CL-824-MU1L1

SPECIFICATIONS 1/11 1. Scope of Application These specifications are applied to the chip type LED lamp , model CL-824-MU1L1-T 2. Part code C L - 8 2 4 - M U1 L1 - T Series 824 : White LED for general lighting. Special specifications M : General Color Rendering Index Typ. 85 Type. Watt Class U1 : Under 1 watt package. Lighting color L1 : Energy Star Correlated Color Temperature 3000(K) Shipping mode Non-coded : Bulk T : Taping (standard) Approved Checked Drawn Symbol Name CITILED CL-824-MU1L1 2009/7/29 2009/6/5 Issue of second edition Issue of first edition Drawing No Mark Date Description Appro. CITIZEN ELECTRONICS CO.,LTD. Ref.CE-P488 08/09 SPECIFICATIONS 2/11 3. Outline drawing resin substrate polarity solder terminal 4. Performance ( 1 ) Absolute Maximum Rating Parameter Symbol Power Dissipation Pd Forward Current IF Forward Pulse Current Reverse Voltage Operating Temperature Storage Temperature IFP VR TOP TST Rating Value 108 30 100 5 -30 ~ +85 -40 ~ +100 Unit mW mA mA V C C *1 Junction Temperature Tj Max 120 C *2 *1Forward Current : Duty£1/10 , Pulse Width£0.1msec *2 D.C. Current : Tj = Tc + Rj-s x Pd Pulse Current : Tj = Tc + Rj-s x Pw(Power Dissipation / one-Pulse) x duty *Tc:Temperature of anode solder terminal Approved Checked Drawn Symbol Name CITILED CL-824-MU1L1 2009/7/29 2009/6/5 Issue of second edition Issue of first edition Drawing No Mark Date Description Appro. CITIZEN ELECTRONICS CO.,LTD. Ref.CE-P488 08/09 SPECIFICATIONS ( 2 ) Electro-optical Characteristics Symbol Condition Parameter Forward Voltage Reverse Current Thermal resistance Luminous Intensity Luminous Flux *1 3/11 MIN 2.8 1100 80 TYP 3.2 175 1670 ( 4.6 ) 85 MAX 3.5 100 - ( Tc=25C ) Unit V μA C/W mcd lm - VF IR Rj-s Iv φV Ra IF=20mA VR=5V Junction-solder IF=20mA IF=20mA IF=20mA General Color Rendering Index *1 In accordance with NIST standard Ranking (Condition : IF=20mA , Tc=25C) Parameter Symbol Rank MIN Q 2.8 VF R Forward Voltage 3.0 S 3.2 B 1100 Iv C Luminous Intensity 1251 D 1693 0 MAX 3.0 3.2 3.5 1251 1693 2291 Unit V mcd 0 Chromaticity coordinates ( Condition : IF=20mA ,Tc=25C ) Color Rank x y 0.4431 0.4213 0.4299 0.4165 L1a 0.4223 0.3990 0.4345 0.4033 0.4431 0.4213 Color Rank L1c x 0.4345 0.4223 0.4147 0.4260 0.4345 y 0.4033 0.3990 0.3814 0.3854 0.4033 Color Rank L1b x 0.4562 0.4431 0.4345 0.4468 0.4562 x 0.4468 0.4345 0.4260 0.4373 0.4468 y 0.4260 0.4213 0.4033 0.4077 0.4260 y 0.4077 0.4033 0.3854 0.3893 0.4077 Color Rank L1d Note 1) The tolerance of measurement at our tester is VF±3% , φv±10% , Chromaticity(x,y)±0.01. Note 2) For handling ,please apply CMOS LSI or equivalent any electrostatic effect. Approved Checked Issue of second edition Issue of first edition Drawn Symbol Name CITILED CL-824-MU1L1 2009/7/29 2009/6/5 Drawing No Mark Date Description Appro. CITIZEN ELECTRONICS CO.,LTD. Ref.CE-P488 08/09 SPECIFICATIONS 4/11 0.43 0.42 L1b 0.41 0.40 0.39 0.38 0.37 0.41 0.42 0.43 x 0.44 0.45 0.46 L1a y L1c L1d Rank information CUSTOMER: TYPE: CL-824-MU1L1 P.NO: Lot No: XXXXXX Q'ty: XXX PASS CITIZEN ELECTRONICS e.g. C C L1a Q L1a Q : Ranking by Luminous Intensity : Ranking by Chromaticity coordinates : Ranking by Forward Voltage Approved Checked Issue of second edition Issue of first edition Drawn Symbol Name CITILED CL-824-MU1L1 2009/7/29 2009/6/5 Drawing No Mark Date Description Appro. CITIZEN ELECTRONICS CO.,LTD. Ref.CE-P488 08/09 SPECIFICATIONS 5. Characteristics Forward Current vs. Relative Luminous Intensity Forward Current vs. Forward Voltage 5/11 160% 140% 120% 100% 80% 60% 40% 20% 0% IF - Iv Characteristics　　Tc=25C 120% 100% VF (a.u.) 80% 60% 40% 20% 0% IF - VF Characteristics　　Tc=25C I v ( a . u) 0 10 20 IF(mA） 30 40 0 10 20 IF(mA） 30 40 Forward Current vs. Chromaticity Coordinate IF - Chromaticity Characteristics Tc=25C 0.020 0.015 0.010 0.005 0.000 -0.005 -0.010 -0.015 -0.020 0 10 20 IF(mA） 30 Case Temperature vs. Chromaticity Coordinate Tc - Chromaticity Characteristics IF=20mA ⊿x ⊿y 0.020 0.015 0.010 0.005 0.000 -0.005 -0.010 -0.015 -0.020 0 ⊿x ⊿y ⊿ x, ⊿ y ⊿x,⊿y 40 20 40 Tc(C) 60 80 100 Case Temperature vs. Forward Voltage 120% 100% VF(a.u) Tc－Vf　Characteristics　　IF=20mA Case Temperature vs. Relative Luminous Intensity 120% 100% 80% Iv(a.u) 60% 40% 20% 0% 0 20 40 60 80 100 Tc－Iv　Characteristics　　IF=20mA 80% 60% 40% 20% 0% 0 20 40 Tc(C) 60 80 100 Tc(C) Approved Checked Drawn Symbol Name CITILED CL-824-MU1L1 2009/7/29 2009/6/5 Issue of second edition Issue of first edition Drawing No Mark Date Description Appro. CITIZEN ELECTRONICS CO.,LTD. Ref.CE-P488 08/09 SPECIFICATIONS Case Temperature vs. Allowable Forward Current Spectrum 120% Relative Emission Intensity (a.u.) 6/11 35 30 25 20 15 10 5 0 0 50 Tc (C) 100 150 Spectrum　　IF=20mA 100% 80% 60% 40% 20% 0% 350 450 550 650 Wavelength (nm) 750 850 IF (ｍA) Directive Characteristic -40° -50° -60° -70° -80° -30° -20° -10° 0° 10° 20° 30° 40° 50° 1.0 0.8 0.6 0.4 0.2 0.0 θ= 0 60° 70° 80° θ -40° -50° -60° -70° -80° -30° -20° -10° 0° 10° 20° 30° 40° 50° 60° 70° 80° 1.0 0.8 0.6 0.4 0.2 0.0 θ= 0 θ *Measurement condition (directive characteristic) LED chip is mounted on black color PCB. Approved Checked Drawn Symbol Name CITILED CL-824-MU1L1 2009/7/29 2009/6/5 Issue of second edition Issue of first edition Drawing No Mark Date Description Appro. CITIZEN ELECTRONICS CO.,LTD. Ref.CE-P488 08/09 SPECIFICATIONS 7/11 6. Reliability (1)Details of the tests Test Item Life Test in Continuous Operation Low Temperature Storage Test High Temperature Storage Test Moisture-proof Test Thermal Shock Test Solder Heat Resistance Test Test Condition 25±3C, IF=20 mA , 1000+24/-12hours -40+3/-5C , 1000+24/-12hours 100+5/-3C , 1000+24/-12hours 60 ±2C, 90 ±5%RH for 1000+24/-12hours -40C . 30 minutes and 100C , 30 minutes, 100cycle Recommended temperature profile (reflow soldering) × 2, (2nd test must be started after the samples are stabilized thermally.) (2)Judgment Criteria of Failure for Reliability Test Measuring Item Forward Voltage Reverse Current Luminous Intensity (Ta=25C) Symbol Measuring Condition Judgement Criteria for Failure IF=20mA VF >U×1.2 VR=5V IR >U×2 IF=20mA IV
