TMP101NA/3K

TMP101NA/3K

  • 厂商:

    BURR-BROWN(德州仪器)

  • 封装:

    SOT23-6

  • 描述:

    SOT-23封装中具有I2C和SMBus接口并具有报警功能的温度传感器

  • 数据手册
  • 价格&库存
TMP101NA/3K 数据手册
Product Folder Sample & Buy Support & Community Tools & Software Technical Documents TMP100, TMP101 SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 TMP10x Temperature Sensor With I2C and SMBus Interface with Alert Function in SOT-23 Package 1 Features • 1 • • • • • • • 3 Description 2 Digital Output: SMBus™, Two-Wire, and I C Interface Compatibility Resolution: 9 to 12 Bits, User-Selectable Accuracy: – ±1°C (Typical) from –55°C to 125°C – ±2°C (Maximum) from –55°C to 125°C Low Quiescent Current: 45-μA, 0.1-μA Standby Wide Supply Range: 2.7 V to 5.5 V TMP100 Features Two Address Pins TMP101 Features One Address Pin and an ALERT Pin 6-Pin SOT-23 Package 2 Applications • • • • • • • • • The TMP100 and TMP101 devices are digital temperature sensors ideal for negative temperature coefficient (NTC) and positive temperature coefficient (PTC) thermistor replacement. The devices offer a typical accuracy of ±1°C without requiring calibration or external component signal conditioning. Device temperature sensors are highly linear and do not require complex calculations or look-up tables to derive the temperature. The on-chip, 12-bit ADC offers resolutions down to 0.0625°C. The devices are available in 6-Pin SOT-23 packages. The TMP100 and TMP101 devices feature SMBus, Two-Wire, and I2C interface compatibility. The TMP100 device allows up to eight devices on one bus. The TMP101 device offers an SMBus Alert function with up to three devices per bus. The TMP100 and TMP101 devices are ideal for extended temperature measurement in a variety of communication, computer, consumer, environmental, industrial, and instrumentation applications. Power-Supply Temperature Monitoring Computer Peripheral Thermal Protection Notebook Computers Cell Phones Battery Management Office Machines Thermostat Controls Environmental Monitoring and HVAC Electromechanical Device Temperature The TMP100 and TMP101 devices are specified for operation over a temperature range of −55°C to 125°C. Device Information(1) PART NUMBER PACKAGE BODY SIZE (NOM) TMP100 SOT-23 (6) 2.90 mm × 1.60 mm TMP101 SOT-23 (6) 2.90 mm × 1.60 mm (1) For all available packages, see the orderable addendum at the end of the data sheet. Simplified Schematics Temperature SCL GND ADD1 Temperature 1 2 3 Diode Temp. Sensor Control Logic 6 ∆Σ ADC Converter Serial Interface 5 OSC Config and Temp Register TMP100 4 SDA SCL ADD0 GND V+ ALERT 1 2 3 Diode Temp. Sensor Control Logic 6 ∆Σ ADC Converter Serial Interface 5 OSC Config and Temp Register 4 SDA ADD0 V+ TMP101 1 An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications, intellectual property matters and other important disclaimers. PRODUCTION DATA. TMP100, TMP101 SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 www.ti.com Table of Contents 1 2 3 4 5 6 7 Features .................................................................. Applications ........................................................... Description ............................................................. Revision History..................................................... Pin Configuration and Functions ......................... Specifications......................................................... 1 1 1 2 3 4 6.1 6.2 6.3 6.4 6.5 6.6 6.7 4 4 4 4 5 6 7 Absolute Maximum Ratings ...................................... ESD Ratings ............................................................ Recommended Operating Conditions....................... Thermal Information ................................................. Electrical Characteristics........................................... Timing Requirements ................................................ Typical Characteristics .............................................. Detailed Description .............................................. 8 7.1 Overview ................................................................... 8 7.2 Functional Block Diagram ......................................... 8 7.3 Feature Description................................................... 9 7.4 Device Functional Modes........................................ 14 7.5 Programming........................................................... 15 8 Application and Implementation ........................ 19 8.1 Application Information............................................ 19 8.2 Typical Application .................................................. 19 9 Power Supply Recommendations...................... 21 10 Layout................................................................... 21 10.1 Layout Guidelines ................................................. 21 10.2 Layout Examples................................................... 21 11 Device and Documentation Support ................. 23 11.1 11.2 11.3 11.4 Related Links ........................................................ Trademarks ........................................................... Electrostatic Discharge Caution ............................ Glossary ................................................................ 23 23 23 23 12 Mechanical, Packaging, and Orderable Information ........................................................... 23 4 Revision History Changes from Revision H (March 2015) to Revision I • Page Changed body size values in Device Information table ........................................................................................................ 1 Changes from Revision G (November 2007) to Revision H Page • Added ESD Ratings table, Feature Description section, Device Functional Modes, Application and Implementation section, Power Supply Recommendations section, Layout section, Device and Documentation Support section, and Mechanical, Packaging, and Orderable Information section. ................................................................................................ 1 • Changed specification values in Timing Requirements table ................................................................................................ 6 2 Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 TMP100, TMP101 www.ti.com SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 5 Pin Configuration and Functions DBV Package 6-Pin SOT-23 Top View 1 GND 2 ADD1 3 T100 SCL 6 SDA 5 ADD0 4 V+ 6 SDA 5 ADD0 4 V+ TMP100 DBV Package 6-Pin SOT-23 Top View 1 GND 2 ALERT 3 T101 SCL TMP101 Pin Functions PIN NAME NO. TMP100 I/O DESCRIPTION TMP101 ADD0 5 5 I Address select. Connect to GND, V+, or leave floating. ADD1 3 — I Address select. Connect to GND, V+, or leave floating. ALERT — 3 O Overtemperature alert. Open-drain output; requires a pullup resistor. GND 2 2 — Ground SCL 1 1 I Serial clock. Open-drain output; requires a pullup resistor. SDA 6 6 I/O Serial data. Open-drain output; requires a pullup resistor. V+ 4 4 I Supply voltage, 2.7 V to 5.5 V Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 3 TMP100, TMP101 SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 www.ti.com 6 Specifications 6.1 Absolute Maximum Ratings over operating free-air temperature range (unless otherwise noted) (1) MIN MAX UNIT 7.5 V Power supply, V+ Input voltage (2) Operating temperature –0.5 7.5 V –55 125 °C 150 °C 150 °C Junction temperature, TJ Storage temperature, Tstg (1) (2) –60 Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings only, which do not imply functional operation of the device at these or any other conditions beyond those indicated under Recommended Operating Conditions. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability. Input voltage rating applies to all TMP100 and TMP101 input voltages. 6.2 ESD Ratings VALUE V(ESD) (1) (2) Electrostatic discharge Human body model (HBM), per ANSI/ESDA/JEDEC JS-001 (1) ±2000 Charged device model (CDM), per JEDEC specification JESD22-C101 (2) ±200 UNIT V JEDEC document JEP155 states that 500-V HBM allows safe manufacturing with a standard ESD control process. JEDEC document JEP157 states that 250-V CDM allows safe manufacturing with a standard ESD control process. 6.3 Recommended Operating Conditions over operating free-air temperature range (unless otherwise noted) MIN NOM MAX UNIT Supply voltage 2.7 5.5 V Operating free-air temperature, TA –55 125 °C 6.4 Thermal Information TMP100, TMP101 THERMAL METRIC (1) DBV (SOT-23) UNIT 6 PINS RθJA Junction-to-ambient thermal resistance 182.9 °C/W RθJC(top) Junction-to-case (top) thermal resistance 115 °C/W RθJB Junction-to-board thermal resistance 30.2 °C/W ψJT Junction-to-top characterization parameter 17.1 °C/W ψJB Junction-to-board characterization parameter 29.7 °C/W (1) 4 For more information about traditional and new thermal metrics, see the IC Package Thermal Metrics application report, SPRA953. Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 TMP100, TMP101 www.ti.com SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 6.5 Electrical Characteristics At TA = −55°C to 125°C and V+ = 2.7 V to 5.5 V, unless otherwise noted. PARAMETER TEST CONDITIONS MIN TYP MAX UNIT 125 °C TEMPERATURE INPUT Range Accuracy (temperature error) –55 −25°C to 85°C −55°C to 125°C Accuracy (temperature error) vs supply Resolution Selectable ±0.5 ±2 ±1 ±2 0.2 ±0.5 0.0625 °C °C/V °C DIGITAL INPUT/OUTPUT Input capacitance 3 pF VIH High-level input logic 0.7 (V+) 6 V VIL Low-level input logic −0.5 0.3 (V+) V IIN Input current 0 V ≤ VIN ≤ 6 V 1 µA VOL Low-level output logic SDA IOL = 3 mA 0 0.15 0.4 V VOL Low-level output logic ALERT IOL = 4 mA 0 0.15 0.4 V Resolution Selectable 9 12 Bits Conversion time Conversion rate 9 bits 40 75 10 bits 80 150 11 bits 160 300 12 bits 320 600 9 bits 25 10 bits 12 11 bits 6 12 bits 3 ms s/s POWER SUPPLY Operating range 2.7 Serial bus inactive IQ ISD Quiescent current Shutdown current 5.5 45 Serial bus active, SCL frequency = 400 kHz 70 Serial bus active, SCL frequency = 3.4 MHz 150 Serial bus inactive 0.1 Serial bus active, SCL frequency = 400 kHz 20 Serial bus active, SCL frequency = 3.4 MHz 100 V 75 µA 13 µA TEMPERATURE RANGE Specified range –55 125 °C Storage range –60 150 °C Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 5 TMP100, TMP101 SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 www.ti.com 6.6 Timing Requirements FAST MODE PARAMETER MIN f(SCL) SCL operating frequency t(BUF) Bus free time between STOP and START condition t(HDSTA) HIGH-SPEED MODE MAX MIN 0.4 MAX 2 UNIT MHz 1300 160 ns Hold time after repeated START condition. After this period, the first clock is generated. 600 160 ns t(SUSTA) Repeated START condition setup time 600 160 ns t(SUSTO) STOP condition setup time 600 160 t(HDDAT) Data hold time 20 t(SUDAT) Data setup time 100 20 ns t(LOW) SCL clock LOW period 1300 360 ns t(HIGH) SCL clock HIGH period 600 60 tRC, tFC Clock rise and fall time 300 40 ns tRD, tFD Data rise and fall time 300 170 ns 6 Submit Documentation Feedback 900 20 ns 170 ns ns Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 TMP100, TMP101 www.ti.com SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 6.7 Typical Characteristics At TA = 25°C and V+ = 5 V, unless otherwise noted. 1 70 0.9 0.8 60 0.7 0.6 ISD (µA) I Q (µA) V+ = 5 V 50 0.5 0.4 0.3 V+ = 27 V 0.2 40 0.1 0 Serial Bus Inactive −0.1 −60 −40 −20 30 −60 −40 −20 0 20 40 60 80 100 120 140 0 Temperature (°C) 20 40 60 80 100 120 140 Temperature (°C) Figure 1. Quiescent Current vs Temperature Figure 2. Shutdown Current vs Temperature 2.0 400 350 Temperature Error (°C) Conversion Time (ms) 1.5 V+ = 5 V 300 V+ = 2.7 V 1.0 0.5 0.0 −0.5 −1.0 −1.5 NOTE: 12−bit resolution. 3 Typical Units −2.0 −60 −40 −20 0 250 −60 −40 −20 0 20 40 60 80 100 120 140 NOTE: 12−bit resolution. 20 40 60 80 100 120 140 Temperature (°C) Temperature (°C) Figure 3. Conversion Time vs Temperature Figure 4. Temperature Accuracy vs Temperature 180 160 125°C 140 25°C I Q (µA) 120 100 125°C 80 25°C −55°C 60 40 20 −55°C FAST MODE Hs MODE 0 10k 100k 1M 10M SCL Frequency (Hz) Figure 5. Quiescent Current With Bus Activity vs Temperature Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 7 TMP100, TMP101 SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 www.ti.com 7 Detailed Description 7.1 Overview The TMP100 and TMP101 devices are digital temperature sensors optimal for thermal management and thermal protection applications. The TMP100 and TMP101 devices are Two-Wire, SMBus, and I2C interface-compatible. These devices are specified over a operating temperature range of −55°C to 125°C. The Functional Block Diagram section shows the internal block diagrams of the TMP100 and TMP101 devices. The temperature sensor in the TMP100 and TMP101 devices is the chip itself. Thermal paths run through the package leads as well as the plastic package. The package leads provide the primary thermal path because of the lower thermal resistance of the metal. The GND pin of the TMP100 or TMP101 is directly connected to the metal lead frame, and is the best choice for thermal input. 7.2 Functional Block Diagram Temperature SCL GND ADD1 Temperature 1 2 3 Diode Temp. Sensor Control Logic 6 ∆Σ ADC Converter Serial Interface 5 OSC Config and Temp Register 4 SDA SCL ADD0 GND V+ ALERT 1 2 3 TMP100 8 Diode Temp. Sensor Control Logic 6 ∆Σ ADC Converter Serial Interface 5 OSC Config and Temp Register 4 SDA ADD0 V+ TMP101 Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 TMP100, TMP101 www.ti.com SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 7.3 Feature Description 7.3.1 Digital Temperature Output The digital output from each temperature measurement conversion is stored in the read-only Temperature Register. The Temperature Register of the TMP100 or TMP101 device is a 12-bit, read-only register that stores the output of the most recent conversion. Two bytes must be read to obtain data and are listed in Table 6 and Table 7. The first 12 bits are used to indicate temperature with all the remaining bits equal to zero. The data format for temperature is listed in Table 1. Negative numbers are represented in binary twos complement format. Following power-up or reset, the temperature register reads 0°C until the first conversion is complete. The user can obtain 9, 10, 11, or 12 bits of resolution by addressing the Configuration Register and setting the resolution bits accordingly. For 9-, 10-, or 11-bit resolution, the most significant bits (MSBs) in the Temperature Register are used with the unused least significant bits (LSBs) set to zero. Table 1. Temperature Data Format DIGITAL OUTPUT TEMPERATURE (°C) BINARY HEX 128 0111 1111 1111 7FF 127.9375 0111 1111 1111 7FF 100 0110 0100 0000 640 80 0101 0000 0000 500 75 0100 1011 0000 4B0 50 0011 0010 0000 320 25 0001 1001 0000 190 0.25 0000 0000 0100 004 0 0000 0000 0000 000 –0.25 1111 1111 1100 FFC –25 1110 0111 0000 E70 –55 1100 1001 0000 C90 –128 1000 0000 0000 800 7.3.2 Serial Interface The TMP100 and TMP101 devices operate only as slave devices on the SMBus, Two-Wire, and I2C interfacecompatible bus. Connections to the bus are made through the open-drain I/O lines SDA and SCL. The TMP100 and TMP101 devices support the transmission protocol for fast (up to 400 kHz) and high-speed (up to 2 MHz) modes. All data bytes are transmitted MSB first. 7.3.2.1 Bus Overview The device that initiates the transfer is called a master, and the devices controlled by the master are slaves. The bus must be controlled by a master device that generates the serial clock (SCL), controls the bus access, and generates the START and STOP conditions. To address a specific device, a START condition is initiated, indicated by pulling the data line (SDA) from a HIGH to LOW logic level while SCL is HIGH. All slaves on the bus shift in the slave address byte, with the last bit indicating whether a read or write operation is intended. During the ninth clock pulse, the slave being addressed responds to the master by generating an Acknowledge and pulling SDA LOW. Data transfer is then initiated and sent over eight clock pulses followed by an Acknowledge Bit. During data transfer, SDA must remain stable while SCL is HIGH because any change in SDA while SCL is HIGH is interpreted as a control signal. When all data are transferred, the master generates a STOP condition indicated by pulling SDA from LOW to HIGH, while SCL is HIGH. Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 9 TMP100, TMP101 SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 www.ti.com 7.3.2.2 Serial Bus Address To program the TMP100 and TMP101 devices, the master must first address slave devices through a slave address byte. The slave address byte consists of seven address bits and a direction bit indicating the intent of executing a read or write operation. The TMP100 device features two address pins to allow up to eight devices to be addressed on a single I2C interface. Table 2 describes the pin logic levels used to properly connect up to eight devices. Float indicates the pin is left unconnected. The state of pins ADD0 and ADD1 is sampled on the first I2C bus communication and must be set before any activity on the interface. Table 2. Address Pins and Slave Addresses for the TMP100 ADD1 ADD0 SLAVE ADDRESS 0 0 1001000 0 Float 1001001 0 1 1001010 1 0 1001100 1 Float 1001101 1 1 1001110 Float 0 1001011 Float 1 1001111 The TMP101 device features one address pin and an ALERT pin, allowing up to three devices to be connected per bus. Pin logic levels are described in Table 3. The address pins of the TMP100 and TMP101 devices are read after reset or in response to an I2C address acquire request. Following reading, the state of the address pins is latched to minimize power dissipation associated with detection. Table 3. Address Pins and Slave Addresses for the TMP101 ADD0 SLAVE ADDRESS 0 1001000 Float 1001001 1 1001010 7.3.2.3 Writing and Reading to the TMP100 and TMP101 Accessing a particular register on the TMP100 and TMP101 devices is accomplished by writing the appropriate value to the Pointer Register. The value for the Pointer Register is the first byte transferred after the I2C slave address byte with the R/W bit LOW. Every write operation to the TMP100 and TMP101 devices requires a value for the Pointer Register (see Figure 7). When reading from the TMP100 and TMP101 devices, the last value stored in the Pointer Register by a write operation is used to determine which register is read by a read operation. To change the register pointer for a read operation, a new value must be written to the Pointer Register. This action is accomplished by issuing an I2C slave address byte with the R/W bit LOW, followed by the Pointer Register Byte. No additional data are required. The master can then generate a START condition and send the I2C slave address byte with the R/W bit HIGH to initiate the read command; see Figure 8 for details of this sequence. If repeated reads from the same register are desired, the Pointer Register bytes do not have to be continually sent because the TMP100 and TMP101 devices remember the Pointer Register value until that value is changed by the next write operation. 10 Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 TMP100, TMP101 www.ti.com SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 7.3.2.4 Slave Mode Operations The TMP100 and TMP101 devices can operate as a slave receiver or slave transmitter. 7.3.2.4.1 Slave Receiver Mode The first byte transmitted by the master is the slave address, with the R/W bit LOW. The TMP100 or TMP101 devices then acknowledges reception of a valid address. The next byte transmitted by the master is the Pointer Register. The TMP100 or TMP101 devices then acknowledges reception of the Pointer Register byte. The next byte or bytes are written to the register addressed by the Pointer Register. The TMP100 and TMP101 devices acknowledge reception of each data byte. The master can terminate data transfer by generating a START or STOP condition. 7.3.2.4.2 Slave Transmitter Mode The first byte is transmitted by the master and is the slave address, with the R/W bit HIGH. The slave acknowledges reception of a valid slave address. The next byte is transmitted by the slave and is the most significant byte of the register indicated by the Pointer Register. The master acknowledges reception of the data byte. The next byte transmitted by the slave is the least significant byte. The master acknowledges reception of the data byte. The master can terminate data transfer by generating a Not-Acknowledge on reception of any data byte, or generating a START or STOP condition. 7.3.2.5 SMBus Alert Function The TMP101 device supports the SMBus Alert function. When the TMP101 device is operating in Interrupt Mode (TM = 1), the ALERT pin of the TMP101 device can be connected as an SMBus Alert signal. When a master senses that an ALERT condition is present on the ALERT line, the master sends an SMBus Alert command (00011001) on the bus. If the ALERT pin of the TMP101 device is active, the TMP101 device acknowledges the SMBus Alert command and responds by returning its slave address on the SDA line. The eighth bit (LSB) of the slave address byte indicates if the temperature exceeding THIGH or falling below TLOW caused the ALERT condition. For POL = 0, this bit is LOW if the temperature is greater than or equal to THIGH. This bit is HIGH if the temperature is less than TLOW. The polarity of this bit is inverted if POL = 1; see Figure 9 for details of this sequence. If multiple devices on the bus respond to the SMBus Alert command, arbitration during the slave address portion of the SMBus alert command determine which device clears its ALERT status. If the TMP101 device wins the arbitration, its ALERT pin becomes inactive at the completion of the SMBus Alert command. If the TMP101 loses the arbitration, its ALERT pin remains active. The TMP100 device also responds to the SMBus ALERT command if its TM bit is set to 1. Because the device does not have an ALERT pin, the device must periodically poll the device by issuing an SMBus Alert command. If the TMP100 device generates an ALERT, the device acknowledges the SMBus Alert command and returns its slave address in the next byte. 7.3.2.6 General Call The TMP100 and TMP101 devices respond to the I2C General Call address (0000000) if the eighth bit is 0. The device acknowledges the General Call address and responds to commands in the second byte. If the second byte is 00000100, the TMP100 and TMP101 devices latch the status of their address pins, but do not reset. If the second byte is 00000110, the TMP100 and TMP101 devices latch the status of their address pins and reset their internal registers. 7.3.2.7 High-Speed Mode In order for the I2C bus to operate at frequencies above 400 kHz, the master device must issue an Hs-mode master code (00001XXX) as the first byte after a START condition to switch the bus to high-speed operation. The TMP100 and TMP101 devices do not acknowledge this byte as required by the I2C specification, but do switch their input filters on SDA and SCL and their output filters on SDA to operate in Hs-mode, allowing transfers at up to 2 MHz. After the Hs-mode master code is issued, the master transmits an I2C slave address to initiate a data transfer operation. The bus continues to operate in Hs-mode until a STOP condition occurs on the bus. Upon receiving the STOP condition, the TMP100 and TMP101 devices switch the input and output filter back to fast-mode operation. Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 11 TMP100, TMP101 SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 www.ti.com 7.3.2.8 POR (Power-On Reset) The TMP100 and TMP101 devices both have on-chip, power-on reset circuits that reset the device to default settings when the device is powered on. This circuit activates when the power supply is less than 0.3 V for more than 100 ms. If the TMP100 and TMP101 devices are powered down by removing supply voltage from the device, but the supply voltage is not assured to be less than 0.3 V, TI recommends issuing a General Call reset command on the I2C interface bus to ensure that the TMP100 and TMP101 devices are completely reset. 7.3.3 Timing Diagrams The TMP100 and TMP101 devices are Two-Wire, SMBUs, and I2C interface-compatible. Figure 6 to Figure 9 describe the various operations on the TMP100 and TMP101. The following list provides bus definitions. Parameters for Figure 6 are defined in the Timing Requirements section. Bus Idle: Both SDA and SCL lines remain HIGH. Start Data Transfer: A change in the state of the SDA line, from HIGH to LOW, while the SCL line is HIGH, defines a START condition. Each data transfer is initiated with a START condition. Stop Data Transfer: A change in the state of the SDA line from LOW to HIGH while the SCL line is HIGH defines a STOP condition. Each data transfer is terminated with a repeated START or STOP condition. Data Transfer: The number of data bytes transferred between a START and a STOP condition is not limited and is determined by the master device. The receiver acknowledges the transfer of data. Acknowledge: Each receiving device, when addressed, is obliged to generate an Acknowledge bit. A device that acknowledges must pull down the SDA line during the Acknowledge clock pulse in such a way that the SDA line is stable LOW during the HIGH period of the Acknowledge clock pulse. Setup and hold times must be taken into account. On a master receive, the termination of the data transfer can be signaled by the master generating a Not-Acknowledge on the last byte that is transmitted by the slave. t(LOW) tFC t(HDSTA) tRC SCL t(HDSTA) t(HIGH) t(HDDAT) t(SUSTO) t(SUSTA) t(SUDAT) SDA t(BUF) P tRD S tFD S P Figure 6. I2C Timing Diagram 12 Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 TMP100, TMP101 www.ti.com SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 1 9 1 9 … SCL 1 SDA 0 0 1 A2 A1 A0 Start By Master R/W 0 0 0 0 0 0 P1 ACK By TMP100 or TMP101 … P0 ACK By TMP100 or TMP101 Frame 1 I2C Slave Address Byte Frame 2 Pointer Register Byte 1 1 9 9 SCL (Continued) SDA (Continued) D7 D6 D5 D4 D3 D2 D1 D7 D0 D6 D5 D4 D3 D2 D1 D0 ACK By Stop By TMP100 or TMP101 Master ACK By TMP100 orTMP101 Frame 3 Data Byte 1 Frame 4 Data Byte 2 Figure 7. I2C Timing Diagram for Write Word Format 1 9 1 9 … SCL SDA 1 0 0 1 A2 A1 A0 R/W Start By Master 0 0 0 0 0 0 P1 ACK By TMP100 or TMP101 … P0 ACK By TMP100 or TMP101 Frame 1 I2C Slave Address Byte Frame 2 Pointer Register Byte 1 9 1 9 … SCL (Continued) SDA (Continued) 1 0 0 1 A2 A1 A0 R/W Start By Master D7 D6 D5 ACK By TMP100 or TMP101 Frame 3 I2C Slave Address Byte 1 D4 D3 D2 D1 D0 From TMP100 or TMP101 … ACK By Master Frame 4 Data Byte 1 Read Register 9 SCL (Continued) SDA (Continued) D7 D6 D5 D4 D3 D2 D1 D0 From TMP100 or TMP101 ACK By Master Stop By Master Frame 5 Data Byte 2 Read Register Figure 8. I2C Timing Diagram for Read Word Format Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 13 TMP100, TMP101 SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 www.ti.com ALERT 1 9 1 9 SCL SDA 0 0 0 1 Start By Master 1 0 0 R/W 1 0 0 1 ACK By TMP100 or TMP101 Frame 1 SMBus ALERT Response Address Byte A2 A1 A0 S ta tu s From NACK By TMP100 orTMP101 Master Stop By Master Frame 2 Slave Address From TMP100 Figure 9. Timing Diagram for SMBus ALERT 7.4 Device Functional Modes 7.4.1 Shutdown Mode (SD) The Shutdown Mode of the TMP100 and TMP101 devices lets the user save maximum power by shutting down all device circuitry other than the serial interface, which reduces current consumption to less than 1 µA. For the TMP100 and TMP101 devices, Shutdown Mode is enabled when the SD bit is 1. The device shuts down when the current conversion is completed. For SD equal to 0, the device maintains continuous conversion. 7.4.2 OS/ALERT (OS) The TMP100 and TMP101 devices feature a One-Shot Temperature Measurement Mode. When the device is in Shutdown Mode, writing 1 to the OS/ALERT bit starts a single temperature conversion. The device returns to the shutdown state at the completion of the single conversion. This feature is useful to reduce power consumption in the TMP100 and TMP101 devices when continuous monitoring of temperature is not required. Reading the OS/ALERT bit provides information about the Comparator Mode status. The state of the POL bit inverts the polarity of data returned from the OS/ALERT bit. For POL = 0, the OS/ALERT reads as 1 until the temperature equals or exceeds THIGH for the programmed number of consecutive faults, causing the OS/ALERT bit to read as 0. The OS/ALERT bit continues to read as 0 until the temperature falls below TLOW for the programmed number of consecutive faults when the OS/ALERT bit again reads as 1. The status of the TM bit does not affect the status of the OS/ALERT bit. 7.4.3 Thermostat Mode (TM) The Thermostat Mode bit of the TMP101 device indicates to the device whether to operate in Comparator Mode (TM = 0) or Interrupt Mode (TM = 1). For more information on comparator and interrupt modes, see the Highand Low-Limit Registers section. 7.4.3.1 Comparator Mode (TM = 0) In Comparator Mode (TM = 0), the ALERT pin is activated when the temperature equals or exceeds the value in the THIGH register and remains active until the temperature falls below the value in the TLOW register. For more information on the Comparator Mode, see the High- and Low-Limit Registers section. 7.4.3.2 Interrupt Mode (TM = 1) In Interrupt Mode (TM = 1), the ALERT pin is activated when the temperature exceeds THIGH or goes below the TLOW registers. The ALERT pin is cleared when the host controller reads the temperature register. For more information on the interrupt mode, see the High- and Low-Limit Registers section. 14 Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 TMP100, TMP101 www.ti.com SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 7.5 Programming 7.5.1 Pointer Register Figure 10 shows the internal register structure of the TMP100 and TMP101 devices. The 8-bit Pointer Register of the TMP100 and TMP101 devices is used to address a given data register. The Pointer Register uses the two LSBs to identify which of the data registers respond to a read or write command. Table 4 identifies the bits of the Pointer Register byte. Table 5 describes the pointer address of the registers available in the TMP100 and TMP101 devices. The power-up reset value of P1 and P0 is 00. Pointer Register Temperature Register SCL Configuration Register I/O Control Interface TLOW Register SDA THIGH Register Figure 10. Internal Register Structure of the TMP100 and TMP101 7.5.1.1 Pointer Register Byte (pointer = N/A) [reset = 00h] Table 4. Pointer Register Byte P7 P6 P5 P4 P3 P2 0 0 0 0 0 0 P1 P0 Register Bits 7.5.1.2 Pointer Addresses of the TMP100 and TMP101 Registers Table 5. Pointer Addresses of the TMP100 and TMP101 Registers P1 P0 TYPE REGISTER 0 0 R only, default Temperature Register 0 1 R/W Configuration Register 1 0 R/W TLOW Register 1 1 R/W THIGH Register Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 15 TMP100, TMP101 SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 www.ti.com 7.5.2 Temperature Register The Temperature Register of the TMP100 or TMP101 devices is a 12-bit, read-only register that stores the output of the most recent conversion. Two bytes must be read to obtain data, and are described in Table 6 and Table 7. The first 12 bits are used to indicate temperature, with all remaining bits equal to zero. Data format for temperature is summarized in Table 1. Following power-up or reset, the Temperature Register reads 0°C until the first conversion is complete. Table 6. Byte 1 of the Temperature Register D7 D6 D5 D4 D3 D2 D1 D0 T11 T10 T9 T8 T7 T6 T5 T4 Table 7. Byte 2 of the Temperature Register D7 D6 D5 D4 D3 D2 D1 D0 T3 T2 T1 T0 0 0 0 0 7.5.3 Configuration Register The Configuration Register is an 8-bit read and write register used to store bits that control the operational modes of the temperature sensor. Read and write operations are performed MSB-first. The format of the Configuration Register for the TMP100 and TMP101 devices is shown in Table 8, followed by a breakdown of the register bits. The power-up or reset value of the Configuration Register is all bits equal to 0. The OS/ALERT bit reads as 1 after power-up or reset value. Table 8. Configuration Register Format BYTE D7 D6 D5 D4 D3 D2 D1 D0 1 OS/ALERT R1 R0 F1 F0 POL TM SD 7.5.3.1 Shutdown Mode (SD) The Shutdown Mode of the TMP100 and TMP101 devices allows the user to save maximum power by shutting down all device circuitry other than the serial interface, which reduces current consumption to less than 1 µA. For the TMP100 and TMP101 devices, Shutdown Mode is enabled when the SD bit is 1. The device shuts down when the current conversion is completed. For SD equal to 0, the device maintains continuous conversion. 7.5.3.2 Thermostat Mode (TM) The Thermostat Mode bit of the TMP101 device indicates to the device whether to operate in Comparator Mode (TM = 0) or Interrupt Mode (TM = 1). For more information on comparator and interrupt modes, see High- and Low-Limit Registers. 7.5.3.3 Polarity (POL) The Polarity bit of the TMP101 device lets the user adjust the polarity of the ALERT pin output. If the POL bit is set to 0 (default), the ALERT pin becomes active low. When the POL bit is set to 1, the ALERT pin becomes active high and the state of the ALERT pin is inverted. The operation of the ALERT pin in various modes is illustrated in Figure 11. 16 Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 TMP100, TMP101 www.ti.com SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 THIGH Measured Temperature TLOW TMP101 ALERT PIN (Comparator Mode) POL = 0 TMP101 ALERT PIN (Interrupt Mode) POL = 0 TMP101 ALERT PIN (Comparator Mode) POL = 1 TMP101 ALERT PIN (Interrupt Mode) POL = 1 Read Read Read Time Figure 11. Output Transfer Function Diagrams 7.5.3.4 Fault Queue (F1, F0) A fault condition occurs when the measured temperature exceeds the user-defined limits set in the THIGH and TLOW Registers. Additionally, the number of fault conditions required to generate an alert can be programmed using the Fault Queue. The Fault Queue is provided to prevent a false alert resulting from environmental noise. The Fault Queue requires consecutive fault measurements in order to trigger the alert function. If the temperature falls below TLOW before reaching the number of programmed consecutive faults limit, the count is reset to 0. Table 9 defines the number of measured faults that can be programmed to trigger an alert condition in the device. Table 9. Fault Settings of the TMP100 and TMP101 F1 F0 CONSECUTIVE FAULTS 0 0 1 0 1 2 1 0 4 1 1 6 7.5.3.5 Converter Resolution (R1, R0) The Converter Resolution bits control the resolution of the internal analog-to-digital converter (ADC), thus allowing the user to maximize efficiency by programming for higher resolution or faster conversion time. Table 10 identifies the Resolution bits and the relationship between resolution and conversion time. Table 10. Resolution of the TMP100 and TMP101 RESOLUTION CONVERSION TIME (Typical) 0 9 bits (0.5°C) 40 ms 1 10 bits (0.25°C) 80 ms 1 0 11 bits (0.125°C) 160 ms 1 1 12 bits (0.0625°C) 320 ms R1 R0 0 0 Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 17 TMP100, TMP101 SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 www.ti.com 7.5.3.6 OS/ALERT (OS) The TMP100 and TMP101 devices feature a One-Shot Temperature Measurement Mode. When the device is in Shutdown Mode, writing 1 to the OS/ALERT bit starts a single temperature conversion. The device returns to the shutdown state at the completion of the single conversion. This feature is useful to reduce power consumption in the TMP100 and TMP101 when continuous temperature monitoring is not required. Reading the OS/ALERT bit provides information about the Comparator Mode status. The state of the POL bit inverts the polarity of data returned from the OS/ALERT bit. For POL = 0, the OS/ALERT reads as 1 until the temperature equals or exceeds THIGH for the programmed number of consecutive faults, causing the OS/ALERT bit to read as 0. The OS/ALERT bit continues to read as 0 until the temperature falls below TLOW for the programmed number of consecutive faults when the OS/ALERT bit again reads as 1. The status of the TM bit does not affect the status of the OS/ALERT bit. 7.5.4 High- and Low-Limit Registers In Comparator Mode (TM = 0), the ALERT pin of the TMP101 becomes active when the temperature equals or exceeds the value in THIGH and generates a consecutive number of faults according to fault bits F1 and F0. The ALERT pin remains active until the temperature falls below the indicated TLOW value for the same number of faults. In Interrupt Mode (TM = 1) the ALERT pin becomes active when the temperature equals or exceeds THIGH for a consecutive number of fault conditions. The ALERT pin remains active until a read operation of any register occurs or the device successfully responds to the SMBus Alert Response Address. The ALERT pin is also cleared if the device is placed in Shutdown Mode. When the ALERT pin is cleared, it only becomes active again by the temperature falling below TLOW. When the temperature falls below TLOW, the ALERT pin becomes active and remains active until cleared by a read operation of any register or a successful response to the SMBus Alert Response Address. When the ALERT pin is cleared, the above cycle repeats with the ALERT pin becoming active when the temperature equals or exceeds THIGH. The ALERT pin can also be cleared by resetting the device with the General Call Reset command. This action also clears the state of the internal registers in the device, returning the device to Comparator Mode (TM = 0). Both operational modes are represented in Figure 11. Table 11, Table 12, Table 13, and Table 14 describe the format for the THIGH and TLOW registers. Power-up reset values for THIGH and TLOW are: THIGH = 80°C and TLOW = 75°C. The format of the data for THIGH and TLOW is the same as for the Temperature Register. Table 11. Byte 1 of the THIGH Register D7 D6 D5 D4 D3 D2 D1 D0 H11 H10 H9 H8 H7 H6 H5 H4 Table 12. Byte 2 of the THIGH Register D7 D6 D5 D4 D3 D2 D1 D0 H3 H2 H1 H0 0 0 0 0 Table 13. Byte 1 of the TLOW Register D7 D6 D5 D4 D3 D2 D1 D0 L11 L10 L9 L8 L7 L6 L5 L4 Table 14. Byte 2 of the TLOW Register D7 D6 D5 D4 D3 D2 D1 D0 L3 L2 L1 L0 0 0 0 0 All 12 bits for the Temperature, THIGH, and TLOW registers are used in the comparisons for the ALERT function for all converter resolutions. The three LSBs in THIGH and TLOW can affect the ALERT output even if the converter is configured for 9-bit resolution. 18 Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 TMP100, TMP101 www.ti.com SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 8 Application and Implementation NOTE Information in the following applications sections is not part of the TI component specification, and TI does not warrant its accuracy or completeness. TI’s customers are responsible for determining suitability of components for their purposes. Customers should validate and test their design implementation to confirm system functionality. 8.1 Application Information The TMP100 and TMP101 devices are used to measure the printed circuit board (PCB) temperature of the board location where the devices are mounted. The TMP100 features two address pins to allow up to eight devices to be addressed on a single I2C interface. The TMP101 device features one address pin and an ALERT pin, allowing up to three devices to be connected per bus. The TMP100 and TMP101 devices require no external components for operation except for pullup resistors on SCL, SDA, and ALERT (TMP101 device), although a 0.1-μF bypass capacitor is recommended. The sensing device of the TMP100 and TMP101 devices is the chip itself. Thermal paths run through the package leads as well as the plastic package. The die flag of the lead frame is connected to GND. The lower thermal resistance of metal causes the leads to provide the primary thermal path. The GND pin of the TMP100 or TMP101 device is directly connected to the metal lead frame, and is the best choice for thermal input. 8.2 Typical Application Supply Voltage 2.7 V to 5.5 V Supply Voltage 2.7 V to 5.5 V Supply Bypass Capacitor Pull-Up Resistors Supply Bypass Capacitor Pull-Up Resistors 0.01 PF 5-k TMP100 Two-Wire Host Controller 1 2 3 0.01 PF 5-k TMP101 SCL SDA GND ADD0 ADD1 6 Two-Wire Host Controller 5 1 2 4 3 V+ Figure 12. Typical Connections of the TMP100 SCL SDA GND ADD0 ALERT 6 5 4 V+ Figure 13. Typical Connections of the TMP101 8.2.1 Design Requirements The TMP100 and TMP101 devices require pullup resistors on the SCL, SDA, and ALERT (TMP101 device) pins. The recommended value for the pullup resistor is 5-kΩ. In some applications, the pullup resistor can be lower or higher than 5-kΩ but must not exceed 3 mA of current on the SCL and SDA pins, and must not exceed 4 mA on the ALERT (TMP101) pin. A 0.1-μF bypass capacitor is recommended, as shown in Figure 12 and Figure 13. The SCL, SDA, and ALERT lines can be pulled up to a supply that is equal to or higher than VS through the pullup resistors. For the TMP100, to configure one of eight different addresses on the bus, connect ADD0 and ADD1 to either the GND pin, V+ pin, or float. Float indicates the pin is left unconnected. For the TMP101 device, to configure one of three different addresses on the bus, connect ADD0 to either the GND pin, V+ pin, or float. 8.2.2 Detailed Design Procedure Place the TMP100 and TMP101 devices in close proximity to the heat source that must be monitored, with a proper layout for good thermal coupling. This placement ensures that temperature changes are captured within the shortest possible time interval. To maintain accuracy in applications that require air or surface temperature measurement, care must be taken to isolate the package and leads from ambient air temperature. A thermallyconductive adhesive is helpful in achieving accurate surface temperature measurement. Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 19 TMP100, TMP101 SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 www.ti.com Typical Application (continued) 8.2.3 Application Curve Temperature (qC) Figure 14 shows the step response of the TMP100 and TMP101 devices to a submersion in an oil bath of 100ºC from room temperature (27ºC). The time constant, or the time for the output to reach 63% of the input step, is 0.9 s. The time-constant result depends on the PCB that the TMP100 and TMP101 devices are mounted. For this test, the TMP100 and TMP101 devices are soldered to a two-layer PCB that measures 0.375 inch × 0.437 inch. 100 95 90 85 80 75 70 65 60 55 50 45 40 35 30 25 -1 1 3 5 7 9 11 Time (s) 13 15 17 19 Figure 14. Temperature Step Response 20 Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 TMP100, TMP101 www.ti.com SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 9 Power Supply Recommendations The TMP100 and TMP101 devices operate with power supply in the range of 2.7 V to 5.5 V. A power-supply bypass capacitor is required for stability; place this capacitor as close as possible to the supply and ground pins of the device. A typical value for this supply bypass capacitor is 0.01 μF. Applications with noisy or highimpedance power supplies can require additional decoupling capacitors to reject power-supply noise. 10 Layout 10.1 Layout Guidelines Place the power-supply bypass capacitor as close as possible to the supply and ground pins. The recommended value of this bypass capacitor is 0.01 μF. Additional decoupling capacitance can be added to compensate for noisy or high-impedance power supplies. Pull up the open-drain output pins SDA , SCL, and ALERT (TMP101) through 5-kΩ pullup resistors. 10.2 Layout Examples Via to Power or Ground Plane Via to Internal Layer Pull-Up Resistors SCL SDA GND ADD0 Supply Voltage ADD1 V+ Supply Bypass Capacitor Ground Plane for Thermal Coupling to Heat Source Serial Bus Traces Heat Source Figure 15. TMP100 Layout Example Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 21 TMP100, TMP101 SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 www.ti.com Layout Examples (continued) Via to Power or Ground Plane Via to Internal Layer Pull-Up Resistors SCL SDA GND ADD0 ALERT Supply Voltage V+ Supply Bypass Capacitor Ground Plane for Thermal Coupling to Heat Source Serial Bus Traces Heat Source Figure 16. TMP101 Layout Example 22 Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 TMP100, TMP101 www.ti.com SBOS231I – JANUARY 2002 – REVISED NOVEMBER 2015 11 Device and Documentation Support 11.1 Related Links The table below lists quick access links. Categories include technical documents, support and community resources, tools and software, and quick access to sample or buy. Table 15. Related Links PARTS PRODUCT FOLDER SAMPLE & BUY TECHNICAL DOCUMENTS TOOLS & SOFTWARE SUPPORT & COMMUNITY TMP100 Click here Click here Click here Click here Click here TMP101 Click here Click here Click here Click here Click here 11.2 Trademarks SMBus is a trademark of NXP Semiconductors. All other trademarks are the property of their respective owners. 11.3 Electrostatic Discharge Caution These devices have limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates. 11.4 Glossary SLYZ022 — TI Glossary. This glossary lists and explains terms, acronyms, and definitions. 12 Mechanical, Packaging, and Orderable Information The following pages include mechanical, packaging, and orderable information. This information is the most current data available for the designated devices. This data is subject to change without notice and revision of this document. For browser-based versions of this data sheet, refer to the left-hand navigation. Submit Documentation Feedback Copyright © 2002–2015, Texas Instruments Incorporated Product Folder Links: TMP100 TMP101 23 PACKAGE OPTION ADDENDUM www.ti.com 15-Oct-2021 PACKAGING INFORMATION Orderable Device Status (1) Package Type Package Pins Package Drawing Qty Eco Plan (2) Lead finish/ Ball material MSL Peak Temp Op Temp (°C) Device Marking (3) (4/5) (6) TMP100NA/250 ACTIVE SOT-23 DBV 6 250 RoHS & Green NIPDAU Level-2-260C-1 YEAR T100 TMP100NA/250G4 ACTIVE SOT-23 DBV 6 250 RoHS & Green NIPDAU Level-2-260C-1 YEAR T100 TMP100NA/3K ACTIVE SOT-23 DBV 6 3000 RoHS & Green NIPDAU Level-2-260C-1 YEAR -55 to 125 T100 TMP100NA/3KG4 ACTIVE SOT-23 DBV 6 3000 RoHS & Green NIPDAU Level-2-260C-1 YEAR -55 to 125 T100 TMP101NA/250 ACTIVE SOT-23 DBV 6 250 RoHS & Green NIPDAU Level-2-260C-1 YEAR -55 to 125 T101 TMP101NA/250G4 ACTIVE SOT-23 DBV 6 250 RoHS & Green NIPDAU Level-2-260C-1 YEAR -55 to 125 T101 TMP101NA/3K ACTIVE SOT-23 DBV 6 3000 RoHS & Green NIPDAU Level-2-260C-1 YEAR -55 to 125 T101 TMP101NA/3KG4 ACTIVE SOT-23 DBV 6 3000 RoHS & Green NIPDAU Level-2-260C-1 YEAR -55 to 125 T101 (1) The marketing status values are defined as follows: ACTIVE: Product device recommended for new designs. LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect. NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in a new design. PREVIEW: Device has been announced but is not in production. Samples may or may not be available. OBSOLETE: TI has discontinued the production of the device. (2) RoHS: TI defines "RoHS" to mean semiconductor products that are compliant with the current EU RoHS requirements for all 10 RoHS substances, including the requirement that RoHS substance do not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered at high temperatures, "RoHS" products are suitable for use in specified lead-free processes. TI may reference these types of products as "Pb-Free". RoHS Exempt: TI defines "RoHS Exempt" to mean products that contain lead but are compliant with EU RoHS pursuant to a specific EU RoHS exemption. Green: TI defines "Green" to mean the content of Chlorine (Cl) and Bromine (Br) based flame retardants meet JS709B low halogen requirements of
