1000 Series Miniature Slide Switches Features/Benefits • Variety of actuators and terminations • Panel mount tabs available • Epoxy terminal seal—compatible with bottom-wash cleaning Typical Applications • Test & measurement equipment • Telecommunications • Computer & peripherals • RoHS compliant Models Available Specifications CONTACT RATING: B contact material: 0.4 VA max. @ 20 V AC or DC max. Q contact material: 6 AMPS @ 120 V AC or 28 V DC, 3 AMPS @ 250 V AC. See page J-15 for additional ratings. ELECTRICAL LIFE: 100,000 make-and-break cycles at full load on models with B, K or P contact material; 40,000 cycles on models with G, Q, L, M, S or R contact material. CONTACT RESISTANCE: Below 10 m Ω typ. initial @ 2-4 V DC, 100 mA, for both silver and gold plated contacts. INSULATION RESISTANCE: 109 Ω min. DIELECTRIC STRENGTH: 1,000 Vrms min. @ sea level. OPERATING TEMPERATURE: –30ºC to 65ºC SOLDERABILITY: Per MIL-STD-202F method 208D, or EIA RS-186E method 9 (1 hour steam aging). Materials CASE: diallyl phthalate (DAP), (UL 94V-0). ACTUATOR: Nylon, black, standard. HOUSING: Stainless steel. SWITCH SUPPORT: Brass or steel, matte-tin plated. END CONTACTS: B contact material: Copper alloy, with gold plate over nickel plate. Q contact material: Coin silver, silver plated. See page I-16 for additional contact materials. CENTER CONTACT & ALL TERMINALS: B contact material: Copper alloy, with gold plate over nickel plate. Q contact material: Copper alloy, silver plated. See page I-16 for additional contact materials. TERMINAL SEAL: Epoxy. Refer to Soldering and Cleaning in Technical Data chapter NOTE: Any models supplied with Q, B, G, P, S or R contact material are RoHS compliant. NOTE: Specifications and materials listed above are for switches with standard options. For information on specific and custom switches, consult Customer Service Center. I Slide Build-A-Switch To order, simply select desired option from each category and place in the appropriate box. Available options are shown and described on pages I–12 through I–16. For additional options not shown in catalog, consult Customer Service Center. All models have epoxy terminal seal and are compatible with all “bottom-wash” PCB cleaning methods. Switch Function 1101 SP On-None-On 1103 SP On-Off-On 1108 SP Mom-None-On 1201 DP On-None-On 1203 DP On-Off-On Mounting Style M2 PC mount without tabs M1 Panel mount with tabs Actuator S3 .200" high S1 .040" high S2 .140" high S4 .285" high S5 .370" high S6 .485" high T3 .200" high Terminations Right angle, PC thru-hole A C PC Thru-hole AV2 Vertical right angle, PC thru-hole Z Solder lug V3 V-bracket V4 V-bracket W .750" long, wire wrap Z3 Quick connect Contact Material B Gold Q Silver G Gold over silver P Gold, matte-tin S Silver, matte-tin R Gold over silver, matte-tin Seal E Epoxy D No epoxy seal I Epoxy potted base Actuator Color 2 Black 1 White 3 Red Dimensions are shown: Inches (mm) Specifications and dimensions subject to change I–11 www.ck-components.com 1000 Series Miniature Slide Switches SWITCH FUNCTION SWITCH FUNCTION POS. 1 POS. 2 POS. 3 NO. POLES MODEL NO. POS. 1 CONNECTED TERMINALS POS. 2 POS. 3 SCHEMATIC ON ON MOM. NONE OFF NONE ON ON ON 1-2 N/A OPEN N/A 2-3 SPDT 1101 SP 1103 1108 SPDT I Slide Actuator shown in position 1 Part number shown: 1101M2S3CQE2 Terminal Nos. For Reference Only NONE OFF ON 2-1,5-4 OPEN 2-3,5-6 DPDT ON 1201 DP ON ON 1203 DPDT Actuator shown in position 1 Part number shown: 1201M2S3CQE2 Terminal Nos. For Reference Only MOM. = Momentary All models with all options when ordered with G, Q, S or R contact material. MOUNTING STYLE M2 PC MOUNTING WITHOUT TABS M1 PANEL MOUNTING WITH TABS NOTE: Available with A, AV2, C, V3, V4, W terminations only. NOTE: Available with C, W, Z, Z3 terminations only. No mounting hardware supplied. PANEL MOUNTING All actuators except T3. Single pole For T3 actuator only. Double pole Dimensions are shown: Inch (mm) Specifications and dimensions subject to change I–12 www.ck-components.com 1000 Series Miniature Slide Switches ACTUATOR COLOR ACTUATOR ACTUATOR S3 .200" HIGH S2 .140" HIGH S1 .040" HIGH S4 .285" HIGH * * 110X models only. * * 120X models only. S5 .370" HIGH S6 .485" HIGH T3 I .200" HIGH Slide OPTION CODE ACTUATOR COLOR BLACK WHITE RED BLUE GRAY 2 * * * 1 3 7 9 120X models only. Other colors available, consult Customer Service Center. * Subtract .014 (0,36) from actuator height, all models with A, AV2, V3, V4 terminations. TERMINATIONS Z SOLDER LUG C PC THRU-HOLE PC MOUNTING SPDT & DPDT Not available with P, S or R contact materials. SPDT & DPDT Z3 QUICK CONNECT W WIRE WRAP .750 (19,05) SPDT & DPDT Not available with P, S or R contact materials. Mating quick connector available; order part number 530100000, page I-16. SPDT & DPDT Dimensions are shown: Inches (mm) Specifications and dimensions subject to change I–13 www.ck-components.com 1000 Series Miniature Slide Switches TERMINATIONS A RIGHT ANGLE, PC THRU-HOLE PC MOUNTING 1101M2S3ABE2 Horizontal Actuation SECTION A-A Actuator Shown In Pos. 1 SPDT I Slide A RIGHT ANGLE, PC THRU-HOLE Not available with M1 mounting style, I seal option. Terminal bend radii and lead-in manufacturing option. PC MOUNTING 1201M2S3ABE2 Horizontal Actuation DPDT Actuator Shown In Pos. 1 SECTION A-A Not available with M1 mounting style, I seal option. Terminal bend radii and lead-in manufacturing option. AV2 VERTICAL RIGHT ANGLE, PC THRU-HOLE, .150" PITCH PC MOUNTING 1101M2S3AV2BE2 Vertical Actuation Actuator Shown In Pos. 1 SECTION A-A SPDT Not available with M1 mounting style, I seal option. Terminal bend radii and lead-in manufacturing option. Dimensions are shown: Inch (mm) Specifications and dimensions subject to change I–14 www.ck-components.com 1000 Series Miniature Slide Switches TERMINATIONS AV2 VERTICAL RIGHT ANGLE, PC THRU-HOLE, .150" PITCH PC MOUNTING SECTION A-A Actuator Shown In Pos. 1 1201M2S3AV2BE2 Vertical Actuation DPDT I Slide Not available with M1 mounting style, I seal option. Terminal bend radii and lead-in manufacturing option. V3, V4 VERTICAL MOUNT, V-BRACKET PC MOUNTING OPTION CODE DIM ‘A’ .350 (8,89) .525 (13,34) V3 V4 1101M2S3__BE2 SPDT Not available with M1 mounting style and I seal. Actuator Shown In Pos. 1 V3, V4 VERTICAL MOUNT, V-BRACKET PC MOUNTING OPTION CODE DIM ‘A’ .400 (10,16) .575 (14,61) V3 V4 1201M2S3__BE2 DPDT Actuator Shown In Pos. 1 Not available with M1 mounting style and I seal. Dimensions are shown: Inches (mm) Specifications and dimensions subject to change I–15 www.ck-components.com 1000 Series Miniature Slide Switches CONTACT MATERIAL OPTION CODE CONTACT MATERIAL TERMINAL PLATING RATINGS B GOLD 1 GOLD 3 MATTE-TIN 6 LOW LEVEL/ DRY CIRCUIT 0.4 VA MAX. @ 20 V AC OR DC MAX. P Q SILVER 4,5 GOLD 3 MATTE-TIN 6 POWER 6 AMPS @ 120 V AC OR 28 V DC; 3 AMPS @ 250 V AC. S G GOLD OVER SILVER 2,3 GOLD 3 MATTE-TIN 6 LOW LEVEL/DRY CIRCUIT OR POWER I Slide 1 2 3 4 5 6 0 4 VA MAX @ 20 V AC OR DC MAX OR 6 AMPS @ 120 V AC OR 0.4 MAX. 28 V DC; 3 AMPS @ 250 V AC. R * Note: See Technical Data section of this catalog for RoHS compliant and compatible definitions and specifications. CONTACTS & TERMINALS: Copper alloy, with gold plate over nickel plate. END CONTACTS: Coin silver, with gold plate over nickel plate. CENTER CONTACTS & ALL TERMINALS: Copper alloy, with gold plate over nickel plate. END CONTACTS: Coin silver, silver plated. CENTER CONTACT & ALL TERMINALS: Copper alloy, silver plated. TERMINALS: Copper alloy, with matte-tin over nickel plate. All models with all options when ordered with G, Q, S or R contact material. B contact material standard with all terminations except C, Z, Z3.. Q contact material standard with C, Z, Z3 terminations. P, S or R contact materials not available with Z, Z3 terminations. NOTE: Any models supplied with Q, B, G, P, S or R contact material are RoHS compliant. SEAL E EPOXY SEAL D NO EPOXY SEAL I EPOXY POTTED BASE NOTE: Available with C, W, W3, Z, Z3 terminations only. AVAILABLE HARDWARE Fits Z3 Termination female connector PART NO. 530100000 Available in loose pieces. Dimensions are shown: Inch (mm) Specifications and dimensions subject to change I–16 www.ck-components.com
