6
5
27.50 `0.60
n31.50
4
3
2
1
D
Shielded or Unshielded Cat. 5e Inline Coupler
D
Key Protrusion x 3 Cover Gasket
21.00
Cover Coupling Ring (Platic or Metallized)
Panel Flange Receptacle Housing (Plastic or Metallized)
93.00 `3.00
Panel Gasket Tether Panel Nut
Bayonet Channel x 3
C
3.50 2.00
n34.00
32.71 REF
C
n30.00
26.60 `0.05
Notes:
0.50
n28.10 `0.05
19.40 29.70
32.00
36.18
B
1. Electrical Specifications: - Meets EIA/TIA-568-B.2 Cat.5e Specification - Contact Resistance: 20mOhm max. - Insulation Resistance: 500MOhm min. @ 100 VDC - Current Rating: 1.2A max. at 25~C - Working Voltage: 100 VDC - DWV: 1000 VDC/60s Contact to Contact, 1500 VDC/60s Contact to Metal Shell - Operating Temperature: -40~C to +85~C 2. Material and Finish: - Receptacle Housing: Polyester (Black) or Metallized ABS (Nickel Plated); UL94 V-0 - Cover Coupling Ring: Polyester (Black) or Meatllized ABS (Nickel Plated); UL94 V-0 - Panel Nut: Brass, Finish: Nickel Plated - Panel Gasket: Silicone, Color: White - Cover Gasket: Silicone, Color: Red - Tether: Polycarbonate, Color: Black - RJ45 Jack Metal Shell: Copper Alloy, Nickel Plated - RJ45 Jack Plastic Housing: Glass filled PBT UL94 V-0, Color: Black - RJ45 Jack Contacts: Phosphor Bronze, Finish: 50u" Gold min. over Nickel 3. Connector can be front or rear mounted to a maximum panel thickness of 3.2mm. 4. RoHS compliant
Recommended Panel Cutout
B
Description Plastic Version with Shielded RJ45 Inline Coupler with Cover Plastic Version with Unshielded RJ45 Inline Coupler with Cover Metallized Plastic Version with Shielded RJ45 Inline Coupler with Cover
THIS DRAWING MAY NOT BE COPIED OR REPRODUCED IN ANY WAY, AND MAY NOT BE PASSED ON TO A THIRD PARTY WITHOUT WRITTEN PERMISSION. OWNERSHIP AND COPYRIGHT OF CONEC CORPORATION
Part Number 17-10000 17-10020 17-10011
DOT NOT ALTER CAD DRAWING BY HAND
Customer: Name Title Approval Date
Unless otherwise specified
0 PLC 1 PLC 2 PLC 3 PLC ANGLES
`0.50 `0.38 `0.25 `0.10 `3~
Tolerance
Scale: 1.2:1
Autodesk Inventor Name Vincent Ke J. Chaudry
Dim. in mm
Material: See Notes
A
Directive 2002/95/EC "RoHS" Compliant
2006 Draw.
Date Oct. 24 Oct. 24
Receptacle & Cover Assembly Kit
Industrial Ethernet Connector (IP67)
with Cat. 5e RJ45 Inline Coupler
Title:
e d c b a
Rev.
Jan/28/08 Vincent Ke Appd. Sept/18/07 Vincent Ke Norm May/15/07 Vincent Ke D-old Mar/08/07 Vincent Ke origin
Changes Date Name
A
R
Drawing No.: 39K1A203 Part No.: SEE P/N ABOVE
DIN
A3
Sheet
1/1
6
5
4
3
2
1
