TPA

TPA Series Multidirection SMT Navigation Switch Features/Benefits • One touch, 5 way switching • Distinctive tactile feel for scanning • • • • and select functions Normally open momentary contacts Push down to select possible in any position Optional pegs for improved mechanical strength and easier PCB positionning RoHS compliant and compatible Typical Applications • Electronic devices requiring • • • • • • direct control on LCD display MP3 player Bluetooth Headset Digital cameras GPS navigation systems Home entertainment systems Security Construction FUNCTION: Multi-directional momentary action CONTACT ARRANGEMENT: Make contact = SP, N.O. TERMINALS: Gullwing type for SMT IP50 Electrical MAXIMUM POWER: MAXIMUM VOLTAGE: MAXIMUM CURRENT DC: MINIMUM CURRENT DC: Silver 1 VA 24 V 50 mA 1 mA Gold 0.2 VA 24 V 10 mA 1 mA C Navigation Mechanical SHAFT DISPLACEMENT: Orthogonal 4 horizontal directions Vertical Push down TRAVEL TO MAKE: Orthogonal 0.35 mm±0.15 mm Push to select 0.25 mm±0.15 mm OPERATING FORCE: Scanning Orthogonal 1.8 N ± 0.5 N Push to select Vertical 4.0 N ± 0.8 N MAXIMUM APPLIED FORCE: Scanning 20N Select 40N Button design may prevent overload (see next page) LIFE EXPECTANCY: Scanning 200,000 operations in each direction 200,000 operations Push to select DIELECTRIC STRENGTH: 250 Vrms CONTACT RESISTANCE, INITIAL: 200 mΩ INSULATION RESISTANCE (100 VDC): 100 MΩ BOUNCE TIME: < 10 ms Environmental Silver OPERATING TEMPERATURE: –40˚C to +85˚C STORAGE TEMPERATURE: –40˚C to +85˚C Gold –40˚C to +85˚C –40˚C to +85˚C Packaging Tape and reels in reels of 1,000 pieces. External diameter 330mm ± 2mm. Process Infared reflow soldering in accordance with IEC 61760-1 Note: Specifications listed above are for switches with standard options. How To Order Our easy build-a-switch concept allows you to mix and match options to create the switch you need. To order, select desired option from each category and place it in the appropriate box. SWITCH T P A 1 G Navigation Select 3 Scanning 2 directions with selection 4 Scanning 4 directions without selection 5 Scanning 4 directions with selection P Pegs Termination G Gullwing Contact Material 1 Silver 3 Gold RoHS compliant and compatible LFS Lead free silver LFG Lead free gold Actuation Force 1 1.8 N scanning, 4 N selection Dimensions are shown: mm Specifications and dimensions subject to change C-8 www.ck-components.com TPA Series Multidirection SMT Navigation Switch TPA ø4,0 (.157) ø3,4 approx. (.134) Actuator rotation center SELECT 7 LEFT 1 4 DOWN 5 SELECT 6 RIGHT 3 UP 0,8 (.031) 0,8 (.031) R 0,2 (.008) D 90˚0'±2˚0' 4,3 (.169) 5,0 (.197) 0,55±0,05 (.022±.002) F/D measurement point ( scanning ) Button snap in sleeve lowest position 2 2,7 (.106) 2,2 (.087) 0,15 (.006) 0,4 mini (.016) 1,1 (.043) 3,1 (.122) SCHEMATIC 0,05+0,05/-0,10 (.002+.002/-.004) 0,1 0,65±0,1 (x7) (.026.004) 0,1 A 1,0 (x7) (.039) 9,3 (.366) 8,05 5,325 (.317) 2,725 (.2096) (.1073) UP 70˚0'±5˚0' LEFT - 7 R 0,17±0,05 (.007±.002) 1 (.393) 2,7 (.106) 1,7 (.067) 0,5 (.020) LEFT 3,5 (.138) 2,6 (.102) 5,3 (.209) RIGHT 8 (.315) 4,3 (.169) 0,52±0,02 (.020±.001) 4,3 (.170) 2.6 (.102) RIGHT - 6 COMMON - 2 ø2,0 (.079) UP - 3 RIGHT 1.4 (.055) SELECT - 5 1,14±0,02 (.045±.001) ø1,95±0,03 (.077±.001) 1,7 (.067) ø6,0 (.024) 5,25 (.207) 2,7 (.106) 2,65 1 (.104) (.393) ø0,9 (.035) 2,7 (.106) C Navigation COMMON - 1 ø 3,2 pick & place area 0,2 (.126) DOWN 3,5 (.138) DOWN - 4 0,3 (.017) 1.5 (.059) PCB LAYOUT TPA with Pegs ø4 ø3,4 approx R0 ,2 SELECT Actuator rotation center 0,55±0,05 7000’±500’ ,05 ±0 ,17 R0 0,8 0,8 D 9000’±200’ F/D measurement point (scanning) D Button snap in sleeve lowest position 2,7 2,2 0,15 0,4 mini 0,5 1,1 (3,1) 4,3 5 ø1,95±0,03 +0,05 -0,10 0,05 0,1 2,7 9,3 8,05 5,325 UP 1,5 0,65±0.1(x7) 0,1 A ø0,6 ø0,9 1,5 2,7 ø 0,8±0,05 1,5±0,05 1,14±0,02 0,52±0,02 1,025(x7) (2,725) A 1 5,25 2,7±0,05 2,65 1 ø1,1±0,05 7 LEFT 4 DOWN 5 SELECT 2 6 RIGHT 3 UP 1,4 (2,7) LEFT-7 4,3 1,7 2,6 1,7 SELECT-5 RIGHT 3,5 2,6 RIGHT-6 COMMON-2 Ø2 4,3 5,3 8 PCB LAYOUT DOWN-4 COMMON-1 ø 3,2 pick & place area 0,2 DOWN 3,5 0,2 UP-3 0,3 1,5±0,05 2,7±0,05 1 Dimensions are shown: mm Specifications and dimensions subject to change C-9 www.ck-components.com 0.2 (.008) 5 8±0,0 R 0,1 .002) ± (.007 R0,1 8±0 ,05 TPA Series Multidirection SMT Navigation Switch TAPE & REEL 2±0,05 (.079±.002) 4,0 (.157) 2±0,05 (.079±.002) 12,0 (.472) ø1,5+0,1/-0,0 (.059+.004/-.000) 2 faces 8˚ max. 1,55+0,10/-0,05 (.061+.004/-.002) 0,343±0,05 (.014±.002) 2,5+0,15/-0,10 (.098+.006/-.004) 2,25 (.089) ø1,5+0,25/-0,0 (.059+.010/-.000) 0,1 B B 4˚0' max. 10,0 (.394) 7,5 (.295) 5,3 (.209) 6 faces at 15˚ max 1,2 (.047) 0,1 A 8,4 (.331) A 1,75 (.069) C Navigation STANDARD BUTTON This drawings shows our standard available product but also provides the dimensional guidelines for a specific button integration, the main points being: - shaft clip - 4 travel stop to avoid overload To be ordered separately - TPA Button - Y43109100OP - Color: Black only - Bags of 1,000 pieces SECTION B-B 0,4mini S1 ø 10 ± 0,2 2x 4.34 2x 4,08 ø 0,05 A 1,4 1,1 0 1,07 -0,03 S1 4x ,6 R0 16±0,3 (.63±0.012) 2X R 0,0 8,2 (.323) 2,05 1,8 2,25 8 A 3,5 R 24,35 1,75 1 SEE DETAIL 8 50 0' SEE DETAIL A AB ø1,97± 0,02 B 2x2,36 0,5 ± 0,02 DETAIL A SCALE 20 B ø 8,85 ø3 0,6 2x 1,4 B 0,5 0,265 0,72 ± 0,05 0,82± 0,02 0,25 3X R0 ,2 4x R 0,1 Dimensions are shown: mm Specifications and dimensions subject to change C-10 www.ck-components.com 0,25 0,35 0,02 1 1,75 ,3 R0 R0 ,8
