TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
TPS54A24 4.5-V to 17-V Input, 10-A Synchronous
SWIFT™ Step-Down Converter
1 Features
3 Description
•
•
•
•
•
•
•
•
•
•
•
•
The TPS54A24 is a full-featured 17-V, 10-A
synchronous step-down DC/DC converter in a
standard 4 mm × 4 mm WQFN package.
Standard 4-mm × 4-mm WQFN package
–40°C to +150°C Operating junction temperature
200-kHz to 1.6-MHz Fixed switching frequency
Peak-current-mode control
Synchronizes to external clock
0.6-V Voltage reference ±0.85% over temperature
0.6-V to 12-V Output voltage range
Safe start-up into prebiased output voltage
Hiccup current limit
Adjustable soft start and power sequencing
Adjustable input undervoltage lockout
Power-good output monitor for undervoltage and
overvoltage
3-µA Shutdown current
Output overvoltage protection
Non-latch thermal shutdown protection
Create a custom design using the TPS54A24 with
the WEBENCH® Power Designer
1
•
•
•
•
2 Applications
•
•
•
•
•
The peak-current-mode control simplifies the loop
compensation and provides fast transient response.
Cycle-by-cycle peak current limiting on the high-side
and low-side sourcing current limit protects the device
in overload situations. Hiccup limits MOSFET power
dissipation if a short circuit or over loading fault
persists.
A power-good supervisor circuit monitors the
regulator output. The PGOOD pin is an open-drain
output and goes high impedance when the output
voltage is in regulation. An internal deglitch time
prevents the PGOOD pin from pulling low unless a
fault has occurred.
A dedicated EN pin can be used to control the
regulator on/off and adjust the input undervoltage
lockout. The output voltage start-up ramp is controlled
by the SS/TRK pin, which allows operation as either a
standalone power supply or in tracking situations.
Wired networking (switches)
Wireless infrastructure
Test and measurement
Medical imaging equipment
Power for FPGAs, SoCs, DSPs and processors
space
space
Device Information(1)
PART NUMBER
100
EN
95
COUT
90
RFBT
PGOOD
SS/TRK
FB
RT/CLK
CSS
VOUT
SW
RFBB
Efficiency (%)
CI
BODY SIZE (NOM)
4.00 mm × 4.00 mm
Efficiency (VIN = 12 V, fSW = 500 kHz)
CBT
LO
VIN
RTW (24)
(1) For all available packages, see the orderable addendum at
the end of the data sheet.
BOOT
VIN
PACKAGE
TPS54A24
Simplified Schematic
TPS54A24
The device is optimized for small solution size
through high efficiency and integrating the high-side
and low-side MOSFETs. Further space savings are
achieved through peak-current-mode control, which
reduces component count, and by selecting a high
switching frequency, reducing the inductor footprint.
85
80
75
COMP
RC
RT
AGND
PGND
CP
CZ
70
VO = 1 V, L = 680 nH, XAL8080-681
VO = 1.8 V, L = 1 PH, 74439358010
VO = 3.3 V, L = 2.2 PH, L = 74439358022
65
60
0
1
2
3
4
5
6
Output Current (A)
7
8
9
10
D001
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
Table of Contents
1
2
3
4
5
6
7
Features ..................................................................
Applications ...........................................................
Description .............................................................
Revision History.....................................................
Pin Configuration and Functions .........................
Specifications.........................................................
1
1
1
2
3
4
6.1
6.2
6.3
6.4
6.5
6.6
6.7
6.8
4
4
4
4
5
6
6
7
Absolute Maximum Ratings ......................................
ESD Ratings..............................................................
Recommended Operating Conditions.......................
Thermal Information ..................................................
Electrical Characteristics...........................................
Timing Requirements ................................................
Switching Characteristics ..........................................
Typical Characteristics ..............................................
Detailed Description ............................................ 12
7.1 Overview ................................................................. 12
7.2 Functional Block Diagram ....................................... 13
7.3 Feature Description................................................. 13
7.4 Device Functional Modes........................................ 22
8
Application and Implementation ........................ 23
8.1 Application Information............................................ 23
8.2 Typical Application ................................................. 23
9 Power Supply Recommendations...................... 34
10 Layout................................................................... 34
10.1 Layout Guidelines ................................................. 34
10.2 Layout Example .................................................... 34
11 Device and Documentation Support ................. 36
11.1
11.2
11.3
11.4
11.5
11.6
Device Support......................................................
Receiving Notification of Documentation Updates
Community Resources..........................................
Trademarks ...........................................................
Electrostatic Discharge Caution ............................
Glossary ................................................................
36
36
36
36
36
36
12 Mechanical, Packaging, and Orderable
Information ........................................................... 36
4 Revision History
Changes from Original (May 2019) to Revision A
•
2
Page
Added Equation 35 .............................................................................................................................................................. 29
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
5 Pin Configuration and Functions
RT/CLK
FB
COMP
SS/TRK
EN
PGOOD
24
23
22
21
20
19
RTW Package
24-Pin WQFN
Top View
AGND
1
18
BOOT
VIN
2
17
VIN
VIN
3
16
VIN
15
PGND
Thermal
Pad
11
12
PGND
PGND
SW
13
10
6
SW
PGND
9
PGND
SW
14
8
5
SW
PGND
7
4
PGND
PGND
Not to scale
Pin Functions
PIN
I/O
DESCRIPTION
1
–
Ground of internal analog circuitry. AGND must be connected to PGND for proper operation.
Connect to PGND in a region outside of the critical switching loop.
2, 3, 16, 17
I
Input voltage supply pin. Power for the internal circuit and the connection to drain of highside MOSFET. Connect both pins to the input power source with a low impedance
connection. Connect both pins and their neighboring PGND pins.
4, 5, 6, 7, 12,
13, 14, 15
–
Ground return for low-side power MOSFET and its drivers.
8, 9, 10, 11
O
Switching node. Connected to the source of the high-side MOSFET and drain of the low-side
MOSFET.
BOOT
18
I
Floating supply voltage for high-side MOSFET gate drive circuit. Connect a 0.1-µF ceramic
capacitor between BOOT and SW pins.
PGOOD
19
O
Open-drain power good indicator. It is asserted low if output voltage is outside if the PGOOD
thresholds, VIN is low, EN is low, device is in thermal shutdown or device is in soft start.
EN
20
I
Enable pin. Float or pull high to enable the device. Connect a resistor divider to this pin to
implement adjustable under voltage lockout and hysteresis.
SS/TRK
21
I
Soft-start and tracking pin. Connecting an external capacitor sets the soft-start time. This pin
can also be used for tracking and sequencing.
COMP
22
I
Error amplifier output and input to the PWM modulator. Connect loop compensation to this
pin.
FB
23
I
Converter feedback input. Connect to the output voltage with a resistor divider.
RT/CLK
24
I
Switching frequency setting pin. In RT mode, an external timing resistor adjusts the switching
frequency. In CLK mode, the device synchronizes to an external clock input to this pin.
Thermal PAD
–
–
Exposed thermal pad. Connect to PGND pins and to internal ground planes using multiple
vias for good thermal performance.
NAME
NO.
AGND
VIN
PGND
SW
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
3
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
6 Specifications
6.1 Absolute Maximum Ratings
over operating free-air temperature range (unless otherwise noted) (1)
MIN
MAX
VIN
–0.3
19
BOOT
–0.3
27
BOOT (10 ns transient)
–0.3
30
BOOT (vs SW)
–0.3
7
SW
–1
20
SW (10 ns transient)
–3
23
–0.3
6.5
Operating junction temperature, TJ
-40
150
°C
Storage temperature, TSTG
-55
150
°C
Voltage
EN, SS/TRK, PGOOD, RT/CLK, FB, COMP
(1)
UNIT
V
Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings
only, which do not imply functional operation of the device at these or any other conditions beyond those indicated under Recommended
Operating Conditions. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
6.2 ESD Ratings
VALUE
V(ESD)
(1)
(2)
Electrostatic discharge
Human body model (HBM), per
ANSI/ESDA/JEDEC JS-001, all pins (1)
±2000
Charged device model (CDM), per
JEDEC specification JESD22-C101, all
pins (2)
±500
UNIT
V
JEDEC document JEP155 states that 500-V HBM allows safe manufacturing with a standard ESD control process.
JEDEC document JEP157 states that 250-V CDM allows safe manufacturing with a standard ESD control process.
6.3 Recommended Operating Conditions
over operating free-air temperature range (unless otherwise noted)
Parameter
MIN
NOM
MAX
UNIT
VIN
Input voltage range
4.5
17
V
VOUT
Output Voltage
0.6
12
V
IOUT
Output current
TJ
Operating junction temperature
fSW
Switching Frequency (RT mode and PLL
mode)
10
A
-40
150
°C
200
1600
kHz
6.4 Thermal Information
TPS54A24
THERMAL METRIC (1)
RTW
UNIT
24 PINS
RΘJA
Junction-to-ambient thermal resistance JEDEC
RΘJA
Junction-to-ambient thermal resistance EVM
37.5
°C/W
21
RΘJC(top)
°C/W
Junction-to-case (top) thermal resistance
22.8
°C/W
RΘJB
Junction-to-board thermal resistance
12.5
°C/W
ΨJT
Junction-to-top characterization parameter
0.3
°C/W
ΨJB
Junction-to-board characterization parameter
12.5
°C/W
RΘJC(bot)
Junction-to-case (bottom) thermal resistance
1.5
°C/W
(1)
4
For more information about traditional and new thermal metrics, see the Semiconductor and IC Package Thermal Metrics application
report, SPRA953.
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
6.5 Electrical Characteristics
TJ = -40°C to 150°C, V(VIN) = 4.5 V to 17 V (unless otherwise noted)
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
4.1
4.3
UNIT
INPUT VOLTAGE
UVLO_rise
UVLO_fall
V(VIN) rising
VIN undervoltage lockout
V(VIN) falling
UVLO_hys
3.7
V
3.9
V
Hysteresis VIN voltage
0.2
580
800
µA
3
11
µA
1.20
1.26
V
Ivin
Operating non-switching supply current
V(EN) = 5 V, V(FB) = 1.5 V
Ivin_sdn
Shutdown supply current
V(EN) = 0 V
V
ENABLE
Ven_rise
Ven_fall
V(EN) rising
EN threshold
Ven_hys
EN pin threshold voltage hysteresis
Ip
EN pin sourcing current
Iph
EN pin sourcing current
Ih
EN pin hysteresis current
V(EN) falling
1.1
1.15
V
50
mV
V(EN) = 1.1V
1.2
µA
V(EN) = 1.3V
4.8
µA
3.6
µA
FB
VFB
TJ = 25°C
Regulated FB voltage
596
600
604
mV
595
600
605
mV
ERROR AMPLIFIER
gmea
Error amplifier transconductance (gm)
–2 µA < I(COMP) < 2 µA, V(COMP) = 1 V
1100
Error amplifier DC gain
µA/V
80
dB
µA
Icomp_src
Error amplifier source current
V(FB) = 0 V
100
Icomp_snk
Error amplifier sink current
V(FB) = 2 V
-100
µA
gmps
Power stage transconductance
17
A/V
SS/TRK
Iss
Soft start current
5
µA
V(SS/TRK) to V(FB) matching
V(SS/TRK) = 0.4 V
30
mV
High-side switch resistance (VIN pins to SW
pins)
TA = 25°C, V(VIN) = 12 V
21
mΩ
TA = 25°C, V(VIN) = 4.5 V, V(BOOT-SW) = 4.5 V
23
mΩ
Low-side switch resistance (SW pins to
PGND pins)
TA = 25°C, V(VIN) = 12 V
8
mΩ
TA = 25°C, V(VIN) = 4.5 V
9
mΩ
MOSFET
Rds(on)_h
Rds(on)_l
BOOT UVLO Falling
2.2
2.6
V
14.6
15.8
A
CURRENT LIMIT
Ioc_HS_pk
High-side peak current limit
V(VIN) = 12 V, TJ = 25℃
Ioc_LS_snk
Low-side sinking current limit
V(VIN) = 12 V
Ioc_LS_src
Low-side sourcing current limit
V(VIN) = 12 V
13.4
-3.4
10
12.9
A
14.6
A
RT/CLK
VIH
Logic high input voltage
VIL
Logic low input voltage
2
V
0.8
V
PGOOD
V(FB) rising (fault)
Power good threshold
104%
108%
V(FB) falling (good)
106%
V(FB) rising (good)
91%
V(FB) falling (fault)
89%
95%
Ipg_lkg
Leakage current into PGOOD pin when
pulled high
V(PGOOD) = 5 V
Vpg_low
PGOOD voltage when pulled low
I(PGOOD) = 2 mA
0.18
0.22
V
Minimum VIN for valid output
V(PGOOD) < 0.5 V, I(PGOOD) = 2.5 mA
0.9
1
V
Temperature rising
170
°C
15
°C
5
nA
THERMAL PROTECTION
TTRIP
Thermal protection trip point
THYST
Thermal protection hysteresis
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
5
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
6.6 Timing Requirements
TJ = -40°C to 150°C, V(VIN) = 4.5 V to 17 V (unless otherwise noted)
MIN
NOM
Minimum synchronization signal pulse width
(PLL mode)
MAX
35
UNIT
ns
6.7 Switching Characteristics
TJ = -40°C to 150°C, V(VIN) = 4.5 V to 17 V (unless otherwise noted)
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
EN
EN to start of switching
135
µs
Deglitch time PGOOD going high
272
Cycles
Deglitch time PGOOD going low
16
Cycles
90
ns
PGOOD
SW
ton_min
Measured at 50% to 50% of V(VIN), L = 1.0
µH, IOUT = 0 A
Minimum on time
toff_min
Minimum off time
(1)
V(BOOT-SW) ≥ 2.6 V
0
ns
RT/CLK
fsw_min
Minimum switching frequency (RT mode)
R(RT/CLK) = 250 kΩ
Switching frequency (RT mode)
R(RT/CLK) = 100 kΩ
fsw_max
Maximum switching frequency (RT mode)
R(RT/CLK) = 30.1 kΩ
fsw_clk
Switching frequency synchronization range
(PLL mode)
RT/CLK falling edge to SW rising edge
delay (PLL mode)
200
450
500
1.6
200
Measure at 500kHz with RT resistor in
series with RT/CLK
kHz
550
kHz
MHz
1600
kHz
70
ns
512
Cycles
16384
Cycles
HICCUP
Wait time before hiccup
Hiccup time before restart
(1)
6
Specified by design.
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
100
100
95
95
90
90
Efficiency (%)
Efficiency (%)
6.8 Typical Characteristics
85
80
75
70
85
80
75
70
VO = 1 V, L = 680 nH, XAL8080-681
VO = 1.8 V, L = 1.0 PH, 74439358010
VO = 3.3 V, L = 2.2 PH, 74439358022
65
65
60
VO = 5 V, L = 2.2 PH, 74439358022
VO = 9 V, L = 4.7 PH, 74439358047
60
0
1
2
3
VIN = 5 V
4
5
6
Output Current (A)
7
8
9
10
0
1
fSW = 500 kHz
100
100
95
95
90
90
85
80
75
4
5
6
Output Current (A)
7
8
9
10
D008
fSW = 500 kHz
Figure 2. Efficiency With 5-V and 9-V Output
Efficiency (%)
Efficiency (%)
3
VIN = 12 V
Figure 1. Efficiency with 5-V Input and 500-kHz Switching
Frequency
70
85
80
75
70
VO = 1 V, L = 820 nH, XEL6060-821
VO = 1.2 V, L = 820 nH, XEL6060-821
VO = 1.8 V, L = 820 nH, XEL6060-821
65
VO = 1 V, L = 820 nH, XEL6060-821
VO = 1.2 V, L = 820 nH, XEL6060-821
VO = 1.8 V, L = 820 nH, XEL6060-821
65
60
60
0
1
2
3
VIN = 5 V
4
5
6
Output Current (A)
7
8
9
10
0
1
2
3
D010
fSW = 500 kHz
VIN = 12 V
Figure 3. Efficiency With 5-V Input, 500-kHz Switching
Frequency and 6.36-mm × 6.56-mm Inductor
4
5
6
Output Current (A)
7
8
9
10
D009
fSW = 500 kHz
Figure 4. Efficiency With 12-V Input, 500-kHz Switching
Frequency and 6.36 mm × 6.56 mm Inductor
100
620
Nonswitching Supply Current (PA)
95
90
Efficiency (%)
2
D003
85
80
75
70
VO = 1 V, L = 400 nH, 744308040
VO = 1.2 V, L = 400 nH, 744308040
VO = 1.8 V, L = 400 nH, 744308040
VO = 2.5 V, L = 400 nH, 744308040
65
1
2
VIN = 5 V
3
4
5
6
Output Current (A)
7
8
9
600
590
580
570
560
550
540
530
520
510
60
0
VIN = 4.5 V
VIN = 12 V
VIN = 17 V
610
10
500
-50
-25
D011
V(EN) = 5 V
fSW = 1 MHz
Figure 5. Efficiency With 5-V Input and 1 MHz Switching
Frequency
0
25
50
75
100
Junction Temperature (qC)
125
150
D005
V(FB) = 0.8 V
Figure 6. VIN Pin Nonswitching Supply Current vs Junction
Temperature
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
7
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
Typical Characteristics (continued)
1.22
VIN = 4.5 V
VIN = 12 V
VIN = 17 V
9
8
1.21
EN Voltage Threshold (V)
VIN Pin Shutdown Supply Current (PA)
10
7
6
5
4
3
2
1.2
1.19
1.18
1.17
1.16
1.15
1.14
EN Rising
EN Falling
1
1.13
0
-50
1.12
-50
-25
0
25
50
75
100
Junction Temperature (qC)
125
150
-25
0
D006
25
50
75
100
Junction Temperature (qC)
125
150
D007
V(EN) = 0.4 V
Figure 8. EN Pin Voltage Threshold vs Junction
Temperature
6
0.605
5.5
0.604
5
0.603
4.5
Voltage Reference (V)
EN Pin Output Current (PA)
Figure 7. VIN Pin Shutdown Current vs Junction
Temperature
4
3.5
V(EN) = 1.1 V
V(EN) = 1.3 V
3
2.5
2
1.5
0.6
0.599
0.598
0.596
0
-50
-25
0
25
50
75
100
Junction Temperature (qC)
125
0.595
-50
150
-25
0
D008
D007
25
50
75
100
Junction Temperature (qC)
125
150
D009
Figure 10. Regulated FB Voltage vs Junction Temperature
Figure 9. EN Pin Current vs Junction Temperature
40
1400
30
Error Amplifier Transconductance (PS)
High-side, V(BOOT-SW) = 4.5 V
High-side, V(IN) = 12 V
Low-side, V(IN) = 4.5 V
Low-side, V(IN) = 12 V
35
RDS(on) (m:)
0.601
0.597
1
0.5
25
20
15
10
5
-50
-25
0
25
50
75
100
Junction Temperature (qC)
125
150
1350
1300
1250
1200
1150
1100
1050
1000
950
900
-50
D004
Figure 11. MOSFET RDS(on) vs Junction Temperature
8
0.602
-25
0
25
50
75
100
Junction Temperature (qC)
125
150
D011
Figure 12. Error Amplifier Transconductance vs Junction
Temperature
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
Typical Characteristics (continued)
5.3
5.25
18
5.2
5.15
17
I(SS/TRK) (µA)
V(COMP) to I(SW) Transconductance (S)
19
16
15
14
5
4.95
4.9
4.85
4.8
13
4.75
12
-50
-25
0
25
50
75
100
Ambient Temperature (qC)
125
4.7
-50
150
38
36
34
V(FB) (V)
32
30
28
26
24
22
-25
0
0
25
50
75
100
Junction Temperature (qC)
125
25
50
75
100
Junction Temperature (qC)
125
150
D013
Figure 14. SS/TRK Current vs Junction Temperature
40
20
-50
-25
D009
Figure 13. V(COMP) to I(SW) Transconductance vs Ambient
Temperature
V(SS/TRK) to V(FB) matching (mV)
5.1
5.05
0.7
0.65
0.6
0.55
0.5
0.45
0.4
0.35
0.3
0.25
0.2
0.15
0.1
0.05
0
0
150
0.2
0.4
D014
0.6
0.8
1
V(SS/TRK) (V)
1.2
1.4
1.6
1.8
D002
V(SS/TRK) = 0.4 V
Figure 16. FB voltage vs SS/TRK Voltage
Figure 15. SS/TRK to FB Offset vs Junction Temperature
110
15
14.5
14
13.5
13
V(VIN) = 4.5 V
V(VIN) = 12 V
V(VIN) = 17 V
12.5
12
-50
-25
0
25
50
75
100
Ambient Temperature (qC)
125
of VREF)
108
15.5
106
PGOOD Threshold (
High-side Peak Current Limit (A)
16
100
104
102
V(FB) falling (fault)
V(FB) rising (good)
V(FB) rising (fault)
V(FB) falling (good)
98
96
94
92
90
88
150
86
-50
D005
-25
0
25
50
75
100
Junction Temperature (qC)
125
150
D016
L = 1.0 µH
Figure 17. High-side Peak Current Limit vs Ambient
Temperature
Figure 18. PGOOD Thresholds vs Junction Temperature
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
9
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
1100
2
1000
1.8
900
1.6
800
1.4
700
V(VIN) (V)
PGOOD Leakage Current (nA)
Typical Characteristics (continued)
600
500
400
200
0.4
100
0.2
0
-25
0
V(FB) = 0.6 V
25
50
75
100
Junction Temperature (qC)
125
0
150
1
TJ = 25 °C
V(PGOOD) = 5 V
1.5
2
2.5
I(PGOOD) (mA)
3
3.5
4
D006
V(PGOOD) < 0.5 V
Figure 20. Minimum Input Voltage for Valid PGOOD Output
vs PGOOD Current
120
520
IOUT = 0 A
IOUT = 0.1 A
IOUT = 0.5 A
110
515
Switching Frequency (kHz)
115
105
100
95
90
85
80
75
70
510
505
500
495
490
485
65
60
-50
0.5
D017
Figure 19. PGOOD Leakage Current vs Junction
Temperature
Minimum on-time (ns)
1
0.8
0.6
300
0
-50
-25
0
V(VIN) = 12 V
25
50
75
100
Ambient Temperature (qC)
125
480
-50
150
-25
0
D007
L = 1.0 µH
25
50
75
100
Junction Temperature (qC)
125
150
D020
R(RT/CLK) = 100 kΩ
Figure 21. Minimum on-time vs Ambient Temperature
Figure 22. Switching Frequency vs Junction Temperature
(500 kHz)
650
1660
1650
600
1640
Switching Frequency (kHz)
Switching Frequency (kHz)
1.2
1630
1620
1610
1600
1590
1580
1570
550
500
450
400
350
300
1560
250
1550
1540
-50
-25
0
25
50
75
100
Junction Temperature (qC)
125
150
200
80
100
D021
120
140
160 180 200
R(RT/CLK) (k:)
220
240
260
D023
R(RT/CLK) = 30.1 kΩ
Figure 23. Switching Frequency vs Junction Temperature
(1600 kHz)
10
Figure 24. Switching Frequency vs RT/CLK Resistor (Low
Range)
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
Typical Characteristics (continued)
1600
Switching Frequency (kHz)
1500
1400
1300
1200
1100
1000
900
800
700
600
25
30
35
40
45
50 55 60 65
R(RT/CLK) (k:)
70
75
80
85
D024
Figure 25. Switching Frequency vs RT/CLK Resistor (High Range)
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
11
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
7 Detailed Description
7.1 Overview
The TPS54A24 is a 17-V, 10-A, synchronous step-down (buck) converter with two integrated n-channel
MOSFETs. To improve performance during line and load transients the device implements a constant frequency,
peak current mode control which also simplifies external frequency compensation. The wide switching frequency
of 200 kHz to 1600 kHz allows for efficiency and size optimization when selecting the output filter components.
The switching frequency is adjusted using a resistor to ground on the RT/CLK pin. The TPS54A24 also has an
internal phase lock loop (PLL) connected to the RT/CLK pin that can be used to synchronize the switching cycle
to the falling edge of an external system clock.
The integrated MOSFETs allow for high efficiency power supply designs with continuous output currents up to 10
amperes. The MOSFETs have been sized to optimize efficiency for lower duty cycle applications. The device
reduces the external component count by integrating a bootstrap recharge circuit. The bias voltage for the
integrated high-side MOSFET is supplied by a capacitor between the BOOT and SW pins. The BOOT capacitor
voltage is monitored by a BOOT to SW UVLO (BOOT-SW UVLO) circuit allowing SW pin to be pulled low to
recharge the BOOT capacitor. The device can operate at 100% duty cycle as long as the BOOT capacitor
voltage is higher than the preset BOOT-SW UVLO threshold which is typically 2.2 V.
The TPS54A24 has been designed for safe startup into pre-biased loads. The default start up is when VIN is
typically 4.1 V. The EN pin has an internal pullup current source that can be used to adjust the input voltage
under voltage lockout (UVLO) with two external resistors. In addition, the internal pullup current of the EN pin
allows the device to operate with the EN pin floating. The operating current for the TPS54A24 is typically 580 μA
when not switching and under no load. When the device is disabled, the supply current is typically 3 μA.
The SS/TRK (soft start/tracking) pin is used to minimize inrush currents or provide power supply sequencing
during power up. A small value capacitor or resistor divider should be coupled to the pin for soft start or critical
power supply sequencing requirements. The output voltage can be stepped down to as low as the 0.6 V voltage
reference (VREF). The device has a power good comparator (PGOOD) with hysteresis which monitors the output
voltage through the FB pin. The PGOOD pin is an open drain MOSFET which is pulled low when the FB pin
voltage is less than 89% or greater than 108% of the reference voltage VREF and asserts high when the FB pin
voltage is 91% to 106% of VREF.
The device is protected from output overvoltage, overload and thermal fault conditions. The device minimizes
excessive output overvoltage transients by taking advantage of the overvoltage circuit power good comparator.
When the overvoltage comparator is activated, the high-side MOSFET is turned off and prevented from turning
on until the FB pin voltage is lower than 106% of the VREF. The device implements both high-side MOSFET over
current protection and bidirectional low-side MOSFET over current protections which help control the inductor
current and avoid current runaway. The device also shuts down if the junction temperature is higher than thermal
shutdown trip point. The device is restarted under control of the soft start circuit automatically when the junction
temperature drops 15°C typically below the thermal shutdown trip point.
12
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
7.2 Functional Block Diagram
PGOOD
VIN
EN
Shutdown
Ip
UV
Ih
Enable
Comparator
Thermal
Shutdown
UVLO
Shutdown
Shutdown
Logic
Logic
Enable
Threshold
Hiccup
Shutdown
OV
ERROR
AMPLIFIER
BOOT
Charge
Minimum
Clamp
Pulse Skip
Current
Sense
FB
BOOT
Boot
UVLO
SS/TRK
Voltage
Reference
HS MOSFET
Current
Comparator
Power Stage
& Deadtime
Control
Logic
SW
Slope
Compensation
VIN
Hiccup
Shutdown
Overload
Recovery
Oscillator
with PLL
Maximum
Clamp
LS
MOSFET
Current
Limit
Regulator
Current
Sense
PGND
COMP
RT/CLK
AGND
Copyright © 2016, Texas Instruments Incorporated
7.3 Feature Description
7.3.1 Fixed Frequency PWM Control
The device uses an adjustable fixed-frequency, peak-current-mode control. The output voltage is compared
through external resistors on the FB pin to an internal voltage reference by an error amplifier which drives the
COMP pin. An internal oscillator initiates the turn on of the high-side power switch. The error amplifier output is
converted into a current reference which compares to the high-side power switch current. When the power switch
current reaches current reference generated by the COMP voltage level the high-side power switch is turned off
and the low-side power switch is turned on.
The device adds an internal slope compensation ramp to prevent subharmonic oscillations. The peak inductor
current limit remains constant over the full duty cycle range.
7.3.2 Continuous Conduction Mode Operation (CCM)
As a synchronous buck converter, the device works in continuous conduction mode (CCM) under all load
conditions.
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
13
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
Feature Description (continued)
7.3.3 VIN Pins and VIN UVLO
The VIN pin voltage supplies the internal control circuits of the device and provides the input voltage to the power
converter system. The input voltage for VIN can range from 4.5 V to 17 V. The device implements internal UVLO
circuitry on the VIN pin. The device is disabled when the VIN pin voltage falls below the internal VIN UVLO
threshold. The internal VIN UVLO threshold has a hysteresis of 200 mV. A voltage divider connected to the EN
pin can adjust the input voltage UVLO appropriately. See Enable and Adjustable UVLO for more details.
7.3.4 Voltage Reference and Adjusting the Output Voltage
The voltage reference system produces a precise ±0.85%, 0.6-V voltage reference over temperature by scaling
the output of a temperature stable band gap circuit. The output voltage is set with a resistor divider from the
output (VOUT) to the FB pin shown in Figure 26. TI recommends using 1%-tolerance or better divider resistors.
Start with a fixed value for the bottom resistor in the divider, typically 5.1 kΩ or less, then use Equation 1 to
calculate the top resistor in the divider. If the values are too high the regulator is more susceptible to noise and
voltage errors from the FB input current are noticeable. If the values too high and if switching stops after low-side
reverse current limit trips or when in thermal shutdown, bias current out of the SW pin can charge up the output
voltage. Using 5.1-kΩ bottom resistance or less prevents the bias current out of the SW pin from charging the
output voltage above the set value. Larger resistance may be used if his bias current is accounted for. The
minimum output voltage and maximum output voltage can be limited by the minimum on time of the high-side
MOSFET and bootstrap voltage (BOOT-SW voltage), respectively.
VOUT
TPS54A24
RFBT
FB
RFBB
0.6 V
+
Copyright © 2018, Texas Instruments Incorporated
Figure 26. FB Resistor Divider
RFBT
§V
RFBB u ¨ OUT
© VREF
·
1¸
¹
(1)
7.3.5 Error Amplifier
The device uses a transconductance error amplifier. The error amplifier compares the FB pin voltage to the lower
of the SS/TRK pin voltage or the internal 0.6-V voltage reference. The transconductance of the error amplifier is
1100 μA/V. The frequency compensation network is connected between the COMP pin and ground.
When operating at current limit the COMP pin voltage is clamped to a maximum level to improve response when
the load current decreases. When FB is greater than the internal voltage reference or SS/TRK the COMP pin
voltage is clamped to a minimum level and the devices enters a high-side skip mode.
14
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
Feature Description (continued)
7.3.6 Enable and Adjustable UVLO
The EN pin provides on/off control of the device. Once the EN pin voltage exceeds its threshold voltage, the
device starts operation. If the EN pin voltage is pulled below the threshold voltage, the regulator stops switching
and enters low operating current state. The EN pin has an internal pullup current source, Ip, allowing the user to
float the EN pin for enabling the device. If an application requires controlling the EN pin, an open drain or open
collector output logic can be interfaced with the pin.
An external resistor divider can be added from VIN to the EN pin for adjustable UVLO and hysteresis as shown
in Figure 27. The EN pin has a small pullup current Ip which sets the default state of the pin to enable when no
external components are connected. The pullup current is also used to control the voltage hysteresis for the
UVLO function since it increases by Ih once the EN pin crosses the enable threshold. The UVLO thresholds can
be calculated using Equation 2 and Equation 3. When using the adjustable UVLO function, 500 mV or greater
hysteresis is recommended. For applications with very slow input voltage slew rate, a capacitor can be placed
from the EN pin to ground to filter any glitches on the input voltage.
TPS54A24
VIN
Ip
Ih
RENT
EN
+
RENB
Copyright © 2018, Texas Instruments Incorporated
Figure 27. Adjustable UVLO Using EN
RENT
§V
·
VSTART u ¨ ENFALLING ¸ VSTOP
V
© ENRISING ¹
§
·
V
Ip u ¨ 1 ENFALLING ¸ Ih
VENRISING ¹
©
(2)
vertical spacer
RENB
RENT u VENFALLING
VSTOP
VENFALLING
RENT u Ip
Ih
(3)
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
15
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
Feature Description (continued)
7.3.7 Soft Start and Tracking
The TPS54A24 regulates to the SS/TRK pin while its voltage is lower than the internal reference to implement
soft start. A capacitor on the SS/TRK pin to ground sets the soft start time. The SS/TRK pin has an internal
pullup current source of 5 μA that charges the external soft start capacitor. Equation 4 calculates the required
soft start capacitor value. The FB voltage will follow the SS/TRK pin voltage with a 25 mV offset up to 90% of the
internal voltage reference. When the SS/TRK voltage is greater than 90% of the internal reference voltage the
offset increases as the effective system reference transitions from the SS/TRK voltage to the internal voltage
reference.
CSS nF
ISS µA u tSS ms
VREF V
8.3 u t SS ms
(4)
If during normal operation, VIN goes below the UVLO, EN pin pulled below 1.15 V, or a thermal shutdown event
occurs, the TPS54A24 stops switching and the SS/TRK pin floats. When the VIN goes above UVLO, EN goes
above 1.2 V, or a thermal shutdown is exited, the SS/TRK pin is discharged to near ground before reinitiating a
powering up sequence.
When the COMP pin voltage is clamped by the maximum COMP clamp in an overload condition the SS/TRK pin
is discharged to near the FB voltage. When the overload condition is removed, the soft-start circuit controls the
recovery from the fault output level to the nominal output regulation voltage. At the beginning of recovery a spike
in the output voltage may occur while the COMP voltage transitions from the maximum clamp to the value
determined by the loop.
If a nominal SS/TRK capacitance of 22 nF or greater is used, TI recommends adding a 470-kΩ to 1-MΩ resistor
in parallel with the SS/TRK capacitor. With higher SS/TRK capacitance and if the EN pin voltage goes low then
high quickly, the SS/TRK capacitor may not fully discharge before switching begins. Adding this resistor helps
discharge the SS/TRK capacitor. For the SS capacitor to fully discharge, disable the TPS54A24 for a time period
equal to 3 times the RC time constant of the SS/TRK capacitor and the added resistor.
7.3.8 Safe Start-Up Into Prebiased Outputs
The device has been designed to prevent the low-side MOSFET from discharging a pre-biased output. During
prebiased startup, the low-side MOSFET is not allowed to sink current until the SS/TRK pin voltage is higher
than the FB pin voltage and the high-side MOSFET begins to switch. The one exception is if the BOOT-SW
voltage is below the UVLO threshold. While in BOOT-SW UVLO, the low-side MOSFET is allowed to turn on to
charge the BOOT capacitor. The low-side MOSFET reverse current protection provides another layer of
protection for the device after the high-side MOSFET begins to switch.
7.3.9 Power Good
The PGOOD pin is an open-drain output requiring an external pullup resistor to output a high signal. Once the FB
pin is between 91% and 106% of the internal voltage reference and SS/TRK is greater than 0.75 V, after a 272
cycle deglitch time the PGOOD pin is de-asserted and the pin floats. A pullup resistor between the values of 10
kΩ and 100 kΩ to a voltage source that is 6.5 V or less is recommended. PGOOD is in a defined state once the
VIN input voltage is greater than 1 V but with reduced current sinking capability.
When the FB is lower than 89% or greater than 108% of the nominal internal reference voltage, after a 16 cycle
deglitch time the PGOOD pin is pulled low. PGOOD is immediately pulled low if VIN falls below its UVLO, EN pin
is pulled low or the TPS54A24 enters thermal shutdown.
16
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
Feature Description (continued)
7.3.10 Sequencing (SS/TRK)
Many of the common power supply sequencing methods can be implemented using the SS/TRK, EN and
PGOOD pins.
The sequential method is illustrated in Figure 28 using two TPS54A24 or similar devices. The power good of the
first device is coupled to the EN pin of the second device which enables the second power supply once the
primary supply reaches regulation.
Figure 29 shows the method implementing ratiometric sequencing by connecting the SS/TRK pins of two devices
together. The regulator outputs ramp up and reach regulation at the same time. When calculating the soft-start
time the current source must be doubled in Equation 4.
TPS54A24
TPS54A24
TPS54A24
PGOOD
EN
EN
SS/TRK
SS/TRK
EN
PGOOD
SS/TRK
PGOOD
Copyright © 2018, Texas Instruments Incorporated
TPS54A24
EN
SS/TRK
PGOOD
Copyright © 2018, Texas Instruments Incorporated
Figure 28. Sequential Start-Up Sequence
Figure 29. Ratiometric Start-Up Sequence
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
17
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
Feature Description (continued)
Ratiometric and simultaneous power supply sequencing can be implemented by connecting the resistor network
of RTRT and RTRB shown in Figure 30 to the output of the power supply that needs to be tracked or another
voltage reference source. Using Equation 6 and Equation 7, the tracking resistors can be calculated to initiate the
VOUT2 slightly before, after or at the same time as VOUT1. Equation 5 is the voltage difference between VOUT1 and
VOUT2.
To design a ratiometric start-up in which the VOUT2 voltage is slightly greater than the VOUT1 voltage when VOUT2
reaches regulation, use a negative number in Equation 6 and Equation 7 for ΔV. Equation 5 results in a positive
number for applications where the VOUT2 is slightly lower than VOUT1 when VOUT2 regulation is achieved.
The ΔV variable is zero volts for simultaneous sequencing. To minimize the effect of the inherent SS/TRK to FB
offset (Vssoffset = 25 mV) in the soft-start circuit and the offset created by the pullup current source (Iss = 5 μA)
and tracking resistors, the Vssoffset and Iss are included as variables in the equations.
When the TPS54A24 is enabled, an internal switch at the SS/TRK pin turns on to discharge the SS/TRK voltage
to near ground as described in Soft Start and Tracking. The SS/TRK pin voltage must discharge low enough
before the TPS54A24 starts up. If there is voltage on VOUT1 and the upper resistor at the SS/TRK pin is too
small, the SS/TRK pin cannot discharge low enough and VOUT2 does not ramp up. The upper resistor in the
SS/TRK divider may need to be increased to allow the SS/TRK pin to drop close enough to ground. To ensure
proper startup of VOUT2 , the calculated RTRT value from Equation 6 must be greater than the value calculated in
Equation 8. Calculate RTRB using the final value of RTRT.
'V
VOUT1 VOUT2
(5)
vertical spacer
RTRT
VOUT2 'V Vssoffset
u
VREF
Iss
(6)
vertical spacer
RTRB
VREF u RTRT
VOUT2 'V VREF
(7)
vertical spacer
RTRT ! 20000 u VOUT1
(8)
As described in Power Good, for the PGOOD output to be active the SS/TRK voltage must be above 0.75 V. The
external divider may prevent the SS/TRK voltage from charging above the threshold. For the SS/TRK pin to
charge above the threshold, a switch may be needed to disconnect the resistor divider or modify the resistor
divider ratio of the VOUT2 converter after start-up is complete. The PGOOD pin of the VOUT1 converter could be
used for this. One solution is to add a resistor from SS/TRK of the VOUT2 converter to the PGOOD of the VOUT1
converter. While the PGOOD of VOUT1 pulls low, this resistor is in parallel with RTRB. When VOUT1 is in regulation
its PGOOD pin will float. If the PGOOD pin of VOUT1 is connected to a pullup voltage, make sure to include this in
calculations. A second option is to use the PGOOD pin to turn on or turn off the external switch to change the
divide ratio.
18
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
Feature Description (continued)
TPS54A24
VOUT1
EN
SS/TRK
PGOOD
TPS54A24
VOUT2
EN
RTRT
SS/TRK
RFBT
RTRB
PGOOD
RFBB
Copyright © 2018, Texas Instruments Incorporated
Figure 30. Ratiometric and Simultaneous Start-Up Sequence
7.3.11 Adjustable Switching Frequency (RT Mode)
In RT mode, a resistor (RT resistor) is connected between the RT/CLK pin and AGND. The switching frequency
of the device is adjustable from 200 kHz to 1600 kHz by placing a maximum of 250 kΩ and minimum of 30.1 kΩ
respectively. To determine the RT resistance for a given switching frequency, use Equation 9. To reduce the
solution size one would set the switching frequency as high as possible, but tradeoffs of the supply efficiency and
minimum controllable on-time must be considered. Equation 10 can be used to calculate the switching frequency
for a given RT resistance.
RT k:
58650 u fSW kHz
1.028
(9)
vertical spacer
fSW kHz
43660 u RT k:
0.973
(10)
7.3.12 Synchronization (CLK Mode)
An internal phase locked loop (PLL) has been implemented to allow synchronization from 200 kHz to 1600 kHz,
and to easily switch from RT mode to CLK mode. To implement the synchronization feature, connect a square
wave clock signal to the RT/CLK pin with a duty cycle from 20% to 80%. If the clock signals rising edge occurs
near the falling edge of SW, increased SW jitter may occur. Use Equation 11 to calculate the maximum clock
pulse width to minimize jitter in CLK mode. The clock signal amplitude must transition lower than 0.8 V and
higher than 2 V. The start of the switching cycle is synchronized to the falling edge of the RT/CLK pin.
æ
ö
V
0.75 ´ ç 1 - OUT ÷
ç
VIN(min ) ÷
è
ø
CLK _ PWMAX =
fSW
(11)
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
19
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
Feature Description (continued)
In applications where both RT mode and CLK mode are needed, the device can be configured as shown in
Figure 31. Before the external clock is present, the device works in RT mode and the switching frequency is set
by RT resistor. When the external clock is present, the CLK mode overrides the RT mode. The first time the
SYNC pin is pulled above the RT/CLK high threshold (2 V), the device switches from the RT mode to the CLK
mode and the RT/CLK pin becomes high impedance as the PLL starts to lock onto the frequency of the external
clock.
If the input clock goes away the internal clock frequency begins to drop and after 10 µs without a clock the
device returns to RT mode. Output undershoot while the switching frequency drops can occur. Output overshoot
can also occur when the switching frequency steps back up to the RT mode frequency. A high impedance tristate buffer as shown in Figure 33 is recommended for best performance during the transition from CLK mode to
RT mode because it minimizes the loading on the RT/CLK pin allowing faster transition back to RT mode.
Figure 34 shows the typical performance for the transition from RT mode to CLK mode then back to RT mode.
A series RC circuit as shown in Figure 32 can also be used to interface the RT/CLK pin but the capacitive load
slows down the transition back to RT mode. The series RC circuit is not recommended if the transition from CLK
mode to RT mode is important. A capacitor in the range of 47 pF to 470 pF is recommended. When using the
series RC circuit verify the amplitude of the signal at the RT/CLK pin goes above the high threshold.
RT/CLK Mode Select
TPS54A24
TPS54A24
RT/CLK
2k
47 pF
RT/CLK
RT
RT
Copyright © 2018, Texas Instruments Incorporated
Copyright © 2018, Texas Instruments Incorporated
Figure 31. Simplified Circuit When Using Both RT
Mode and CLK Mode
TPS54A24
OE
Figure 32. Interfacing to the RT/CLK Pin with
Series RC
CH2: VOUT DC OFFSET
RT/CLK
RT
CH3: RT/CLK
CH1: SW
Copyright © 2018, Texas Instruments Incorporated
VIN = 12 V, IOUT = 4 A,
VOUT = 3.3 V, fsw = 1.2 MHz
Figure 33. Interfacing to the RT/CLK Pin with
Buffer
20
Figure 34. RT to CLK to RT Transition with Buffer
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
Feature Description (continued)
7.3.13 Bootstrap Voltage and 100% Duty Cycle Operation (BOOT)
The device provides an integrated bootstrap-voltage regulator. A small capacitor between the BOOT and SW
pins provides the gate-drive voltage for the high-side MOSFET. The BOOT capacitor is refreshed when the lowside MOSFET is on. The recommended value of the BOOT capacitor is 0.1 μF. A ceramic capacitor with an X7R
or X5R grade dielectric with a voltage rating of 10 V or higher is recommended for stable performance over
temperature and voltage.
When operating with a low voltage difference from input to output, the high-side MOSFET of the device operate
at 100% duty cycle as long as the BOOT to SW pin voltage is greater than 2.2 V. The device begins to transition
to 100% duty cycle operation when the high-side MOSFET off-time is less than 200 ns typical. Equation 12 can
be used to estimate the input voltage the switching frequency begins to decrease. When the switching frequency
decreases the BOOT to SW capacitor is not recharged as often so the BOOT to SW voltage will start to
decrease. If the voltage from BOOT to SW drops below 2.2 V, the high-side MOSFET is turned off due to BOOT
UVLO and the low-side MOSFET pulls SW low to recharge the BOOT capacitor. When operating at 100% duty
cycle the high-side MOSFET can remain on for many switching cycles before the MOSFET is turned off to
refresh the capacitor because the gate drive current sourced by the BOOT capacitor is small. The effective
switching frequency reduced and the effective maximum duty cycle of the switching regulator is near 100%. The
output voltage of the converter during dropout is mainly influenced by the voltage drops across the power
MOSFET, the inductor resistance, and the printed circuit board resistance.
VOUT
VIN
RDS (LS) RDCR u IOUT
1 tOFF u fSW
RDS (HS) RDS (LS) u IOUT
where
•
•
•
•
RDS(LS) = low-side MOSFET RDS(on)
RDS(HS) = high-side MOSFET RDS(on)
RDCR = DC resistance of inductor
tOFF = off-time that 100% duty cycle operation begins
(12)
7.3.14 Output Overvoltage Protection (OVP)
The TPS54A24 incorporates an output overvoltage protection (OVP) circuit to minimize output voltage overshoot.
The OVP feature minimizes the overshoot by comparing the FB pin voltage to the OVP threshold. The OVP
threshold is the same as the 108% PGOOD threshold. If the FB pin voltage is greater than the OVP threshold
the high-side MOSFET is turned off preventing current from flowing to the output and minimizing output
overshoot. When the high-side MOSFET turns off, the low-side MOSFET turns on and the current in the inductor
discharges. The output voltage can overshoot the OVP threshold as the current in the inductor discharges to 0 A.
When the FB voltage drops lower than the 106% PGOOD threshold, the high-side MOSFET is allowed to turn on
at the next clock cycle.
7.3.15 Overcurrent Protection
The device is protected from overcurrent conditions by cycle-by-cycle current limiting on both the high-side
MOSFET and the low-side MOSFET. In an extended overcurrent condition the device enters hiccup to reduce
power dissipation. Figure 35 shows the typical response with an overload on the output. At time (1) the high-side
MOSFET peak current limit starts to limit the peak inductor current. At time (2) the low-side MOSFET forward
current limit starts to cause the switching frequency to drop to prevent current runaway.
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
21
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
Feature Description (continued)
(1)
(2)
Figure 35. Example Current Limit Waveform
7.3.15.1 High-Side MOSFET Overcurrent Protection
The device implements current mode control which uses the COMP pin voltage to control the turnoff of the highside MOSFET and the turnon of the low-side MOSFET on a cycle-by-cycle basis. Each cycle the switch current
and the current reference generated by the COMP pin voltage are compared, when the peak switch current
intersects the current reference the high-side switch is turned off. The maximum peak switch current through the
high-side MOSFET for overcurrent protection is done by limiting the current reference internally. If the peak
current required to regulate the output is greater than the internal limit, the output voltage is pulled low and the
error amplifier responds by driving the COMP pin high. The maximum COMP voltage is then clamped by an
internal COMP clamp circuit. If the COMP voltage is clamped high for more than the hiccup wait time of 512
switching cycles, the device will shut down itself and restart after the hiccup time of 16384 cycles.
7.3.15.2 Low-Side MOSFET Overcurrent Protection
While the low-side MOSFET is turned on the current through it is monitored. During normal operation the lowside MOSFET sources current to the load. At the end of every clock cycle, the low-side MOSFET sourcing
current is compared to the internally set low-side sourcing current limit. If the low-side sourcing current is
exceeded the high-side MOSFET is not turned on and the low-side MOSFET stays on for the next cycle. The
high-side MOSFET is turned on again when the low-side current is below the low-side sourcing current limit at
the start of a cycle. The low-side sourcing current limit prevents current runaway.
The low-side MOSFET may also sink current from the load. If the low-side sinking current limit is exceeded the
low-side MOSFET is turned off immediately for the rest of that clock cycle. In this scenario both MOSFETs are
off until the start of the next cycle. If the low-side MOSFET turns off due to sinking current limit protection, the
low-side MOSFET can only turn on again after the high-side MOSFET turns on then off or if the device enters
BOOT UVLO.
7.4 Device Functional Modes
The EN pin and a VIN UVLO is used to control turn on and turn off of the TPS54A24. The device becomes active
when V(VIN) exceeds the 4.1 V typical UVLO and when V(EN) exceeds 1.20 V typical. The EN pin has an internal
current source to enable the output when the EN pin is left floating. If the EN pin is pulled low the device is put
into a low quiescent current state.
22
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
8 Application and Implementation
NOTE
Information in the following applications sections is not part of the TI component
specification, and TI does not warrant its accuracy or completeness. TI’s customers are
responsible for determining suitability of components for their purposes. Customers should
validate and test their design implementation to confirm system functionality.
8.1 Application Information
The TPS54A24 is a synchronous buck converter designed for 4.5 V to 17 V input and 10-A load. This procedure
illustrates the design of a high-frequency switching regulator using ceramic output capacitors. Alternatively the
WEBENCH® software can be used to generate a complete design. The WEBENCH® software uses an interactive
design procedure and accesses a comprehensive database of components when generating a design. This
section presents a simplified discussion of the design process.
8.2 Typical Application
Figure 36. TPS54A24 4.5-V to 17-V Input, 1.8-V Output Converter Application Schematic
8.2.1 Design Requirements
For this design example, use the parameters shown in Table 1.
Table 1. Design Parameters
PARAMETER
EXAMPLE VALUE
Input voltage range (VIN)
4.5 to 17 V, 12 V nominal
Output voltage (VOUT)
1.8 V
Transient response
± 4%, ± 72 mV
Output ripple voltage
0.5%, 9 mV
Output current rating (IOUT)
10 A
Operating frequency (fSW)
500 kHz
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
23
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
8.2.2 Detailed Design Procedure
8.2.2.1 Custom Design With WEBENCH® Tools
Click here to create a custom design using the TPS54A24 device with the WEBENCH® Power Designer.
1. Start by entering the input voltage (VIN), output voltage (VOUT), and output current (IOUT) requirements.
2. Optimize the design for key parameters such as efficiency, footprint, and cost using the optimizer dial.
3. Compare the generated design with other possible solutions from Texas Instruments.
The WEBENCH Power Designer provides a customized schematic along with a list of materials with real-time
pricing and component availability.
In most cases, these actions are available:
• Run electrical simulations to see important waveforms and circuit performance
• Run thermal simulations to understand board thermal performance
• Export customized schematic and layout into popular CAD formats
• Print PDF reports for the design, and share the design with colleagues
Get more information about WEBENCH tools at www.ti.com/WEBENCH.
8.2.2.2 Switching Frequency
The first step is to decide on a switching frequency for the converter. The TPS54A24 is capable of running from
200 kHz to 1.6 MHz. Typically the highest switching frequency possible is desired because it produces the
smallest solution size. A high switching frequency allows for smaller inductors and output capacitors compared to
a power supply that switches at a lower frequency. The main trade off made with selecting a higher switching
frequency is extra switching power loss, which hurt the converter’s efficiency.
The maximum switching frequency for a given application is limited by the minimum on-time of the converter and
is estimated with Equation 13. Using a maximum minimum on-time of 150 ns for the TPS54A24 and 17 V
maximum input voltage for this application, the maximum switching frequency is 706 kHz. The selected switching
frequency must also consider the 10% tolerance of the switching frequency. A switching frequency of 500 kHz
was selected for a good balance of solution size and efficiency. Equation 14 calculates R7 (RT) to be 97.6 kΩ. A
standard 1% value of 100 kΩ was chosen in the design.
VOUT
1
fSW max
u
tonmin VIN max
(13)
vertical spacer
RT k:
58650 u fSW kHz
1.028
(14)
8.2.2.3 Output Inductor Selection
To calculate the value of the output inductor, use Equation 15. KIND is a ratio that represents the amount of
inductor ripple current relative to the maximum output current. The inductor ripple current is filtered by the output
capacitor. Therefore, choosing high inductor ripple currents impacts the selection of the output capacitor since
the output capacitor must have a ripple current rating equal to or greater than the inductor ripple current.
Additionally with current mode control the sensed inductor current ripple is used in the PWM modulator.
Choosing small inductor ripple currents can degrade the transient response performance or introduce jitter in the
high-side MOSFET on-time. The inductor ripple, KIND, is normally from 0.1 to 0.4 for the majority of applications
giving a peak to peak ripple current range of 1 A to 4 A. For applications requiring operation near the minimum
on-time, with on-times less than 200 ns, the target Iripple must be 2 A or larger for best performance. For other
applications the target Iripple must be 1 A or larger.
For this design example, KIND = 0.3 is used and the inductor value is calculated to be 1.07 µH. The nearest
standard value 1 µH is selected. It is important that the RMS (Root Mean Square) current and saturation current
ratings of the inductor not be exceeded. The RMS and peak inductor current can be found from Equation 17 and
Equation 18. For this design, the RMS inductor current is 10 A, and the peak inductor current is 11.6 A. The
chosen inductor is a 74437358010. It has a saturation current rating of 32.5 A and a RMS current rating of 14 A.
The DC series resistance is 3.65 mΩ typical.
24
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
The current flowing through the inductor is the inductor ripple current plus the output current. During power up,
faults or transient load conditions, the inductor current can increase above the calculated peak inductor current
level calculated in Equation 18. In transient conditions, the inductor current can increase up to the switch current
limit of the device. For this reason, the most conservative approach is to specify the ratings of the inductor based
on the switch current limit rather than the steady-state peak inductor current.
Vinmax - Vout
Vout
´
L1 =
Io ´ Kind
Vinmax ´ ¦ sw
(15)
vertical spacer
Iripple =
Vinmax - Vout
Vout
´
L1
Vinmax ´ ¦ sw
(16)
vertical spacer
ILrms =
Io 2 +
æ Vo ´ (Vinmax - Vo) ö
1
´ ç
÷
12
è Vinmax ´ L1 ´ ¦ sw ø
2
(17)
vertical spacer
ILpeak = Iout +
Iripple
2
(18)
8.2.2.4 Output Capacitor
There are two primary considerations for selecting the value of the output capacitor. The output voltage ripple
and how the regulator responds to a large change in load current. The output capacitance needs to be selected
based on the more stringent of these two criteria.
The desired response to a large change in the load current is the first criteria and is typically the most stringent.
A regulator does not respond immediately to a large, fast increase or decrease in load current. The output
capacitor supplies or absorbs charge until the regulator responds to the load step. The control loop needs to
sense the change in the output voltage then adjust the peak switch current in response to the change in load.
The minimum output capacitance is selected based on an estimate of the loop bandwidth. Typically the loop
bandwidth is near fSW/10. Equation 19 estimates the minimum output capacitance necessary, where ΔIOUT is the
change in output current and ΔVOUT is the allowable change in the output voltage.
For this example, the transient load response is specified as a 4% change in VOUT for a load step of 5 A.
Therefore, ΔIOUT is 5 A and ΔVOUT is 72 mV. Using this target gives a minimum capacitance of 221 μF. This
value does not take the ESR of the output capacitor into account in the output voltage change. For ceramic
capacitors, the effect of the ESR can be small enough to be ignored. Aluminum electrolytic and tantalum
capacitors have higher ESR that must be considered for load step response.
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
25
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
Equation 20 calculates the minimum output capacitance needed to meet the output voltage ripple specification.
Where fsw is the switching frequency, Vripple is the maximum allowable output voltage ripple, and Iripple is the
inductor ripple current. In this case, the target maximum output voltage ripple is 9 mV. Under this requirement,
Equation 20 yields 89.4 µF.
vertical spacer
'I
COUT ! OUT u
'VOUT
1
f
2S u SW
10
(19)
vertical spacer
Co >
1
´
8 ´ ¦ sw
1
Voripple
Iripple
where
•
•
•
ΔIOUT is the change in output current
ΔVOUT is the allowable change in the output voltage
fsw is the regulators switching frequency
(20)
Equation 21 calculates the maximum combined ESR the output capacitors can have to meet the output voltage
ripple specification, and this shows the ESR should be less than 3 mΩ. In this case ceramic capacitors are used,
and the combined ESR of the ceramic capacitors in parallel is much less than 3 mΩ. Capacitors also have limits
to the amount of ripple current they can handle without producing excess heat and failing. An output capacitor
that can support the inductor ripple current must be specified. The capacitor datasheet specifies the RMS value
of the maximum ripple current. Equation 22 can be used to calculate the RMS ripple current the output capacitor
needs to support. For this application, Equation 22 yields 930 mA and ceramic capacitors typically have a ripple
current rating much higher than this.
Voripple
Resr <
Iripple
(21)
vertical spacer
Icorm s =
Vout ´ (Vinm ax - Vout)
12 ´ Vinm ax ´ L1 ´ ¦ sw
(22)
Select X5R and X7R ceramic dielectrics or equivalent for power regulator capacitors because they have a high
capacitance to volume ratio and are fairly stable over temperature. The output capacitor must also be selected
with the DC bias and AC voltage derating taken into account. The derated capacitance value of a ceramic
capacitor due to DC voltage bias and AC RMS voltage is usually found on the capacitor manufacturer's website.
For this application example, three 100 µF 6.3 V 1210 X7S ceramic capacitors each with 2 mΩ of ESR are used.
The estimated capacitance after derating using the capacitor manufacturer's website is 64 µF each. With three
parallel capacitors the total effective output capacitance is 192 µF and the ESR is 0.7 mΩ. Although this is below
the estimated value of 221 µF to meet the load step response requirement, bench evaluation showed this
amount of capacitance to be sufficient.
8.2.2.5 Input Capacitor
The TPS54A24 requires input decoupling ceramic capacitors type X5R, X7R or similar from VIN to PGND placed
as close as possible to the IC. A total of at least 10 µF of capacitance is required and some applications may
require a bulk capacitance. At least 1 µF of bypass capacitance is recommended near both VIN pins to minimize
the input voltage ripple. A 0.1-µF to 1-µF capacitor must be placed by both VIN pins 2-3 and 16-17 to provide
high frequency bypass to reduce the high frequency overshoot and undershoot on VIN and SW pins. The voltage
rating of the input capacitor must be greater than the maximum input voltage. The capacitor must also have a
ripple current rating greater than the maximum RMS input current of the TPS54A24. The RMS input current can
be calculated using Equation 23.
26
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
For this example design, a ceramic capacitor with at least a 25-V voltage rating is required to support the
maximum input voltage. Two 10-µF, 1210, X7R, 25-V and two 0.1-μF, 0603, X7R 25-V capacitors in parallel has
been selected to be placed on both sides of the TPS54A24 near both VIN pins to PGND pins. Based on the
capacitor manufacturer's website, the total ceramic input capacitance derates to 14 µF at the nominal input
voltage of 12 V. A 100-µF bulk capacitance is also used in this circuit to bypass long leads when connected a lab
bench top power supply.
The input capacitance value determines the input ripple voltage of the regulator. The input voltage ripple can be
calculated using Equation 24. The maximum input ripple occurs when operating nearest to 50% duty cycle. Using
the nominal design example values of Ioutmax = 10 A, CIN = 14 μF, and fSW = 500 kHz, the input voltage ripple
with the 12 V nominal input is 150 mV and the RMS input ripple current with the 4.5 V minimum input is 4.9 A.
Icirms = Iout ´
Vout
´
Vinmin
(Vinmin
- Vout )
Vinmin
(23)
vertical spacer
'Vin
Vout · Vout
§
u
Iout maxu ¨ 1
Vin ¸¹ Vin
©
Cin u fSW
(24)
8.2.2.6 Output Voltage Resistors Selection
The output voltage is set with a resistor divider created by R8 (RFBT) and R6 (RFBB) from the output node to the
FB pin. It is recommended to use 1% tolerance or better resistors. For this example design, 6.04 kΩ was
selected for R8. Using Equation 25, R6 is calculated as 12.08 kΩ. The nearest standard 1% resistor is 12.1 kΩ.
RFBT
§V
RFBB u ¨ OUT
© VREF
·
1¸
¹
(25)
8.2.2.7 Soft-Start Capacitor Selection
The soft-start capacitor (CSS = C16) determines the amount of time it takes for the output voltage to reach its
nominal programmed value during power up. This is useful if a load requires a controlled voltage slew rate. This
is also used if the output capacitance is very large and would require large amounts of current to quickly charge
the capacitor to the output voltage level. The large currents necessary to charge the capacitor may make the
TPS54A24 reach its current limit or cause the input voltage rail to sag due excessive current draw from the input
power supply. Limiting the output voltage slew rate solves both of these problems. The soft-start capacitor value
can be calculated using Equation 26. For the example circuit, the soft-start time is not critical because the output
capacitor value of 3 × 100 μF does not require much current to charge to 1.8 V. The example circuit has the softstart time set to an arbitrary value of 1.2 ms, which requires a 0.01-µF capacitor. With this soft-start time the
current required to charge the output capacitors is only 0.18 A.
CSS nF
ISS µA u tSS ms
VREF V
8.3 u t SS ms
(26)
8.2.2.8 Undervoltage Lockout Setpoint
The undervoltage lockout (UVLO) is adjusted using the external voltage divider network of R2 (RENT) and R9
(RENB). The UVLO has two thresholds; one for power up when the input voltage is rising and one for power down
or brownouts when the input voltage is falling. For the example design, the supply must turn on and start
switching once the input voltage increases above 4.5 V (UVLO start or enable). After the regulator starts
switching, it continues to do so until the input voltage falls below 4.0 V (UVLO stop or disable). Equation 2 and
Equation 3 can be used to calculate the values for the upper and lower resistor values. For the voltages
specified, the standard resistor value used for RENT is 86.6 kΩ and for RENB is 30.9 kΩ.
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
27
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
8.2.2.9 Bootstrap Capacitor Selection
A 0.1-µF ceramic capacitor must be connected between the BOOT to SW pin for proper operation. A 1 Ω to 5.6
Ω resistor can be added in series with the BOOT capacitor to slow down the turn on of the high-side MOSFET.
This can reduce voltage spikes on the SW node with the trade off of more power loss and lower efficiency.
8.2.2.10 PGOOD Pullup Resistor
A 100-kΩ resistor is used to pull up the power good signal when FB conditions are met. The pullup voltage
source must be less than the 6.5 V absolute maximum of the PGOOD pin.
8.2.2.11 Compensation
There are several methods used to compensate DC/DC regulators. The method presented here is easy to
calculate and ignores the effects of the slope compensation internal to the device. Because the slope
compensation is ignored, the actual cross-over frequency will usually be lower than the cross-over frequency
used in the calculations. This method assumes the cross-over frequency is between the modulator pole and the
ESR zero and the ESR zero is at least 10 times greater the modulator pole. This is the case when using low
ESR output capacitors. Use the WEBENCH® software for more accurate loop compensation. These tools include
a more comprehensive model of the control loop.
To get started, the modulator pole, fpmod, and the ESR zero, fzmod must be calculated using Equation 27 and
Equation 28. For COUT, use a derated value of 192 μF and an ESR of 0.7 mΩ. Use equations Equation 29 and
Equation 30, to estimate a starting point for the crossover frequency, fco, to design the compensation. For the
example design, fpmod is 7.2 kHz and fzmod is 1940 kHz. Equation 29 is the geometric mean of the modulator
pole and the ESR zero. Equation 30 is the mean of modulator pole and one half the switching frequency.
Equation 29 yields 118 kHz and Equation 30 yields 42.4 kHz. Use the lower value of Equation 29 or Equation 30
for an initial crossover frequency. Next, the compensation components are calculated. A resistor in series with a
capacitor is used to create a compensating zero. A capacitor in parallel to these two components forms the
compensating pole.
Ioutmax
¦p mod =
2 × p × Vout × Cout
(27)
vertical spacer
¦ z mod =
1
2 ´ p ´ Resr × Cout
(28)
vertical spacer
fco =
f p mod ´ f z mod
(29)
vertical spacer
fco =
f p mod ´
f sw
2
(30)
To determine the compensation resistor (RCOMP = R5) use Equation 31. RCOMP is calculated to be 5.26 kΩ and
the closest standard value 5.23 kΩ. Use Equation 32 to set the compensation zero to the modulator pole
frequency. Equation 32 yields 2120 pF for compensating capacitor (CCOMP = C14); round this up to the next
standard value of 2200 pF.
§ 2 u S u fCO u COUT · §
·
VOUT
RCOMP ¨
¸u¨
¸
gmPS
©
¹ © VREF u gmEA ¹
where
•
•
•
•
CCOMP
28
Power stage transconductance, gmPS = 17 A/V
VOUT = 1.8 V
VREF = 0.6 V
Error amplifier transconductance, gmEA = 1100 µA/V
1
2 u S u RCOMP u fPMOD
(31)
(32)
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
A compensation pole is implemented using an additional capacitor (CHF = C13) in parallel with the series
combination of RCOMP and CCOMP. This capacitor is recommended to help filter any noise that may couple to the
COMP voltage signal. Use the larger value of Equation 33 and Equation 34 to calculate the CHF and to set the
compensation pole. CHF is calculated to be the largest of 16 pF and 112 pF. Round this down to the next
standard value of 100 pF.
COUT u RESR
CHF
RCOMP
(33)
vertical spacer
CHF
1
S u RCOMP u fSW
(34)
Type III compensation can be used by adding the feed forward capacitor (CFF = C15) in parallel with the upper
feedback resistor. Type III compensation adds phase boost above what is possible from type II compensation
because it places an additional zero/pole pair. The zero/pole pair is not independent. As a result once the zero
location is chosen, the pole is fixed as well. The zero is placed at 1/2 the fSW by calculating the value of CFF with
Equation 35. The calculated value is 53 pF — round this down to the closest standard value of 47 pF. It is
possible to use larger feedforward capacitors to further improve the transient response but take care to ensure
there is a minimum of -10 dB gain margin at 1/2 the fSW in all operating conditions. The feedforward capacitor
injects noise on the output into the FB pin and this added noise can result in more jitter at the switching node. To
little gain margin can cause a repeated wide and narrow pulse behavior.
1
CFF
S u RFBT u fSW
(35)
The initial compensation based on these calculations is RCOMP = 5.23 kΩ, CCOMP = 2200 pF, CHF = 100 pF and
CFF = 47 pF. These values yield a stable design but after testing the real circuit these values were changed to
target a higher crossover frequency to improve transient response performance. The crossover frequency is
increased by increasing the value of R5 and decreasing the value of the compensation capacitors. The final
values used in this example are RCOMP = 10.0 kΩ, CCOMP = 2700 pF, CHF = 22 pF and CFF = 100 pF.
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
29
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
8.2.3 Application Curves
100
100
95
90
80
90
Efficiency (%)
Efficiency (%)
70
85
80
75
60
50
40
30
70
20
VIN = 5 V
VIN = 12 V
VIN = 17 V
65
60
0
1
2
3
TA = 25°C
4
5
6
Output Current (A)
7
8
9
VIN = 5 V
VIN = 12 V
VIN = 17 V
10
0
0.001
10
0.010.02 0.05 0.1 0.2 0.5
Output Current (A)
D001
VOUT = 1.8 V
fSW = 500 kHz
TA = 25°C
Figure 37. Efficiency
0.4
Output Voltage Regulation (%)
0.5
45
40
Temperature Rise (°C)
VOUT = 1.8 V
2 3 4 5 7 10
D002
fSW = 500 kHz
Figure 38. Efficiency (Log Scale)
50
35
30
25
20
15
10
TPS54A24
Inductor
5
1
0.3
0.2
0.1
0
-0.1
-0.2
-0.3
VIN = 5 V
VIN = 12 V
VIN = 17 V
-0.4
0
-0.5
0
1
2
3
VIN = 12 V
3 inch × 3 inch
EVM
4
5
6
Output Current (A)
7
VOUT = 1.8 V
4 layers
8
9
10
0
1
2
3
D006
fSW = 500 kHz
2 ounce copper
TA = 25°C
4
5
6
Output Current (A)
7
8
9
10
D003
VOUT = 1.8 V
fSW = 500 kHz
Figure 40. Load Regulation
Figure 39. Thermal Performance
0.5
60
180
40
120
20
60
0
0
0.3
0.2
0.1
Gain (dB)
Output Voltage Regulation (%)
0.4
0
-0.1
-20
-0.2
-0.3
IO = 0 A
IO = 5 A
IO = 10 A
-0.4
-0.5
4
5
6
7
TA = 25°C
8
9 10 11 12 13 14 15 16 17 18
Input Voltage (V)
D004
VOUT = 1.8 V
fSW = 500 kHz
-60
-40
-60
100 200
5001000
VIN = 12 V
Figure 41. Line Regulation
30
-120
Gain
Phase
10000
Frequency (Hz)
100000
VOUT = 1.8 V
-180
1000000
D005
ROUT = 0.3 Ω
Figure 42. Loop Response
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
VIN = 12 V
VOUT = 1.8 V
VIN = 12 V
Figure 43. Transient Response
VIN = 12 V
VOUT = 1.8 V
IOUT = 10 A
VOUT = 1.8 V
IOUT = 0 A
Figure 44. Output Ripple, No Load
VIN = 12 V
Figure 45. Output Ripple, 10-A Load
VIN = 12 V
VOUT = 1.8 V
IOUT = 10 A
VOUT = 1.8 V
IOUT = 0 A
Figure 46. Input Ripple, No Load
ROUT = 1 Ω
Figure 47. Input Ripple, 10-A Load
Figure 48. VIN Start-up
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
31
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
ROUT = 1 Ω
ROUT = 1 Ω
Figure 49. VIN Shutdown
Figure 50. EN Start-up
Figure 51. EN Shutdown
Figure 52. EN Start-up With Prebiased Output
ROUT = 1 Ω
VIN = 12 V
Load = short
VIN = 12 V
Figure 53. Output Short-Circuit Response
32
Submit Documentation Feedback
Load = short
Figure 54. Hiccup Current Limit
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
VIN = 12 V
Load = short
Figure 55. Hiccup Recovery
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
33
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
9 Power Supply Recommendations
The TPS54A24 is designed to be powered by a well-regulated DC voltage between 4.5 and 17 V. The
TPS54A24 is a buck converter so the input supply voltage must be greater than the desired output voltage to
regulate the output voltage to the desired value. If the input supply voltage is not high enough the output voltage
begins to drop. Input supply current must be appropriate for the desired output current.
10 Layout
10.1 Layout Guidelines
•
•
•
•
•
•
•
•
•
•
•
•
VIN and PGND traces must be as wide as possible to reduce trace impedance and improve heat dissipation.
At least 1 µF of input capacitance is required on both VIN pins of the IC and must be placed as close as
possible to the IC. The input capacitors must connect directly to the adjacent PGND pins.
Connect the PGND pins on both sides of the IC to the thermal pad with a trace as wide as possible to reduce
trace impedance and improve heat dissipation.
The PGND trace between the output capacitor and the PGND pin must be as wide as possible to minimize its
trace impedance.
Provide sufficient vias for the input capacitor and output capacitor.
Keep the SW trace as physically short and wide as practical to minimize radiated emissions.
Minimize the length of the trace connected to the BOOT pin and the BOOT capacitor to minimize radiated
emissions.
Connect a separate VOUT path to the upper feedback resistor.
Place voltage feedback loop away from the high-voltage switching trace. It is preferable to use ground copper
near it as a shield.
The trace connected to the FB node must be as small as possible to avoid noise coupling.
Place components connected to the RT/CLK, FB, COMP and SS/TRK pins as close to the IC as possible and
minimize traces connected to these pins to avoid noise coupling.
AGND must be connected to PGND on the PCB. Connect AGND to PGND in a region away from switching
currents.
10.2 Layout Example
Figure 56 through Figure 59 shows an example PCB layout and the following list provides a description of each
layer.
• The top layer has all components and the main traces for VIN, SW, VOUT and PGND. Both VIN pins are
bypassed with two input capacitors placed as close as possible to the IC and are connected directly to the
adjacent PGND pins. Multiple vias are placed near the input and output capacitors. The Net Tie (NT)
connects AGND to PGND near CIN4.
• Midlayer 1 has a solid PGND plane to aid with thermal performance. The other trace on this layer to connect
the PGOOD pin to the pullup resistor.
• Midlayer 2 has a wide trace connecting both VIN pins of the IC. It is also used to route the BOOT-SW
capacitor (CBT) to the SW node. It also has a parallel trace for VOUT to minimize trace resistance. The rest
of this layer is covered with PGND.
• The bottom layer has the trace connecting the FB resistor divider to VOUT at the point of regulation. PGND is
filled into the rest of this layer to aid with thermal performance.
34
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
TPS54A24
www.ti.com
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
Layout Example (continued)
Figure 56. TPS54A24 Layout Top
Figure 57. TPS54A24 Layout Midlayer 1
Figure 58. TPS54A24 Layout Midlayer 2
Figure 59. TPS54A24 Layout Bottom
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
35
TPS54A24
SLVSEQ0A – MAY 2019 – REVISED MARCH 2020
www.ti.com
11 Device and Documentation Support
11.1 Device Support
11.1.1 Development Support
11.1.1.1 Custom Design With WEBENCH® Tools
Click here to create a custom design using the TPS54A24 device with the WEBENCH® Power Designer.
1. Start by entering the input voltage (VIN), output voltage (VOUT), and output current (IOUT) requirements.
2. Optimize the design for key parameters such as efficiency, footprint, and cost using the optimizer dial.
3. Compare the generated design with other possible solutions from Texas Instruments.
The WEBENCH Power Designer provides a customized schematic along with a list of materials with real-time
pricing and component availability.
In most cases, these actions are available:
• Run electrical simulations to see important waveforms and circuit performance
• Run thermal simulations to understand board thermal performance
• Export customized schematic and layout into popular CAD formats
• Print PDF reports for the design, and share the design with colleagues
Get more information about WEBENCH tools at www.ti.com/WEBENCH.
11.2 Receiving Notification of Documentation Updates
To receive notification of documentation updates, navigate to the device product folder on ti.com. In the upper
right corner, click on Alert me to register and receive a weekly digest of any product information that has
changed. For change details, review the revision history included in any revised document.
11.3 Community Resources
TI E2E™ support forums are an engineer's go-to source for fast, verified answers and design help — straight
from the experts. Search existing answers or ask your own question to get the quick design help you need.
Linked content is provided "AS IS" by the respective contributors. They do not constitute TI specifications and do
not necessarily reflect TI's views; see TI's Terms of Use.
11.4 Trademarks
E2E is a trademark of Texas Instruments.
WEBENCH is a registered trademark of Texas Instruments.
All other trademarks are the property of their respective owners.
11.5 Electrostatic Discharge Caution
These devices have limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam
during storage or handling to prevent electrostatic damage to the MOS gates.
11.6 Glossary
SLYZ022 — TI Glossary.
This glossary lists and explains terms, acronyms, and definitions.
12 Mechanical, Packaging, and Orderable Information
The following pages include mechanical, packaging, and orderable information. This information is the most
current data available for the designated devices. This data is subject to change without notice and revision of
this document. For browser-based versions of this data sheet, refer to the left-hand navigation.
36
Submit Documentation Feedback
Copyright © 2019–2020, Texas Instruments Incorporated
Product Folder Links: TPS54A24
PACKAGE OPTION ADDENDUM
www.ti.com
10-Dec-2020
PACKAGING INFORMATION
Orderable Device
Status
(1)
Package Type Package Pins Package
Drawing
Qty
Eco Plan
(2)
Lead finish/
Ball material
MSL Peak Temp
Op Temp (°C)
Device Marking
(3)
(4/5)
(6)
TPS54A24RTWR
ACTIVE
WQFN
RTW
24
3000
RoHS & Green
NIPDAU
Level-2-260C-1 YEAR
-40 to 150
S54A24
(1)
The marketing status values are defined as follows:
ACTIVE: Product device recommended for new designs.
LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.
NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in a new design.
PREVIEW: Device has been announced but is not in production. Samples may or may not be available.
OBSOLETE: TI has discontinued the production of the device.
(2)
RoHS: TI defines "RoHS" to mean semiconductor products that are compliant with the current EU RoHS requirements for all 10 RoHS substances, including the requirement that RoHS substance
do not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered at high temperatures, "RoHS" products are suitable for use in specified lead-free processes. TI may
reference these types of products as "Pb-Free".
RoHS Exempt: TI defines "RoHS Exempt" to mean products that contain lead but are compliant with EU RoHS pursuant to a specific EU RoHS exemption.
Green: TI defines "Green" to mean the content of Chlorine (Cl) and Bromine (Br) based flame retardants meet JS709B low halogen requirements of
工商网监
湘ICP备2023018690号
