User's Guide
SLUUB53 – July 2014
Control Card in Digitally Controlled Off-Line Isolated
Power Converters
This user’s guide describes the characteristics, operation, and use of the UCD3138A64CEVM-660
evaluation module (EVM). The UCD3138A64CEVM-660 is a fully assembled and tested platform for
evaluating the performance of the UCD3138A64 digital controller device from Texas Instruments. This
document includes schematic diagrams, a printed circuit board (PCB) layout, bill of materials, and test
data. Throughout this document, the abbreviations EVM, UCD3138A64CEVM, and the term evaluation
module are synonymous with the UCD3138A64CEVM-660, unless otherwise noted.
Contents
Introduction ................................................................................................................... 2
Description .................................................................................................................... 3
2.1
Typical Applications ................................................................................................ 3
2.2
Features .............................................................................................................. 3
2.3
Configuring the EVM to Access EEPROM SPI or I2C Communication with UCD3138A64 ............... 3
3
Specifications ................................................................................................................. 4
4
Schematics ................................................................................................................... 5
5
Test Equipment .............................................................................................................. 7
5.1
PC Computer ........................................................................................................ 7
5.2
Oscilloscope ........................................................................................................ 7
6
Equipment Setup............................................................................................................. 8
6.1
Graphical User Interface (GUI).................................................................................... 8
6.2
Hardware Setup ..................................................................................................... 8
6.3
List of Test Points .................................................................................................. 9
7
Test Procedure ............................................................................................................. 10
7.1
Download Firmware Code to UCD3138A64EVM-660 ........................................................ 10
7.2
Erase Firmware Code from UCD3138A64EVM-660.......................................................... 11
7.3
Equipment Shutdown ............................................................................................. 11
8
EVM Assembly Drawing and PCB layout ............................................................................... 12
9
Bill of Materials ............................................................................................................. 15
Appendix A
Summary of Using Code Composer Studio v5.5 .............................................................. 17
1
2
List of Figures
1
UCD3138A64EVM-660 Schematics (1 of 2) ............................................................................. 5
2
UCD3138A64EVM-660 Schematics (2 of 2) ............................................................................. 6
3
USB-to-GPIO Interface Adapter (HPA172) ............................................................................... 7
4
UCD3138A64EVM-660 Test Connections................................................................................ 8
5
UCD3xxx/UCD9xxx Device GUI.......................................................................................... 10
6
Firmware Code Downloading ............................................................................................. 11
7
UCD3138A64EVM-660 Top Layer Assembly Drawing (Top View) .................................................. 12
8
UCD3138A64EVM-660 Bottom Assembly Drawing (No Components) ............................................. 12
9
UCD3138A64EVM-660 Top Copper (Top View) ....................................................................... 13
10
UCD3138A64EVM-660 Internal Layer 1 (Top View) .................................................................. 13
11
UCD3138A64EVM-660 Internal Layer 2 (Top View) .................................................................. 14
12
UCD313A64CEVM-660 Bottom Copper (Top View)................................................................... 14
SLUUB53 – July 2014
Submit Documentation Feedback
Control Card in Digitally Controlled Off-Line Isolated Power Converters
Copyright © 2014, Texas Instruments Incorporated
1
Introduction
www.ti.com
13
CCSv5.5 Workspace Launcher ........................................................................................... 17
14
Import Existing CCS Eclipse Project ..................................................................................... 18
15
Importing a CCSv5.5 Project
16
Project Explorer............................................................................................................. 19
17
Successful Build of UCD3138-Related Source Code
.............................................................................................
.................................................................
18
20
List of Tables
1
2
3
4
1
............................................................... 2
UCD3138A64EVM-660 Specifications .................................................................................... 4
Test Point Functions......................................................................................................... 9
Bill of Materials ............................................................................................................. 15
Key Differences Between UCD3138 and UCD3138A64
Introduction
This UCD3138A64CEVM-660 evaluation module helps evaluate the UCD3138A64 digital controller device
from Texas Instruments and aids in design of digitally controlled isolated power converters. The
UCD3138A64 device belongs to the UCD3138 family of highly-integrated digital controller devices
optimized for isolated power supply applications. Compared to the UCD3138 device, the UCD3138A64
device offers the following features:
Table 1. Key Differences Between UCD3138 and UCD3138A64
Product Features
UCD3138
UCD3138A64
Program Flash Memory
32 kB
64 kB
RAM
4 kB
8 kB
Number of Memory Banks
1 (32 kB)
2 (32 kB each)
Available (Pin Numbers 50, 51, 52, 53)
SPI Communication Hardware
Not Available
I2C Communication Hardware (in addition to PMBUS)
Not Available
Available (Pin Numbers 19, 20)
Peak Current Mode Control
EADC2 Only
Available on all EADC channels
EADC A0 Min Output Voltage (Max)
100 mV
21 mV
RTC Function - External Clock Input
Not Available
Available (Pin Numbers 45, 62)
4
External PWM Timers
2
Timer Capture Modules
1
2
Total GPIO
30
43
ADC12 Inputs
14
15
For additional device information, see http://www.ti.com/product/ucd3138a64.
The UCD3138A64CEVM-660 is similar to the UCD3138CC64EVM-030. The UCD3138A64CEVM-660 is
used either as a stand-alone control card to study the UCD3138A64 controller IC or as a DPWM controller
board working with a power stage board to implement a fully-regulated power converter. To help the
targeted off-line isolated power applications, this EVM has been designed to work seamlessly with two
power converter EVMs offered by TI: UCD3138PSFBEVM-027, and UCD3138LLCEVM-028. Contact
Texas Instruments for assistance obtaining the firmware source code used to interface the UCD3138A64
with these EVMs, which were originally developed to support the UCD3138 device. Alternately, the EVM
can also be loaded with custom-developed firmware. In order to communicate with the UCD3138A64
digital controller in this EVM, a separate USB interface adapter EVM from Texas Instruments known as
the USB-TO-GPIO Adapter is required. The USB-TO-GPIO Adapter is NOT supplied with
UCD3138A64CEVM-660 evaluation module and must be purchased separately. Texas Instruments also
offers a Graphical User Interface (GUI) in order to program the UCD3138A64 controller and configure
parameters when used with the two power converter EVMs.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
All other trademarks are the property of their respective owners.
2
Control Card in Digitally Controlled Off-Line Isolated Power Converters
Copyright © 2014, Texas Instruments Incorporated
SLUUB53 – July 2014
Submit Documentation Feedback
Description
www.ti.com
2
Description
UCD3138A64CEVM-660 is an EVM board, functioning as a control card for UCD3138A64PFC digital
power supply applications. This EVM is used to control a power converter topology such as LLC Resonant
Half-Bridge DC converter, and Phase-Shifted Full-Bridge DC converter, and so forth, by downloading the
associated firmware and interfacing with an appropriate power stage board. When coupled with the
appropriate corresponding firmware, the EVM works seamlessly with the following EVM boards:
• UCD3138PSFBEVM-027, A Digital Controlled Phase-Shifted Full-Bridge DC-to-DC Converter
Evaluation Board
• UCD3138LLCEVM-028, A Digital Controlled LLC Half-Bridge DC-to-DC Converter Evaluation board
Contact Texas Instruments for assistance with obtaining the firmware source code used to interface the
UCD3138A64 with these EVMs.
2.1
Typical Applications
•
•
•
2.2
Features
•
•
•
•
•
•
•
2.3
Off-line isolated power supply applications such as, LLC resonant half-bridge dc-dc power converter,
and phase-shifted full-bridge dc-dc power converter
Server systems
Telecommunication systems
40-pin digital signal connector to connect digital signals to power converters
40-pin analog signal connector to connect analog signals to power converters
2-Mbit SPI and I2C accessible EEPROMs for additional, onboard memory storage capacity
JTAG connector
LED indicator
PMBus connector to PC computer connection through USB-to-GPIO adapter
Rich test points to facilitate the IC evaluation, system design and circuit and firmware debugging
Configuring the EVM to Access EEPROM SPI or I2C Communication with
UCD3138A64
The UCD3138A64CEVM-660 contains all the features of the UCD3138CC64EVM-030. However, the
UCD3138A64CEVM-660 adds two programmable EEPROM devices for use with the UCD3138A64
device – one accessed via SPI communication port and the other via the 2nd I2C port in UCD3138A64.
Additionally, unlike the UCD3138064EVM-166, both EEPROMs can be accessed by the device
simultaneously, since both SPI and I2C hardware have been assigned dedicated pins. Appropriate
firmware is necessary to configure the UCD3138A64 device to choose the communication port desired.
No hardware changes are required to interface with either the SPI or I2C EEPROMs.
• To choose I2C EEPROM, connect jumpers J9 and J10, each in position 1 (Pins 1 and 2). Also, make
sure J7 and J8 are disconnected.
• To choose SPI EEPROM, connect jumpers J7 and J8 as well as jumpers J9 and J10, each in position
2 (Pins 2 and 3).
SLUUB53 – July 2014
Submit Documentation Feedback
Control Card in Digitally Controlled Off-Line Isolated Power Converters
Copyright © 2014, Texas Instruments Incorporated
3
Specifications
3
www.ti.com
Specifications
Table 2. UCD3138A64EVM-660 Specifications
Parameter
Notes and Conditions
Min
TYP
Max
Unit
Connector J1
Analog signal connection
Pin definition in compliance with UCD3138
40 pin
Digital signal connection
Pin definition in compliance with UCD3138
40 pin
Pin 39
External voltage source input
11.5
12.0
12.5
VDC
3.3-V connection to
PMBus
Port to use on-board 3.3 VDC to bias PMBus
3.25
3.30
3.35
VDC
3.27
3.30
3.32
VDC
3.25
3.30
3.32
VDC
Connector J2
Connector J3
3.3-V on board to external
Port to use 3.3 V on board to bias external circuit
use
Connector J4
3.3-V connection to
PMBus
Port to use on board 3.3 VDC to bias or receive bias from PMBus
Connector J5
PMBus connector
PMBus Connection to USB to GPIO pin definition refer to TI
standard USB-to-GPIO document SLLU093
Standard
JTAG
Standard JTAG communication connection
Standard
Standard JTAG communication connection
Standard
Connector J6
JTAG
Operation Environment
Operating Temperature
Range
Natural Convection
25
°C
Mechanical Characterstics
Dimensions
Width
1.965
Length
3.400
Component height
4
Control Card in Digitally Controlled Off-Line Isolated Power Converters
Copyright © 2014, Texas Instruments Incorporated
inches
0.5
SLUUB53 – July 2014
Submit Documentation Feedback
Schematics
www.ti.com
4
Schematics
Figure 1 and Figure 2 illustrate the schematic information for this EVM.
