17-10035

6 5 4 3 2 1 c D Shielded Cat. 5e RJ45 PCB Jack accepts both Solid and Stranded AWG 24 to 26 Wires D 26.60 `0.05 Panel Flange Receptacle Housing (Plastic or Metallized Plastic with Bayonet Locking Style) Panel Gasket n28.10 `0.05 Recommended Panel Cutout Sealed with epoxy, provides IP67 even when uncovered (For potted version only) Bayonet Channel x 3 C Panel Nut 37.75 REF. C 3.5 n34 d Notes: B 1. Electrical Specifications: - Meets EIA/TIA-568-B.2 Cat.5e Specification - Contact Resistance: 20mOhm max. - Insulation Resistance: 500MOhm min. @ 100 VDC - Current Rating: 1.2A max. at 25~C - Working Voltage: 100 VDC - DWV: 1000 VDC/60s Contact to Contact, 1500 VDC/60s Contact to Metal Shell - Operating Temperature: -40~C to +85~C 2. Material and Finish: - Receptacle Housing: Polyester (Black) or Metallized ABS (Nickel Plated); UL94 V-0 - Panel Nut: Brass, Finish: Nickel Plated - Panel Gasket: Silicone, Color: White - RJ45 PCB Jack Metal Shell: Copper Alloy, Nickel Plated - RJ45 PCB Jack Plastic Housing: Glass filled PBT UL94 V-0, Color: Black - RJ45 PCB Jack Contacts: Phosphor Bronze, Finish: 50u" Gold min. over Nickel 3. Connector can be front or rear mounted to a maximum panel thickness of 3.2mm. 4. RoHS compliant 32.0 19.4 2.0 36.18 max. d B Part Number 17-10017 17-10018 17-10035 17-10036 Description Directive 2002/95/EC "RoHS" Compliant THIS DRAWING MAY NOT BE COPIED OR REPRODUCED IN ANY WAY, AND MAY NOT BE PASSED ON TO A THIRD PARTY WITHOUT WRITTEN PERMISSION. OWNERSHIP AND COPYRIGHT OF CONEC CORPORATION Plastic Version Metallized Plastic Version Potted Plastic Version Potted Metallized Plastic Version Unless otherwise specified DOT NOT ALTER CAD DRAWING BY HAND Customer: Name Title Approval Date Tolerance 0 PLC 1 PLC 2 PLC 3 PLC ANGLES `0.50 `0.38 `0.25 `0.10 `3~ Scale: 1.5:1 Autodesk Inventor Name Vincent Ke J. Chaudry Dim. in mm Material: See Notes Title: 2007 Draw. Appd. Date Oct. 25 Oct. 25 Receptacle Assembly Kit A with Cat. 5e RJ45 PCB Jack DIN A Industrial Ethernet Connector (IP67) Drawing No.: 39K1A333 Part No.: SEE P/N ABOVE A3 Sheet d c b a Rev. Apr/29/09 Vincent Ke Norm Apr/17/09 Vincent Ke D-old Jan/28/08 Vincent Ke origin Changes Date Name R 1/1 6 5 4 3 2 1
