43-02641

n14 4 n0,8 9 29 Sealing Rated voltage: IEC 61076-2-101 30 V Current rating: IEC 61076-2-101 1,5 A at 40°C Insulation resistance: IEC 60512 >=100 M Pollution degree: IEC 60664-1 3/2 Degree of protection: IEC 60529 IP 67, in mated condition Temperature range: EN 60512-11-10 EN 60512-11-4 -30°C ... +85°C -40°C -40°C ... +85°C Mating cycles: IEC 60512-9a >=100 Ω M12x1 Panel thikness min. 1mm - max. 2mm Technical specification: Materials: M12x1 PCB 19,7 Contact: CuZn, Ni b / Au 0,2 gal. Contact carrier: PA, UL 94 V-0 Sealing: FPM Socket housing: CuZn, nickel plated Shroud: CuSn6 / Sn Installation specification: 16 8,5 Recommended torque: Conec installation tool: Shroud 0,8-1 Nm Torque wrench: 36-000200 Insert across flats 15: 36-000320 see fig.1 43K1A1791 Pin Layout PCB 1,6mm 19 15 s ros ac dth 15 Wi flats 5,61 3,54 Panel n1 2,9 0,2 6 7 5 4,3 8 12 9 4 11 9 1 n 3 10 2 ,05 12 1( x) 2,86 n2 n 1,91 2, 8 5,34 Part no: Description: Pos 43-02640 SAL - 12 - FKW12 12 43-02641 SAL - 12S - FKW12 12 date drawn 07.08.15 appd. general tolerance: 0 0,0 0,00 ∢ ± ± ± ± 0,50mm 0,25mm 0,10mm 5° THIS DRAWING MAY NOT BE COPIED OR REPRODUCED IN ANY WAY, AND MAY NOT BE PASSED ON TO A THIRD PARTY WITHOUT WRITTEN PERMISSION. OWNERSHIP AND COPYRIGHT OF CONEC GmbH 07.08.15 Note: with shroud title: dim. in mm RoHS & REACH compliant DO NOT ALTER CAD DRAWING BY HAND 15 `0,1 Female socket M12x1 ngled, frontmounting, dip solder name Böckeler dwg no: Franz 43K1A3062 R part no: see table 4 Hole for optional shroud ,3 20,3 12,2 1,27 n17 Installation hole:
