OC-32A-3048T

OC-32 Series 3.2X2.5X1.2mm / SMD / HCMOS/TTL Oscillator Lead-Free RoHS Compliant CALIBER Electronics Inc. PART NUMBERING GUIDE Package OC-32 = 3.3Vdc OC-32A = 1.8Vdc OC-32B = 2.5Vdc Inclusive Stability 100= +/-100ppm, 50= +/-50ppm, 30= +/-30ppm, 25= +/-25ppm, 20= +/-20ppm Environmental/Mechanical Specifications on page F5 OC-32A- 100 48 A T - 30.000MHz Pin One Connection T = Tri State Enable High Output Symmetry Blank = 40/60%, A = 45/55% Operating Temperature Range Blank = -10°C to 70°C, 27 = -20°C to 70°C, 48 = -40°C to 85°C ELECTRICAL SPECIFICATIONS Frequency Range Operating Temperature Range Storage Temperature Range Supply Voltage Input Current 1.544MHz to 32.000MHz and 32.768kHz 36,001MHz to 70.000MHz 70.001MHz to 125.000MHz Inclusive of Operating Temperature Range, Supply Voltage and Load w/HCMOS or TTL Load wHCMOS or TTL Load Revision: 2006-C 1.544MHz to 80.000MHz / 32.768kHz (@ 3.3V) -10°C to 70°C / -20°C to 70°C / -40°C to 85°C -55°C to 125°C A=1.8Vdc / B=2.5Vdc / BLANK=3.3Vdc ±10% 2mA Maximum 3mA Maximum 4mA Maximum (3.3v, 2.5v, 1.8v) (3.3v, 2.5v, 1.8v) (3.3v, 2.5v, 1.8v) Frequency Tolerance / Stability Output Voltage Logic High (Voh) Output Voltage Logic Low (Vol) Rise / Fall Time Duty Cycle Load Drive Capability Pin 1 Tristate Function Aging (@ 25°C) Start Up Time Absolute Clock Jitter One Sigma Clock Jitter ±100ppm, ±50ppm, ±30ppm, ±25ppm, ±20ppm, (±50ppm for 32.768kHz only) 90% of Vdd Min. / Ioh=-8mA 10% of Vdd Max. / Iol=8mA 10% to 90% of Waveform w/HCMOS Load; 0.4Vdc to 2.4V w/TTL Load / 6nSec Max. @1.4Vdc w/TTL Load; @50% w/HCMOS Load @1.4Vdc w/TTL Load or w/HCMOS Load 50 ±10% (Standard) 50±5% (Optional) 15pF HCMOS Load Pin 1 = H or Open / Output Active at pin 3 Pin 1 = L / High Impedance at pin 3 ±5ppm / year Maximum 10mSeconds Maximum ±250pSeconds Maximum ±50pSeconds Maximum NOTE: A 0.01uF bypass capacitor should be placed between Vdd (Pin 4) and GND (Pin 2) to minimize power supply line noise. MECHANICAL DIMENSIONS Recommended Solder Pattern 0.95 X4 Marking Guide 2.5 ± 0.15 Metal 0.9 ±0.2 (X4 plcs.) All Dimensions in mm. 4 1 2.20 ±0.15 3 2 Line 1: A, B or Blank - Frequency Line 2: CEI YM A = Voltage designator CEI = Caliber Electronics Inc. YM = Date Code (Year / Month) 1.20 X4 3.2 ± 0.15 2.2 Ceramic 1.75 1.2 Max 1.00± 0.15 Pin 1: Tri-State Pin 2: Case Ground Pin 3: Output Pin 4: Supply Voltage (3.3v, 2.5v, 1.8v) TEL 949-366-8700 FAX 949-366-8707 WEB http://www.caliberelectronics.com
