Digital Filter Ripple 1: USB Mode Only . . . . . . . . . . . . . . . . . . . . . . . . ADC Digital Filter Response 2: USB mode and Normal Modes (Group Delay = 3 Output Samples) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ADC Digital Filter Ripple 2: USB Mode and Normal Modes . . . . . . . . . . . ADC Digital Filter Response 3: USB Mode Only . . . . . . . . . . . . . . . . . . . . ADC Digital Filter Ripple 3: USB Mode Only . . . . . . . . . . . . . . . . . . . . . . . . DAC Digital Filter Response 0: USB Mode . . . . . . . . . . . . . . . . . . . . . . . . . DAC Digital Filter Ripple 0: USB Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . DAC Digital Filter Response 1: USB Mode Only . . . . . . . . . . . . . . . . . . . . DAC Digital Filter Ripple 1: USB Mode Only . . . . . . . . . . . . . . . . . . . . . . . . DAC Digital Filter Response 2: USB Mode and Normal Modes . . . . . . . . DAC Digital Filter Ripple 2: USB Mode and Normal Modes . . . . . . . . . . . DAC Digital Filter Response 3: USB Mode Only . . . . . . . . . . . . . . . . . . . . DAC Digital Filter Ripple 3: USB Mode Only . . . . . . . . . . . . . . . . . . . . . . . . Page 2−5 2−5 2−6 2−7 2−7 3−1 3−2 3−5 3−6 3−7 3−8 3−8 3−8 3−12 3−12 3−13 3−13 3−14 3−14 3−15 3−15 3−16 3−16 3−17 3−17 3−18 3−18 3−19 3−19 3−20 3−20 v vi 1 Introduction The TLV320AIC23B is a high-performance stereo audio codec with highly integrated analog functionality. The analog-to-digital converters (ADCs) and digital-to-analog converters (DACs) within the TLV320AIC23B use multibit sigma-delta technology with integrated oversampling digital interpolation filters. Data-transfer word lengths of 16, 20, 24, and 32 bits, with sample rates from 8 kHz to 96 kHz, are supported. The ADC sigma-delta modulator features third-order multibit architecture with up to 90-dBA signal-to-noise ratio (SNR) at audio sampling rates up to 96 kHz, enabling high-fidelity audio recording in a compact, power-saving design. The DAC sigma-delta modulator features a second-order multibit architecture with up to 100-dBA SNR at audio sampling rates up to 96 kHz, enabling high-quality digital audio-playback capability, while consuming less than 23 mW during playback only. The TLV320AIC23B is the ideal analog input/output (I/O) choice for portable digital audio-player and recorder applications, such as MP3 digital audio players. Integrated analog features consist of stereo-line inputs with an analog bypass path, a stereo headphone amplifier, with analog volume control and mute, and a complete electret-microphone-capsule biasing and buffering solution. The headphone amplifier is capable of delivering 30 mW per channel into 32 Ω. The analog bypass path allows use of the stereo-line inputs and the headphone amplifier with analog volume control, while completely bypassing the codec, thus enabling further design flexibility, such as integrated FM tuners. A microphone bias-voltage output provides a low-noise current source for electret-capsule biasing. The AIC23B has an integrated adjustable microphone amplifier (gain adjustable from 1 to 5) and a programmable gain microphone amplifier (0 dB or 20 dB). The microphone signal can be mixed with the output signals if a sidetone is required. While the TLV320AIC23B supports the industry-standard oversampling rates of 256 fs and 384 fs, unique oversampling rates of 250 fs and 272 fs are provided, which optimize interface considerations in designs using TI C54x digital signal processors (DSPs) and universal serial bus (USB) data interfaces. A single 12-MHz crystal can supply clocking to the DSP, USB, and codec. The TLV320AIC23B features an internal oscillator that, when connected to a 12-MHz external crystal, provides a system clock to the DSP and other peripherals at either 12 MHz or 6 MHz, using an internal clock buffer and selectable divider. Audio sample rates of 48 kHz and compact-disc (CD) standard 44.1 kHz are supported directly from a 12-MHz master clock with 250 fs and 272 fs oversampling rates. Low power consumption and flexible power management allow selective shutdown of codec functions, thus extending battery life in portable applications. This design solution, coupled with the industry’s smallest package, the TI proprietary MicroStar Junior using only 25 mm2 of board area, makes powerful portable stereo audio designs easily realizable in a cost-effective, space-saving total analog I/O solution: the TLV320AIC23B. 1.1 Features • High-Performance Stereo Codec − − − − − • Software Control Via TI McBSP-Compatible Multiprotocol Serial Port − − • 90-dB SNR Multibit Sigma-Delta ADC (A-weighted at 48 kHz) 100-dB SNR Multibit Sigma-Delta DAC (A-weighted at 48 kHz) 1.42 V – 3.6 V Core Digital Supply: Compatible With TI C54x DSP Core Voltages 2.7 V – 3.6 V Buffer and Analog Supply: Compatible Both TI C54x DSP Buffer Voltages 8-kHz – 96-kHz Sampling-Frequency Support 2-wire-Compatible and SPI-Compatible Serial-Port Protocols Glueless Interface to TI McBSPs Audio-Data Input/Output Via TI McBSP-Compatible Programmable Audio Interface − − − I2S-Compatible Interface Requiring Only One McBSP for both ADC and DAC Standard I2S, MSB, or LSB Justified-Data Transfers 16/20/24/32-Bit Word Lengths MicroStar Junior is a trademark of Texas Instruments. 1−1 − − − • Integrated Total Electret-Microphone Biasing and Buffering Solution − − − • Low-Noise MICBIAS pin at 3/4 AVDD for Biasing of Electret Capsules Integrated Buffer Amplifier With Tunable Fixed Gain of 1 to 5 Additional Control-Register Selectable Buffer Gain of 0 dB or 20 dB Stereo-Line Inputs − − Integrated Programmable Gain Amplifier Analog Bypass Path of Codec • ADC Multiplexed Input for Stereo-Line Inputs and Microphone • Stereo-Line Outputs − Analog Stereo Mixer for DAC and Analog Bypass Path • Volume Control With Mute on Input and Output • Highly Efficient Linear Headphone Amplifier − • • 23-mW Power Consumption During Playback Mode Standby Power Consumption 0.5465 fs −60 dB −3 dB, fs = 44.1 kHz fs = 48 kHz 3.7 Hz 4.0 Hz −0.5 dB, fs = 44.1 kHz −0.5 dB, fs = 48 kHz 10.4 Hz 11.3 Hz −0.1 dB 21.6 Hz 23.5 Hz ADC High-Pass Filter Characteristics −3 dB, Corner frequency fs = 44.1 kHz −0.1 dB, fs = 48 kHz DAC Filter Characteristics (48-kHz Sampling Rate) Passband ±0.03 dB Stopband −6 dB 0.416 fs Hz 0.5 fs ±0.03 Passband ripple Stopband attenuation Hz f > 0.584 fs −50 dB dB DAC Filter Characteristics (44.1-kHz Sampling Rate) Passband ±0.03 dB Stopband −6 dB 0.4535 fs Hz 0.5 fs ±0.03 Passband ripple Stopband attenuation Hz f > 0.5465 fs −50 dB dB 3−11 FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY 0 Filter Response − dB −2 −4 −6 −8 −10 0 0.1 0.2 0.3 0.4 0.5 Normalized Audio Sampling Frequency Figure 3−9. Digital De-Emphasis Filter Response − 44.1 kHz Sampling FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY 0 Filter Response − dB −2 −4 −6 −8 −10 0 0.10 0.20 0.30 0.40 0.50 Normalized Audio Sampling Frequency Figure 3−10. Digital De-Emphasis Filter Response − 48 kHz Sampling 3−12 FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 10 −10 −30 −50 −70 −90 0 0.5 1 2 1.5 2.5 3 Normalized Audio Sampling Frequency Figure 3−11. ADC Digital Filter Response 0: USB Mode (Group Delay = 12 Output Samples) FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 0.10 0.08 0.06 0.04 0.02 0 −0.02 −0.04 −0.06 −0.08 −0.10 0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5 Normalized Audio Sampling Frequency Figure 3−12. ADC Digital Filter Ripple 0: USB (Group Delay = 20 Output Samples) 3−13 FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 10 −10 −30 −50 −70 −90 0 0.5 1 1.5 2.5 2 3 Normalized Audio Sampling Frequency Figure 3−13. ADC Digital Filter Response 1: USB Mode Only FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 0.10 0.08 0.06 0.04 0.02 0 −0.02 −0.04 −0.06 −0.08 −0.10 0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 Normalized Audio Sampling Frequency Figure 3−14. ADC Digital Filter Ripple 1: USB Mode Only 3−14 0.45 0.5 FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 10 −10 −30 −50 −70 −90 0 0.5 1 1.5 2 2.5 3 Normalized Audio Sampling Frequency Figure 3−15. ADC Digital Filter Response 2: USB mode and Normal Modes (Group Delay = 3 Output Samples) FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 0.4 0.3 0.2 0.1 0 −0.1 −0.2 −0.3 −0.4 0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5 Normalized Audio Sampling Frequency Figure 3−16. ADC Digital Filter Ripple 2: USB Mode and Normal Modes 3−15 FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 10 −10 −30 −50 −70 −90 0 0.5 1 1.5 2 2.5 3 Normalized Audio Sampling Frequency Figure 3−17. ADC Digital Filter Response 3: USB Mode Only FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 0.4 0.3 0.2 0.1 0 −0.1 −0.2 −0.3 −0.4 0 0.05 0.10 0.15 0.20 0.25 0.30 0.35 0.40 Normalized Audio Sampling Frequency Figure 3−18. ADC Digital Filter Ripple 3: USB Mode Only 3−16 0.45 0.50 FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 10 −10 −30 −50 −70 −90 0 0.5 1 1.5 2 Normalized Audio Sampling Frequency 2.5 3 Figure 3−19. DAC Digital Filter Response 0: USB Mode FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 0.10 0.08 0.06 0.04 0.02 0 −0.02 −0.04 −0.06 −0.08 −0.10 0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5 Normalized Audio Sampling Frequency Figure 3−20. DAC Digital Filter Ripple 0: USB Mode 3−17 FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 10 −10 −30 −50 −70 −90 0 0.5 1 1.5 2 2.5 3 Normalized Audio Sampling Frequency Figure 3−21. DAC Digital Filter Response 1: USB Mode Only FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 0.10 0.08 0.06 0.04 0.02 0 −0.02 −0.04 −0.06 −0.08 −0.10 0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 Normalized Audio Sampling Frequency Figure 3−22. DAC Digital Filter Ripple 1: USB Mode Only 3−18 0.45 0.5 FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 10 −10 −30 −50 −70 −90 0 0.5 1 1.5 2 2.5 3 Normalized Audio Sampling Frequency Figure 3−23. DAC Digital Filter Response 2: USB Mode and Normal Modes FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 0.4 0.3 0.2 0.1 0 −0.1 −0.2 −0.3 −0.4 0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5 Normalized Audio Sampling Frequency Figure 3−24. DAC Digital Filter Ripple 2: USB Mode and Normal Modes 3−19 FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 10 −10 −30 −50 −70 −90 0 0.5 1 1.5 2 2.5 3 Normalized Audio Sampling Frequency Figure 3−25. DAC Digital Filter Response 3: USB Mode Only FILTER RESPONSE vs NORMALIZED AUDIO SAMPLING FREQUENCY Filter Response − dB 0.4 0.3 0.2 0.1 0 −0.1 −0.2 −0.3 −0.4 0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5 Normalized Audio Sampling Frequency Figure 3−26. DAC Digital Filter Ripple 3: USB Mode Only The delay between the converter is a function of the sample rate. The group delays for the AIC23B are shown in the following table. Each delay is one LR clock (1/sample rate). Table 3−1. Group Dealys FILTER 3−20 GROUP DELAY DAC type 0 11 DAC type 1 18 DAC type 2 5 DAC type 3 5 ADC type 0 12 ADC type 1 20 ADC type 2 3 ADC type 3 6 Appendix A Mechanical Data GQE/ZQE (S-PBGA-N80) PLASTIC BALL GRID ARRAY 5,10 SQ 4,90 4,00 TYP 0,50 J 0,50 H G F E D C B A 1 0,68 0,62 2 3 4 5 6 7 8 9 1,00 MAX Seating Plane 0,35 0,25 NOTES: A. B. C. D. ∅ 0,05 M 0,21 0,11 0,08 4200461/C 10/00 All linear dimensions are in millimeters. This drawing is subject to change without notice. MicroStar Junior BGA configuration Falls within JEDEC MO-225 MicroStar Junior is a trademark of Texas Instruments. A−1 PW (R-PDSO-G**) PLASTIC SMALL-OUTLINE PACKAGE 14 PINS SHOWN 0,30 0,19 0,65 14 0,10 M 8 0,15 NOM 4,50 4,30 6,60 6,20 Gage Plane 0,25 1 7 0°−ā 8° A 0,75 0,50 Seating Plane 0,15 0,05 1,20 MAX PINS ** 0,10 8 14 16 20 24 28 A MAX 3,10 5,10 5,10 6,60 7,90 9,80 A MIN 2,90 4,90 4,90 6,40 7,70 9,60 DIM 4040064/F 01/97 NOTES: A. B. C. D. A−2 All linear dimensions are in millimeters. This drawing is subject to change without notice. Body dimensions do not include mold flash or protrusion not to exceed 0,15. Falls within JEDEC MO-153 RHD (S−PQFP−N28) PLASTIC QUAD FLATPACK 5,00 A B ÉÉÉÉÉ ÉÉÉÉÉ ÉÉÉÉÉ ÉÉÉÉÉ 5,00 28 1 PIN 1 INDEX AREA 1,00 0,80 0,20 REF C SEATING PLANE 0,08 C 3,25 SQ 3,00 PIN 1 IDENTIFIER 0,05 MAX 1 0,65 28 0,45 0,435 28 0,18 0,435 4 3,00 0,18 0,50 EXPOSED THERMAL DIE PAD D 28 0,30 0,18 0,10 M C A B 4204400/A 05/02 NOTES: A. B. C. D. All linear dimensions are in millimeters. This drawing is subject to change without notice. QFN (Quad Flatpack No−Lead) Package configuration. The Package thermal performance may be enhanced by bonding the thermal die pad to an external thermal plane. This pad is electrically and thermally connected to the backside of the die and possibly selected ground leads. E. Package complies to JEDEC MO-220. A−3 PACKAGE OPTION ADDENDUM www.ti.com 14-Oct-2022 PACKAGING INFORMATION Orderable Device Status (1) Package Type Package Pins Package Drawing Qty Eco Plan (2) Lead finish/ Ball material MSL Peak Temp Op Temp (°C) Device Marking (3) Samples (4/5) (6) TLV320AIC23BIPW ACTIVE TSSOP PW 28 50 RoHS & Green NIPDAU Level-1-260C-UNLIM -40 to 85 AIC23BI Samples TLV320AIC23BIPWG4 ACTIVE TSSOP PW 28 50 RoHS & Green NIPDAU Level-1-260C-UNLIM -40 to 85 AIC23BI Samples TLV320AIC23BIPWR ACTIVE TSSOP PW 28 2000 RoHS & Green NIPDAU Level-1-260C-UNLIM -40 to 85 AIC23BI Samples TLV320AIC23BIRHD ACTIVE VQFN RHD 28 73 RoHS & Green NIPDAU Level-2-260C-1 YEAR -40 to 85 AIC23BI Samples TLV320AIC23BIRHDR ACTIVE VQFN RHD 28 3000 RoHS & Green NIPDAU Level-2-260C-1 YEAR -40 to 85 AIC23BI Samples TLV320AIC23BPW ACTIVE TSSOP PW 28 50 RoHS & Green NIPDAU Level-1-260C-UNLIM -10 to 70 AIC23B Samples TLV320AIC23BPWG4 ACTIVE TSSOP PW 28 50 RoHS & Green NIPDAU Level-1-260C-UNLIM -10 to 70 AIC23B Samples TLV320AIC23BPWR ACTIVE TSSOP PW 28 2000 RoHS & Green NIPDAU Level-1-260C-UNLIM -10 to 70 AIC23B Samples TLV320AIC23BRHD ACTIVE VQFN RHD 28 73 RoHS & Green NIPDAU Level-2-260C-1 YEAR -10 to 70 AIC23B Samples TLV320AIC23BRHDR ACTIVE VQFN RHD 28 3000 RoHS & Green NIPDAU Level-2-260C-1 YEAR -10 to 70 AIC23B Samples TLV320AIC23IPW ACTIVE TSSOP PW 28 50 RoHS & Green NIPDAU Level-1-260C-UNLIM -40 to 85 320AIC23I Samples TLV320AIC23PW ACTIVE TSSOP PW 28 50 RoHS & Green NIPDAU Level-1-260C-UNLIM 0 to 70 320AIC23 Samples TLV320AIC23PWR ACTIVE TSSOP PW 28 2000 RoHS & Green NIPDAU Level-1-260C-UNLIM 0 to 70 320AIC23 Samples (1) The marketing status values are defined as follows: ACTIVE: Product device recommended for new designs. LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect. NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in a new design. PREVIEW: Device has been announced but is not in production. Samples may or may not be available. OBSOLETE: TI has discontinued the production of the device. (2) RoHS: TI defines "RoHS" to mean semiconductor products that are compliant with the current EU RoHS requirements for all 10 RoHS substances, including the requirement that RoHS substance do not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered at high temperatures, "RoHS" products are suitable for use in specified lead-free processes. TI may reference these types of products as "Pb-Free". RoHS Exempt: TI defines "RoHS Exempt" to mean products that contain lead but are compliant with EU RoHS pursuant to a specific EU RoHS exemption. Green: TI defines "Green" to mean the content of Chlorine (Cl) and Bromine (Br) based flame retardants meet JS709B low halogen requirements of
