15-000200

F E D C B A 0,31 67 + 0,45 - 61,11 + 0,13 - 0,12 D 52,5 + 0,05 - 0,2 (5:1) D 15,38 + 0,,37 - 0 39 n4 C NOTE 2 JACKSCREW LANYARD ROTATES FREELY 10,81 + 0,05 - 0,2 6,1 + 0,,25 -0 0 0, 8 C 16,4 + 0,1 -0 M3 4-40 UNC NOTE 11 NOTES: 1. METALSHELLS: COPPER ALLOY; min. 315µin TIN over 40-80µin NICKEL 2. TPE ETHYLENE PROPYLENE THERMOPLASTIC RUBBER SEAL 3. IP RATING: THE WATER RESISTANT CAP MUST BE MOUNTED PROPERLY TO THE MATING CONNECTOR FOR IP 67 B 4. THREADED INSERT: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL 5. COLLAR: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL 6. JACKSCREW: STAINLESS STEEL 1.4305 7. WIRE ROPE: STAINLESS STEEL 1.4401 8. RETAINING WASHER: STAINLESS STEEL 1.4122 9. TERMINAL RING: UNINSULATED, COPPER ALLOY; min. 200µinTIN over 80µin NICKEL 10. MAXIMUM TORQUE VALUE FOR THREAD: 6in.LB 11. CONNECTOR IS PART MARKED: PART NO. CONEC ABC THIS DRAWING MAY NOT BE COPIED OR REPRODUCED IN ANY WAY, AND MAY NOT BE PASSED ON TO A THIRD PARTY WITHOUT WRITTEN PERMISSION. OWNERSHIP AND COPYRIGHT OF CONEC GmbH B DO NOT ALTER CAD DRAWING BY HAND tolerance Part. No. for plug connector A WIRE ROPE n1,0 2x TERMINAL RING n 3 ,2 D IS O 2 7 6 8 -m date drawn 26.05.08 appd. 26.05.08 norm d-old dim . in m m name scale: material: title: 10 8 ` 2:1 (5:1) SEE NOTES 35 6, Petker Fischer WATER RESISTANT SCREEN CAP 50pos. FOR PLUG CONNECTOR A with threaded insert, jackscrew and wire rope dwg no: Inventor 10 DINR UNC 4-40 15-000150 M3 15-000200 n5 a Origin 15K1A225 part no: sh: 1 A A3 F E C r e v . d e s c r ip t io n d a te na m e B see table
