160-1245

CAMBION Technical Data Sheet ® Wearnes Cambion LTD Castleton, Hope Valley, Derbyshire, S33 8WR, England Telephone: +44(0)1433 621555 Fax: +44(0)1433 621290 Web: www.cambion.com Email: enquiries@cambion.com 160-1245 Solder terminal, turreted Recommended mounting hole .116 (2,95), #32 drill How to order code 160-1245-XX-YY-00 Basic Part No XX = L dimension, YY = Plating Finish Basic Part No 160-1245 (XX) -01 -02 -03 -04 DIMENSIONS (XX) L Board Thickness .078 (1,98) .031 (0,79) .109 (2,77) .062 (1,58) .141 (3,58) .094 (2,38) .172 (4,37) .125 (3,18) D .068 (1,19) .098 (2,48) .098 (2,48) .098 (2,48) MATERIALS Component Terminal Material Brass -01 Silver Finish (YY) -03 Gold -05 Electro Solder SWAGE TOOLING Recommended Swaging Tools:Anvil 435-6401-01-00-00 Roll punch 435-6601-01-00-00 Flare punch 435-6663-01-00-00 Copyright© Cambion® Thursday, 29 May 2003 Page 1 of 1
