側面発光・単色タイプ
CL-Z482S シリーズ
Mono-Color Side-Lighting Type
NEW
(Ta 25℃)
Top (℃) Tst (℃)
CL-Z482S Series
●絶対最大定格/Absolute Maximum Rating※1
Product code
CL-Z482S-WS Pd (mW) 76 IF (mA) 20 IFP※2 (mA) 50 VR (V) 5
−25∼+80 −30∼+85
※1 1素子当たりの値です。 /The values are based on 1-die performance. ※2 IFPの条件はduty1/10、 パルス巾30msecです。 /Condition for IFP is pulse of 1/10 duty and 30msec width.
●電気的光学的特性/Electro-optical Characteristics
1.8 (L) ×1.1 (W) ×0.3 (H) mm
(Ta 25℃) MAX
3.15 2 ー
Parameter
順電圧/Forward Voltage※1 逆電流/Reverse Current※1 光度/Luminous Intensity※2
Symbol
VF IR IV
Conditions
IF=5mA VR=5V IF=5mA
MIN
ー ー ー a
TYP
2.9 ー 115
Unit
V μA mcd
● 小型 薄型の白色LEDです。 ・ ● ツェナーダイオードを搭載し、 静電耐圧に 優れています。
● Compact and thin white LED ● Zener diode LED, excellent in resistance to electrostatic potential.
x(±0.02) y(±0.02) 0.28 0.28 0.34 0.34 0.236 0.301 0.386 0.321 色度座標/Chromaticity coordinates※3 x, y IF=5mA b c d
※1 1素子当たりの値です。 /The values are based on 1-die performance. ※2 NIST規格に準拠、 各素子同時点灯の値です。 Compliant with NIST. The values are based on the condition that each die lights simultaneously. a、 c、 /Chromaticity coordinates is surrounded with a,b,c,d ※3 色度座標は、 b、 dに囲まれた範囲です。
●外形寸法図/Outline drawing
推奨はんだ付けパターン
素子センター /Die center 樹脂 /Resin 基板 /P.C.board
The following soldering patterns are recommended for reflow-soldering:
0.3
リフローはんだ用 For reflow soldering
ツェナー/Zener
(0.7)
1.8
1.4
1.2
0.3
極性/Polarity
(0.2)
(0.15)
(0.68)
カソードマーク /Cathode mark はんだ付け電極 /Soldering terminal
1.2
0.9
1.2
0.3
1.1
単位/Unit : mm
■ 諸特性/ Characteristics
IF-VF 特性 IF-VF Characteristics
100
VF-Ta 特性 VF-Ta Characteristics
1000
Iv-IF 特性 Iv-IF Characteristics
3.8
50
3.6
IF (mA)
20
100
3.4
V F( V )
10 5
3.2 3.0 2.8
Iv(mcd)
80 100
IF=5mA
10
1 2.6 3.0 3.4
-20
0
20
40
V F( V )
IV-Ta 特性 IV-Ta Characteristics
1000
T a (°C)
60
1 0.5
1
5
10
50
IF(mA)
IFmax-Ta 特性 IFmax-Ta Characteristics
30
指向特性 Directive Characteristics
40° 50° 30° 20° 10° 0° 120 100 80 10° 20° 30° 40° 50° 60° 70° 80° 0 90°
500
25
IV(in%)
IFmax(mA)
20 15 10 5
100 50
60° 70° 80° 90°
60 40 20
10 -20
0
20
40
T a (°C)
60
80
100
0 - 20
0
20
40
60
80
100
T a (°C)
63
