CR5-040

CR5-010 SERIES GLASS PASSIVATED JUNCTION GENERAL PURPOSE SILICON RECTIFIER 5.0 AMP, 100 THRU 1200 VOLTS Central TM Semiconductor Corp. DESCRIPTION: The CENTRAL SEMICONDUCTOR CR5-010 Series types are 5.0 Amp, Glass Passivated Junction, Silicon Rectifiers which are high quality, well constructed, highly reliable components designed for use in all types of military, commercial, industrial, entertainment, computer, and automotive applications. THIS DEVICE IS MANUFACTURED WITH A GLASS PASSIVATED CHIP FOR OPTIMUM RELIABILITY. DO-201AD CASE MARKING CODES: SEE MARKING CODES ON FOLLOWING PAGE MAXIMUM RATINGS: (TA=25°C unless otherwise noted) SYMBOL Peak Repetitive Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Average Forward Current (TA=75°C) Peak Forward Surge Current Operating and Storage Junction Temperature VRRM VR VR(RMS) IO IFSM TJ,Tstg CR5 -010 100 100 70 CR5 -020 200 200 140 CR5 -040 400 400 280 CR5 -060 600 600 420 5.0 200 -65 to +150 CR5 -080 800 800 560 CR5 -100 1000 1000 700 CR5 -120 UNITS 1200 1200 840 V V V A A °C ELECTRICAL CHARACTERISTICS: (TA=25°C unless otherwise noted) SYMBOL IR IR VF CJ CJ TEST CONDITIONS VR=Rated VRRM VR=Rated VRRM, TA=100°C IF=5.0A VR=4.0V, f=1.0MHz (CR5-010 THRU CR5-040) VR=4.0V, f=1.0MHz (CR5-060 THRU CR5-120) 50 25 MIN TYP MAX 5.0 100 1.2 UNITS µA µA V pF pF R2 (10-March 2006) Central TM CR5-010 SERIES GLASS PASSIVATED JUNCTION GENERAL PURPOSE SILICON RECTIFIER 5.0 AMP, 100 THRU 1200 VOLTS Semiconductor Corp. JEDEC DO-201AD - MECHANICAL OUTLINE Device CR5-010 CR5-020 CR5-040 CR5-060 CR5-080 CR5-100 CR5-120 Marking Code CENTRAL CR5-010 CENTRAL CR5-020 CENTRAL CR5-040 CENTRAL CR5-060 CENTRAL CR5-080 CENTRAL CR5-100 CENTRAL CR5-120 R2 (10-March 2006)
