5100-823

147 Central Avenue Hackensack, New Jersey 07601 Tel: 201-489-8989 • Fax: 201-489-6911 CHICAGO MINIATURE LAMP, INC. WHERE INNOVATION COMES TO LIGHT Miniature Relampable Indicator Light DESCRIPTION AND FEATURES 5100 Series 1.660 .080 1.660 5200 Series .130 Ø.813 Ø.813 11/16-27 T HD. All dimensions in inches. 11/16-27 T HD. Dome .438 Ø.625 Fluted Dome .438 Ø.625 Cylindrical .375 Ø.625 Fluted Cylindrical .375 Ø.625 9/16-27 T HD. 9/16-27 T HD. 9/16-27 T HD. 9/16-27 T HD. The Chicago Miniature Lamp Miniature Indicator Lights are versatile, industry standard, front panel indicators capable of accepting a variety of T-2 and T-3 1/4 miniature bayonet based incandescent and neon lamps. Available in the deluxe 5200 Series and the very cost efficient 5100 Series. These indicator lights accept a variety of different lens styles and colors, and are excellent for providing a large, bright, easily noticed status indicator. The lamp is not included with this indicator light; please order the required lamp separately. SPECIFICATIONS Part Number: 5100-822 5100-823 5100-824 5200-222 5200-232 5200-242 Description solder lug terminals, no resistor screw type terminals, no resistor .250 Q.C. terminals, no resistor solder lug terminals, no resistor solder lug terminals, built-in 22K ohm resistor solder lug terminals, built-in 100K ohm resistor Lens Part No: 25P-306* 25P-307** 25P-326* 25P-606* 25P-607** 25P-626* Description Transparent dome Translucent dome Transparent fluted dome Transparent cylindrical Translucent cylindrical Transparent fluted cylindrical Mounting Hole: Mounting Centers: Maximum Panel Thickness: Housing/Lens Material: Bezel: Mounting Bushing/Bezel: Hex Nut: Lockwasher: Lenses: Approvals: Electrical Rating: .688 .969 .406 5100 Series-Glass filled polyester, 5200 Series-Phenolic (5100 Series only): stainless steel (5200 Series only): chrome plated brass Zinc plated steel Chromate treated steel High temperature lexan UL listed, CSA certified (except Q.C. terminal versions) up to 250 Volts, up to 3 Watts (contact factory for specific product rating) Chicago Miniature Lamp reserves the right to make specification revisions that enhance the design and/or performance of the product 4-63
